CHAPTER 5: SETPOINTS
5.2.6

Message Scratchpad

MESSAGE
489 GENERATOR MANAGEMENT RELAY – INSTRUCTION MANUAL
Courtesy of NationalSwitchgear.com
scratchpad. For example, the relay could be set to alternately scan a generator
identification message, the current in each phase, and the hottest stator RTD. Currently
selected default messages can be viewed in
Default messages can be added to the end of the default message list, as follows:
Enter the correct passcode at
PASSCODE FOR ACCESS
been entered or is "0", defeating the passcode security feature).
Select the message to be add to the default message list using the
MESSAGE
The selected message can be any actual value or message scratchpad
message.
Press
ENTER
The
PRESS [ENTER] TO ADD DEFAULT MESSAGES
be displayed for 5 seconds:
Press
ENTER
message to the end of the default message list.
If the procedure was followed correctly, the
flash message is displayed:
ADDED
To verify that the message was added, view the last message under the
S1 489 SETUP
Default messages can be removed from the default message list, as follows:
Enter the correct passcode at
PASSCODE FOR ACCESS
already been entered or unless the passcode is "0" defeating the
passcode security feature).
Select the message to remove from the default message list under the
489 SETUP
Select the default message to remove and press
The relay will display
Press
ENTER
message out of the default message list.
If the procedure was followed correctly, the
flash message is displayed.
REVOVED
PATH: SETPOINTS S1 489 SETUP
TEXT 1
[ ]
TEXT 2
MESSAGE
TEXT 3
MESSAGE
DEFAULT MESSAGES
S1 489 SETUP
to allow setpoint entry (unless it has already
keys.
.
again while this message is displayed to add the current
DEFAULT MESSAGE HAS BEEN
menu.
DEFAULT MESSAGES
S1 489 SETUP
to allow setpoint entry (unless the passcode has
menu.
DEFAULT MESSAGES
PRESS [ENTER] TO REMOVE MESSAGE
while this message is displayed to remove the current
DEFAULT MESSAGE HAS BEEN
MESSAGE SCRATCHPAD
Range: 40 alphanumeric characters
Range: 40 alphanumeric characters
Range: 40 alphanumeric characters
subgroup.
PASSCODE ENTER
message will
PASSCODE ENTER
S1
.
ENTER
.
5–15
