Page 1 QUICK GUIDE BASIC FUNCTION AUDIO SYSTEM VOICE COMMAND SYSTEM INFORMATION PERIPHERAL MONITORING SYSTEM PHONE NAVIGATION SYSTEM Entune App Suite INDEX For more information about the following items, see the “Owner’s Manual”.  Fuel consumption  Vehicle customization settings  Energy monitor ...
Page 2 Introduction NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL This manual explains the operation of this system. Please read this manual carefully to ensure proper use. Keep this manual in your vehicle at all times. The screen shots in this document and the actual screens of this system differ depending on whether the functions and/or a contract existed and the map data available at the time of producing this document.
Page 3 NAVIGATION SYSTEM (ENTUNE PREMIUM AUDIO) The Navigation System is one of the most technologically advanced vehicle ac- cessories ever developed. The system receives satellite signals from the Global Positioning System (GPS) operated by the U.S. Department of Defense. Using these signals and other vehicle sensors, the system indicates your present po- sition and assists in locating a desired destination.
Page 4 IMPORTANT INFORMATION ABOUT THIS MANUAL For safety reasons, this manual indicates items requiring particular attention with the following marks. WARNING ● This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.
Page 5 HOW TO READ THIS MANUAL Name Description Operational An outline of the operation is explained. Outlines Main Operations The steps of an operation are explained. Related Operations A main operation’s supplementary operations are described. Information Useful information for the user is described. ■...
Page 6 SAFETY INSTRUCTION SAFETY INSTRUCTION (ENTUNE AUDIO PLUS) (ENTUNE PREMIUM AUDIO) To use this system in the safest possible To use this system in the safest possible manner, follow all the safety tips shown manner, follow all the safety tips shown below.
Page 7 While driving, listen to the voice instruc- WARNING tions as much as possible and glance at the screen briefly and only when it is safe. ● For safety, the driver should not operate However, do not totally rely on voice guid- the system while he/she is driving.
Page 8: Table Of Contents
TABLE OF CONTENTS ® 2. Bluetooth SETTINGS ....43 QUICK GUIDE REGISTERING/CONNECTING ® Bluetooth DEVICE ......43 1. BASIC FUNCTION......12 ® SETTING Bluetooth DETAILS ..... 48 OVERVIEW BUTTONS ......12 3. OTHER SETTINGS ......56 “Apps” SCREEN ........14 GENERAL SETTINGS ......
Page 9 2. TOYOTA PARKING ASSIST VOICE COMMAND SYSTEM MONITOR ........168 TOYOTA PARKING ASSIST 1. VOICE COMMAND SYSTEM MONITOR ......... 168 OPERATION ........ 138 ESTIMATED COURSE LINE VOICE COMMAND SYSTEM....138 DISPLAY MODE ....... 173 CASUAL SPEECH PARKING ASSIST GUIDE LINE RECOGNIZATION ......
Page 10 TABLE OF CONTENTS 3. ROUTE GUIDANCE ...... 297 PHONE ROUTE GUIDANCE SCREEN..... 297 TYPICAL VOICE GUIDANCE 1. PHONE OPERATION PROMPTS ......... 302 (HANDS-FREE SYSTEM EDITING ROUTE ......... 303 FOR CELLULAR PHONES) ..220 4. MEMORY POINTS ......308 QUICK REFERENCE ......220 MEMORY POINTS SETTINGS....
Page 11: Quick Guide
QUICK GUIDE BASIC FUNCTION 1. OVERVIEW BUTTONS ....12 2. “Apps” SCREEN ......14 3. HOME SCREEN ......16 STATUS DISPLAY......... 18 QUICK REFERENCE 1. “Setup” SCREEN ......20 NAVIGATION OPERATION 1. REGISTERING HOME ....22 2. REGISTERING PRESET DESTINATIONS ......24 3.
Page 12: Basic Function
1. BASIC FUNCTION 1. OVERVIEW BUTTONS Entune Audio Plus Entune Premium Audio RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 13 1. BASIC FUNCTION Function Page Press to eject a disc. By touching the screen with your finger, you can control the selected 34, 35 functions. Insert a disc into this slot. The CD player turns on immediately. ® Press to access the Bluetooth hands-free system.
Page 14: Apps" Screen
1. BASIC FUNCTION 2. “Apps” SCREEN Press the “APPS” button to display the “Apps” screen. Entune Premium Audio Entune Audio Plus RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 15 1. BASIC FUNCTION Function Page Select to display the map screen. Select to display the audio control screen. Select to display the hands-free operation screen. Select to display the “Message Inbox” screen. Select to display weather information. Select to reorder the applications. ...
Page 16: Home Screen
1. BASIC FUNCTION 3. HOME SCREEN Press the “HOME” button to display the home screen. The home screen can display multiple information screens, such as the audio sys- tem screen, hands-free screen, application screen and clock screen, simulta- neously. When a screen is selected, the selected screen is switched to a full-screen display.
Page 17 1. BASIC FUNCTION Two-way split screen Function Page Displays the current time Select the displaying time to set the clock. (P.58)  The clock setting can be also set from the “General Settings” screen. (P.56) ® Displays the condition of the Bluetooth connection Select to display the “Setup”...
Page 18: Status Display
1. BASIC FUNCTION STATUS DISPLAY ® The condition of the Bluetooth connection, as well as the level of reception and the amount of cellular phone battery charge left, are displayed on the status dis- play. RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 19 1. BASIC FUNCTION Indicators Conditions (Gray) (Blue) No connection Poor Good  An antenna for the Bluetooth ® connection is built into the instru- ® The condition of ment panel. The condition of the Bluetooth connection may dete- ® ® Bluetooth riorate and the system may not function when a Bluetooth phone...
Page 20: Quick Reference
2. QUICK REFERENCE 1. “Setup” SCREEN The items shown on the “Setup” screen can be set. Press the “APPS” button, then select “Setup” to display the “Setup” screen. Entune Premium Audio Entune Audio Plus RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 21 2. QUICK REFERENCE Function Page Select to change the selected language, operation sound, automatic screen change settings, etc. Select to customize the home screen. Select to set the voice settings. Select to adjust the contrast and brightness of the screens. Select to set memory points (home, preset destinations, address book entries, areas to avoid), navigation details or to delete previous desti- 308, 318...
Page 22: Navigation Operation
3. NAVIGATION OPERATION 1. REGISTERING HOME* Press the “APPS” button. Select “Go Home”. Select “Yes”. Select “Navigation”. There are different kinds of meth- ods to search for your home. (P.281) Select “Dest.”. *: Entune Premium Audio only RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 23 3. NAVIGATION OPERATION Select “Enter”. Select “OK”. Registration of home is complete. Registering home in a different way P.309 Editing the name, location, phone num- ber and icon P.309 Setting home as the destination P.284 RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 24: Registering Preset Destinations
3. NAVIGATION OPERATION 2. REGISTERING PRESET DESTINATIONS* Press the “APPS” button. Select one of the preset destina- tion buttons. Select “Yes”. Select “Navigation”. There are different kinds of meth- ods to search for a destination. (P.281) Select “Dest.”. *: Entune Premium Audio only RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 25 3. NAVIGATION OPERATION Select “Enter”. Select a position for this preset destination. Select “OK”. Registration of preset destinations is complete. Registering preset destinations in a dif- ferent way P.310 Editing the name, location, phone num- ber and icon P.311 Setting preset destinations as the desti- nation P.284 RAV4_Navi+MM_OM42A43U_(U)
Page 26: Operation Flow: Guiding The Route
3. NAVIGATION OPERATION 3. OPERATION FLOW: GUIDING THE ROUTE* Press the “APPS” button. There are different kinds of meth- ods to search for a destination. (P.281) Select “Go”. Select “Navigation”. Select “OK”. Select “Dest.”. Selecting routes other than the one recom- mended.
Page 27: Setting Home As The Destination
3. NAVIGATION OPERATION 4. SETTING HOME AS THE DESTINATION* Press the “APPS” button. Select “OK”. Selecting routes other than the one recom- mended. (P.293) Guidance to the destination is displayed on the screen and can be heard via voice guidance. Select “Navigation”.
Page 28: Function Index
4. FUNCTION INDEX 1. FUNCTION INDEX Map* Displaying maps Page Viewing the map screen Displaying the current position Viewing the current position vicinity map Changing the scale Changing the map orientation Displaying map information Displaying the estimated travel/arrival time to the destination Selecting the map mode Displaying traffic information Searching for destinations...
Page 29 4. FUNCTION INDEX Useful functions Information Page Displaying vehicle maintenance* Hands-free system (for cellular phone) Page ® Registering/connecting Bluetooth phone ® Making a call on a Bluetooth phone ® Receiving a call on the Bluetooth phone Voice command system Page Operating the system with your voice Peripheral monitoring system Page...
Page 30 RAV4_Navi+MM_OM42A43U_(U) 15.08.12 17:29...
Page 31: Basic Function
BASIC FUNCTION ® BASIC INFORMATION BEFORE Bluetooth SETTINGS OPERATION 1. REGISTERING/CONNECTING ® 1. INITIAL SCREEN ......32 Bluetooth DEVICE ....43 ® REGISTERING A Bluetooth 2. TOUCH SCREEN GESTURES ..34 PHONE FOR THE FIRST TIME ..43 ® REGISTERING A Bluetooth AUDIO 3.
Page 32: Basic Information Before Operation
1. BASIC INFORMATION BEFORE OPERATION 1. INITIAL SCREEN When the engine switch is in the “ACC” MAINTENANCE or “ON” position, the initial screen will INFORMATION* be displayed and the system will begin operating. (Vehicles without a smart This system reminds users when to re- key system) place certain parts or components and When the engine <power>...
Page 33 1. BASIC INFORMATION BEFORE OPERATION RESTARTING THE SYSTEM When system response is extremely slow, the system can be restarted. Press and hold the “PWR VOL” knob for 3 seconds or more. Entune Audio Plus Entune Premium Audio RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 34: Touch Screen Gestures
1. BASIC INFORMATION BEFORE OPERATION 2. TOUCH SCREEN GESTURES Operations are performed by touching the touch screen directly with your finger. Operation method Outline Main use Touch Changing and selecting various set- Quickly touch and release tings once. Drag* Touch the screen with ...
Page 35: Touch Screen Operation
1. BASIC INFORMATION BEFORE OPERATION 3. TOUCH SCREEN OPERATION This system is operated mainly by the INFORMATION buttons on the screen. (Referred to as ● If the system does not respond to touch- screen buttons in this manual.) ing a screen button, move your finger away from the screen and then touch it ...
Page 36: Home Screen Operation
1. BASIC INFORMATION BEFORE OPERATION 4. HOME SCREEN OPERATION The home screen can display multiple CUSTOMIZING THE HOME information screens, such as the audio SCREEN system screen and hands-free screen, The display items/area on the home simultaneously. screen can be changed. Press the “HOME”...
Page 37: Entering Letters And Numbers/List Screen Operation
1. BASIC INFORMATION BEFORE OPERATION 5. ENTERING LETTERS AND NUMBERS/LIST SCREEN OPERATION When searching by an address, name, LIST SCREEN etc., or entering data, letters and num- bers can be entered via the screen. The list screen may be displayed after entering characters.
Page 38 1. BASIC INFORMATION BEFORE OPERATION LIST SCREEN OPERATION INFORMATION ● The number of matching items is shown When a list is displayed, use the appro- on the right side of the screen. If the priate screen button to scroll through number of matching items is more than the list.
Page 39 1. BASIC INFORMATION BEFORE OPERATION SORTING CHARACTER JUMP BUTTONS IN LISTS The order of a list displayed on the screen can be sorted in the order of Some lists contain character screen distance from the current location, buttons, “ABC”, “DEF” etc., which al- date, category, etc.
Page 40: Screen Adjustment
1. BASIC INFORMATION BEFORE OPERATION 6. SCREEN ADJUSTMENT The contrast and brightness of the Function Page screen display and the image of the Select to adjust the screen camera display can be adjusted. The display. screen can also be changed to either day or night mode.
Page 41 1. BASIC INFORMATION BEFORE OPERATION ADJUSTING THE CONTRAST/ Screen button Function BRIGHTNESS Select to brighten the “Brightness” “+” screen. The contrast and brightness of the screen can be adjusted according to Select to darken the “Brightness” “-” screen. the brightness of your surroundings. Select to strengthen the Select “General”...
Page 42: System
1. BASIC INFORMATION BEFORE OPERATION 7. LINKING MULTI-INFORMATION DISPLAY AND NAVIGATION SYSTEM* The following functions of the navigation system are linked with the multi-informa- tion display in the instrument cluster: • Navigation • Audio etc. These functions can be operated using multi-information display control switches on the steering wheel.
Page 43: Bluetooth ® Settings
® 2. Bluetooth SETTINGS ® 1. REGISTERING/CONNECTING Bluetooth DEVICE ® Select “Phone”. REGISTERING A Bluetooth  Operations up to this point can also be PHONE FOR THE FIRST TIME performed by pressing the switch on To use the hands-free system, it is the steering wheel or switch on the ®...
Page 44: Registering A Bluetooth Audio Player For The First Time
® 2. Bluetooth SETTINGS ® ® Register the Bluetooth device using REGISTERING A Bluetooth ® your Bluetooth device. AUDIO PLAYER FOR THE  A PIN-code is not required for SSP FIRST TIME (Secure Simple Pairing) compatible ® Bluetooth devices. Depending on the ®...
Page 45 ® 2. Bluetooth SETTINGS Press the “AUDIO” button. Entune Audio Plus Entune Premium Audio Select “Source” on the audio screen or press “AUDIO” button again. Select “ Audio”. Select “Yes” to register an audio play- Follow the steps in “REGISTERING A ®...
Page 46: Profiles
® ● If the connected Bluetooth device version is older than recommended or incompatible, ® the Bluetooth device function may not work properly. ® ● Refer to http://www.toyota.com/entune/ to find approved Bluetooth phones for this sys- tem. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 47 ® 2. Bluetooth SETTINGS ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Fujitsu Ten Limited is under license. Other trademarks and trade names are those of their respective owners. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 48: Setting Bluetooth ® Details
® 2. Bluetooth SETTINGS ® 2. SETTING Bluetooth DETAILS Press the “APPS” button. “Bluetooth* Setup” SCREEN Entune Audio Plus Function Page ® Registering a Bluetooth device Entune Premium Audio ® Deleting a Bluetooth device ® Connecting a Bluetooth device ® Editing the Bluetooth device infor- mation...
Page 49: Registering A Bluetooth Device
® 2. Bluetooth SETTINGS ® DISPLAYING THE “Bluetooth* REGISTERING A Bluetooth Setup” SCREEN IN A DEVICE DIFFERENT WAY ® From Up to 5 Bluetooth devices can be reg- phone/message settings screen istered. ® Press the “APPS” button. Bluetooth compatible phones (HFP) and audio players (AVP) can be regis- Select “Setup”.
Page 50: Deleting A Bluetooth ® Device
® 2. Bluetooth SETTINGS ®  For details about operating the Bluetooth ® DELETING A Bluetooth device, see the manual that comes with it. DEVICE  To cancel the registration, select “Can- cel”. Display the “Bluetooth* Setup” screen. ® Register the Bluetooth device using (P.48) ®...
Page 51: Connecting A Bluetooth ® Device
® 2. Bluetooth SETTINGS ® Select the desired connection. CONNECTING A Bluetooth ® When another Bluetooth DEVICE device is con- nected ® ®  To disconnect the Bluetooth device, Up to 5 Bluetooth devices (Phones select “Yes”. (HFP) and audio players (AVP)) can be registered.
