  • Page 1 ® ABB i-bus SA/S Switch Actuators Product Manual...

  • Page 2: Using The Product Manual

    High living standards, comfort and safety can be easily combined with cost- effectiveness and environmental awareness using KNX bus systems from ABB. KNX products cover the entire range of buildings applications, from illumination and blind control to heating, ventilation, energy management, security and surveillance.
  • Page 3 ® ABB i-bus General 1.1.1 Structure of the product manual All parameters are described in section 3. Please note This product manual describes all the current 2/4/8 and 12-fold Switch Actuators. However, as the functions for all outputs are identical, only the functions of output A will be described.

  • Page 4: Product And Functional Overview

    KNX SA/S Switch Actuators are modular installation devices with module widths of 2/4/8/12 units in ProM design for installation in a distribution board. ® Connection to the ABB i-bus is established via a bus connection terminal on the front. The Switch Actuators require no auxiliary voltage.
  • Page 5 The SA/S x.16.6.1 and SA/S x.16.5.1 are suitable for rated currents up to 20 A and have C-load switching capacity. ® In the following table you will find an overview of the ABB i-bus Switch Actuators and their type designations: –...

  • Page 6: Device Technology

    ® ABB i-bus Device technology Device technology Switch Actuators SA/S x.6.1.1, 6 A, MDRC Switch Actuators SA/S x.6.1.1 6 A are The device does not require an modular installation devices in ProM additional power supply and is ready for design for installation in the distribution immediate use after the bus voltage board.
  • Page 7 ® ABB i-bus Device technology Output switching times Maximum output relay position change per 4.6.1.1 8.6.1.1 12.6.1.1 minute if all relays are switched simultaneously. The position changes should be distributed equally within the minute. Maximum output relay position change per minute if only one relay is switched.
  • Page 8 The current application program is available for download at www.abb.com/knx. After import into ETS it can be found under ABB/Output/Binary output xf 6A/…* (x = 4, 8 or 12). The device does not support the locking function of a KNX device in ETS. If you inhibit access to all of the project devices by using a BCU code, it has no effect on this device.
  • Page 9 ® ABB i-bus Device technology 2.1.3 Connection schematic SA/S x.6.1.1 Label carrier Programming button Programming LED Bus connection terminal Load current circuits, one screw terminal for phase connection per contact Danger Touch voltages. Danger of injury. Observe all-pole disconnection. 12 2CDC 505 056 D0208 | SA/S...
  • Page 10 ® ABB i-bus Device technology 2.1.4 Dimension drawing
 SA/S x.6.1.1 SA/S 4.6.1.1 SA/S 8.6.1.1 SA/S 12.6.1.1 72 mm 108 mm 144 mm Width W Mounting width 4 units 6 units 8 units (18 mm modules) SA/S | 2CDC 505 056 D0208 13...
  • Page 11 ® ABB i-bus Device technology Switch Actuators SA/S x.6.2.1, 6 A, manual, MDRC Switch Actuators SA/S x.6.2.1, 6 A are The actuators can switch up to modular installation devices in ProM 12 independent electrical loads via design for installation in the distribution floating contacts.
  • Page 12 ® ABB i-bus Device technology Output switching times SA/S type 2.6.2.1 4.6.2.1 8.6.2.1 12.6.2.1 Maximum output relay position change per minute if all relays are switched simultaneously. The position changes should be distributed equally within the minute. Maximum output relay position change per minute if only one relay is switched.
  • Page 13 ETS and the current version of the device application program are required for programming. The current application program is available for download at www.abb.com/knx. After import into ETS it can be found under ABB/Output/Binary output xf 6AM/…* (x = 2, 4, 8 or 12).
  • Page 14 ® ABB i-bus Device technology 2.2.3 Connection schematic SA/S x.6.2.1 Label carrier Programming button Programming LED Bus connection terminal Contact position display and manual operation Load current circuits, for every 2 connection terminals Danger Touch voltages. Danger of injury. Observe all-pole disconnection.
  • Page 15 ® ABB i-bus Device technology 2.2.4 Dimension drawing
 SA/S x.6.2.1 SA/S 2.6.2.1 SA/S 4.6.2.1 SA/S 8.6.2.1 SA/S 12.6.2.1 36 mm 72 mm 144 mm 216 mm Width W Mounting width 2 units 4 units 8 units 12 units (18 mm modules) 18 2CDC 505 056 D0208 | SA/S...
  • Page 16 ® ABB i-bus Device technology Switch Actuators SA/S x.10.2.1, 10 A, MDRC Switch Actuators SA/S x.6.2.1, 10 A are The Switch Actuators can switch up to modular installation devices in ProM 12 independent electrical loads via design for installation in the distribution floating contacts.
  • Page 17 ® ABB i-bus Device technology Output switching times Maximum relay position change of output and 2.10.2.1 4.10.2.1 8.10.2.1 12.10.2.1 minute if all relays are switched simultaneously. The position changes should be distributed equally within the minute. Maximum output relay position change per minute if only one relay is switched.
  • Page 18 The current application program is available for download at www.abb.com/knx. After import into ETS, it is available in ETS under ABB/Output/Binary output xf 10A/…* (x = 2, 4, 8 or 12). The device does not support the locking function of a KNX device in ETS. If you inhibit access to all of the project devices by using a BCU code, it has no effect on this device.
  • Page 19 ® ABB i-bus Device technology 2.3.3 Connection schematic SA/S x.10.2.1 Label carrier Programming button Programming LED Bus connection terminal Contact position display and manual operation Load current circuits, for every 2 connection terminals Danger Touch voltages. Danger of injury. Observe all-pole disconnection.
  • Page 20 ® ABB i-bus Device technology Dimension drawing
SA/S x.10.2.1 2.3.4 SA/S 2.10.2.1 SA/S 4.10.2.1 SA/S 8.10.2.1 SA/S 12.10.2.1 36 mm 72 mm 144 mm 216 mm Width W Mounting width 2 units 4 units 8 units 12 units (18 mm modules) SA/S | 2CDC 505 056 D0208 23...
  • Page 21 ® ABB i-bus Device technology Switch Actuators SA/S x.16.2.1, 16 A MDRC Switch Actuators SA/S x.16.2.1, 16 A are The Switch Actuators can switch up to modular installation devices in ProM 12 independent electrical loads via design for installation in the distribution floating contacts.
  • Page 22 ® ABB i-bus Device technology Output switching times Maximum relay position change of output and 2.10.2.1 4.10.2.1 8.10.2.1 12.10.2.1 minute if all relays are switched simultaneously. The position changes should be distributed equally within the minute. Maximum output relay position change per minute if only one relay is switched.
  • Page 23 The current application program is available for download at www.abb.com/knx. After import into ETS, it is available in ETS under ABB/Output/Binary output xf 10A/…* (x = 2, 4, 8 or 12). The device does not support the locking function of a KNX device in ETS. If you inhibit access to all devices of the project with a BCU code, it has no effect on this device.

