CHAPTER 2: MODBUS COMMUNICATION
Address Description
7073 Phase Distance Zone 1 Direction
7074 Phase Distance Zone 1 Comparator Limit
7075 Phase Distance Zone 1 Delay
7076 Phase Distance Zone 1 Block
7077 Phase Distance Zone 1 Events
7078 Phase Distance Zone 1 Shape
7079 Phase Distance Zone 1 RCA
707A Phase Distance Zone 1 DIR RCA
707B Phase Distance Zone 1 DIR Comp Limit
707C Phase Distance Zone 1 Quad Right Blinder
707D Phase Distance Zone 1 Quad Right Blinder RCA
707E Phase Distance Zone 1 Quad Left Blinder
707F Phase Distance Zone 1 Quad Left Blinder RCA
7080 Phase Distance Zone 1 Volt Limit
7081 Phase Distance Zone 1 Transformer Voltage
Connection
7082 Phase Distance Zone 1 Transformer Current
Connection
7083 Phase Distance Zone 1 Rev Reach
7084 Phase Distance Zone 1 Rev Reach RCA
7085 Phase Distance Zone 1 Reserved (11 items)
7090 ...Repeated for Phase Distance Zone 2
70B0 ...Repeated for Phase Distance Zone 3
70D0 ...Repeated for Phase Distance Zone 4
70F0 ...Repeated for Phase Distance Zone 5
Ground Distance (Read/Write Grouped Setting) (5 Modules)
7130 Ground Distance Zone 1 Function
7131 Ground Distance Zone 1 Current Supervision
7132 Ground Distance Zone 1 Reach
7133 Ground Distance Zone 1 Direction
7134 Ground Distance Zone 1 Comparator Limit
7135 Ground Distance Zone 1 Delay
7136 Ground Distance Zone 1 Block
7137 Ground Distance Zone 1 Events
7138 Ground Distance Zone 1 Shape
7139 Ground Distance Zone 1 Z0 Z1 Magnitude
713A Ground Distance Zone 1 Z0 Z1 Angle
713B Ground Distance Zone 1 RCA
713C Ground Distance Zone 1 DIR RCA
713D Ground Distance Zone 1 DIR Comp Limit
713E Ground Distance Zone 1 Quad Right Blinder
713F Ground Distance Zone 1 Quad Right Blinder RCA
7140 Ground Distance Zone 1 Quad Left Blinder
7141 Ground Distance Zone 1 Quad Left Blinder RCA
7142 Ground Distance Zone 1 Z0M Z1 Magnitude
7143 Ground Distance Zone 1 Z0M Z1 Angle
7144 Ground Distance Zone 1 Voltage Level
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
0 to 2 ---
30 to 90 degrees 1
0 to 65.535 s
0 to 65535 ---
0 to ---
0 to 1 ---
30 to 90 degrees 1
30 to 90 degrees 1
30 to 90 degrees 1
0.02 to 500 ohms
60 to 90 degrees 1
0.02 to 500 ohms
60 to 90 degrees 1
0 to 5 pu
0 to 12 ---
0 to 12 ---
0.02 to 500 ohms
30 to 90 degrees 1
--- ---
0 to 1 ---
0.05 to 30 pu
0.02 to 500 ohms
0 to 2 ---
30 to 90 degrees 1
0 to 65.535 s
0 to 65535 ---
0 to 1 ---
0 to 1 ---
0 to 10 ---
-90 to 90 degrees 1
30 to 90 degrees 1
30 to 90 degrees 1
30 to 90 degrees 1
0.02 to 500 ohms
60 to 90 degrees 1
0.02 to 500 ohms
60 to 90 degrees 1
0 to 7 ---
-90 to 90 degrees 1
0 to 5 pu
MODBUS MEMORY MAP
Step Format Default
1 F154 0 (Forward)
F001 90
0.001 F001 0
1 F300 0
1 F102 0 (Disabled)
1 F120 0 (Mho)
F001 85
F001 85
F001 90
0.01 F001 1000
F001 85
0.01 F001 1000
F001 85
0.001 F001 0
1 F153 0 (None)
1 F153 0 (None)
0.01 F001 200
F001 85
--- F001 0
1 F102 0 (Disabled)
0.001 F001 200
0.01 F001 200
1 F154 0 (Forward)
F001 90
0.001 F001 0
1 F300 0
1 F102 0 (Disabled)
1 F120 0 (Mho)
0.01 F001 270
F002 0
F001 85
F001 85
F001 90
0.01 F001 1000
F001 85
0.01 F001 1000
F001 85
0.01 F001 0
F002 0
0.001 F001 0
95