Page 52 ® 2. Bluetooth SETTINGS ■ ■ ® AUTO CONNECTION MODE RECONNECTING THE Bluetooth PHONE To turn auto connection mode on, set “Bluetooth* Power” to on. (P.54) ® If a Bluetooth phone is disconnected ® Leave the Bluetooth device in a loca- due to poor reception from the tion where the connection can be es- ®...
Page 53: Editing The Bluetooth Device Information
® 2. Bluetooth SETTINGS ® EDITING THE Bluetooth Information DEVICE INFORMATION ® The name of the Bluetooth device. Can be changed to a desired name. (P.54) ® The Bluetooth device’s information can be displayed on the screen. The ® Select to set the Bluetooth audio displayed information can be edited.
Page 54: System Settings" Screen
® 2. Bluetooth SETTINGS CHANGING A DEVICE NAME “System Settings” SCREEN Select “Device Name”. ® The Bluetooth settings can be con- Enter the name and select “OK”. firmed and changed. Display the “Bluetooth* Setup” screen. INFORMATION (P.48) ● Even if the device name is changed, the ®...
Page 55 ® 2. Bluetooth SETTINGS Vehicles without a smart key system Information Page ® The Bluetooth device is automatically ® Select to set Bluetooth connected when the engine switch is connection on/off. turned to the “ACC” or “ON” position. Vehicles with a smart key system Displays system name.
Page 56: Other Settings
3. OTHER SETTINGS 1. GENERAL SETTINGS Settings are available for system time, GENERAL SETTINGS operation sounds, etc. SCREEN Press the “APPS” button. Entune Audio Plus Entune Premium Audio Select “Setup”. Select “General”. Select the items to be set. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 57 Select to delete personal data. for distance/fuel consumption. (P.62) Select to change the unit of weather Select to update software versions. temperature. For details, contact your Toyota dealer. Select to set the sound beeps on/off. ® Select to update “Gracenote ” data- Select to change the screen button base versions.
Page 58 3. OTHER SETTINGS ■ SETTING THE TIME ZONE CLOCK SETTINGS Select “Time Zone”. Used for changing time zones and the settings of daylight saving time, and Select the desired time zone. the on/off settings of automatic adjust- ment of the clock by GPS can be changed.
Page 59 3. OTHER SETTINGS ■ MANUAL CLOCK SETTING CUSTOMIZING THE STARTUP AND SCREEN OFF IMAGES When “Auto Adjust by GPS” is turned off, the clock can be manually An image can be copied from a USB adjusted. memory and used as the startup and screen off images.
Page 60 3. OTHER SETTINGS ■ TRANSFERRING IMAGES INFORMATION ● Open the cover and connect a USB When saving the images to a USB, name the folder that the startup image is memory. saved to “StartupImage” and name the folder that the screen off image is saved to “DisplayOffImage”.
Page 61 3. OTHER SETTINGS ■ ■ SETTING THE STARTUP IMAGES DELETING TRANSFERRED IMAG- Display the “General Settings” screen. Display the “General Settings” screen. (P.56) (P.56) Select “Customize Startup Image”. Select “Customize Startup Image” or Select the desired image. “Customize Screen Off Image”. Select “Delete All”.
Page 62 3. OTHER SETTINGS DELETING PERSONAL DATA NOTICE Display the “General Settings” screen. ● Entune Premium Audio: Make sure the (P.56) map SD card is inserted when deleting personal data. The personal data cannot Select “Delete Personal Data”. be deleted when the map microSD card is removed.
Page 63: Voice Settings
3. OTHER SETTINGS 2. VOICE SETTINGS Voice volume, etc. can be set. VOICE SETTINGS SCREEN Press the “APPS” button. Entune Audio Plus Entune Premium Audio Function Select to adjust the volume of voice guidance. Select to set the voice guidance dur- ing route guidance on/off.
Page 64 3. OTHER SETTINGS Function Select to set the voice recognition tutorial. Select to reset all setup items. *: Entune Premium Audio only RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 65: Driver Settings
3. OTHER SETTINGS 3. DRIVER SETTINGS The driver settings feature will allow MANUALLY SELECT LINKED the system to link some preferences SETTINGS (such as audio presets, button colors, ® language, etc.) to a paired Bluetooth Display the driver settings screen. phone.
Page 66: Maintenance
3. OTHER SETTINGS 4. MAINTENANCE* When this system is turned on, the Function “Maintenance Reminder” screen dis- Select to set the condition of parts or plays when it is time to replace a part components. or certain components. (P.32) Select to add new information items Press the “APPS”...
Page 67 3. OTHER SETTINGS MAINTENANCE INFORMATION INFORMATION SETTING ● For scheduled maintenance information, refer to “Scheduled Maintenance Guide” Select the desired part or component or “Owner’s Manual Supplement”. screen button. ● Depending on driving or road conditions,  When the vehicle needs to be serviced, the actual date and distance that main- tenance should be performed may differ the screen button color will change to...
Page 68 3. OTHER SETTINGS ■ EDITING DEALER OR CONTACT Select the items to be edited. NAME Select “Edit” next to “Dealer” or “Con- tact”. Enter the name and select “OK”. ■ EDITING THE LOCATION Select “Edit” next to “Location”. Function Page Scroll the map to the desired point (P.272) and select “OK”.
Page 69 3. OTHER SETTINGS RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 70: Audio System
AUDIO SYSTEM BASIC OPERATION RADIO OPERATION 1. QUICK REFERENCE ..... 72 1. AM/FM RADIO....... 80 OVERVIEW ..........80 2. SOME BASICS....... 74 PRESETTING A STATION ....84 TURNING THE SYSTEM SELECTING A STATION ON AND OFF ........75 FROM THE LIST ......... 84 SELECTING AN AUDIO SOURCE..
Page 71 AUDIO SYSTEM MEDIA OPERATION AUDIO REMOTE CONTROLS 1. CD ..........99 1. STEERING SWITCHES....121 OVERVIEW ........... 99 PLAYING AN AUDIO CD ....102 SETUP PLAYING AN MP3/WMA/AAC DISC ... 102 1. AUDIO SETTINGS ...... 124 2. USB MEMORY......103 AUDIO SETTINGS SCREEN....
Page 72: Basic Operation
1. BASIC OPERATION 1. QUICK REFERENCE Press the “AUDIO” button to display the audio screen. Entune Audio Plus Entune Premium Audio RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 73 1. BASIC OPERATION Function Page Using the radio 80, 91, 98 Playing an audio CD or MP3/WMA/AAC disc* Playing a USB memory Playing an iPod ® Playing a Bluetooth device Using the AUX port Using the steering wheel audio switches Audio system settings INFORMATION ●...
Page 74: Some Basics
1. BASIC OPERATION 2. SOME BASICS This section describes some of the ba- WARNING sic features of the audio system. Some ● information may not pertain to your For vehicles sold in U.S.A.: system. Part 15 of the FCC Rules WARNING: Changes Vehicles without a smart key system...
Page 75: Turning The System On And Off
1. BASIC OPERATION TURNING THE SYSTEM ON SELECTING AN AUDIO AND OFF SOURCE Entune Audio Plus Press the “AUDIO” button. Entune Audio Plus Entune Premium Audio Entune Premium Audio “PWR•VOL” knob: Press to turn the audio system on and off. The system turns on in Select “Source”...
Page 76: Disc Slot
1. BASIC OPERATION DISC SLOT* INFORMATION ● Dimmed screen buttons cannot be oper- ated. INSERTING A DISC ● When there are two pages, select Insert a disc into the disc slot. to change the page. REORDERING THE AUDIO SOURCE Display the “Select Audio Source” screen.
Page 77: Usb/Aux Port
1. BASIC OPERATION SOUND SETTINGS INFORMATION ● The player is intended for use with 4.7 in. (12 cm) discs only. AUTOMATIC SOUND ● When inserting a disc, gently insert the LEVELIZER (ASL) disc with the label facing up. The system adjusts to the optimum vol- ume and tone quality according to ve- USB/AUX PORT hicle...
Page 78 1. BASIC OPERATION Select “Sound” on the audio control TONE AND BALANCE screen. TONE: Select the desired screen button. How good an audio program sounds is largely determined by the mix of the treble, mid and bass levels. In fact, dif- ferent kinds of music and vocal pro- grams usually sound better with different mixes of treble, mid and bass.
Page 79: Voice Command System
1. BASIC OPERATION VOICE COMMAND SYSTEM Press this switch to operate the voice command system.  The voice command system and its list commands operated. (P.138) RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 80: Radio Operation
2. RADIO OPERATION 1. AM/FM RADIO OVERVIEW Select “AM” or “FM” on the “Select Audio Source” screen. (P.75) ■ CONTROL SCREEN Entune Audio Plus Top screen Option screen RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 81 2. RADIO OPERATION Entune Premium Audio Top screen Option screen ■ CONTROL PANEL Entune Audio Plus RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 82 2. RADIO OPERATION Entune Premium Audio Function Select to scroll the page of preset buttons. Select to display the option screen. Select to display the audio source selection screen. Select to display the sound setting screen. Select to display a list of receivable stations/channels. Select to scan for receivable stations/channels.
Page 83 2. RADIO OPERATION Function  Turn to step up/down frequencies.  Turn to move up/down the list. Also, the knob can be used to enter selections on the list screens by pressing it.  Press to seek for a station/channel. ...
Page 84: Presetting A Station
2. RADIO OPERATION PRESETTING A STATION SELECTING A STATION FROM THE LIST Radio mode has a mix preset function, which can store up to 36 stations (6 A station list can be displayed. stations per page x 6 pages) from any Select “Station List”.
Page 85: Caching A Radio Program
2. RADIO OPERATION ■ REFRESHING THE STATION LIST CACHING A RADIO PROGRAM* Select “Refresh” on the station list screen and the following screen will be displayed. A radio program can be cached and played back in a time-shifted manner. PLAYING BACK THE CACHE MANUALLY The broadcast cached in the program cache can be played back manually.
Page 86: Radio Broadcast Data System
2. RADIO OPERATION AUTOMATIC PLAYBACK OF RADIO BROADCAST DATA THE CACHE SYSTEM If the radio broadcast is interrupted by This audio system is equipped with Ra- another audio output, such as an dio Broadcast Data Systems (RBDS). incoming phone call, the system will RBDS mode allows text messages to automatically cache the interrupted be received from radio stations that uti-...
Page 87: Traffic Announcement (Fm Radio)
2. RADIO OPERATION SELECTING A DESIRED TRAFFIC ANNOUNCEMENT GENRE (FM RADIO) Select “Station List”. A station that regularly broadcasts traf- FM radio only: Select a desired genre fic information is automatically located. of station and select a desired station. Select “Station List”. ...
Page 88: Using Hd Radio™ Technology
2. RADIO OPERATION AVAILABLE HD Radio ™ USING HD Radio ™ TECHNOLOGY TECHNOLOGY HD Radio ™ Technology is the digital MULTICAST evolution of analog AM/FM radio. Your radio product has a special receiver On the FM radio frequency most digital which allows it to receive digital stations have “multiple”...
Page 89 2. RADIO OPERATION PRESERVING A MUSIC INFORMATION INFORMATION ● The tag information can not be pre- served while scanning or caching the Tag information in the music broad- radio station. casting is preserved in the system and ● If tagging the music information fails, transmits to an iPod.
Page 90: Troubleshooting Guide
2. RADIO OPERATION TROUBLESHOOTING GUIDE Experience Cause Action Mismatch of time align- The radio stations analog ment- a user may hear a and digital volume is not None, radio broadcast issue. A short period of program- properly aligned or the sta- user can contact the radio station.
Page 91: Xm Satellite Radio
2. RADIO OPERATION 2. XM Satellite Radio* OVERVIEW Select “XM” on the “Select Audio Source” screen. (P.75) ■ CONTROL SCREEN ■ CONTROL PANEL Entune Audio Plus *: If equipped RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 92 2. RADIO OPERATION Entune Premium Audio Function Select to scroll the page of preset buttons. Select to display the option screen.  Select to scan for receivable channels.  Select “Additional Information” to display the information. Select to display the audio source selection screen. Select to display the sound setting screen.
Page 93: How To Subscribe To An Xm Satellite Radio
2. RADIO OPERATION HOW TO SUBSCRIBE TO AN NOTICE XM Satellite Radio XM Radio Services  Legal Disclaimers ● and Warnings To listen to a satellite radio broadcast • Fees and Taxes  Subscription fee, in the vehicle, a subscription to the XM taxes, one time activation fee, and Satellite Radio service is necessary.
Page 94 2. RADIO OPERATION NOTICE INFORMATION ● Radio ServicesSubscription ● It is prohibited to copy, decompile, disas- Instructions semble, reverse engineer, hack, manip- • For XM Services requiring a subscrip- ulate, or otherwise make available any tion (such as XM Radio, and some technology or software incorporated in Infotainment &...
Page 95: Displaying The Radio Id
PRESETTING A CHANNEL SATELLITE TUNER TECHNOLOGY NOTICE Tune in the desired channel. Toyota’s satellite radio tuners are Select “(add new)”. awarded Type Approval Certificates from XM Satellite Radio Inc. as proof of compatibility with the services offered by XM Satellite Radio.
Page 96: Selecting A Channel From The List
2. RADIO OPERATION SELECTING A CHANNEL FROM THE LIST Select “Channel List”. Select the desired program genre. Select the desired channel and select “OK”. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 97: If The Satellite Radio Tuner Malfunctions
“Check Antenna” A short circuit occurs in the antenna or the surrounding antenna ca- ble. See a Toyota certified dealer for assistance. You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryption code. Contact XM Satellite Radio for subscription information.
Page 98: Internet Radio
Select the internet radio application. steering wheel. ● For additional information, refer to http://www.toyota.com/entune/ or call 1-800-331-4331.  The internet radio application screen is displayed.  Perform operations according to the dis- played application screen.
Page 99: Media Operation
3. MEDIA OPERATION 1. CD* OVERVIEW The CD operation screen can be reached by the following methods: Insert a disc. (P.76) Select “CD” on the “Select Audio Source” screen. (P.75) ■ CONTROL SCREEN *: Entune Audio Plus RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 100 3. MEDIA OPERATION ■ CONTROL PANEL RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 101 3. MEDIA OPERATION Function  Displays cover art  Select to display a track/file list. Select to display the audio source selection screen. Select to display the sound setting screen. Select to play/pause. Shows progress Select to set repeat playback. Select to set random playback.
Page 102: Playing An Audio Cd
3. MEDIA OPERATION PLAYING AN AUDIO CD PLAYING AN MP3/WMA/AAC DISC REPEATING REPEATING The track currently being listened to can be repeated. The file currently being listened to can be repeated. Select the repeat button to change on/ off. Select the repeat button to change on/ off.
Page 103: Usb Memory
3. MEDIA OPERATION 2. USB MEMORY OVERVIEW The USB memory operation screen can be reached by the following methods: Connect a USB memory. (P.77) Select “USB (DEVICE NAME)” on the “Select Audio Source” screen. (P.75) ■ CONTROL SCREEN RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 104 3. MEDIA OPERATION ■ CONTROL PANEL Entune Audio Plus Entune Premium Audio RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 105 3. MEDIA OPERATION Function Select to display the audio source selection screen. Select to display the sound setting screen. Select to play/pause. Shows progress Select to set repeat playback. Select to set random playback. Select to display the play mode selection screen. To return to the top screen, select “Now Playing”...
Page 106 3. MEDIA OPERATION WARNING ● Do not operate the player’s controls or connect the USB memory while driving. NOTICE ● Do not leave your portable player in the car. In particular, high temperatures inside the vehicle may damage the portable player. ●...