  • Page 24: Abb I-Bus ® Knx

    ® ABB i-bus Device technology 2.4.3 Connection schematic SA/S x.16.2.1 Label carrier Programming button Programming LED Bus connection terminal Contact position display and manual operation Load current circuits, for every 2 connection terminals Danger Touch voltages. Danger of injury. Observe all-pole disconnection.
  • Page 25 ® ABB i-bus Device technology 2.4.4 Dimension drawing
 SA/S x.16.2.1 SA/S 2.16.2.1 SA/S 4.16.2.1 SA/S 8.16.2.1 SA/S 12.16.2.1 36 mm 72 mm 144 mm 216 mm Width W Mounting width 2 units 4 units 8 units 12 units (18 mm modules) 28 2CDC 505 056 D0208 | SA/S...
  • Page 26 ® ABB i-bus Device technology Switch Actuator SA/S 16.5.1, 16/20 A, MDRC Switch Actuators SA/S x.16.5.1, 16/20 A The Switch Actuators can switch up to are modular installation devices in ProM 12 independent electrical loads via design for installation in the distribution floating contacts.
  • Page 27 ® ABB i-bus Device technology Output switching times Maximum relay position changes 2.16.5.1 4.16.5.1 8.16.5.1 12.16.5.1 per output per minute if all relays are switched simultaneously. Position changes should be distributed equally within the minute. Maximum relay position changes per output per minute if only one relay is switched.
  • Page 28 The current application program is available for download at www.abb.com/knx. After import into ETS, it is available in ETS under ABB/Output/Binary output xf 16C/…* (x = 2, 4, 8 or 12). The device does not support the locking function of a KNX device in ETS. If you inhibit access to all of the project devices by using a BCU code, it has no effect on this device.
  • Page 29 ® ABB i-bus Device technology 2.5.3 Connection schematic SA/S 12.16.5.1 Label carrier Programming button Programming LED Bus connection terminal Contact position display and manual operation Load current circuits, for every 2 connection terminals Danger Touch voltages. Danger of injury. Observe all-pole disconnection.
  • Page 30 ® ABB i-bus Device technology 2.5.4 Dimension drawing
 SA/S 12.16.5.1 SA/S 2.16.5.1 SA/S 4.16.5.1 SA/S 8.16.5.1 SA/S 12.16.5.1 36 mm 72 mm 144 mm 216 mm Width W Mounting width 2 units 4 units 8 units 12 units (18 mm modules) SA/S | 2CDC 505 056 D0208 33...
  • Page 31 ® ABB i-bus Device technology Switch Actuators SA/S x.16.6.1, 16/20 A, MDRC Switch Actuators SA/S x.16.6.1, 16/20 A The Switch Actuators can switch up to are modular installation devices in ProM 12 independent electrical loads via design for installation in the distribution floating contacts.
  • Page 32 ® ABB i-bus Device technology Output service life Mechanical service life > 10 Electrical endurance To IEC 60 947-4-1 (240 V/cos ϕ = 0.8) > 10 (240 V/cos ϕ = 0.45) > 3 x 104 (240 V/cos ϕ = 0.45) AC5a > 3 x 10 0.02…20 A...
  • Page 33 (600 µs) 300 A Maximum peak inrush current I Number of electronic ballasts (T5/T8, single 18 W (ABB EVG 1 x 18 SF) element) 24 W (ABB EVG-T5 1 x 24 CY) 36 W (ABB EVG 1 x 36 CF)
  • Page 34 The current application program is available for download at www.abb.com/knx. After import into ETS it can be found under ABB/Output/Binary output xf 16CS/…* (x = 2, 4, 8 or 12). The device does not support the locking function of a KNX device in ETS. If you inhibit access to all of the project devices by using a BCU code, it has no effect on this device.
  • Page 35 ® ABB i-bus Device technology Please note Only load currents with a sine wave characteristic can be detected correctly. On other signal types, e.g. phase angle or inverse phase angle control signals, the detected current value is distorted. In this case, the measured value is meaningless.
  • Page 36 ® ABB i-bus Device technology 2.6.3 Connection schematic SA/S x.16.6.1 Label carrier Programming button Programming LED Bus connection terminal Contact position display and manual operation Load current circuits, for every 2 connection terminals Danger Touch voltages. Danger of injury. Observe all-pole disconnection.
  • Page 37 ® ABB i-bus Device technology Dimension drawing
SA/S x.16.6.1 2.6.4 SA/S 2.16.6.1 SA/S 4.16.6.1 SA/S 8.16.6.1 SA/S 12.16.6.1 36 mm 72 mm 144 mm 216 mm Width W Mounting width 2 units 4 units 8 units 12 units (18 mm modules) 40 2CDC 505 056 D0208 | SA/S...
  • Page 38 Number of electronic ballasts (T5/T8, single element): 10 EBUs 23 EBUs 23 EBUs 23 EBUs EBUs EBUs 18 W (ABB EVG 1 x 18 CF) 10 EBUs 23 EBUs 23 EBUs 23 EBUs EBUs EBUs 24 W (ABB EVG 1 x 24 CY)

  • Page 39: Ballast Calculation

    ® ABB i-bus Device technology Ballast calculation The electronic ballast is a device for operating gas discharge lamps, e.g. fluorescent lamps. During normal operation, it converts the mains voltage to an optimum operating voltage for gas discharge lamps. It also enables them to ignite (start) via capacitor circuitry.

