Sony VPL-AW10 Specification Sheet

Key Features
24p True Cinema allows 1080/24p input signal via
HDMI™
Cinema Black Pro (with Advanced Iris function and
Lamp Control)
Advanced Iris Function and Lamp Control
High Contrast Ratio of up to 6,000:1 (Advanced Iris
Auto Mode ON)
Quite operation with low fan noise of 20dB
Three 1280 x 720 LCD Panels, 0.73" p-Si TFT Panels
Resolution: 1280 x 720 (x3) or 2,764,800 Total Pixels
Lens. 1.6 Times Manual Zoom/Focus Lens (F2.4-3.1)
Projection Picture Size: 40" - 200" measured
diagonally
Ceiling or Table Mount Capable
Key Technologies
24p True Cinema
Many films are shot at 24 images per second. Because of the limitations of conventional
televisions (both CRT and flat panels), these 24 images can't be faithfully reproduced. The sequence of the 24
images gets altered in order to display the content on television. The result is a unnatural, jerky movement that the
movie creators did not intend. With24p True Cinema, the 24 progressive images are displayed as they should be, in
the same sequence as the original film source. In combination with next-generation video devices like Blu-ray
Disc, the same film-like motion that you could only enjoy in the theaters in now available in the comfort of your
living room.
Advanced Iris Function
This function reproduces bright images in bright scenes and deep blacks in dark scenes
by dynamically changing the opening according to the level of input signals. Two " Auto" nodes offer the user some
flexibility depending on content. And each mode has three sensitivity settings- Recommended, Fast and Slow to
allow additional adjustments. Working in combination with the High Contrast Plate, an awesome contrast ration of
up to 6,000:1 can now be achieved.
Full Digital Processing
Sony's Full Digital Video Processing circuits include a number of processes designed to
optimize picture performance of any input source, the 12- Bit Panel Driver achieves excellent gradation
reproduction and a high level of detail.
720p HD Home Entertainment Projector
VPL-AW10