Page 107: Playing A Usb Audio
3. MEDIA OPERATION PLAYING A USB AUDIO REPEATING The file/track currently being listened to can be repeated. Select the repeat button to change on/ off. RANDOM ORDER Files/tracks can be automatically and randomly selected. Select the random button to change on/off.
Page 108: Ipod
3. MEDIA OPERATION 3. iPod OVERVIEW The iPod operation screen can be reached by the following methods: Connect an iPod. (P.77) Select “iPod (DEVICE NAME)” on the “Select Audio Source” screen. (P.75) When the iPod connected to the system includes iPod video, the system can only output the sound by selecting the browse screen.
Page 109 3. MEDIA OPERATION ■ CONTROL PANEL Entune Audio Plus Entune Premium Audio RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 110 3. MEDIA OPERATION Function  Displays cover art  Select to display a track list. Select to display the audio source selection screen. Select to display the sound setting screen. Select to play/pause. Shows progress Select to set repeat playback. Select to set random playback.
Page 111 Files/tracks selected by operating a connected iPod may not be recognized or displayed properly. ● ® If an iPhone is connected via Bluetooth and USB at the same time, system operation may become unstable. For known phone compatibility information, refer to http://www.toyota.com/entune/. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 112: Ipod Audio
3. MEDIA OPERATION iPod AUDIO iPod VIDEO To change to iPod video mode, select REPEATING “Browse” on the iPod audio screen, then select the “Videos” tab and se- The track currently being listened to lect the desired video file. can be repeated. The system can only output the iPod Select the repeat button to change on/ video sound.
Page 113: Bluetooth ® Audio
3. MEDIA OPERATION ® 4. Bluetooth AUDIO ® The Bluetooth audio system enables users to enjoy listening to music that is played on a portable player on the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing ®...
Page 114 3. MEDIA OPERATION ■ CONTROL PANEL Entune Audio Plus Entune Premium Audio RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 115 3. MEDIA OPERATION Function Select to display the audio source selection screen. ® Displays Bluetooth device condition. Select to display the sound settings screen. Select to play/pause. Shows progress Select to set repeat playback. Select to set random playback. Select to display the playlist screen. To return to the top screen, select “Now Playing”...
Page 116 3. MEDIA OPERATION WARNING ● ® Do not operate the player’s controls or connect to the Bluetooth audio system while driv- ing. ● ® Your audio unit is fitted with Bluetooth antennas. People with implantable cardiac pace- makers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators should maintain a reasonable distance between themselves and the ®...
Page 117 3. MEDIA OPERATION INFORMATION ● ® Depending on the Bluetooth device that is connected to the system, the music may start playing when selecting while it is paused. Conversely, the music may pause when selecting while it is playing. ● In the following conditions, the system may not function: ®...
Page 118: Connecting A Bluetooth Device
3. MEDIA OPERATION ® ® CONNECTING A Bluetooth LISTENING TO Bluetooth DEVICE AUDIO ® To use the Bluetooth audio system, it REPEATING ® is necessary to register a Bluetooth The track currently being listened to device with the system. can be repeated. Registering an additional device Select the repeat button to change on/ Select...
Page 119: Aux
3. MEDIA OPERATION 5. AUX OVERVIEW Select “AUX” on the “Select Audio Source” screen. (P.75) ■ CONTROL SCREEN ■ CONTROL PANEL Entune Audio Plus RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 120 3. MEDIA OPERATION Entune Premium Audio Function Select to display the audio source selection screen. Select to display the sound setting screen. Press to turn mute on/off. Press to select an audio mode.  Turn to adjust volume.  Press to turn the audio system on/off. ...
Page 121: Audio Remote Controls
4. AUDIO REMOTE CONTROLS 1. STEERING SWITCHES Some parts of the audio system can be adjusted using the switches on the steering wheel. Switch Volume control switch “ ” switch “MODE/HOLD” switch Volume control switch Mode Operation Function Press Volume up/down Press and hold Volume up/down continuously RAV4_Navi+MM_OM42A43U_(U)
Page 122 4. AUDIO REMOTE CONTROLS “ ” switch Mode Operation Function Press Preset station/channel up/down AM/FM Radio Seek up/down continuously while the switch is being Press and hold pressed Press Preset channel up/down Seek up/down continuously while the switch is being Press and hold pressed Press...
Page 123 4. AUDIO REMOTE CONTROLS “MODE/HOLD” switch Mode Operation Function Press Change audio modes AM, FM, , AUX Press and hold Mute (Press and hold again to resume the sound.) Press Change audio modes Audio CD* MP3/WMA/ AAC disc* USB, iPod, Press and hold Pause (Press and hold again to resume the playmode.) BT audio,...
Page 124: Setup
5. SETUP 1. AUDIO SETTINGS Detailed audio settings can be pro- AUDIO SETTINGS SCREEN grammed. Press the “APPS” button. Entune Audio Plus Function Page Select to change the num- ber of preset radio sta- tions/channels displayed on the screen. Entune Premium Audio Select to set cover art set- ...
Page 125 5. SETUP SETTING THE NUMBER OF RADIO PRESETS Display the “Audio Settings” screen. (P.124) Select “Number of Radio Presets”. Select the button with the desired num- ber to be displayed. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 126: Tips For Operating The Audio System
6. TIPS FOR OPERATING THE AUDIO SYSTEM 1. OPERATING INFORMATION NOTICE Fading and drifting stations: Generally, the ● To avoid damage to the audio system: effective range of FM is about 25 miles (40 • Be careful not to spill beverages over km).
Page 127: Cd Player And Disc
6. TIPS FOR OPERATING THE AUDIO SYSTEM CD PLAYER AND DISC Fading: AM broadcasts are reflected by  This CD player is intended for use with 4.7 the upper atmosphere — especially at in. (12 cm). discs only. night. These reflected signals can interfere ...
Page 128 6. TIPS FOR OPERATING THE AUDIO SYSTEM Special shaped discs NOTICE ● Do not use special shaped, transparent/ translucent, low quality or labeled discs such as those shown in the illustrations. The use of such discs may damage the player, or it may be impossible to eject the disc.
Page 129: Ipod
6. TIPS FOR OPERATING THE AUDIO SYSTEM iPod  “Made for iPod” and “Made for iPhone” mean that an electronic accessory has To clean a disc: Wipe it with a soft, lint- been designed to connect specifically to free cloth that has been dampened with iPod or iPhone respectively, and has been water.
Page 130: File Information
6. TIPS FOR OPERATING THE AUDIO SYSTEM COMPATIBLE MODELS FILE INFORMATION ® ® The following iPod , iPod nano , iPod ■ COMPATIBLE USB DEVICES ® ® ® classic , iPod touch and iPhone devic- es can be used with this system. USB 2.0 HS (480 communication Made for...
Page 131 6. TIPS FOR OPERATING THE AUDIO SYSTEM ■  MP3 (MPEG Audio Layer 3), WMA CORRESPONDING SAMPLING (Windows Media Audio) FREQUENCY (Advanced Audio Coding) are audio com- pression standards. File type Frequency (kHz)  This system can play MP3/WMA/AAC files on CD-R, CD-RW discs and USB memory.
Page 132 6. TIPS FOR OPERATING THE AUDIO SYSTEM Entune Audio Plus Entune Premium Audio  This system can play disc recordings com-  MP3 files are compatible with the ID3 Tag patible with ISO 9660 level 1 and level 2 Ver. 1.0, Ver. 1.1, Ver. 2.2 and Ver. 2.3 for- and with the Romeo and Joliet file system.
Page 133: Terms
6. TIPS FOR OPERATING THE AUDIO SYSTEM ISO 9660 FORMAT TERMS  This is the international standard for the formatting of CD-ROM folders and files. PACKET WRITE For the ISO 9660 format, there are 2 lev- els of regulations.  This is a general term that describes the ...
Page 134 6. TIPS FOR OPERATING THE AUDIO SYSTEM  WMA (Windows Media Audio) is an audio compression format developed ® Microsoft . It compresses files into a size smaller than that of MP3 files. The decod- ing formats for WMA files are Ver. 7, 8 and ...
Page 135: Error Messages
6. TIPS FOR OPERATING THE AUDIO SYSTEM ERROR MESSAGES Mode Message Explanation This indicates that no MP3/WMA/AAC files are “No music files found.” included in the disc. It indicates that the disc is dirty, damaged, or it was inserted upside down. Clean the disc or in- “Check disc”...
Page 136 6. TIPS FOR OPERATING THE AUDIO SYSTEM INFORMATION ● If the malfunction is not rectified: Take your vehicle to your Toyota dealer. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 137 VOICE COMMAND SYSTEM VOICE COMMAND SYSTEM OPERATION 1. VOICE COMMAND SYSTEM ..138 USING THE VOICE COMMAND SYSTEM..........138 VOICE COMMAND SYSTEM OPERATION ........139 2. CASUAL SPEECH RECOGNIZATION..... 145 3. COMMAND LIST ......146 MOBILE ASSISTANT OPERATION 1. MOBILE ASSISTANT....149 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 138: Voice Command System Operation
1. VOICE COMMAND SYSTEM OPERATION 1. VOICE COMMAND SYSTEM The voice command system enables MICROPHONE the audio, hands-free systems, etc. to be operated using voice commands. Refer to the command list for samples of voice commands. (P.146) USING THE VOICE COMMAND SYSTEM STEERING SWITCH ...
Page 139: Voice Command System Operation
1. VOICE COMMAND SYSTEM OPERATION VOICE COMMAND SYSTEM INFORMATION OPERATION ● The voice command system can be operated while guidance is being spo- ken, when “Voice Prompt Interrupt” The voice command system is operat- (P.63) is set to on. (It is not necessary ed by selecting a tab corresponding to to wait for the confirmation beep before each function.
Page 140 1. VOICE COMMAND SYSTEM OPERATION Say the tab selection command or se-  Selecting “Help” or saying “Help” lect the desired tab. prompts voice guidance to offer exam- ples of commands and operation meth- ods. Say the command displayed on the screen.
Page 141 1. VOICE COMMAND SYSTEM OPERATION ■ DISPLAYING THE “Voice Settings” VOICE COMMAND EXAMPLE: SCREENS LAUNCH Entune App Suite APPLICATION* Press the talk switch. Say “Launch <application name>”.  Entune App Suite application screen is displayed. VOICE COMMAND EXAMPLE:  Selecting “Voice Settings” can be dis- PERFORMING A DESTINATION played “Voice...
Page 142 1. VOICE COMMAND SYSTEM OPERATION VOICE COMMAND EXAMPLE: INFORMATION SEARCH FOR A SONG ● The voice command recognition is designed to recognize the main body of Press the talk switch. the official street name. For example: if the official street name is Say “Play song <name>”.
Page 143 1. VOICE COMMAND SYSTEM OPERATION VOICE COMMAND EXAMPLE: INFORMATION CALL NAME ● In the same manner as it is displayed on the screen, “Call <contacts> <phone Press the talk switch. types>”, after saying “Call a contact” say the name, or the name and type of “Call <contacts>...
Page 144 1. VOICE COMMAND SYSTEM OPERATION VOICE COMMAND EXAMPLE: or press the switch on “Call” DIAL NUMBER the steering wheel. Press the talk switch.  When the system recognizes multiple phone numbers, a phone number candi- Say the phone number. date list will be displayed on the screen. ...
Page 145: Casual Speech Recognization
1. VOICE COMMAND SYSTEM OPERATION 2. CASUAL SPEECH RECOGNIZATION Due to natural language speech recog- EXPRESSION EXAMPLES FOR nition technology, this system enables EACH FUNCTION recognition of a command when spo- ken naturally. However, the system Command Expression examples cannot recognize every variation of Navigate to my house.
Page 146: Command List
1. VOICE COMMAND SYSTEM OPERATION 3. COMMAND LIST Recognizable voice commands and their actions are shown below.  Frequently used commands are listed in the following tables.  For devices that are not installed in the vehicle, the related commands will not be dis- played in the screen.
Page 147 1. VOICE COMMAND SYSTEM OPERATION Navigation* Command Action Displays a list of <POI category > near the current posi- “Find Nearby <POI category>” tion “Enter an Address” Enables setting a destination by saying the address “Go Home” Displays the route to home “Cancel Route”...
Page 148 1. VOICE COMMAND SYSTEM OPERATION Info* Command Action “Show Forecast” Displays weather information “Show Traffic” Displays traffic information *: Available models and available country and areas (P.152, 154) RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 149: Mobile Assistant Operation
2. MOBILE ASSISTANT OPERATION 1. MOBILE ASSISTANT The Mobile Assistant feature will  The volume of the Mobile Assistant can ® be adjusted using the “PWR VOL” activate Apple’s Siri Eyes Free mode knob or steering wheel volume control via the steering wheel switches. To switches.
Page 150 2. MOBILE ASSISTANT OPERATION MICROPHONE It is not necessary to speak directly into the microphone when using the Mobile Assistant. (Microphone location: P.138) INFORMATION ● Wait for the listening beeps before using the Mobile Assistant. ● The Mobile Assistant may not recognize commands in the following situations: •...
Page 151: Information
INFORMATION USEFUL INFORMATION 1. RECEIVING WEATHER INFORMATION ......152 DISPLAYING WEATHER INFORMATION ......... 152 2. RECEIVING TRAFFIC MAP INFORMATION ......154 DISPLAYING TRAFFIC MAP INFORMATION ......... 154 3. DATA SERVICES SETTINGS..155 SETTING DOWNLOAD METHODS ..155 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 152: Useful Information
1. USEFUL INFORMATION 1. RECEIVING WEATHER INFORMATION Entune Premium Audio Entune Audio Plus Weather information can be received via the HD Radio. Entune Premium Audio Weather information can be received via the HD Radio or by the Entune App ® Suite application on a Bluetooth phone.
Page 153 1. USEFUL INFORMATION DISPLAYING THE WEATHER Function OF THE CURRENT LOCATION Select to display weather informa- tion over the map. Display “Weather” screen. (P.152) *: Entune Premium Audio only Select “Current Weather”. INFORMATION Select the desired tab to be displayed. ●...
Page 154: Receiving Traffic Map Information
1. USEFUL INFORMATION 2. RECEIVING TRAFFIC MAP INFORMATION* Check that the “Traffic Map” screen is Traffic map information can be re- displayed. ceived via the HD Radio. DISPLAYING TRAFFIC MAP INFORMATION Press the “APPS” button. Function Current position of your car Traffic information line The line color means the following: Red: Heavy congestion...
Page 155: Data Services Settings
1. USEFUL INFORMATION 3. DATA SERVICES SETTINGS* Select the desired item to be set. SETTING DOWNLOAD METHODS Data service information, which is comprised of traffic information and weather information, can be received via the HD Radio and by the Entune ®...
Page 156: Peripheral Monitoring System
PERIPHERAL MONITORING SYSTEM REAR VIEW MONITOR TOYOTA PARKING ASSIST SYSTEM MONITOR 1. REAR VIEW MONITOR 1. TOYOTA PARKING ASSIST SYSTEM........158 MONITOR ........168 REAR VIEW MONITOR SYSTEM ..158 TOYOTA PARKING ASSIST MONITOR.......... 168 DRIVING PRECAUTIONS ....158 DRIVING PRECAUTIONS ....168 SCREEN DESCRIPTION ....
Page 157 PERIPHERAL MONITORING SYSTEM 6. PANORAMIC VIEW MONITOR PANORAMIC VIEW MONITOR PRECAUTIONS......205 AREA DISPLAYED ON SCREEN..205 1. PANORAMIC VIEW THE CAMERA ........208 MONITOR ........184 DIFFERENCES BETWEEN THE DRIVING PRECAUTIONS....184 SCREEN AND THE ACTUAL CAMERA SWITCH ......187 ROAD ..........
Page 158: Rear View Monitor
1. REAR VIEW MONITOR SYSTEM 1. REAR VIEW MONITOR SYSTEM* REAR VIEW MONITOR DRIVING PRECAUTIONS SYSTEM The rear view monitor system is a sup- plemental device intended to assist the The rear view monitor system assists driver when backing up. When backing the driver by displaying an image of the up, be sure to visually check all around view behind the vehicle with fixed...