  • Page 40: Ac1, Ac3, Ax, C-Load Specifications

    ® ABB i-bus Device technology Example ® ABB i-bus ballast 1 x 58 CF = 33.9 A (147.1 µs) Peak inrush current I For Switch Actuator SA/S 4.16.6.1 this results in: maximum number of electronic ballasts/output = 600 A/34 A = 17 electronic ballasts This number has been limited to 12 electronic ballasts in conjunction with a B16 miniature circuit breaker.

  • Page 41: Current Detection Specifications

    ® ABB i-bus Device technology The switching capacity specifications AC and AX are not directly comparable. However, the following switching capacity capability can still be determined: The lowest switching capacity corresponds with the specification AC1 – mainly for ohmic loads.
  • Page 42 ® ABB i-bus Device technology For a non-sinusoidal curve type, the resulting values can diverge significantly from the real RMS value. This measurement method is used in most commercially available analog and digital multimeters that are calibrated for sinusoidal curve types.
  • Page 43 ® ABB i-bus Device technology It is possible to program two threshold values for each output. With an overshoot or undershoot of the current threshold value a 1 bit telegram is sent via the bus. Thus for example, the failure of equipment can be detected and displayed.

  • Page 44: Assembly And Installation

    ® ABB i-bus Device technology 2.11 Assembly and installation ® ABB i-bus Switch Actuators are modular installation devices for installation in the distribution board on 35 mm EN 60 715 mounting rails. The mounting position can be selected as required. The electrical connection is implemented using screw terminals. The connection to the bus is implemented using the supplied bus connection terminal.
  • Page 45 ® ABB i-bus Device technology Supplied state The device is supplied with the physical address 15.15.255. The application program is preloaded. It is therefore only necessary to load group addresses and parameters during commissioning. However, the complete application program can be reloaded if required. Downloads may take longer after a change of application program, a discharge or an aborted download.
  • Page 46 The applications feature the same appearance and the same parameter window. This significantly ® simplifies engineering and programming for ABB i-bus KNX Switch Actuators. Current detection is only integrated in types SA/S x.16.6.1. Every Switch Actuator has its own application program with the same functions, whereby devices with current detection feature additional parameters and communication objects for the current detection.
  • Page 47 ■ ■ ■ ■ – Status messages ® See special ABB i-bus KNX devices for the HVAC area, e.g. Valve Drive actuator, Fan/Fan Coil actuator or Fan Coil actuator. ■ = possible functions 50 2CDC 505 056 D0208 | SA/S...
  • Page 48 *… = ETS and the current version of the device application program are required for programming. The current application program is available for download at www.abb.com/knx. After import into ETS it is available under ABB/Output/Binary output xf /... (x = 2, 4, 8 or 12).
  • Page 49 ® ABB i-bus Commissioning The following operating modes are available for each output of a Switch Actuator: For “normal” switching, e.g. of lighting. The output is controlled directly via the communication object Switch. A large number of additional functions Switch actuator (time, logic, safety, etc.) are possible.
  • Page 50 Commissioning 3.1.1 Conversion of previous application program versions ® For ABB i-bus KNX devices, using ETS3 or higher it is possible to assume the parameter settings and group addresses from earlier application programs. Please note Default values for newly added parameters are set after conversion.
  • Page 51 ® ABB i-bus Commissioning The following conversions are possible from the point of view of the target devices: Device type Application name Convertible to Device type Application name Target device Target device Source device Source device SA/S x.16.5S Switch xf 16CS/2.0 SA/S x.20.1S...
  • Page 52 ® ABB i-bus Commissioning Important Usually, the version numbers of our product names match the version number of the application program. Among our Switch Actuators there are some exceptions, e.g. the SA/S 4.16.6.1: Product name: Switch Actuator, 4-fold, 16 A, MDRC (V1.0) Application program: Switch 4f 16CS/3.0...
  • Page 53 ® ABB i-bus Commissioning 3.1.1.2 Procedure • Import the current VD3 file into ETS3 and add a product and its current application program to the project. • After you have parameterized a device, you can transfer the settings to a second device.
  • Page 54 ® ABB i-bus Commissioning 3.1.2 Copying and exchanging parameter settings Please note The output copy and exchange function is integrated into all Switch Actuators. Parameterization of devices can take a lot of time depending on the complexity of the application and the number of device outputs.
  • Page 55 When the term “channels” is used in ETS, it means inputs and/or outputs. To make the language of ETS ® generally valid for as many ABB i-bus devices as possible, the word channels is used in this document. 58 2CDC 505 056 D0208 | SA/S...
  • Page 56 ® ABB i-bus Commissioning 3.1.2.2 Copy/Exchange channels dialog You can see general product information in the upper area of the window. Below it you will find a selection window for the source channel so that you can mark it. Beside it is the selection window for marking the destination channel(s).
  • Page 57 ® ABB i-bus Commissioning Destination channels By selecting the destination channel(s) you define which channel(s) are to assume the parameter settings of the source channel. • For the Exchange function, only one target output can be selected at a time.
  • Page 58 The Switch Actuator is parameterized using Engineering Tool Software (ETS), version ETS2 V1.3 or higher. In ETS2/ETS3 the application program can be found under ABB/Output/Binary output/Switch xf. The following sections describe the parameters of the Switch Actuators by their parameter windows.
  • Page 59 ® ABB i-bus Commissioning 3.2.1 Parameter window General Higher level parameters can be set in the General parameter window. Transmission and switching delay time after recovery of bus voltage [2…255s] Options: 2…255 During the transmission and switching delay, telegrams are received only. The telegrams are not processed, however, and the outputs remain unchanged.
  • Page 60 ® ABB i-bus Commissioning Rate of telegrams Options: not limited 1 Telegram / Second 2 Telegrams / Second 3 Telegrams / Second 5 Telegrams / Second 10 Telegrams / Second 20 Telegrams / Second The load on the bus generated by the device can be limited by the telegram rate. This limit relates to all telegrams sent by the device.
  • Page 61 ® ABB i-bus Commissioning Enable Safety Object for operating mode "Switch Actuator" Options: • yes: Three further parameters appear: Function Safety Priority 1 Function Safety Priority 2 Function Safety Priority 3 Options: inactive enabled by object value “0” enabled by object value “1”...
  • Page 62 ® ABB i-bus Commissioning Control period in seconds
[0…65,535s, 0 = inactive] Options: 0…65,535 This parameter defines the monitoring period of the Safety Priority x function. If during this time communication object Safety Priority x* receives a telegram with the triggering condition defined in parameter Function Safety Priority x, it will be triggered.
  • Page 63 ® ABB i-bus Commissioning 3.2.2 Parameter window A: General Please note This product manual describes all the current 2/4/8 and 12-fold Switch Actuators. These devices have 2/4/8 or 12 outputs respectively. However, as the functions for all outputs are identical, only the functions of output A will be described.
