Chapter 3
Uninterruptible
Power
Supply
Captive
Unterminated
Cord to be
Terminated Locally
Cable Orderable for 16-Amp
PDU, E7798A, IEC 320 C19
to C20, 2.5 m
(Other Configurations
Possible)
Figure 3-6. 230/240 VAC PDU Configuration

Redundant Power Configuration

Dual Power Supply Example
A dual power supply configuration can be created by ensuring that two different
branch circuits feed two different Uninterruptible Power Supplies, which in turn
power two PDUs. Figure 3-7 shows a dual power cabling example. This example
Procedure for Connecting and Routing Cables to the LXr 8500
Recommended 230/240 VAC
LXr 8500 Configuration
HP NetServer
LXr 8500
Mass Storage Unit
Jumper Cable
Supplied with
NetServer
Jumper Cables
Supplied with
Mass
Storage
Units
16-Amp Power
Distribution Unit
E7671A
39