Page 159 1. REAR VIEW MONITOR SYSTEM WARNING WARNING ● ● Never depend on the rear view monitor Do not use the rear view monitor system system entirely when backing up. The in the following cases: image and the position of the guide lines •...
Page 160: Screen Description
1. REAR VIEW MONITOR SYSTEM SCREEN DESCRIPTION Vehicles without a smart key system The rear view monitor system screen will be displayed if the shift lever is shifted to the “R” position while the engine switch is in “ON” position. Vehicles with a smart key system The rear view monitor system screen will be displayed if the shift lever is shifted to the “R”...
Page 161 1. REAR VIEW MONITOR SYSTEM CANCELING REAR VIEW MONITOR SYSTEM The rear view monitor system is canceled when the shift lever is shifted into any position other than the “R” position. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 162: Rear View Monitor System Precautions
1. REAR VIEW MONITOR SYSTEM 2. REAR VIEW MONITOR SYSTEM PRECAUTIONS AREA DISPLAYED ON INFORMATION SCREEN ● The area displayed on the screen may vary according to vehicle orientation conditions. The rear view monitor system displays ● Objects which are close to either corner an image of the view from the bumper of the bumper or under the bumper can- of the rear area of the vehicle.
Page 163: The Camera
● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 164: Differences Between The Screen And The Actual Road
1. REAR VIEW MONITOR SYSTEM WHEN THE GROUND BEHIND DIFFERENCES BETWEEN THE VEHICLE SLOPES UP THE SCREEN AND THE SHARPLY ACTUAL ROAD The distance guide lines will appear to  The distance guide lines and the vehicle be closer to the vehicle than the actual width guide lines may not actually be par- allel with the dividing lines of the parking distance.
Page 165: When Approaching Three-Dimensional Objects
1. REAR VIEW MONITOR SYSTEM WHEN THE GROUND BEHIND WHEN ANY PART OF THE THE VEHICLE SLOPES DOWN VEHICLE SAGS SHARPLY When any part of the vehicle sags due The distance guide lines will appear to to the number of passengers or the dis- be further from the vehicle than the ac- tribution of the load, there is a margin tual distance.
Page 166 1. REAR VIEW MONITOR SYSTEM VEHICLE WIDTH GUIDE LINES DISTANCE GUIDE LINES Visually check the surroundings and Visually check the surroundings and the area behind the vehicle. In the case the area behind the vehicle. On the shown below, the truck appears to be screen, it appears that a truck is park- outside of the vehicle width guide lines ing at point B.
Page 167: Things You Should Know
If you notice any of the following symptoms, refer to the likely cause and the so- lution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Symptom Likely cause Solution ...
Page 168: Toyota Parking Assist Monitor
2. TOYOTA PARKING ASSIST MONITOR 1. TOYOTA PARKING ASSIST MONITOR* TOYOTA PARKING ASSIST WARNING MONITOR ● Never depend on the parking assist monitor entirely when backing up. The The parking assist monitor assists the image and the position of the guide lines...
Page 169 2. TOYOTA PARKING ASSIST MONITOR WARNING ● Do not use the parking assist monitor system in the following cases: • On icy or slick road surfaces, or in snow • When using tire chains or emergency tires • When the back door is not closed com- pletely •...
Page 170: Screen Display
2. TOYOTA PARKING ASSIST MONITOR SCREEN DISPLAY Vehicles without a smart key system The parking assist monitor screen will be displayed if the shift lever is shifted to the “R” position while the engine switch is in “ON” position. Vehicles with a smart key system The parking assist monitor screen will be displayed if the shift lever is shifted to the “R”...
Page 171: Using The System
2. TOYOTA PARKING ASSIST MONITOR Parking assist guide line display mode USING THE SYSTEM (P.175) The steering wheel return points (park- Use any of the following modes. ing assist guide lines) are displayed. Distance guide line display mode Estimated course line display mode Distance guide lines only are dis- played.
Page 172 2. TOYOTA PARKING ASSIST MONITOR SWITCHING THE DISPLAY MODE Press the “APPS” button. Select “Setup”. Select “Vehicle”. Select “Back Camera Guide Line Setting”. Select the display mode. Name Detail Estimated course line display mode Parking assist guide line display mode...
Page 173: Estimated Course Line Display Mode
This line indicates the estimated vehicle center on the Vehicle center guide line ground. WARNING ● If the steering wheel is straight and the vehicle width guide lines and the estimated course lines are not in alignment, have the vehicle inspected by your Toyota dealer. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 174: Parking
2. TOYOTA PARKING ASSIST MONITOR When the rear position of the vehicle PARKING has entered the parking space, turn the steering wheel so that the vehicle width When parking in a space which is in guide lines are within the left and right the reverse direction to the space de- dividing lines of the parking space.
Page 175: Parking Assist Guide Line Display Mode
2. TOYOTA PARKING ASSIST MONITOR 3. PARKING ASSIST GUIDE LINE DISPLAY MODE SCREEN DESCRIPTION Display Function Displays a guide path when the vehicle is being backed straight up. Vehicle width guide line  The displayed width is wider than the actual vehicle width.
Page 176: Parking
2. TOYOTA PARKING ASSIST MONITOR Turn the steering wheel all the way to PARKING the right, and back up slowly. When parking in a space which is in Once the vehicle is parallel with the the reverse direction to the space de-...
Page 177: Toyota Parking Assist Monitor Precautions
2. TOYOTA PARKING ASSIST MONITOR 4. TOYOTA PARKING ASSIST MONITOR PRECAUTIONS AREA DISPLAYED ON INFORMATION SCREEN ● The area displayed on the screen may vary according to vehicle orientation conditions. The parking assist monitor displays an ● Objects which are close to either corner...
Page 178: The Camera
● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 179: Differences Between The Screen And The Actual Road
2. TOYOTA PARKING ASSIST MONITOR WHEN THE GROUND BEHIND DIFFERENCES BETWEEN THE VEHICLE SLOPES UP THE SCREEN AND THE SHARPLY ACTUAL ROAD The distance guide lines will appear to  The distance guide lines and the vehicle be closer to the vehicle than the actual...
Page 180: When Approaching Three-Dimensional Objects
2. TOYOTA PARKING ASSIST MONITOR WHEN THE GROUND BEHIND WHEN ANY PART OF THE THE VEHICLE SLOPES DOWN VEHICLE SAGS SHARPLY When any part of the vehicle sags due The distance guide lines will appear to to the number of passengers or the dis-...
Page 181 2. TOYOTA PARKING ASSIST MONITOR ESTIMATED COURSE LINES DISTANCE GUIDE LINES Visually check the surroundings and Visually check the surroundings and the area behind the vehicle. In the case the area behind the vehicle. On the shown below, the truck appears to be...
Page 182: Things You Should Know
2. TOYOTA PARKING ASSIST MONITOR 5. THINGS YOU SHOULD KNOW IF YOU NOTICE ANY SYMPTOMS If you notice any of the following symptoms, refer to the likely cause and the so- lution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer.
Page 183 2. TOYOTA PARKING ASSIST MONITOR Symptom Likely cause Solution The guide lines are very far The camera position is out of Have the vehicle inspected by out of alignment alignment. your Toyota dealer.  The vehicle is tilted (there is...
Page 184: Panoramic View Monitor
3. PANORAMIC VIEW MONITOR 1. PANORAMIC VIEW MONITOR* Panoramic view monitor assists the DRIVING PRECAUTIONS driver in viewing the surroundings, when operating at low speeds, by com- The panoramic view monitor is a sup- bining the front, side and rear cameras plemental device intended to assist the and displaying a complete vehicle driver when checking around the vehi-...
Page 185 3. PANORAMIC VIEW MONITOR WARNING NOTICE ● ● Depending on the circumstances of the In panoramic view/moving view/see- vehicle (number of passengers, amount through view, the system combines of luggage, etc.), the position of the images taken from the front, back, left guide lines displayed on the screen may and right side cameras into a single change.
Page 186 3. PANORAMIC VIEW MONITOR NOTICE NOTICE ● ● There are blind spots around the vehi- When the back door, which is equipped cle. Accordingly, there are regions not with the back camera, or front doors, displayed in panoramic view/moving which are equipped with door mirrors view/see-through view.
Page 187: Camera Switch
3. PANORAMIC VIEW MONITOR CAMERA SWITCH DISPLAY The camera switch is located as shown CHECKING AROUND THE in the illustration. VEHICLE Moving view See-through view RAV4_Navi+MM_OM42A43U_(U) 15.08.21 12:27...
Page 188 3. PANORAMIC VIEW MONITOR CHECKING THE FRONT AND CHECKING THE REAR AND AROUND THE VEHICLE AROUND THE VEHICLE Wide front view & panoramic view Rear view & panoramic view Wide rear view CHECKING THE SIDES OF THE VEHICLE Side views Rear view RAV4_Navi+MM_OM42A43U_(U) 15.08.21...
Page 189: How To Switch The Display
3. PANORAMIC VIEW MONITOR HOW TO SWITCH THE DISPLAY Vehicles without a smart key system When you press the camera switch or shift the shift lever to the “R” position while the engine switch is in “ON” position, the panoramic view monitor operates. Vehicles with a smart key system When you press the camera switch or shift the shift lever to the “R”...
Page 190 3. PANORAMIC VIEW MONITOR Map screen, Moving view See-through view audio screen, etc. Map screen, audio screen, etc. Rear view & panoramic view Side views Wide front view & panoramic view Rear view Wide rear view Pressing the camera switch Shifting the shift lever Selecting the display mode switching button RAV4_Navi+MM_OM42A43U_(U)
Page 191: Checking Around The Vehicle
3. PANORAMIC VIEW MONITOR 2. CHECKING AROUND THE VEHICLE The moving view screen and the see-through view screen provide support when checking the areas of around the vehicle while parking. Displays an image of the vicinity of the vehicle combined from the 4 cameras. The screen will display a 360 view around the vehicle from either inside the vehicle or from a birds-eye view at an angle.
Page 192: Checking The Front And Around The Vehicle
3. PANORAMIC VIEW MONITOR 3. CHECKING THE FRONT AND AROUND THE VEHICLE The wide front view & panoramic view screen provides support when checking the areas in front of the vehicle and around the vehicle when taking-off at T-intersec- tions or other intersections during poor visibility. To display the screen, press the camera switch when the shift lever is in the “N”...
Page 193 3. PANORAMIC VIEW MONITOR INFORMATION ● Pressing the camera switch changes the screen to the side views screen or previously displayed screen, such as the navigation screen. RAV4_Navi+MM_OM42A43U_(U) 15.08.21 12:27...
Page 194 3. PANORAMIC VIEW MONITOR SWITCHING THE GUIDE LINE AUTOMATIC DISPLAY MODE MODE In addition to screen switching by oper- Each time the guide line switching but- ating the camera switch, automatic dis- ton is selected, the mode will change play mode is available. In this mode, as follows: the screen is switched automatically in response to vehicle speed.
Page 195: Checking The Sides Of The Vehicle
3. PANORAMIC VIEW MONITOR 4. CHECKING THE SIDES OF THE VEHICLE The side views screen provides support when checking the areas on both sides of the vehicle, for example when taking off and stopping, when turning, etc. To display the screen, press the camera switch when the shift lever is in the “N” or “D”...
Page 196 3. PANORAMIC VIEW MONITOR AUTOMATIC DISPLAY MODE USING THE VEHICLE WIDTH GUIDE LINE In addition to screen switching by oper- ating the camera switch, automatic dis- play mode is available. In this mode, the screen is switched automatically in response to vehicle speed. In automatic mode, the monitor will auto- matically display images in the following situations:...
Page 197 3. PANORAMIC VIEW MONITOR  Pull over to the curb as shown in the illus- tration above, taking care not to let the vehicle width guide line overlap the target object.  Ensure that the vehicle width line is paral- lel to the target object enables parking alongside the target object.
Page 198: Checking The Rear And Around The Vehicle
3. PANORAMIC VIEW MONITOR 5. CHECKING THE REAR AND AROUND THE VEHICLE The rear view & panoramic view screen, the wide rear view screen and the rear view screen provide support when checking the areas of behind the vehicle and around the vehicle while backing up, for example while parking.
Page 199 3. PANORAMIC VIEW MONITOR  Rear view Displays the rear view of the vehicle. Display Function Each time the display mode switching button is selected, the mode will change as follows:  From the rear view & panoramic view mode to the wide Display mode switching rear view mode button...
Page 200: Guide Lines Displayed On The Screen
3. PANORAMIC VIEW MONITOR GUIDE LINES DISPLAYED ON THE SCREEN Each time the guide line switching button is selected, the mode will change as fol- lows:  Estimated course line Estimated course lines are displayed which move in accordance with the operation of the steering wheel.
Page 201 3. PANORAMIC VIEW MONITOR  Distance guide line Only distance guide line is displayed. Display Function Shows distance in front of the vehicle.  Display points approximately 3 ft. (1 m) from the edge Distance guide lines of the bumper. Displays a guide path when the vehicle is being backed straight up.
Page 202 ● If the steering wheel is straight and the vehicle width guide lines and the estimated course lines are not in alignment, have the vehicle inspected by your Toyota dealer. ● Do not use the system if the display is incorrect due to an uneven (hilly) road or a non- straight (curvy) road.
Page 203: Parking
3. PANORAMIC VIEW MONITOR When the rear position of the vehicle PARKING has entered the parking space, turn the steering wheel so that the vehicle width USING THE ESTIMATED guide lines are within the left and right COURSE LINE dividing lines of the parking space. When parking in a space which is in the reverse direction to the space de- scribed in the procedure below, the...
Page 204 3. PANORAMIC VIEW MONITOR Turn the steering wheel all the way to USING PARKING ASSIST the right, and back up slowly. GUIDE LINE Once the vehicle is parallel with the When parking in a space which is in parking space, straighten the steering the reverse direction to the space de- wheel and back up slowly until the ve- scribed in the procedure below, the...
Page 205: Panoramic View Monitor Precautions
3. PANORAMIC VIEW MONITOR 6. PANORAMIC VIEW MONITOR PRECAUTIONS AREA DISPLAYED ON SCREEN AREA OF IMAGE OF PANORAMIC VIEW The panoramic view monitor displays an image of the surrounding view of the ve- hicle. Since the panoramic view processes and displays images based on flat road sur- faces, it cannot depict the position of three-dimension objects (such as vehicle bumpers, etc.) that are in positions higher than the surface of the road.
Page 206 3. PANORAMIC VIEW MONITOR INFORMATION WARNING ● As the images obtained from four cam- ● When the Intuitive parking assist display eras are processed and displayed on is red, be sure to check directly and do the standard of a flat road surface; the not proceed any further.
Page 207 3. PANORAMIC VIEW MONITOR Side views Rear view RAV4_Navi+MM_OM42A43U_(U) 15.08.21 12:27...
Page 208: The Camera
3. PANORAMIC VIEW MONITOR Wide rear view THE CAMERA The cameras for the panoramic view monitor are located as shown in the il- lustration. Front camera Side cameras INFORMATION ● Black masking is done for distance detection differences to the front of the vehicle.
