Chapter 1
Attach power cables
Connect each component to a Power Distribution Unit (PDU) or Units.
Connect PDU cables to Uninterruptible Power Supply (UPS) and UPS
cables to Branch Circuits--if present.
Route and secure cables
Route cables through Cable Guide and tie them in place.
Power on the components in the rack.
Follow the power up sequence. See "Power Up Sequence" in Chapter 2.
8. Configure the System, Install Doors and Side Panels
At this point, refer to the HP NetServer LPr Installation Guide and configure the
system.
Install front and rear doors as required, and mount side panels. Detailed
instructions and illustrations are included with the rack enclosure and
components.
General Cabling Warnings and Cautions
Unterminated Power Cords Require Licensed Electrician
In some cases in the 230/240V environment, the Uninterruptible Power Supply
(UPS) is shipped with a power cord that is unterminated (that is, there is no
power connector, just wires). The reason is that the current demand of a fully
loaded rack may exceed the demand for the normal circuit in some countries.
Therefore, you should have a qualified electrician or electrical engineer analyze
the current demand for each branch circuit used by rack mounted equipment.
Proper wiring and cord termination are part of the same process.
Prevent Electric Shock
WARNING
The LPr must be installed only in locations where access is
restricted to technically qualified personnel.
About This Cabling Reference
9
