Contents
Safety Precautions .................................. 2
Usage Precautions .................................. 4
Installation ............................................... 6
Parts Identification ....................................8
Operation Panel............................................ 9
Temperature Control............................... 10
ECONAVI Operation............................... 11
Quick Freezing....................................... 11
■ NON-CFC
This unit uses totally NON-CFC MATERIALS both for refrigerant (R600a) and for
insulation (Cyclo-Pentane). So, this refrigerator does not damage the Earth's ozone layer.
Thank you for purchasing the Panasonic product.
• Please read these instructions carefully and follow safety precautions on page 2-5 before using
this product.
• Please make sure the date and name of store of purchase are stamped in warranty card and
keep it with these operating instructions.
HK
Operating Instructions
Model No.:
Prime Fresh+.......................................... 12
Fridge compartment .............................. 13
Prime Fresh case .................................. 14
Freezer compartment............................. 15
How to clean the Refrigerator ................ 17
Troubleshooting ..................................... 20
Specifications......................................... 22
Refrigerator
For Household Use
NR-BV361B
ARAH1E203580
Printed in Vietnam
P0423-0
Advertisement
Table of Contents
Related Manuals for Panasonic NR-BV361B
Summary of Contents for Panasonic NR-BV361B
-
Page 1: Table Of Contents
This unit uses totally NON-CFC MATERIALS both for refrigerant (R600a) and for insulation (Cyclo-Pentane). So, this refrigerator does not damage the Earth’s ozone layer. Thank you for purchasing the Panasonic product. • Please read these instructions carefully and follow safety precautions on page 2-5 before using this product. -
Page 2: Safety Precautions
Safety Precautions Please be sure to follow these instructions. WARNING CAUTION This sign means: It may lead to a serious This sign means: It may result in injury or injury or death. property damage. These signs mean prohibited action. This sign means required action. This sign means the appliance must be earthed to prevent electric shock. - Page 3 Otherwise, it may WARNING cause a fire, injury, electrical shock. For power plug and cord: ● Do not plug or unplug with wet hands. ● Do not let the cord or plug be damaged. ● Disconnect power plug when cleaning. ● Plug into a wall outlet of the rated voltage on its own with the rated current and insert plug fully.
-
Page 4: Usage Precautions
CAUTION Otherwise it may cause injury, accidents. When opening/closing the doors: ● While opening the refrigerator, be careful not to pinch other one's hand holding the door. ● Mind the gap between the doors. They may nip your hand while closing the door. When storing food: ●... - Page 5 Usage Precautions When using: ● When the plug is disconnected, leave it for 5 minutes before 5 mins plugging again. If not, the compressor may not work. ● Adjust the temperature according to the actual operating condition for energy saving. ●...
-
Page 6: Installation
Installation The distance requested for installation ● The top of the refrigerator is at 5 cm least 5 cm from the ceiling. 5 cm ● The left and right sides of the refrigerator are at least 5 cm from the walls. ●... - Page 7 ● The refrigerator LED lamp, specially designed for this refrigerator, do not replace it by yourself. If you need replacement, please contact Panasonic Service Center. ● If the refrigerator plug has no ground wire, it should be connected with a grounding connection to prevent electrical hazard from electric leakage.