  • Page 64 ® ABB i-bus Commissioning 3.2.3 Operating mode Switch Actuator The Switch Actuator operating mode is used for normal switching, e.g. of lighting. The output is controlled via various logic, time and safety functions. The input signal for the function is received via communication object Switch.
  • Page 65 ® ABB i-bus Commissioning • always: The status of the contact position is always actively sent via the bus via communication object Status Switch, even when a change in status has not occurred. Transmission is triggered as soon as the communication objects Switch, Threshold input or Permanent ON receive a telegram. Even a scene or a preset recall triggers transmission of the switch state.
  • Page 66 ® ABB i-bus Commissioning Value object "Switch" on bus voltage recovery Options: not write to write with 0 to write with 1 With this parameter, the output can be influenced after bus voltage recovery. As standard the communication object Switch receives the value 0.
  • Page 67 ® ABB i-bus Commissioning Overwrite scene, preset and threshold value 1 with download Options: This parameter determines whether the preset and scene values and threshold value 1 of the output modified via the bus are overwritten in the Switch Actuator by the values set in parameter windows A: Scene, A: Preset or A: Threshold.
  • Page 68 ® ABB i-bus Commissioning 3.2.3.1 Parameter window A: Function In this parameter window you determine the response (reaction) of the output and can enable different functions, which makes further parameter windows available. Reaction of output A Options: Normally closed contact Normally open contact This parameter determines the reaction of the output as a normally open or normally closed contact.
  • Page 69 ® ABB i-bus Commissioning Please note The Time function is only disabled when the ongoing Time function has ended. While the output is disabled, the higher switching priorities, e.g. Safety functions, are undertaken. Enabling the Time function enables the communication object Permanent ON. The output is switched on via this communication object.
  • Page 70 ® ABB i-bus Commissioning How does the staircase lighting react on bus voltage failure? Reaction in the event of bus voltage failure is specified by the parameter Reaction on bus voltage failure in parameter window A: General. How does the staircase lighting react on bus voltage recovery? Reaction on bus voltage recovery is defined by two conditions: By the communication object Disable time function.
  • Page 71 ® ABB i-bus Commissioning Enable functions "priority and safety operation" Options: • no: Parameter window A: Safety is not enabled for output A. • yes: Parameter window A: Safety is enabled for output A. This parameter window is used for parameterizing Safety Priorities 1, 2, 3 and Forced operation.
  • Page 72 ® ABB i-bus Commissioning Send status via object "contact monitoring" Options: only after changing always The send behavior of the communication object Contact monitoring can be set using this parameter. The Contact monitoring communication object displays contact faults. An error (value 1) is displayed as soon as a current of about 30 mA (observe the tolerances) is detected on an open contact.
  • Page 73 ® ABB i-bus Commissioning 3.2.3.1.1 Parameter window A: Time All settings for the Time function are undertaken in this parameter window: ON/OFF delay, Staircase lighting function and Flashing. This parameter window is visible if the Enable time function parameter has been enabled in Parameter window A: Function, p.
  • Page 74 ® ABB i-bus Commissioning Time function Options: Staircase lighting function ON/OFF delay Flashing This parameter defines the type of Time function for each output. • Staircase lighting function: The value that switches the staircase lighting on and off can be parameterized.
  • Page 75 ® ABB i-bus Commissioning The following parameters appear when Staircase lighting is selected: Duration of staircase lighting Minutes Options: 0…5…1,000 Seconds Options: 0…59 The staircase lighting time defines how long the staircase lighting is switched on after an ON telegram. The input is made in minutes and seconds. The staircase lighting time may extend depending on the value set in the parameter Warning before end of staircase lighting.
  • Page 76 ® ABB i-bus Commissioning Staircase lighting can be switched off Options: ON with "1" and OFF with "0" ON with "1" no action with "0" ON with "0" or "1", switch OFF not possible This parameter defines the telegram value used for switching the staircase lighting on and off prematurely.
  • Page 77 ® ABB i-bus Commissioning There are two types of warning: The communication object warning stair lighting is set to the value 1 when the warning time starts, and remains until it has elapsed. The communication object can be used, for example, to switch a warning light.
  • Page 78 ® ABB i-bus Commissioning How does the staircase lighting react on bus voltage failure? Reaction in the event of bus voltage failure is specified by the parameter Reaction on bus voltage failure in parameter window A: General. How does the staircase lighting react on bus voltage recovery? Reaction on bus voltage recovery is defined by two conditions.
  • Page 79 ® ABB i-bus Commissioning The following parameters appear with ON/OFF delay: The output can be switched on or off with a delay via this function. Explanations for ON/OFF delay can be found at ON/OFF delay, p. 151. You will also find a timing diagram as well as explanations on the effect of various ON and OFF telegrams in combination with ON/OFF delay.
  • Page 80 ® ABB i-bus Commissioning The following parameters appear when Flashing is selected: The output starts to flash as soon as communication object Switch receives the parameterized value. The flashing period can be adjusted via the parameterized time duration for ON or OFF. At the start of the flashing period, the output is switched on with a normally open contact and off with a normally closed contact.
  • Page 81 ® ABB i-bus Commissioning Flashing if object "Switching" is Options: ON (1) OFF (0) always flashing, ON (1) or OFF (0) Here you set the value of the communication object Switch at which the output flashes. Flashing is not retriggerable.
  • Page 82 ® ABB i-bus Commissioning Number of ON impulses: [1...100] Options: 1…5…100 This parameter defines the maximum number of pulses. This is useful to prevent flashing causing unnecessary wear of the contacts. Contact position after flashing This parameter defines the state that the parameter should assume after flashing.
  • Page 83 ® ABB i-bus Commissioning 3.2.3.1.2 Parameter window A: Preset Preset settings can be made in this parameter window. This parameter window is visible if Enable function "presets" has been enabled in Parameter window A: Function, p. 71. What is a preset? Presets are used to recall a parameterized switch value, e.g.
  • Page 84 ® ABB i-bus Commissioning Reaction on preset 1 (telegr. value 0) Options: no reaction restore old value before preset 2 restore parameterized value of preset 2 This parameter determines the contact position that the output assumes when preset 1 is recalled, i.e., communication object Call Preset 1/2 receives a telegram with the value 0.
  • Page 85 ® ABB i-bus Commissioning Reaction on preset 2 (telegr. value 1) Options: no reaction This parameter determines the contact position that the output assumes when preset 2 is recalled, i.e., communication object Recall Preset 1/2 receives a telegram with the value 1.
  • Page 86 ® ABB i-bus Commissioning 3.2.3.1.3 Parameter window A: Scene All settings for the Scene function are undertaken in this parameter window. This parameter window is visible if the parameter Enable function "scene" has been enabled in Parameter window A: Function, p. 71.