Page 209 Doing so may result in the camera malfunctioning. ● Do not expose the camera to strong impacts as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. RAV4_Navi+MM_OM42A43U_(U) 15.08.21 12:27...
Page 210: Differences Between The Screen And The Actual Road
3. PANORAMIC VIEW MONITOR WHEN THE GROUND BEHIND DIFFERENCES BETWEEN THE VEHICLE SLOPES UP THE SCREEN AND THE SHARPLY ACTUAL ROAD The distance guide lines will appear to  The distance guide lines and the vehicle be closer to the vehicle than the actual width guide lines may not actually be par- allel with the dividing lines of the parking distance.
Page 211 3. PANORAMIC VIEW MONITOR WHEN THE GROUND BEHIND WHEN ANY PART OF THE THE VEHICLE SLOPES DOWN VEHICLE SAGS SHARPLY When any part of the vehicle sags due The distance guide lines will appear to to the number of passengers or the dis- be farther from the vehicle than the ac- tribution of the load, there is a margin tual distance.
Page 212: When Approaching Three-Dimensional Objects
3. PANORAMIC VIEW MONITOR ESTIMATED COURSE LINES WHEN APPROACHING THREE-DIMENSIONAL Since the estimated course line is dis- OBJECTS played for a flat road surface, it can not depict the position of three-dimension- The estimated course lines target flat al objects (such as vehicle bumpers, surfaced objects (such as the road).
Page 213 3. PANORAMIC VIEW MONITOR Three-dimensional objects (such as Visually check the surroundings and the overhang of a wall or loading plat- the area behind the vehicle. In the case form of a truck) in high positions may shown below, the truck appears to be not be projected on the screen.
Page 214 3. PANORAMIC VIEW MONITOR DISTANCE GUIDE LINES Visually check the surroundings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point B. However, in reality if you back up to point A, you will hit the truck. On the screen, it appears that A is clos- est and C is farthest away.
Page 215: Things You Should Know
If you notice any of the following symptoms, refer to the likely cause and the so- lution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Symptom Likely cause Solution ...
Page 216 The back door is open. Close the back door. If this does not resolve the symptom, have the vehicle in- spected by your Toyota deal-  The steering wheel has been The estimated course lines Have the vehicle inspected by...
Page 217: Product License
3. PANORAMIC VIEW MONITOR PRODUCT LICENSE RAV4_Navi+MM_OM42A43U_(U) 15.08.21 12:27...
Page 218 3. PANORAMIC VIEW MONITOR RAV4_Navi+MM_OM42A43U_(U) 15.08.21 12:27...
Page 219: Phone
PHONE ® 4. RECEIVING ON THE Bluetooth PHONE OPERATION PHONE ........231 (HANDS-FREE SYSTEM INCOMING CALLS ......231 FOR CELLULAR PHONES) ® 5. TALKING ON THE Bluetooth 1. QUICK REFERENCE....220 PHONE ........232 INCOMING CALL WAITING ....234 2. SOME BASICS ......221 REGISTERING/CONNECTING A ®...
Page 220: Phone Operation
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) 1. QUICK REFERENCE The phone top screen can be used to make a phone call. To display the hands-free operation screen, press the “APPS” button and select “Phone”, the switch on the steering wheel or switch on the instrument panel.
Page 221: Some Basics
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) 2. SOME BASICS The hands-free system enables calls NOTICE to be made and received without hav- ● ing to take your hands off the steering Do not leave your cellular phone in the wheel.
Page 222: Using The Phone Switch/ Microphone
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) MICROPHONE USING THE PHONE SWITCH/ MICROPHONE The microphone is used when talking on the phone. STEERING SWITCH By pressing the phone switch, a call can be received or ended without tak- ing your hands off the steering wheel. Volume control switches ...
Page 223: Voice Command System
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) VOICE COMMAND SYSTEM INFORMATION ● The other party’s voice will be heard Press this switch to operate the voice from the front speakers. The audio sys- tem will be muted during phone calls or command system.
Page 224: About The Contacts In The Contact List
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ABOUT THE CONTACTS IN THE CONTACT LIST  The following data is stored for every reg- istered phone. When another phone is connected, the following registered data cannot be read: • Contact data •...
Page 225: Calling On The Bluetooth
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 3. CALLING ON THE Bluetooth PHONE Select the desired tab to call from. ® After a Bluetooth phone has been registered, a call can be made using the hands-free system. There are sev- eral methods by which a call can be made, as described below.
Page 226: By Favorites List
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) How to make a call list Page BY FAVORITES LIST By favorites list Calls can be made using registered By call history contacts which can be selected from a contact list. (P.248) By contacts list* Display phone...
Page 227: By Call History
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) BY CALL HISTORY INFORMATION ● When making a call to the same number Up to 30 of the latest call history items continuously, only the most recent call is listed in call history. (missed, incoming and outgoing) can ●...
Page 228: By Contacts List
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) WHEN THE CONTACT IS BY CONTACTS LIST EMPTY Calls can be made by using contact ■ PBAP COMPATIBLE data which is transferred from a regis- ® Bluetooth PHONES tered cellular phone. (P.228) When “Automatic Transfer”...
Page 229: By Dial Pad
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ FOR PBAP INCOMPATIBLE BUT INFORMATION ® COMPATIBLE Bluetooth ● Manual transfer operation cannot be PHONES performed while driving. ● If your cellular phone is neither PBAP Select the desired item. nor OPP compatible, the contacts can- not be transferred.
Page 230: By Off Hook Switch
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) BY OFF HOOK SWITCH BY “Home” SCREEN Display the home screen. (P.36) Calls can be made using the latest call history item. Select the desired contact. Press the switch on the steering wheel to display the phone top screen.
Page 231: Receiving On The Bluetooth Phone
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 4. RECEIVING ON THE Bluetooth PHONE INCOMING CALLS When a call is received, this screen is displayed with a sound. Select or press the switch on the steering wheel to talk on the phone.
Page 232: Talking On The Bluetooth
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 5. TALKING ON THE Bluetooth PHONE While talking on the phone, this screen INFORMATION is displayed. The operations outlined ● Changing from hands-free call to cellular below can be performed on this phone call is not possible while driving.
Page 233 1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ BY SELECTING “Release Tones” TRANSMIT VOLUME SETTING “Release Tones” appear when a con- Select “Transmit Volume”. tinuous tone signal(s) containing a (w) Select the desired level for the transmit is registered in the contact list. volume.
Page 234: Incoming Call Waiting
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) INCOMING CALL WAITING When a call is interrupted by a third party while talking, this screen is dis- played. Select or press the switch on the steering wheel to start talking with the other party. To refuse to receive the call: Select or press the switch on the...
Page 235: Phone Message Function
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 6. Bluetooth PHONE MESSAGE FUNCTION Select “Phone”. Received messages can be forwarded ® from the connected Bluetooth phone, enabling checking and replying using the system. ® Depending on the type of Bluetooth phone connected, received messages may not be transferred to the message inbox.
Page 236: Receiving A Message
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) RECEIVING A MESSAGE INFORMATION ● Depending on the cellular phone used When an e-mail/SMS/MMS is re- for receiving messages, or its registra- tion status with the system, some infor- ceived, the incoming message screen mation may not be displayed.
Page 237: Checking Messages
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) CHECKING MESSAGES Function Select to make a call to the sender. Display the message inbox screen. (P.235) *: E-mail only Select the desired message from the INFORMATION list. ● Reading a text message is not available Check that the message is displayed.
Page 238: Replying To A Message (Quick Reply)
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ EDITING QUICK REPLY MESSAG- REPLYING TO A MESSAGE (QUICK REPLY) This operation cannot be performed 15 messages have already been while driving. stored. Select “Quick Message”. Display the message inbox screen. (P.235) Select the desired message from the list.
Page 239: Calling The Message Sender
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ CALLING FROM A NUMBER WITH- CALLING THE MESSAGE IN A MESSAGE SENDER Calls can be made to a number identi- Calls can be made to an e-mail/SMS/ fied in a message’s text area. MMS message sender’s phone num- This operation cannot be performed ber.
Page 240: Setup
2. SETUP 1. PHONE/MESSAGE SETTINGS Press the “APPS” button. PHONE/MESSAGE SETTINGS Entune Audio Plus SCREEN Information Page Entune Premium Audio Registering/connecting phone Sound settings Contact/call history set- tings Messaging settings Phone display settings Select “Setup”. DISPLAYING THE PHONE/ Select “Phone”. MESSAGE SETTINGS SCREEN IN A DIFFERENT WAY Select the item to be set.
Page 241: Sound Settings" Screen
2. SETUP “Sound Settings” SCREEN Function Select to set the desired ringtone. The call and ringtone volume can be adjusted. A ringtone can be selected. Select “-” or “+” to adjust the ring- tone volume. Display the “Phone/Message Settings” Select “-” or “+” to adjust the mes- screen.
Page 242: Contact/Call History Settings" Screen
2. SETUP “Contact/Call History Function Page Settings” SCREEN PBAP compatible ® Bluetooth phones, select to set automatic contact/ The contact can be transferred from a history transfer on/off. ®  Bluetooth phone to the system. The When contact also can be added, edited and phone’s contact data and deleted.
Page 243 2. SETUP UPDATE CONTACTS FROM Function Page PHONE Select to delete contacts from the contact list. Operation methods differ between PBAP compatible and PBAP incom- Select to reset all setup  items. ® patible but OPP compatible Bluetooth phones. ® *: For PBAP compatible Bluetooth If your cellular phone is neither PBAP phones, this function is available when...
Page 244 2. SETUP ■ ■ FOR PBAP INCOMPATIBLE BUT UPDATING THE CONTACTS IN A ® DIFFERENT WAY (FROM THE “Call COMPATIBLE Bluetooth History” SCREEN) PHONES ® This operation cannot be performed For only OPP compatible Bluetooth while driving. phones, this function is available when “Automatic Transfer”...
Page 245 2. SETUP ■ REGISTERING A NEW CONTACT IN REGISTERING A NEW A DIFFERENT WAY (FROM THE CONTACT TO THE CONTACT “Call History” SCREEN) LIST ® For only OPP compatible Bluetooth New contact data can be registered. phones, this function is available when Up to 4 numbers per person can be “Automatic Transfer”...
Page 246 2. SETUP ■ EDITING THE CONTACT IN A DIF- Select “Add to Contacts”. FERENT WAY (FROM THE “Contact Follow the steps in “REGISTERING A Details” SCREEN) NEW CONTACT TO THE CONTACT Display phone screen. LIST” from “STEP 2”. (P.245) (P.225) EDITING THE CONTACT DATA Select the “Contacts”, “Call History”...
Page 247 2. SETUP ■ DELETING THE CONTACT IN A DIF- DELETING THE CONTACT FERENT WAY (FROM THE “Contact DATA Details” SCREEN) ® PBAP compatible Bluetooth Display phone screen. phones, this function is available when (P.225) “Automatic Transfer” is set to off. Select the “Contacts”, “Call History”...
Page 248 2. SETUP When 15 contacts have already been FAVORITES LIST SETTING registered to the favorites list Up to 15 contacts (maximum of 4 num- When 15 contacts have already been bers per contact) can be registered in registered to the favorites list, a regis- the favorites list.
Page 249 2. SETUP ■ Registering contacts in the favorites list DELETING THE CONTACTS IN THE in a different way (from the “Contacts” FAVORITES LIST screen) Select “Remove Favorite”. Display phone screen. Select the desired contacts and select (P.225) “Remove”. Select the “Contacts” tab. Select ...
Page 250: Messaging Settings" Screen
2. SETUP Deleting contacts in the favorites list in a “Messaging Settings” different way (from the “Contacts” SCREEN screen) Display phone screen. Display the “Phone/Message Settings” (P.225) screen. (P.240) Select the “Contacts” tab. Select “Messaging Settings”.  Select at the beginning of the con- Select the desired item to be set.
Page 251 2. SETUP DISPLAYING THE “Messaging Function Settings” SCREEN IN A Select to set adding the vehicle signa- DIFFERENT WAY ture to outgoing messages on/off. Display phone screen. Select to set updating message read status on phone on/off. (P.225) Select to change the incoming SMS/ Select MMS display.
Page 252: Phone Display Settings" Screen
2. SETUP “Phone Display Settings” SCREEN Display the “Phone/Message Settings” screen. (P.240) Select “Phone Display Settings”. Select the desired item to be set. Function Select to change the incoming call display. “Full Screen”: When a call is re- ceived, the hands-free screen is dis- played and can be operated on the screen.
Page 253: What To Do If
  compatible system, check with ® your Toyota dealer or Bluetooth cellular the following website: phone. The hands-free sys- http://www.toyota.com/ ® tem or Bluetooth entune/ vice does not work. ®...
Page 254: What To Do If
3. WHAT TO DO IF... When registering/connecting a cellular phone Page Symptom Likely cause Solution Cellular This phone system An incorrect pass- Enter the correct pass- code was entered   code on the cellular cellular phone. phone. Complete the registra- The registration op- tion operation on the eration has not been...
Page 255 3. WHAT TO DO IF... Page Symptom Likely cause Solution Cellular This phone system ® Manually connect the Another Bluetooth  cellular phone you wish device is already to use to this system. connected. ® ® Bluetooth function Enable the Bluetooth ...
Page 256 3. WHAT TO DO IF... Page Symptom Likely cause Solution Cellular This phone system ® ® Bluetooth function Enable the Bluetooth   is not enabled on function on the cellular the cellular phone. phone. Delete the existing reg- “Unable dial.
Page 257   system, check with not be compatible your Toyota dealer or with transferring the following website: phonebook data. http://www.toyota.com/ entune/ Automatic contact Phonebook data can- Set automatic contact transfer function on ...
Page 258 3. WHAT TO DO IF... ® When using the Bluetooth message function Page Symptom Likely cause Solution Cellular This phone system Enable message trans- Message transfer is cellular   not enabled on the phone (approve mes- cellular phone. sage transfer on the Messages cannot be phone).
Page 259 3. WHAT TO DO IF... In other situations Page Symptom Likely cause Solution Cellular This phone system ® The Bluetooth con- nection status is dis- played at the top of the screen each time the engine <power> switch is in following. Vehicles without a smart key sys- Connection...
Page 260 3. WHAT TO DO IF... Page Symptom Likely cause Solution Cellular This phone system The cellular phone Bring cellular   is not close enough phone closer to this to this system. system. Turn the cellular phone off, remove and rein- ...
Page 261 3. WHAT TO DO IF... RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:04...
Page 262: Navigation System
