2. Specification and components
3. Schematic diagram
4. Performance data
6.4 Replace FC/PC door
6. Disassembly instruction with BK series in Vietnamese
7. Parts exploded view and replacement parts list.
7.1 Parts exploded view: Body
7.2 Parts exploded view: Machine room & Door
7.3 Parts exploded view: Packing
7.4 Replacement part list : NR-BK266 SERIES
7.5 Replacement part list : NR-BK306 SERIES
7.6 Replacement part list : NR-BK346 SERIES
CONTENT
- 2 -
- 2 -
Page
3
4
5
6
7
8
9
10-14
15-19
20
21
22-24
25-26
27-28
29-30
Advertisement
Table of Contents
Related Manuals for Panasonic NR-BK266SN
Summary of Contents for Panasonic NR-BK266SN
-
Page 1: Table Of Contents
CONTENT Page 1. Safety caution for repairing 1.1 Warning 1.2 Caution 2. Specification and components 2.1 NR- BK266 SERIES 2.2 NR- BK306 SERIES 2.3 NR- BK346 SERIES 3. Schematic diagram 4. Performance data 4.1 NR- BK266 SERIES 4.2 NR- BK306 SERIES 4.3 NR- BK346 SERIES 5. -
Page 2: Safety Caution For Repairing
1. SAFETY CAUTION FOR REPAIRING When you repair the refrigerator, please kindly take care for the following cautions 1.1 Warning Before repairing unit, unplug supply cord • Before you repair the refrigerator, please unplug the supply cord Use authentic parts when replacing •... - Page 3 2.1 NR-BK266 SERIES Model NR-BK266SN, MS, GS Destination Vietnam Malaysia Sin-DBD Hong Kong Code Attached Model Power Source 220V 220～240V 240V 230V 220V Plug Colour Model SN, GS SN,GS SN,MS,GS SN,MS Colour Code System Spec. Induction Material Spec. PCM = SN, VCM = MS, GS...
- Page 4 2.2 NR-BK306 SERIES Model NR-BK306SN,MS, GS Destination Vietnam Malaysia Sin-DBD Hong Kong GULF Code Attached Model Power Source 220V 240V 230V 220V 220～240V 220～240V 220～240V Plug (SHUKO) Colour Model SN,MS SN,GS SN,MS SN,MS,GS Colour Code System Spec. Induction Material Spec. PCM = SN, VCM = MS, GS Specification Total Volume...
- Page 5 2.3 NR-BK346 SERIES Model NR-BK346SN,MS,GS Destination Vietnam Malaysia Sin-DBD Hong Kong GULF Code Attached Model Power Source 220V 220～240V 240V 230V 220V 220～240V 220～240V Plug (SHUKO) Colour Model SN,MS SN,GS SN,MS SN,MS,GS Colour Code System Spec. Induction Material Spec. PCM = SN, VCM = MS, GS Specification Total Volume 333L...
-
Page 6: Nr-Bk266 Series
NR-BK266 SERIES NR-BK306 SERIES NR-BK346 SERIES - 7 -... -
Page 7: Nr- Bk266 Series
4.1 NR- BK266 SERIES REFRIGE MAX NORMAL FREEZER MAX Control setting "1" "2" "3" 5.0 ± 2.5 2.0 ± 2.5 1.0 ± 2.5 Mean fresh food compartment (°C) -10.0 ± 2.5 -18.5 ± 2.5 -21.0± 2.5 Mean freezer compartment (°C) -17.0 ±... -
Page 8: Troubleshooting Guide
5. TROUBLESHOOTING GUIDE Cause: Not cool or not enough cooling • MF capacitor, PCB Protector register ohmmeter. To follow the R134a unit repair instruction - 9 -... -
Page 9: Freezer Compartment
6. DISASSEMBLY INSTRUCTION WITH MODEL NR-BK266 SSERIES, NR-BK306 SERIES, NR-BK346 SERIES 6.1. Freezer compartment 6.1.1. Remove cover coil: 1. Take out the ice cube tray and tray FC. 2. Use a small screw driver to open the cap of cover coil window. 3. -
Page 10: Provision Compartment
6.1.3. Defrost heater as defrost heater cover radiant 1. Bend the cooper tupe lightly, raise the coil about 7cm. 2. Bend the clamp lightly then take out defrost heater as. 3. Pull out the head of rubber lightly then take out cover radiant. 6.2. - Page 11 6.2.3. Door switch connector 1. Push to the left then pull out door switch. 2. Pull down the door switch lightly, then undo connector. 6.3. Machine room 6.3.1. PCB, Supply cord & harness as wire main, MF capacitor, Relay, Motor protector capacitor box hook screw...
- Page 12 6.4. Replace FC, PC door 6.4.1. Replace FC door Disassembly FC door cover hinge top screw cap hinge top 1. Close the FC door then remove cover hinge top: - Pull follow direction 1. - Push up follow direction 2. 2.
- Page 13 6.4.2. Replace PC door Disassembly PC door: FC door must be disassembly before the disassembly of the PC door. screw - Unscrew No. 1, 2, 3 of hinge center. - Lift up the PC door. Assembly PC door hinge bottom 600 ±...
- Page 14 6. HƯỚNG DẪN THÁO LẮP VỚI MODEL NR-BK266 SSERIES, NR-BK306 SERIES, NR-BK346 SERIES 6.1. Ngăn đá 6.1.1. Tháo cover coil: 1. Lấy khay đá và tray FC ra trước khi tháo cover coil. 2. Dùng tua vít nhỏ có cạnh sắc mở nắp đậy cửa sổ cover coil ra. 3.
- Page 15 6.1.4. Tháo defrost heater as defrost heater cover radiant 1. Uốn nhẹ ống đồng một chút, nâng nhẹ coil lên khoảng 7cm. 2. Bẻ nhẹ clamp ở hai đầu rồi nhấc defrost heater as ra. 3. Kéo nhẹ hai đầu cao su, nhấc cover radiant ra. 6.2.
-
Page 16: Machine Room
6.2.3. Door switch connector connector 1. Đẩy sang trái một chút rồi kéo ra. 2. Kéo nhẹ door switch xuống, rồi tháo connector. 6.3. Machine room 6.3.1. Supply cord & harness as wire main, MF capacitor, Relay, motor protector capacitor box hook screw Protector cover... - Page 17 6.4. Thay thế cánh FC, PC 6.4.1. Thay thế cánh FC Tháo cánh FC cover hinge top screw cap hinge top 1. Đóng cánh FC lại. Sau đó tháo cover hinge top: - Đẩy sang ngang theo mũi tên. - Đẩy lên trên theo chiều mũi tên. 2.
- Page 18 6.4.2. Thay thế cánh PC Tháo cánh PC: trước khi tháo cánh PC, thì phải tháo cánh FC. hinge center 1. Tháo vít 1,2 của hinge center. 2. Nhấc cánh PC ra. Lắp cánh PC hinge bottom 600 ± 200cN.m vị...
- Page 19 - 22 -...
- Page 20 - 23 -...
- Page 21 - 24 -...