  • Page 87 ® ABB i-bus Commissioning Standard value Options: By storing a scene, the user has the opportunity to change the parameterized value stored in ETS. After a bus voltage failure, the value saved via KNX is retained. Please note When a scene is recalled: - the Time function is restarted.
  • Page 88 ® ABB i-bus Commissioning 3.2.3.1.4 Parameter window A: Logic All settings for the Logic function are undertaken in this parameter window. This parameter window is visible if Enable function "logic" has been enabled in Parameter window A: Function, p. 71.
  • Page 89 ® ABB i-bus Commissioning Function of object "Logical Connection 1" Options: GATE The logical function of the communication object Logical Connection 1 is determined with the switch telegram. All three standard operations (AND, OR, XOR) are possible. In addition, the GATE operation can be used to inhibit switch commands.
  • Page 90 ® ABB i-bus Commissioning Gate disabled, if Object value "Logical Connection 1" is Options: This parameter defines the value at which communication object Logical Connection 1 disables the GATE. While it is disabled, telegrams received on communication object Switch are ignored. As long as GATE is active, the last value sent to the GATE input remains on the output's logic gate.
  • Page 91 ® ABB i-bus Commissioning 3.2.3.1.5 Parameter window A: Safety All settings for the Safety function are undertaken in this parameter window. This parameter window is visible if the parameter Enable functions "priority and safety operation" has been enabled in Parameter window A: Function, p.
  • Page 92 ® ABB i-bus Commissioning If multiple demands occur, the priority is defined as follows in accordance with the sequence in parameter window A: Safety: • Safety Priority 1 (highest priority) • Forced operation • Safety Priority 2 • Safety Priority 3 (lowest priority) With the option inactive, Safety Priority x or Forced operation and the associated communication object are not considered and are omitted from the priority sequence.
  • Page 93 ® ABB i-bus Commissioning Value Bit 1 Bit 0 State Description Enabled If the communication object Forced operation receives a telegram with the value 0 (binary 00) or 1 (binary 01), the output is enabled and can be actuated via different communication objects.
  • Page 94 ® ABB i-bus Commissioning 2 bit communication object: Options: "0" inactive "2" OFF "3" ON • "0" inactive: Forced operation is switched off and the output behaves in the same way as with parameter Reaction when forced operation and all safety Priority x end.
  • Page 95 ® ABB i-bus Commissioning 3.2.3.1.6 Parameter window A: Threshold All settings for the Threshold function are undertaken in this parameter window. This parameter window is visible if the Enable function threshold parameter has been enabled in Parameter window A: Function, p. 71.
  • Page 96 ® ABB i-bus Commissioning Change Threshold 1 over bus Options: This parameter defines whether threshold value 1 can or cannot be changed via the bus. • yes: Communication object Threshold value 1 can be changed via the bus. This can be a 1 or 2 byte communication object depending on the parameterization of the threshold value input.
  • Page 97 ® ABB i-bus Commissioning Behaviour Falling below lower threshold Exceeding upper threshold Options: no reaction This parameter determines the contact position of the output based on the value of communication object Threshold input if this value exceeds or falls below the upper or lower threshold respectively.
  • Page 98 ® ABB i-bus Commissioning 3.2.3.1.7 Parameter window A: Current Detection All settings for the Current Detection function are undertaken in this parameter window. This parameter window is visible if the Enable function "current detection" parameter has been enabled in Parameter window A: Function, p.
  • Page 99 ® ABB i-bus Commissioning Datapoint type object "Current Value" [0...65,535 in mA] Options: 2 byte counter (DTP 7.012) 4 byte float (DTP 14.019) This parameter determines the data type (datapoint, DTP) of the communication object Current Value. A 2 byte counter (EIS 10, DPT 7.012, 1 mA per digit) or a 4 byte float value (EIS 9, DTP 14.019) can be selected.
  • Page 100 ® ABB i-bus Commissioning If the parameter Send current value, transmission time [0...65,535s, 0 = not send] is also activated, the counter is reset and restarted after sending the current value. Please note If for example, a current change of 1 A has been selected, a current value is only sent if the load current exceeds 1 A when starting, for example, from 0 A.
  • Page 101 ® ABB i-bus Commissioning Enable current threshold value(s) Options: Up to two current thresholds values can be enabled for detected currents. • no: No current threshold values are enabled. • yes: A current threshold value with the corresponding parameterization option and the communication object Status Current-Threshold 1 are enabled.
  • Page 102 ® ABB i-bus Commissioning • only with closed contact: Falling below or exceeding the set current threshold value can only be evaluated when the contact is closed. As a result, a current threshold undershoot is never detected (as an error) on a contact opened via KNX (current flow interrupted). The precondition for evaluation to work properly is that the contact is closed by a switch action via KNX.
  • Page 103 ® ABB i-bus Commissioning If the value dropped below the threshold before the contact was opened and is still below the threshold after the contact is closed again, the below threshold value information is not sent again as the status has not changed.
  • Page 104 ® ABB i-bus Commissioning Value of hysteresis current threshold 1 Options: 3/25/50/100/200/500 mA 1/2/5 A To avoid a continuously changing threshold value state, the current detection thresholds feature a hysteresis function. The set Value of hysteresis current threshold ensures that a current change is only registered as such if it is greater than the hysteresis value.
  • Page 105 ® ABB i-bus Commissioning • send "1" when crossing lower: Should current threshold value 1 be undershot, communication object Status Current-Threshold 1 sends the value 1. An overshoot sets the value to 0 but no telegram is sent. • send "0" at crossing over – "1" at crossing lower: Should current threshold value 1 be overshot, communication object Status Current-Threshold 1 sends the value 0, or if the threshold is undershot, 1.
  • Page 106 EIS 1, 1 bit C, R, T DPT 1.002 ®, To regularly monitor the presence of the Switch Actuator on the ABB i-bus a monitoring telegram can be sent cyclically via the bus. This communication object is always enabled. Telegram value:...
  • Page 107 ® ABB i-bus Commissioning Function Object name Data type Flags Safety Priority 2 General EIS 1, 1 bit C, W, U DPT 1.005 See communication object 1 Safety Priority 3 General EIS 1, 1 bit C, W, U DPT 1.005 See communication object 1 4…...
  • Page 108 ® ABB i-bus Commissioning 3.2.4.2 Communication objects, Output A Please note This product manual describes all the current 2/4/8 and 12-fold Switch Actuators. These devices have 2/4/8 or 12 outputs respectively. However, as the functions for all outputs are identical, only the functions of output A will be described.
  • Page 109 ® ABB i-bus Commissioning Function Object name Data type Flags switch Output A EIS 1, 1 C, W bit DPT 1.001 This communication object is used for switching the output ON/OFF. The device receives a switch telegram via the switch object.
  • Page 110 ® ABB i-bus Commissioning Function Object name Data type Flags Disable time function Output A EIS 1, 1 bit C, W DPT 1.003 This communication object is enabled if the yes option is selected for parameter Enable time functions in the A: Function parameter window.
