Summary of Contents for Bosch VIP-XDHD
- Page 1 VIP XD HD VIP-XDHD Installation Guide...
-
Page 3: Table Of Contents
Preparations Mounting Connection Sequence of connections Monitor Network Power Power on/power off Configuration Setup Setup using Bosch Video Client Troubleshooting General malfunctions Power light and LEDs Maintenance Updates Repairs Setting out of order Transfer and disposal Bosch Sicherheitssysteme GmbH Installation Guide... -
Page 4: En | Table Of Contents
| Table of Contents VIP XD HD Technical data 10.1 Electrical 10.2 Mechanical 10.3 Environmental conditions 10.4 Certifications and approvals 10.5 Standards F.01U.217.838 | V3 | 2012.06 Installation Guide Bosch Sicherheitssysteme GmbH... -
Page 5: Safety
– If safe operation of the unit cannot be ensured, remove it from service and secure it to prevent unauthorized operation. In such cases, have the unit checked by Bosch Security Systems. Safe operation is no longer possible in the following cases: –... -
Page 6: Short Information
The unit is intended for use with CCTV systems. Other applications are not permitted. In the event of questions concerning the use of the unit which are not answered in this manual, please contact your sales partner or: Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany www.boschsecurity.com... -
Page 7: System Overview
Compact in size in relation to its decoding power, VIP XD HD is perfect for any display application that requires space-saving solutions. Remote control Control the viewing mode remotely and establish the video connections using Bosch’s comprehensive video management systems. Operating system VIP XD HD is based on the latest Intel H67 Express Chipset on a Mini-ITX board with a Core i3 CPU running at 3.1 GHz. - Page 8 HD monitor, for example, a high-performance 26" or 42" Bosch HD LCD monitor. VIP XD HD is capable of decoding two full HD 1080p30 streams or four 720p30 streams, for example, displayed in quad view. It can handle up to six Standard Definition streams at up to 6 Mbps with full resolution and frame rate, and display it in a 2 ×...
-
Page 9: Connections, Controls And Displays
NOTICE! For more information about the LEDs, see Section 7.2 Power light and LEDs, page 15. Bosch Sicherheitssysteme GmbH Installation Guide F.01U.217.838 | V3 | 2012.06... -
Page 10: Installation
– Avoid impacts, blows and severe vibrations that exceed the specification limits (see Section 10 Technical data, page 18), as these can irreparably damage the VIP XD HD decoder. F.01U.217.838 | V3 | 2012.06 Installation Guide Bosch Sicherheitssysteme GmbH... -
Page 11: Mounting
The mounting location must be able to reliably hold the unit. The load-bearing capacity must be adequate for four times the weight of the unit. If mounting the unit to the back of a monitor, use only monitors that are approved by Bosch Security Systems. -
Page 12: Connection
Monitor NOTICE! You can obtain a list of approved monitors from your supplier or directly from Bosch Security Systems. This list is constantly being updated and extended. You must connect a suitable monitor to the VIP XD HD decoder. The unit provides three monitor outputs, DVI-I, HDMI and Display Port. -
Page 13: Power On/Power Off
Switch on the monitor in order to see the user interface after the boot-up procedure. NOTICE! All information regarding the functions and the operation can be found in the relevant documentation of Monitor Wall, Bosch Video Management System, or Bosch Video Client. Bosch Sicherheitssysteme GmbH Installation Guide... -
Page 14: Configuration
VIP XD HD Configuration Setup The setup procedure is carried out via Bosch Video Client or other management systems. You must at least assign a valid IP address to operate on your network. NOTICE! All information regarding the configuration can be found in the relevant documentation of the video management system in use. -
Page 15: Troubleshooting
General malfunctions If you are unable to resolve a malfunction, please contact your supplier or systems integrator, or go directly to Bosch Security Systems Customer Service. The following tables are intended to help you identify the causes of malfunctions and correct them where possible. -
Page 16: Maintenance
Ensure that all maintenance or repair work is carried out only by qualified personnel (electrical engineers or network technology specialists). In case of doubt, contact your dealer's technical service center. F.01U.217.838 | V3 | 2012.06 Installation Guide Bosch Sicherheitssysteme GmbH... -
Page 17: Setting Out Of Order
Transfer and disposal VIP XD HD should only be passed on together with this installation and operating manual. Your Bosch product is designed and manufactured with high-quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste. -
Page 18: Technical Data
0 to 90% atmospheric humidity, non-condensing Thermal value Approx. 310 BTU/h, 460 BTU/h max. 10.4 Certifications and approvals Safety IEC 60950 Electromagnetic EN55022 compatibility EN55024 FCC 47 CFR Chapter 1 Part 15 F.01U.217.838 | V3 | 2012.06 Installation Guide Bosch Sicherheitssysteme GmbH... - Page 19 10/100/1000 Base-T, auto-sensing, half/full duplex, RJ45 Protocols RTP, Telnet, UDP, TCP, IP, HTTP, HTTPS, FTP, DHCP, IGMP V2/ V3, ICMP, ARP, SMTP, SNTP, SNMP (V1, MIB-II) Encryption TLS 1.0, SSL, AES (optional) Bosch Sicherheitssysteme GmbH Installation Guide F.01U.217.838 | V3 | 2012.06...
- Page 20 | Technical data VIP XD HD F.01U.217.838 | V3 | 2012.06 Installation Guide Bosch Sicherheitssysteme GmbH...
- Page 22 Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2012...
