Chapter 2
Two 120 V PDUs per UPS Possible
Two 120 VAC PDUs can be plugged into the UPS in this 120 V power
configuration. There are also six NEMA 5-15R receptacles in the standard UPS
which can be used for equipment in the same rack if needed.

200/208V PDU Rack Power Configurations

The 208 VAC PDU power configurations appear as shown below in Table
200/
4 and Figure 12.
2- 2-
Recommended 208 VAC Power Configurations
In the United States, if you are using a UPS use PDU model E7671A or E7672A.
Attach the IEC 320 C19 end of the E7801A cord to the PDU, and attach the L6-
20 end of the same cord to the NEMA L6-20 receptacle on the UPS.
Alternate 208 VAC Power Configurations
In the 200/208 VAC case, without a UPS, make sure your power system has the
capacity to support the power and current needs of the components you will
power. (See the section titled "Site Preparation: Circuit Breakers.") If power and
current capacity are adequate, plug the PDU into a 200/208 V, L6-20 receptacle.
Table 2-4. 200/208 VAC Components
Component
(Note 1)
208 VAC PDU
HP NetServer LPr
HP NetServer
Rack Storage/8
HP NetServer
Rack Storage/12
HP Console Switch
Video Monitor
Note 1 For a full list of power ratings, see the rack configuration utilities (for instance,
Rack Assistant) on the HP Web Site.
Note 2 Indicated current ratings are for use in selecting PDU and UPS components and
may not reflect actual measured amounts.
36
Connecting and Routing Cables to the HP NetServer LPr
Model Power (W)
E7671A or E7672A
All models
D4902A
-
J1497A
Varies with model chosen.
Current (A)
Note 2
N/A maximum
16
305 2.2
209 1.1
537 2.6
70 0.2