  • Page 111 ® ABB i-bus Commissioning Function Object name Data type Flags Set preset 1/2 Output A EIS 1, 1 bit C, W DPT 1.002 This communication object is enabled if the yes option is selected for parameter Enable function "presets" in the A: Function parameter window.
  • Page 112 ® ABB i-bus Commissioning Function Object name Data type Flags Logical connection 1 Output A 1 bit (EIS 1) C, W DPT 1.002 This communication object is enabled if the yes option is selected for parameter Enable function "logic" in parameter window A: Function Using this communication object, the output of the first of two logic objects can be assigned.
  • Page 113 ® ABB i-bus Commissioning Function Object name Data type Flags Forced Positioning Output A 2 bit (EIS 8) C, W DPT 2.001 This communication object is enabled if in parameter window A: Function the yes option has been selected for parameter Enable functions "priority and safety operation"...
  • Page 114 ® ABB i-bus Commissioning Function Object name Data type Flags Contact monitoring Output A EIS 1, 1 bit C, T DPT 1.002 This communication object is enabled if the yes option is selected for parameter Enable function "current detection" in the A: Function parameter window.
  • Page 115 ® ABB i-bus Commissioning Status Current- Output A EIS 1, 1 bit C, T Threshold 2 DPT 1.002 This communication object is enabled if the yes option is selected for parameter Enable current threshold value(s) and Enable threshold value 2 in the A: Current Detection parameter window.
  • Page 116 Considering these aspects, it can be useful to use an Electronic Switch Actuator, Fan Coil Actuator or Fan ® Coil Controller from the ABB i-bus KNX range. These actuators do not feature electrical isolation and have a considerably smaller, but quite sufficient, switching capacity. Mechanical wear and switching noises are not an issue.
  • Page 117 ® ABB i-bus Commissioning Please note The current detection function and associated parameter window is only visible on Switch Actuators with current detection (SA/S x.16.6.1). It offers the same functionality in both Switch Actuator and Heating Actuator modes. Status response of switching state Object "Status Switch"...
  • Page 118 ® ABB i-bus Commissioning The status value to be sent is defined using the parameter Object value switching status (Object “Status Switch”). Please note The contact position is determined by a sequence of priorities and logical connections – Function diagram, p. 161.
  • Page 119 ® ABB i-bus Commissioning Connected valve type Options: normally closed normally open This parameter sets the valve type for the connected valve. How does a de-energized closed (normally closed) valve react? If no current is flowing in the control circuit, the valve closes.
  • Page 120 ® ABB i-bus Commissioning With 1 byte (continuous) selected, an additional parameter appears: Transmit status response Object "Status heating" Options: yes, 0% = "0" otherwise "1" (1 bit) yes, 0% = "1" otherwise "0" (1 bit) yes, continuous control value (1 byte) This parameter is only visible with continuous control with a 1 byte value.
  • Page 121 ® ABB i-bus Commissioning 3.2.5.1 Parameter window A: Function In this parameter window you determine the response (reaction) of the output and can enable different functions, which makes further parameter windows available. Enable monitoring of the controller Options: • no: Parameter window A: Monitoring is not enabled for output A.
  • Page 122 ® ABB i-bus Commissioning Enable function "valve purge" Options: Cyclic valve purge prevents deposits from forming in the valves. • no: Parameter window A: Valve Purge is not enabled for output A. • yes: Parameter window A: Valve Purge and communication objects Trigger valve purge and Status valve purge are enabled for output A.
  • Page 123 ® ABB i-bus Commissioning Send status via object "contact monitoring" Options: only after changing always The send behavior of the communication object Contact monitoring can be parameterized by this parameter. A contact fault is indicated via communication object Contact monitoring. An error (value 1) is displayed as soon as a current of about 30 mA (observe the tolerances) is detected on an open contact.
  • Page 124 ® ABB i-bus Commissioning 3.2.5.1.1 Parameter window A: Monitoring All settings for the Monitoring function are undertaken in this parameter window. This parameter is visible if parameter Enable monitoring of the controller has been enabled in Parameter window A: Function, p. 124.
  • Page 125 ® ABB i-bus Commissioning Position of the valve drive during fault of room thermostat Options: unchanged 0% (closed) 10% (26) 90% (230) 100% (open) This parameter determines the safety position that the SA/S controls in error mode. The value in brackets corresponds to the 1 byte value.
  • Page 126 ® ABB i-bus Commissioning 3.2.5.1.2 Parameter window A: Forced Operation All settings for the Forced Operation function are undertaken in this parameter window. This parameter window is visible if the Enable function "forced operation" parameter has been enabled in Parameter window A: Function, p.
  • Page 127 ® ABB i-bus Commissioning 3.2.5.1.3 Parameter window A: Valve Purge All settings for the Valve Purge function are undertaken in this parameter window. This parameter window is visible if the Enable function "valve purge" parameter has been enabled in Parameter window A: Function, p.
  • Page 128 ® ABB i-bus Commissioning Automatic valve purge Options: disable one times per day one times per week one times per month The counter for automatic purging starts to run when the parameter is downloaded. The time is reset each time it is downloaded.
  • Page 129 ® ABB i-bus Commissioning 3.2.5.1.4 Parameter window A: Current Detection All settings for the Current Detection function are undertaken in this parameter window. This parameter window is visible if the Enable function "current detection" parameter has been enabled in Parameter window A: Function, p.
  • Page 130 EIS 1, 1 bit C, R, T DPT 1.002 ®, To regularly monitor the presence of the Switch Actuator on the ABB i-bus a monitoring telegram can be sent cyclically via the bus. This communication object is always enabled. Telegram value:...
  • Page 131 ® ABB i-bus Commissioning Function Object name Data type Flags Safety Priority 2 General EIS 1, 1 bit C, W, U DPT 1.005 See communication object 1 Safety Priority 3 General EIS 1, 1 bit C, W, U DPT 1.005 See communication object 1 4…...
  • Page 132 ® ABB i-bus Commissioning 3.2.6.2 Communication objects, Output A Please note This product manual describes all the current 2/4/8 and 12-fold Switch Actuators. These devices have 2/4/8 or 12 outputs respectively. However, as the functions for all outputs are identical, only the functions of output A will be described.
  • Page 133 ® ABB i-bus Commissioning Function Object name Data type Flags switch Output A EIS 1, 1 bit C, W DPT 1.001 This communication object is visible if control of the heating actuator is implemented via a 1 bit communication object. The heating valve is controlled directly using it.
  • Page 134 ® ABB i-bus Commissioning Function Object name Data type Flags Status valve purge Output A EIS 1, 1 bit C, T DPT 1.002 This communication object is enabled if the yes option is selected for parameter Enable function "valve purge" in the A: Function parameter window.
  • Page 135 ® ABB i-bus Commissioning Function Object name Data type Flags Status heating Output A EIS 1, 1 bit C, T DPT 1.001 This communication object is visible if control of the heating actuator is implemented via a 1 bit communication object, e.g.
  • Page 136 ® ABB i-bus Commissioning Function Object name Data type Flags Status Current-Threshold 1 Output A EIS 1, 1 bit C, T DPT 1.002 This communication object is enabled if the yes option is selected for parameter Enable current threshold value(s) in the A: Current Detection parameter window.

