Parts List - HP D5970A - NetServer - LCII Service & Reference Manual

Parts List

Fig
1 Top cover assembly w/ref labels
2 I/O shield
3 PCI Slot Divider
4 I/O baseboard shield
5 Remote control board
6a I/O riser board
6b I/O Riser PCA
7 I/O baseboard
8 Battery, I/O baseboard, type CR 2032
9 PCI slot filler panel
10 PCI LED board
11 PCI hold-down latch
12 I/O tray
13 750W power supply module**
14 PCI card guide
15 Chassis
16 AC line receptacle
17 Midplane Board
18 Center support
19 Fan bay cover assy w/ref label
20 Fan assy
21 Fan cage
22 CPU cage top cover
23 CPU Terminator
24 CPU DS2P 400 MHz / 512 KB cache
A
24 CPU DS2P 400 MHz / 1 MB cache
B
24 CPU 450 MHz / 512 KB cache
C
24 CPU 450 MHz / 1 MB cache
D
24 CPU 450 MHz / 2 MB cache
E
24 CPU 500 MHz / 512 KB cache
F
24 CPU 500 MHz / 1 MB cache
G
24 CPU 500 MHz / 2 MB cache
H
24I CPU 550 MHz / 512 KB cache
24 CPU 550 MHz / 1 MB cache
J
24 CPU 550 MHz / 2 MB cache
K
25 CPU card cage
26 CPU carrier board
27 Coherency filter
66
Description Replacement
D7054-63014
Not orderable
Not orderable
Not orderable
D6028-60001 D6028-69001
D6021-63007
D6021-6372
D7054-63003 D7054-69003
1420-0356
D7054-63008
D7054-63006
D7054-63015
Not orderable
D6021-63070 D6021-69070
Not orderable
Not orderable
Not orderable
D7054-63001 D7054-69001
Not orderable
D7054-63017
D6021-63034
Not orderable
Not orderable
D6021-63006
D7007-63001 D7007-69001
D6119-63001 D6119-69001
D7001-63001 D7001-69001
D6121-63001 D6121-69001
D6122-63001 D6122-69001
D7109-63001 D7109-69001
D7110-63001 D7110-69001
D7091-63001 D7091-69001
D9417-63000 D9417-69000
D9418-63000 D9418-69000
D8531-63001 D8531-69001
Not orderable
D7054-63004 D7054-69004
D7054-63007 D7054-69007
Exchange
