Chapter 3
CAUTION Do not push in on the VRM release latches; the release
latches will close automatically when the VRM is installed
completely. If the VRM is not installed completely, pushing
in on release latches may damage the latches, the socket, or
the VRM.

Installing Terminator Board for Single-Processor NetServer

A single-processor system board should already have a terminator board
(terminating resistor module) installed in the secondary processor position. If not,
install the terminator board originally supplied with the NetServer:
1. Orient the terminator board as shown in Figure 3-15.
30
Installation in LC 3 and LH 3/3r