  • Page 138: Planning And Application

    ABB i-bus Planning and application Planning and application ® In this section you will find some tips and application examples for practical use of ABB i-bus Switch Actuators. Current detection The current detection feature opens many new fields of application for the Switch Actuators. The following list contains a few examples: •...
  • Page 139 ® ABB i-bus Planning and application 4.1.1 Threshold
function with current detection The current detection function features two independent thresholds. The detected current value will fluctuate by about 20 mA due to the necessary analog/digital conversion of the detected load current. To avoid a continuous change of the threshold value state, the thresholds for current recognition feature a hysteresis function.
  • Page 140 ® ABB i-bus Planning and application 4.1.2 Operating state displays A Switch Actuator with current detection is designed for recording and displaying operating states of electrical loads. The operating state is detected indirectly via the load current. If the load current exceeds a threshold, an ON telegram is sent via the bus, if the value drops below the threshold, an OFF telegram is issued.
  • Page 141 ® ABB i-bus Planning and application 4.1.3 Recording operating hours With the help of current detection in the Switch Actuator and a separate meter or counter element, it is possible to record, signal and display the actual electrical operating hours of electrical loads. This function can be used in facility management or for preventative maintenance and service planning.
  • Page 142 ® ABB i-bus Planning and application 4.1.4 Trend analysis Trend analysis is used to monitor the states of electrical systems over long periods and to receive early warnings of possible defects. The system operator can use this information for planning and carrying out inspections, and undertake repairs before the system fails.
  • Page 143 ® ABB i-bus Planning and application Current display The Switch Actuators with current detection are not current measurement display devices. The detected current and its tolerances (see Technical data, from p. 9), can be displayed. Using the KNX, this current value can be sent to a complex maintenance center or a simple LCD display or visualization, e.g.