NAVIGATION SYSTEM * BASIC OPERATION DESTINATION SEARCH 1. QUICK REFERENCE ....264 1. DESTINATION SEARCH SCREEN ........281 MAP SCREEN ........264 NAVIGATION OPTIONS SCREEN..266 2. SEARCH OPERATION....283 SELECTING SEARCH AREA ....284 2. MAP SCREEN OPERATION ..267 SETTING HOME AS DESTINATION ...
Page 263 NAVIGATION SYSTEM * ROUTE GUIDANCE SETUP 1. ROUTE GUIDANCE SCREEN..297 1. DETAILED NAVIGATION SETTINGS......... 318 SCREEN FOR ROUTE GUIDANCE ... 297 SCREENS FOR NAVIGATION ROUTE OVERVIEW......298 SETTINGS ........318 DURING FREEWAY DRIVING.... 299 WHEN APPROACHING 2. TRAFFIC SETTINGS....322 INTERSECTION .......
Page 264: Basic Operation
1. BASIC OPERATION 1. QUICK REFERENCE MAP SCREEN To display this screen, press the “APPS” button, then select “Navigation” on the “Apps” screen. Name Function Page Indicates whether the map orientation is set to 2D North-up, 2D north-up or heading-up. The letter(s) beside this heading-up or 3D symbol indicate the vehicle’s heading direction heading-up sym-...
Page 265 1. BASIC OPERATION Name Function Page Shows that traffic information is received. Select to start voice guidance for traffic information. Traffic indicator When traffic information is received via HD, HD mark is displayed on the right. Scale indicator This figure indicates the map scale. Select to magnify or reduce the map scale.
Page 266: Navigation Options Screen
1. BASIC OPERATION NAVIGATION OPTIONS SCREEN The navigation options allow you to change map configurations, display/hide POI icons, and edit the navigation routes. To display the “Navigation Options” screen, press the “APPS” button, select “Navigation” on the “Apps” screen, and select “Options”...
Page 267: Map Screen Operation
1. BASIC OPERATION 2. MAP SCREEN OPERATION CURRENT POSITION INFORMATION DISPLAY ● While driving, the current position mark is fixed on the screen and the map moves. Press the “APPS” button. ● The current position is automatically set as the vehicle receives signals from the GPS (Global Positioning System).
Page 268: Map Scale
1. BASIC OPERATION MAP SCALE ORIENTATION OF THE MAP The orientation of the map can be Select to change the changed between 2D north-up, 2D scale of the map screen. heading-up and 3D heading-up by se- lecting the orientation symbol dis- played at the top left of the screen.
Page 269: Switching The Map Mode
1. BASIC OPERATION 3D screen Function Page Select to display the single map screen. Select to display the dual map screen. Select to display the com- pass mode screen. Select to display the turn list : North-up symbol screen. Regardless of the direction of vehicle trav- Select to display the free- el, north is always up.
Page 270 1. BASIC OPERATION ■ Editing right map MAP ONLY The right side map can be edited. Select any point on the right side map. Select the desired item. ■ DUAL MAP Function Page Select to change the orien- tation of the map. ...
Page 271: Screen Scroll Operation
1. BASIC OPERATION ■ COMPASS SCREEN SCROLL OPERATION Information about the destination, cur- rent position and a compass is dis- Use the scroll feature to move the de- played on the screen. sired point to the center of the screen for looking at a point on the map that is different from the current position.
Page 272: Adjusting Location In Small Increments
1. BASIC OPERATION  To scroll over the map screen, place the ADJUSTING LOCATION IN cursor mark in the desired position and SMALL INCREMENTS then touch and hold the map screen. The map will continue scrolling in that direction until the finger is released. The cursor location can be adjusted in small increments when “Adjust Loca- tion”...
Page 273: Map Screen Information
1. BASIC OPERATION 3. MAP SCREEN INFORMATION SELECTING THE POI ICONS DISPLAYING MAP INFORMATION Display the “Map Information” screen. (P.273) Information such as POI icons, route Select “Select POI”. trace, speed limit, etc. can be dis- played on the map screen. ...
Page 274 1. BASIC OPERATION ■ ■ SELECTING OTHER POI ICONS TO DISPLAYING THE LOCAL POI LIST BE DISPLAYED POIs that are within 20 miles (32 km) of Select “Other POIs”. the current position will be listed from among the selected categories. Select the desired POI categories and select “OK”.
Page 275: Displaying Information About The Icon Where The Cursor Is Set
1. BASIC OPERATION ROUTE TRACE DISPLAYING INFORMATION ABOUT THE ICON WHERE The traveled route can be stored and THE CURSOR IS SET retraced on the map screen. This fea- ture is available when the map scale is When the cursor is placed over an icon 30 miles (50 km) or less.
Page 276: Standard Map Icons
1. BASIC OPERATION Destination information STANDARD MAP ICONS Icon Name Island Park Function Industry Select to register as a memory point. To change the icon, name, etc.: Business facility  P.312 Airport Select to set as a destination. Select to call the registered number. Military Select to delete destination or mem- ory point.
Page 277: Traffic Information
1. BASIC OPERATION 4. TRAFFIC INFORMATION Traffic data can be received via HD or DISPLAYING TRAFFIC Entune App Suite to display traffic in- INFORMATION formation on the map screen. A list of current traffic information can Press the “APPS” button. be displayed along with information on the incident’s distance and position rel- ative to the vehicle.
Page 278 1. BASIC OPERATION DISPLAYING PREDICTIVE MY TRAFFIC ROUTES TRAFFIC INFORMATION Traffic information along the saved A map with predictive traffic data can routes can be displayed. To use this be displayed. function, it is necessary to register a route. (P.325) Display “Traffic Information”...
Page 279: Displaying Traffic Information On The Map
1. BASIC OPERATION Check that the traffic information is dis- DISPLAYING TRAFFIC played. INFORMATION ON THE MAP Select “Options” on the map screen. Select “Map Information”. Select “Traffic Information”.  When set to on, the indicator will illumi- nate. Check that the traffic information is dis- “Detail”: Select to display detailed traffic played.
Page 280 1. BASIC OPERATION Information/Function The icons show traffic incident, road repair, traffic obstacles, etc. Select to display traffic information and start voice guidance for the traffic informa- tion. The color of the arrow changes de- pending on the traffic information re- ceived.
Page 281: Destination Search
2. DESTINATION SEARCH 1. DESTINATION SEARCH SCREEN The “Destination” screen enables to search for a destination. To display the “Des- tination” screen, press the “APPS” button, and select “Navigation” on the “Apps” screen. Then select “Dest.” on the map screen. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 282 2. DESTINATION SEARCH Function Page Select to search for a destination by address. Select to search for a destination by point of interest. Select to search for a destination from previously set destinations. Select to search for a destination from a registered entry in “Address book”.
Page 283: Search Operation
2. DESTINATION SEARCH 2. SEARCH OPERATION Press the “APPS” button. Select “Go” when the confirm destina- tion screen is displayed. Function Select “Navigation”. Select to adjust the position in small- Select “Dest.”. er increments. (P.272) Search for a destination. Select to register as a memory point. Select to call the registered number.
Page 284: Selecting Search Area
2. DESTINATION SEARCH SELECTING SEARCH AREA SETTING HOME AS DESTINATION The selected state (province) can be changed to set a destination from a To use this function, it is necessary to different state (province) by using register a home address. (P.309) “Address”, “Point of Interest”...
Page 285: Searching By Address
2. DESTINATION SEARCH Select the desired street name. SEARCHING BY ADDRESS Enter a house number and select There are 2 methods to search for a “OK”. destination by address.  If the same address exists, the address list screen will be displayed. Select the Display “Destination”...
Page 286: Searching By Point Of Interest
2. DESTINATION SEARCH SEARCHING BY NAME SEARCHING BY POINT OF INTEREST Select “Name”. There are 3 methods to search for a Enter a POI name and select “OK”. destination by Points of Interest. Select the desired POI. Display “Destination” screen. (P.283) Select “Point of Interest”.
Page 287 2. DESTINATION SEARCH ■ SELECTING A CITY TO SEARCH SEARCHING BY CATEGORY Select “City”. Select “Category”. Enter a city name and select “OK”. Select the desired search point. “Any City”: Select to cancel the city set- ting. Select the desired city name. Select the desired POI.
Page 288 2. DESTINATION SEARCH “List All Categories”: Select to display all SEARCHING BY PHONE POI categories. NUMBER “Favorite POI Categories”: Select to use the 6 POIs that have been previously set. Select “Phone #”. (P.319) Enter a phone number and select Select the desired POI.
Page 289: Searching From Previous Destinations
2. DESTINATION SEARCH SEARCHING FROM SEARCHING BY ADDRESS PREVIOUS DESTINATIONS BOOK Display “Destination” screen. To use this function, it is necessary to (P.283) register address book entry. (P.312) Select “Previous Destinations”. Display “Destination” screen. Select the desired destination. (P.283) Select “Address Book”. Select the desired address book entry.
Page 290: Searching By Emergency
2. DESTINATION SEARCH SEARCHING BY SEARCHING BY EMERGENCY INTERSECTION AND FREEWAY Display “Destination” screen. (P.283) There are 2 methods to search for a destination by Intersection & Freeway. Select “Emergency”. Display “Destination” screen. Select the desired emergency catego- (P.283) Select “Intersection & Freeway”. Select the desired method.
Page 291 2. DESTINATION SEARCH SEARCHING BY SEARCHING BY FREEWAY INTERSECTION ENTRANCE/EXIT Select “Intersection”. Select “Freeway Entrance / Exit”. Enter the name of the first intersecting Enter a freeway name and select street which is located near the desti- “OK”. nation and select “OK”. Select the desired freeway.
Page 292: Searching By Map
2. DESTINATION SEARCH SEARCHING BY MAP SEARCHING BY COORDINATES By selecting “Map” the last displayed location is displayed again on the map Display “Destination” screen. screen. You can search for a destina- (P.283) tion from this map. Select “Coordinates”. Display “Destination”...
Page 293: Starting Route Guidance
2. DESTINATION SEARCH 3. STARTING ROUTE GUIDANCE When the destination is set, the entire WARNING route map from the current position to ● the destination is displayed. Be sure to obey traffic regulations and keep road conditions in mind while driv- ing.
Page 294 2. DESTINATION SEARCH ■ DISPLAYING 3 ROUTES INFORMA- 3 ROUTES SELECTION TION Select “3 Routes”. Select “Info”. Select the desired route. Check that the “3 Route Information” screen is displayed. Function Information Select to display the quickest route. Time necessary for the entire trip Select to display the route that is the shortest distance to the set destina- Distance of the entire trip...
Page 295 2. DESTINATION SEARCH DISPLAYING TURN LIST EDITING ROUTE A list of turn information from the cur- Destinations can be added, reordered rent position to the destination can be or deleted, and conditions for the route displayed. to the destination can be changed. Select “Turn List”.
Page 296: Pausing Guidance
2. DESTINATION SEARCH PAUSING GUIDANCE INFORMATION ● Even if the “Freeways” indicator is Select “Options” on the map screen. dimmed, the route cannot avoid includ- ing a freeway in some cases. (P.305) Select “Pause Guidance”. ● If the calculated route includes a trip by ferry, the route guidance shows a sea route.
Page 297: Route Guidance
3. ROUTE GUIDANCE 1. ROUTE GUIDANCE SCREEN During the route guidance, various CHANGING ROUTE types of guidance screens can be dis- INFORMATION BAR played depending on conditions. When the vehicle is on the guidance route, the route information bar dis- SCREEN FOR ROUTE plays the current street name or the GUIDANCE...
Page 298: Route Overview
3. ROUTE GUIDANCE ROUTE OVERVIEW INFORMATION ● When the vehicle is on the guidance The entire route from the current posi- route, the distance measured along the route is displayed. Travel time and tion to the destination can be displayed arrival time are calculated based on the during the route guidance.
Page 299: During Freeway Driving
3. ROUTE GUIDANCE WHEN APPROACHING DURING FREEWAY DRIVING FREEWAY EXIT OR JUNCTION During freeway driving, the freeway When the vehicle approaches an exit exit information screen will be dis- or junction, the freeway guidance played. screen will be displayed. No./ Information/Function Information/Function Icon...
Page 300: When Approaching Intersection
3. ROUTE GUIDANCE TOLLGATE GUIDANCE WHEN APPROACHING INTERSECTION When the vehicle approaches a toll- gate, the tollgate view will be dis- When the vehicle approaches an inter- played. section, the intersection guidance screen will be displayed. Information/Function Distance from the current position to Information/Function the tollgate Next street name...
Page 301: Turn List Screen
3. ROUTE GUIDANCE TURN LIST SCREEN TURN-BY-TURN ARROW SCREEN Select “Turn List” on the “Map Mode” screen. (P.269) On this screen, information about the next turn on the guidance route can be Check that the turn list screen is dis- displayed.
Page 302: Typical Voice Guidance Prompts
3. ROUTE GUIDANCE 2. TYPICAL VOICE GUIDANCE PROMPTS As the vehicle approaches an intersec- tion, or point, where maneuvering the vehicle is necessary, the system’s voice guidance will provide various messages. WARNING ● Be sure to obey the traffic regulations and keep the road condition in mind especially when you are driving on IPD roads (roads that are not completely dig-...
Page 303: Editing Route
3. ROUTE GUIDANCE 3. EDITING ROUTE Press the “APPS” button. Select the item to be set. Function Page Select to add destinations. Select “Navigation”. Select “Options”. Select to delete destina- tions. Select “Edit Route”. Select to reorder destina- tions. Select to set route prefer- ences.
Page 304: Adding Destinations
3. ROUTE GUIDANCE ADDING DESTINATIONS DELETING DESTINATIONS Display the “Edit Route” screen. Display the “Edit Route” screen. (P.303) (P.303) Select “Add”. Select “Delete”. Search for an additional destination in Select “Yes” when the confirmation the same way as a destination search. screen appears.
Page 305: Setting Route Preferences
3. ROUTE GUIDANCE SETTING ROUTE SELECTING ROUTE TYPE PREFERENCES Display the “Edit Route” screen. (P.303) The conditions to determine the route can be selected from various choices Select “Route Type”. such as freeways, toll roads, ferries, Select the desired route type. etc.
Page 306: Detour Setting
3. ROUTE GUIDANCE DETOUR SETTING INFORMATION During the route guidance, the route can be changed to detour around a section of the route where a delay is caused by road repairs, an accident, etc. Display the “Edit Route” screen. (P.303) ●...
Page 307: Starting From Adjacent Road
3. ROUTE GUIDANCE STARTING FROM ADJACENT ROAD When a freeway and a surface road run in parallel, the system may show the guidance route going on the free- way while driving on the surface road, or vice versa. If this happens, you can instantly choose the adjacent road for the route guidance.
Page 308: Memory Points
4. MEMORY POINTS 1. MEMORY POINTS SETTINGS Select the desired item to be set. Home, preset destinations, address book entries, areas to avoid can be set as memory points. The registered points can be used as the destinations. (P.281) Registered areas to avoid, will be avoided when the system searches for a route.
Page 309: Setting Up Home
4. MEMORY POINTS EDITING HOME SETTING UP HOME Select “Edit”. If home has been registered, that infor- mation can be recalled by selecting Select the desired item to be edited. “Go Home” on the “Destination” screen. (P.284) Display “Navigation Settings” screen.