-
Page 8: Parts Identification
Parts Identification ① ⑥ ⑦ ② ③ ④ ⑤ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑯ ⑭ ⑮ ⑰ A-Fridge compartment B-Freezer compartment 1 LED Lamp a Ice maker 2 Glass tray of Fridge compartment b Ice box (Quantity: 2 pcs) c Glass tray of Freezer compartment 3 Operation Panel (Page 9) d Glass tray Freezer case... -
Page 9: Operation Panel
Operation Panel 1 LED of compartments: the icon of the respective compartment will light up when the compartment is selected. 2 Temperature display area: display the temperature of Fridge compartment, Freezer compartment, Prime Fresh case. 3 Temperature control button of Fridge compartment. 4 Temperature control button of Freezer compartment. -
Page 10: Temperature Control
Temperature Control ● Default setting temperature for Fridge compartment is 4 °C, Prime Fresh case is -3 °C and Freezer compartment is -20 °C. The temperature setting for each compartment can be adjusted. ● The temperature setting range of the Fridge compartment is 1 °C ~ 7 °C, of the Prime Fresh case is -5 °C ~ 4 °C (the temperature for soft freezing is -5 °C ~ -1 °C, and the temperature to use the Prime Fresh case as the Fridge compartment is 0 °C ~ 4 °C), of the Freezer compartment is -23 °C ~ -15 °C. -
Page 11: Econavi Operation
ECONAVI Operation The refrigerator detects the opening and closing of the refrigerator door to control operations automatically to ensure maximum energy saving.* „ ECONAVI operation ● The refrigerator learns the lifestyle patterns of your family from door opening and time periods of infrequent use to maximize energy efficiency. -
Page 12: Prime Fresh
Prime Fresh+ When “Prime Fresh+” is set, the Prime Fresh case will reduce the temperature quickly for better performance of preserving food. „ How to operate the “Prime Fresh+” mode ● Press and hold the “Prime Fresh” icon for 3 seconds to Light is on: Prime Fresh+ is operated. -
Page 13: Fridge Compartment
Fridge compartment The temperature range of the Fridge compartment is 1 °C ~ 7 °C. If the temperature of the Fridge compartment is set to 1 °C during a long period of time, your food may be frozen. The position of the glass tray of Fridge compartment can be changed 1 Lift up the back of the glass tray and pull it Protrusion forward. -
Page 14: Prime Fresh Case
Prime Fresh case The temperature in the Prime Fresh case can be selected as below: • The temperature for soft freeze is -5 °C ~ -1 °C . • The temperature to use the Prime Fresh case as the Fridge compartment is 0 °C ~ 4 °C. When using the refrigerator, the temperature can be adjusted according to your usage. -
Page 15: Freezer Compartment
Freezer compartment Storing frozen foods for a long period of time The temperature range of the Freezer compartment is -23 °C to -15 °C. Three tips for freezing food and locking in the flavour 1. Freeze thin and small items of food quickly 2. - Page 16 To use the Ice maker in comfort Please use only drinking Do not put liquids such as the following into Ice water for Ice making. maker. (These liquids may damage the Ice maker). The hardness of water must be 100 mg/L or less. Drinking water Juice, etc.
-
Page 17: How To Clean The Refrigerator
How to clean the Refrigerator Before cleaning or conducting maintenance, be absolutely sure to disconnect the power plug from the power outlet. Do not connect or disconnect the power plug with wet hands. When the plug is disconnected, leave it for 5 minutes before plugging again. If not, the compressor may not work. - Page 18 How to clean the Refrigerator Once every 3 months Door shelf / Bottle shelf „ Removing 1 Lift it upward, alternating between the right and left side. „ Attaching 2 Place it on both supporters, and then press until it reaches the end of supporters.
- Page 19 Once every 3 months Vegetable case / Freezer case „ Removing „ Attaching 1 Pull the case forward until it reaches the 1 Insert the case into the shelf. end. 2 Gently lift the case and push forward 2 Gently lift the front of the case to remove until it reaches the end.
-
Page 20: Troubleshooting
Troubleshooting Before you call for service, please check the following steps: ●Check that the plug and its socket are in good condition. ●Check if there is any problem on main fuse and electrical The refrigerator system of the house. does not operate. ●Check by unplug and wait for 5 minutes before plugging it back ●Check to be sure that light in Operation Panel is displayed at proper position. - Page 21 The sound becomes more quiet after cooling fully. Light does not ●Please contact Panasonic Service Center. turn on. ●Are you adjusting the temperature of your refrigerator? → Flashes during adjusting. Please complete the setting or the The Operation Operation Panel will stop flashing after 5 seconds.
-
Page 22: Specifications
Width x Depth x Height (mm) Net Weight (kg) Refrigerant Type R600a Cooling System Non-frost cooling. Rated Voltage (V) Refer to the rating label attached inside the Rated Frequency (Hz) cabinet. Panasonic Corporation Website: https://www.panasonic.com © Panasonic Appliances Vietnam Co., Ltd. 2023...