  • Page 144: Operating Mode Switch Actuator

    ® ABB i-bus Planning and application Operating mode Switch Actuator 4.2.1 Function diagram The following illustration indicates the sequence in which the functions are processed. Communication objects which lead to the same box have the same priority and are processed in the sequence in which the telegrams are received.
  • Page 145 ® ABB i-bus Planning and application Example If both communication objects Logical connection x are activated, a telegram received via communication object Switch is connected to them. The result of this action serves as the input signal for the Time function. If this is not disabled, a corresponding switch signal is generated, e.g. delay or flashing.
  • Page 146 ® ABB i-bus Planning and application Warning The additional Warning function enables the user to be warned in good time before the staircase lighting time elapses. The warning can be carried out by switching the output on/off briefly or by sending a communication object.
  • Page 147 ® ABB i-bus Planning and application Retriggering Via “pumping up” – actuation of the push button several times in succession – the user can adapt the staircase lighting to current needs. The maximum duration of the staircase lighting time can be set in the parameters.
  • Page 148 ® ABB i-bus Planning and application 4.2.2.2 ON/OFF delay The ON/OFF delay delays output switch-on or switch-off. The delay time T or T starts after a switch telegram, and after it has elapsed, the output executes the switch telegram. If a new ON telegram with the value 1 is received during the switching ON delay, the ON delay time starts again.
  • Page 149 ® ABB i-bus Planning and application 4.2.2.3 Flashing The output can flash, i.e. switch on and off periodically. The switch on time (T ) and switch off time (T ) during flashing can be parameterized. Please note The contact life of the contacts should be considered and can be found in the technical data. Limiting the number of switching operations with the parameter Number of ON impulses may be useful.
  • Page 150 ® ABB i-bus Planning and application 4.2.3 Logic function With the Logic function it is possible to connect the switching of the output with certain conditions. Two connection objects are available: Initially the communication object Switch is evaluated with communication object Logical connection 1.
  • Page 151 ® ABB i-bus Planning and application The Logic function is always re-calculated when an object value is received. Example GATE function • The GATE connection is set to disable as soon as the communication object Logical connection x receives a 0.
  • Page 152 ® ABB i-bus Planning and application 4.2.4 Preset function A parameterizable contact position can be retrieved with the help of presets. Light scenes can therefore be implemented for example with a 1 bit communication object. Call preset Contact positions (preset values) can be recalled via communication objects Call preset 1/2. A maximum...
  • Page 153 ® ABB i-bus Planning and application Special function: Restore state A useful special function can be assigned to preset 1. It is possible to recreate the brightness levels (states) which were present before recalling preset 2. The following diagram clarifies this: This function can be used for example after a presentation to restore the lighting to the state it was in beforehand.
  • Page 154 A typical Scene function might be as follows and is described using the 8 bit scene telegram as an example: ® The task is to implement the room lighting for a presentation with ABB i-bus devices. The following devices are used in the room: •...
  • Page 155 ® ABB i-bus Planning and application Example An 8 bit scene (no. 8) comprises some lamps which are connected to two Switch Actuators and a light controller output. Also, two blinds are integrated into the Scene function via a blind actuator. The Scene can be recalled via a single KNX telegram.
  • Page 156 ® ABB i-bus Planning and application 4.2.6 Threshold function The Threshold function monitors a 1 or 2 byte value. As soon as a threshold is undershot or overshot, the output can be switched. The threshold values can be interpreted as hysteresis values: Threshold values are hysteresis values When the value exceeds the upper threshold or falls below the lower threshold, the output is switched.
  • Page 157 ® ABB i-bus Planning and application Threshold values are not hysteresis values The output is switched when any threshold is undershot or overshot. Please note If the communication object Threshold receives a value that does not overshoot or undershoot the old value, no switching action is triggered.

  • Page 158: Operating Mode Heating Actuator

    ® ABB i-bus Planning and application Operating mode Heating Actuator 4.3.1 Function diagram The following illustration indicates the sequence in which the functions are processed: SA/S | 2CDC 505 056 D0208 161...
  • Page 159 ® ABB i-bus Planning and application 4.3.2 2-step control 2-step control is the simplest form of control. No control value is calculated here. The room thermostat sends a 1 via the communication object Switch if a certain temperature is exceeded and a 0 if the value drops below a certain temperature.
  • Page 160 ® ABB i-bus Planning and application 4.3.3 Pulse width modulation (PWM) Should the SA/S receive a 1 byte control value as an input signal, it can use this value with the parameterized cycle time and undertake a PWM calculation. With PWM control, the received control value [0…100 %] calculated in the control algorithm is converted to a pulse width modulation.
  • Page 161 ® ABB i-bus Planning and application 4.3.4 Pulse width modulation – calculation With pulse width modulation, control is implemented by a variable mark-space ratio. During the time t the valve is opened, and during the time t it is closed. On account of t = 0.4 x t...
  • Page 162 ® ABB i-bus Planning and application 4.3.5 Lifetime examination of a PWM control If a PWM cycle time of 15 minutes has been selected, this means that 4 switching operations (switching on/off) occur each hour, 96 in a day and 3,000 in a month. This amounts to 36,000 switching operations a year.
  • Page 163 ® ABB i-bus Planning and application Reaction on bus voltage failure, recovery and download Reaction on bus voltage failure Response in the event of bus voltage failure is specified by the parameter Reaction on bus voltage failure in parameter window A: General. This parameterization acts directly on the relay and has the highest priority in the Switch Actuator.
  • Page 164 ® ABB i-bus Planning and application Download: During a download, the SA/S is not ready to function. No telegrams are received or sent and no switching actions are carried out. The primary objective is to ensure that a download has no effect on the operation of the device at the time.
  • Page 165 ® ABB i-bus Planning and application Reaction on: Bus voltage recovery Download ETS bus reset Operating mode Switch Actuator Switch object Parameterizable Unchanged. Evaluation only after As for download a new event has been received. (Parameter window X: General) Time function...
  • Page 166 ® ABB i-bus Planning and application Reaction on: Bus voltage recovery Download ETS bus reset Threshold Threshold value evaluation is carried out Overwrite Threshold 1 can be The Threshold 1 stored after bus voltage recovery using the parameterized (parameter in the SA/S will be...

  • Page 167: Scope Of Delivery

    ® ABB i-bus Appendix Appendix Scope of delivery ® ABB i-bus KNX SA/S Switch Actuators are supplied together with the following components. Please check the items received using the following list. • 1 (one) SA/S x.y.z.w , MDRC • 1 (one) set of installation and operating instructions •...
  • Page 168 ® ABB i-bus Appendix        – – – 172 AC           – – – 173 AD         –...

  • Page 169: Ordering Details

    ® ABB i-bus Appendix Ordering details Device type Product Name Order No. bbn 40 16779 Price Unit Packaging group weight (pcs.) 1 pc. [kg] 6 A Switch Actuators for resistive, inductive or capacitive loads SA/S 4.6.1.1 Switch Actuator, 4-fold 2CDG 110 152 R0011 87786 2 0.18...
  • Page 170 ® ABB i-bus Appendix Device type Product Name Order No. bbn 40 16779 Price Unit Packaging group weight (pcs.) 1 pc. [kg] 16 A Switch Actuators for loads with high peak inrush currents, e.g. lighting equipment with compensation capacitors or fluorescent lamp loads (AX) to EN 60 669, C-load SA/S 2.16.5.1...
  • Page 171 +49 (0)6221 701 607 (Marketing) The agreed properties are definitive for any orders Fax: +49 (0)6221 701 724 placed. ABB AG does not accept any responsibility whatsoever for potential errors or possible lack of E-mail: knx.marketing@de.abb.com information in this document.

This manual is also suitable for:

I-bus sa/s 2.16.2.1I-bus sa/s 2.16.6.1I-bus sa/s 2.10.2.1I-bus sa/s 4.6.1.1I-bus sa/s 4.10.2.1I-bus sa/s 4.6.2.1 ... Show all

Table of Contents