Page 310: Setting Up Preset Destinations
4. MEMORY POINTS REGISTERING PRESET SETTING UP PRESET DESTINATIONS DESTINATIONS Select “Set”. If a preset destination has been regis- tered, that information can be recalled Select the desired item to search for by using preset destinations on the the location. (P.281) “Destination”...
Page 311 4. MEMORY POINTS EDITING PRESET DELETING PRESET DESTINATIONS DESTINATIONS Select “Edit”. Select “Delete”. Select the desired preset destination. Select the preset destination to be de- leted and select “Delete”. Select the item to be edited. Select “Yes” when the confirmation Function Page screen appears.
Page 312: Setting Up Address Book
4. MEMORY POINTS REGISTERING ADDRESS SETTING UP ADDRESS BOOK ENTRIES BOOK Select “New”. Points on the map can be registered. Select the desired item to search for Display “Navigation Settings” the location. (P.281) screen. (P.308) Select “OK” when the editing address Select “Address Book”.
Page 313 4. MEMORY POINTS ■ CHANGING THE ICON EDITING ADDRESS BOOK ENTRIES Select “Edit” next to the “Icon”. The icon, name, location and/or phone Select the desired icon. number of a registered address book entry can be edited. Select “Edit”. Select the desired address book entry. Select the item to be edited.
Page 314 4. MEMORY POINTS ■ When the “With Sound” tab is selected CHANGING THE NAME Select “Edit” next to “Name”. A sound for some address book entries can be set. When the vehicle ap- Enter a name and select “OK”. proaches the location of the address ■...
Page 315: Setting Up Areas To Avoid
4. MEMORY POINTS REGISTERING AREAS TO SETTING UP AREAS TO AVOID AVOID Select “New”. Areas to be avoided because of traffic jams, construction work or other rea- Select the desired item to search for sons can be registered as “Areas to the location.
Page 316 4. MEMORY POINTS ■ CHANGING THE NAME EDITING AREAS TO AVOID Select “Edit” next to “Name”. The name, location and/or area size of a registered area can be edited. Enter a name and select “OK”. ■ Select “Edit”. CHANGING THE LOCATION Select the area and select “OK”.
Page 317: Deleting Previous Destinations
4. MEMORY POINTS DELETING AREAS TO AVOID Select “Delete”. Select the area to be deleted and se- lect “Delete”. Select “Yes” when the confirmation screen appears. DELETING PREVIOUS DESTINATIONS Previous destinations can be deleted. Display “Navigation Settings” screen. (P.308) Select “Delete Previous Dest.”. Select the previous destination to be deleted and select “Delete”.
Page 318: Setup
5. SETUP 1. DETAILED NAVIGATION SETTINGS Settings are available for pop-up infor- SCREENS FOR NAVIGATION mation, favorite POI categories, low SETTINGS fuel warning, etc. Press the “APPS” button. Select “Setup”. Select “Navigation”. Select “Detailed Navi. Settings”. Select the items to be set. Select “OK”.
Page 319 5. SETUP FAVORITE POI CATEGORIES Function Page (SELECT POI ICONS) Select to set the voice guid-  ance for the next street Up to 6 POI icons, which are used for name on/off. selecting POIs on the map screen, can Select to set IPD road guid- be selected as favorites.
Page 320 5. SETUP ■ POSITION/DIRECTION CALIBRA- CURRENT POSITION/TIRE TION CHANGE CALIBRATION When driving, the current position The current position mark can be ad- mark will be automatically corrected by justed manually. Miscalculation of the GPS signals. If GPS reception is poor distance caused by tire replacement due to location, the current position can also be adjusted.
Page 321 5. SETUP ■ ■ TIRE CHANGE CALIBRATION SEARCHING GAS STATION IN LOW FUEL WARNING The tire change calibration function will be used when replacing the tires. This A nearby gas station can be selected function will adjust miscalculation as a destination. caused by the circumference differ- Select “Yes”...
Page 322: Traffic Settings
5. SETUP 2. TRAFFIC SETTINGS Traffic information such as traffic con- SCREEN FOR TRAFFIC gestion or traffic incident warnings can SETTINGS be made available. Press the “APPS” button. Select “Setup”. Select “Traffic”. Select the items to be set. Select “OK”. Function Select to set specific routes (such as frequently used routes) on which...
Page 323: Auto Avoid Traffic
5. SETUP Function AUTO AVOID TRAFFIC Select to set of traffic incident voice Display the “Traffic Settings” screen. warning on/off. (P.322) Select to reset all setup items. Select “Avoid Traffic”. Select the desired item. Function Select automatically change routes when congestion information of the guidance route has been re- ceived.
Page 324: My Traffic Routes
5. SETUP ■ CHANGING THE ROUTE MANUAL- MY TRAFFIC ROUTES Specific routes (such as frequently When the navigation system calcu- used routes) on which you wish to re- lates a new route, the following screen ceive traffic information can be regis- will be displayed.
Page 325 5. SETUP REGISTERING PERSONAL EDITING PERSONAL ROUTES ROUTES Select “Edit”. Select “New”. Select the desired traffic route. Select “Edit” next to “Name”. Select “Edit” next to the item to be ed- Enter the name and select “OK”. ited. Select “Edit” next to “Start”. Select the desired item to search for the location.
Page 326 5. SETUP DELETING PERSONAL SETTING PREFERRED ROADS ROUTES “My Traffic Routes” can be adjusted by Select “Delete”. setting up to 2 preferred roads. Select the traffic route to be deleted Select “Set Preferred Roads”. and select “Delete”. Select the desired item. Select “Yes”...
Page 327 5. SETUP ■ ■ ADDING PREFERRED ROADS MODIFYING PREFERRED ROADS Select “Add”. Select “Modify”.  If two preferred roads are already set, Select the preferred road to be modi- select “Yes” and delete a preferred road fied if 2 preferred roads have been set. before add a new one.
Page 328 5. SETUP ■ DELETING PREFERRED ROADS Select “Delete”. Select the preferred road to be deleted if 2 preferred roads have been set. “Delete All”: Select to delete all preferred roads on the list. Select “Yes” when the confirmation screen appears. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 329: Tips For The Navigation System
6. TIPS FOR THE NAVIGATION SYSTEM 1. GPS (GLOBAL POSITIONING SYSTEM) When the vehicle is receiving signals from LIMITATIONS OF THE satellites, the “GPS” mark appears at the NAVIGATION SYSTEM top left of the screen. The GPS signal may be physically ob- This navigation system calculates the structed, leading to inaccurate vehicle po- current position using satellite signals,...
Page 330 6. TIPS FOR THE NAVIGATION SYSTEM  Accurate current position may not be  Inappropriate route guidance may occur in shown in the following cases: the following cases: • When driving on a small angled Y- • When turning at an intersection off the shaped road.
Page 331 6. TIPS FOR THE NAVIGATION SYSTEM INFORMATION ● This navigation system uses tire turning data and is designed to work with fac- tory-specified tires for the vehicle. Installing tires that are larger or smaller than the originally equipped diameter may cause inaccurate display of the cur- rent position.
Page 332: Map Database Version And Covered Area
Select to display map coverage ar- eas. Select to display legal information. Select “Navigation”. Select “Options”. INFORMATION ● Map data updates are available for a Select “Map Data”. fee. Contact your Toyota dealer for fur- ther information. RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 333: About The Map Data
6. TIPS FOR THE NAVIGATION SYSTEM ABOUT THE MAP DATA Map data for the navigation system is contained in a SD card that is inserted in the SD card slot. Do not eject the SD card, as doing so may deactivate the navigation system. NOTICE ●...
Page 334 6. TIPS FOR THE NAVIGATION SYSTEM RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 335: Entune App Suite
Entune App Suite * Entune App Suite OVERVIEW 1. Entune App Suite SERVICE ..336 BEFORE USING THE FUNCTION ..338 PREPARATION BEFORE USING Entune App Suite ......339 Entune App Suite OPERATION 1. Entune App Suite ....... 341 USING Entune App Suite..... 341 LINKING Entune App Suite AND NAVIGATION FUNCTION....
Page 336: Entune App Suite Overview
1. Entune App Suite OVERVIEW 1. Entune App Suite SERVICE* Entune App Suite is a service that enables downloadable applications to be dis- played on and operated from the screen. Before Entune App Suite can be used, a few actions need to be performed first. (P.339) USB * *: Entune App Suite is available in the contiguous United States, D.C.
Page 337 The system is equipped with an application player to run applications. : For iPhone only, Entune App Suite can be used while the battery is being charged. : For known compatible phones, refer to http://www.toyota.com/entune/. INFORMATION ●...
Page 338: Before Using The Function
 Services requiring a separate contract can • Downloaded application content also be used.* *: For details, refer to INFORMATION http://www.toyota.com/entune/ or call ● 1-800-331-4331. Once initialized, data will be erased from the system. Pay close attention when initializing the data.
Page 339: Preparation Before Using Entune App Suite
1. Entune App Suite OVERVIEW USER REGISTRATION PREPARATION BEFORE USING Entune App Suite Perform user registration at http://www.toyota.com/entune/. SETUP REQUIRED TO USE Entune App Suite Perform the following actions. User registration Download the Entune App Suite ap- plication to your cellular phone.
Page 340 ● Entune App Suite operational proce- dures can also be confirmed by visiting http://www.toyota.com/entune/. ● In order to use applications, it is neces- sary to run the Entune App Suite appli- cation on your cellular phone.
Page 341: Entune App Suite Operation
Suite can be used, a few actions need to be performed first. (P.339) For details about the function and ser- Function Page vice of each application, refer to http://www.toyota.com/entune/. Select to activate an appli-  cation. Press the “APPS” button. Select to update the appli- cation.
Page 342 2. Entune App Suite OPERATION Check that downloading is completed. UPDATING an application When Entune App Suite is activated, an application may need to be updat- ed. By updating, an application can be kept to the latest version. When updat- ing the application, it is necessary to download the updated data and install Function...
Page 343: Entune App Suite Operation
2. Entune App Suite OPERATION ■ INSTALLING THE UPDATED DATA REORDERING THE APPLICATIONS After the downloading is complete, “Update” will be changed to “Install”. Order of the applications can be changed. Select “Install”. Display the “Apps” screen. (P.341) Select “Continue”. Select “Reorder”.
Page 344 Bluetooth* phone. For trou- The cellular phone cannot be www.toyota.com/entune/ bleshooting assistance, connected. confirm if the phone is com- please visit toyota.com.” patible or not. “This feature is unavailable hands-free call After the hands-free call is fin- during a handsfree call.”...
Page 345: Linking Entune App Suite And Navigation Function
Entune App tination. Suite. For details about the function and service of each application, refer Display the “Web Search” screen. to http://www.toyota.com/entune/. (P.345) Press the “APPS” button. Select the desired application button to search. Enter a search term, and select “GO”.
Page 346: Entune App Suite Keyword Operation
For details about the function and service of each applica- Display the “Web Search” screen. tion, refer to (P.345) http://www.toyota.com/entune/. Select the desired application button to search.  The keyboard layout can be changed. (P.56) Enter a search term, and select “GO”.
Page 347 2. Entune App Suite OPERATION Entering characters will be reflected on the character input space.  For details on operating the keyboard: P.37 ENTERING A KEYWORD USING THE VOICE RECOGNITION FUNCTION Display the “Apps” screen. (P.341) Select the desired application button. Press the talk switch.
Page 348: Setup
3. SETUP 1. Entune App Suite SETTINGS Select the items to be set. The phone data plan pop-up can be set when a paid application is download- Press the “APPS” button. Function Select to set the pop up reminder for cellular phone data usage.
Page 349: Index
INDEX RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 350: Alphabetical Index
ALPHABETICAL INDEX ALPHABETICAL INDEX ® AM/FM radio ..........80 Calling on the Bluetooth phone.....225 Available HD radio™ technology... 88 By call history ........227 Caching a radio program....... 85 By contacts list........228 Overview ..........80 By dial pad...........229 Presetting a station........ 84 By favorites list ........226 Radio broadcast data system....
Page 351 Editing route..........303 Function index...........28 Adding destinations......304 Deleting destinations......304 Detour setting........306 General settings........56 Reordering destinations ...... 304 General settings screen ......56 Selecting route type ......305 GPS (Global positioning system) ....329 Setting route preferences....305 Limitations of the navigation system ..........
Page 352 ALPHABETICAL INDEX Maintenance ..........66 Operating information......126 Map database version and CD player and disc ......127 covered area ........332 Error messages ........135 About the map data ......333 File information ........130 Map information........332 iPod .............129 Map screen information ......273 Radio ...........126 Displaying information about the Terms ..........133...
Page 353 Phone/message settings ......240 Registering home........22 “Contact/Call History Settings” Registering preset destinations....24 screen..........242 Registering/connecting ® “Messaging Settings” screen....250 Bluetooth device........43 “Phone Display Settings” screen..252 Profiles ..........46 ® Phone/message settings screen ..240 Registering a Bluetooth audio player for the first time .......
Page 354 Setup....... 124, 240, 318, 348 Touch screen gestures......34 “Setup” screen .......... 20 Touch screen operation ......35 Some basics ........74, 221 Toyota parking assist monitor ....168 About the contacts in the Driving precautions......168 contact list........224 Screen display ........170 Disc slot..........76 Using the system .........171...
Page 355 USB memory .......... 103 Overview ..........103 Playing a USB audio ......107 Useful information........152 Voice command system....137, 138 Using the voice command system ..138 Voice command system operation ..139 Voice command system operation..138 Voice settings ........... 63 Voice settings screen ......
Page 356: Map Database Information And Updates
Map database information and updates RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 357 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 358 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 359 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 360 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 361 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 363 Certification  Gracenote, the Gracenote logo and logotype, “Powered by Gracenote”, MusicID, Playlist Plus and MediaVOCS are either registered trademarks or trademarks of Gracenote, Inc. in the United States and/or other countries RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 364 RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 365 For U.S. owners RAV4_Navi+MM_OM42A43U_(U) 15.08.10 11:05...
Page 366 U.S.A. (Entune Audio Plus)  FCC ID: BABFT0045B  This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 367 Mexico (Entune Audio Plus)  RCPFUFT13-1083  La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
Page 368 U.S.A. (Entune Premium Audio)  FCC ID: BABFT0044E  This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Toyota Navigation System RAV4 Owner's Manual

