Sealey VS0220 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instruction protection
manual
1. SAFETY
Familiarise yourself with the applications and limitations, as well as any potential hazards, of the kit.
9
Keep this product in good working order and condition. (take immediate action to repair or replace damaged parts).
9
Use approved parts only (unapproved parts may be dangerous and will invalidate the warranty).
9
Keep children and unauthorised persons away from the work area.
9
Keep work area clean and tidy and free from unrelated materials.
9
Ensure the work area has adequate lighting.
9
DO NOT use the kit to perform a task for which it is not designed.
8
DO NOT allow untrained persons to use the kit.
8
DO NOT use whilst under the influence of drugs, alcohol or intoxicating medication.
8
After use, clean equipment and store in a cool, dry, childproof area.
9
Dispose of waste liquids in accordance with local authority regulations.
9
Always read and comply with the warnings on the brake fluid container.
9
Wear eye protection and keep skin contact to a minimum. If brake fluid enters eyes, rinse with plenty of water and seek medical
9
advice. If swallowed seek medical advice immediately.
WARNING! Brake fluid is flammable - keep away from sources of ignition, including hot surfaces e.g. exhaust manifold.
‰
WARNING! Brake fluid will damage paintwork. Any spillage should be flushed with water immediately.
‰
After use, clean equipment and store in a cool, dry, childproof area.
9
2. INTRODUCTION
One-person operation using standard workshop air supply (87-174psi/6-12bar). With a flexible hanging hook. Durable hard-wearing Acetal plastic.
Trigger for adjusting air pressure, with an added trigger lock. Draws fluid from the bleeding nipple enabling either bleeding or full replacement of
fluid in the system. Clear PVC hose easily checks for air bubbles. Hose length 1.5m. Does not require specialised brake reservoir caps.
3. SPECIFICATION
Model No:................................................................. VS0220
Air Consumption: .................................................... 180L/min
Inlet Size: ..................................................................1/4"BSP
Maximum Air Supply: ........................................ 174psi/12bar
Tank Capacity: ................................................................ 1.2L
© Jack Sealey Limited
PREMIER 1.2L PNEUMATIC VACUUM BRAKE &
CLUTCH BLEEDER
VS0220
MODEL NO:
Original Language Version
VS0220 Issue 2 (2,3) 22/03/23