Table of Contents

Quick Guide

Basic Function

Overview Buttons

Home Screen

Quick Reference

Navigation Operation

Registering Home

Registering Preset Destinations

Operation Flow: Guiding the Route

Setting Home as the Destination

Function Index

Basic Function

Basic Information before Operation

5 ENTERING LETTERS and 2. SETTING Bluetooth DETAILS

Bluetooth ® SETTINGS

Other Settings

3 Audio System

Quick Reference

Basic Operation

Some Basics

Radio Operation

Am/Fm Radio

XM Satellite Radio

Internet Radio

Media Operation

Usb Memory

Ipod

Bluetooth ® AUDIO

Aux

Steering Switches

Audio Remote Controls

Setup

Audio Settings

Operating Information

Tips for Operating the Audio System

Voice Command System

Voice Command System Operation

Mobile Assistant Operation

Information

Useful Information

Receiving Weather Information

Receiving Traffic Map Information

Data Services Settings

6 Peripheral Monitoring System

System

Rear View Monitor System

Rear View Monitor

Rear View Monitor System Precautions

Things You Should Know

Toyota Parking Assist

Toyota Parking Assist Monitor

Estimated Course Line Display Mode

Parking Assist Guide Line Display Mode

Toyota Parking Assist Monitor Precautions

Things You Should Know

Monitor

Panoramic View

Panoramic View Monitor

Checking Around the Vehicle

Checking the Front and Around the Vehicle

Checking the Sides of the Vehicle

Checking the Rear and Around the Vehicle

Panoramic View Monitor Precautions

Things You Should Know

Phone

Phone Operation

Quick Reference

Some Basics

CALLING on the Bluetooth

Phone

RECEIVING on the Bluetooth PHONE

TALKING on the Bluetooth PHONE

Setup

Phone/Message Settings

What to Do if

What to Do if

8 Navigation System *

Navigation System
