[1] Plate heat exchanger
[2] Key slot (wireless gateway)
[3] On/Off-switch
[4] Condensate trap
[5] Data plate 1
[6] DHW temperature sensor
[7] Pressure sensor
[8] Pressure gauge
[9] Adjustable nozzle
[10] Valve for filling with nitrogen
[11] Fan
[12] Expansion Vessel
[13] CH flow
[14] De-aerator
[15] Mixing device with exhaust gas check valve (non-return valve)
[16] Ignition transformer
[17] Flue gas pipe
[18] Ignition electrodes
[19] Flame sense electrode
[20] Heating block temperature limiter
[21] Flow temperature sensor at heating block
[22] Inspection aperture cover
[23] Condensate sump
[24] Air/gas ratio control valve
[25] Data plate 2
[26] 3-way valve
[27] Heating system circulation pump
[28] Pressure relief valve (heating circuit)
[29] Drain cock
[30] Turbine
[31] Filling facility
[32] Control box
Condens 8300i W – 6721841531 (2022/10)
3

Regulations

▶ Observe all regulations and standards applicable to the system in
your country prior to installation and commissioning.
▶ Make sure the entire system satisfies the following standards,
regulations and directives.
Where no specific instruction is given, reference should be made to the
following standards:
• AS 1596 LPG storage and handling
• AS 1697 Installation and maintenance of steel pipe systems for gas
• AS 1910 Water supply - float control valves for use in hot and cold
water
• AS 3498 Authorization requirements for plumbing products - water
heaters and hot water storage tanks
• AS 3500 National plumbing and drainage code
• AS 4032 Water supply - valves for the control of hot water supply
temperatures
• AS/NZS5263.1.2 Gas fired water heaters for hot water supply and/
or central heating
• AS/NZS 5601 Gas Installations
• AS/NZS 3000 Electrical Installations
Number Description
92/42/EEC Efficiency Directive
98/83/EC Directive in relation to the quality of water for human
consumption
2004/108/EC EMC Directive
2006/96/EC Low-voltage guideline
2009/142/EC EC Gas Appliances Directive
DIN 4726/4729 Oxygen diffusion resistance
EN 437 Test gases, test pressures, appliance categories
EN 12828 Heating systems in buildings - planning hot water
heating systems
EN 12831 Heating systems in buildings – process for
calculating the standard heat energy demand
EN 13384 Flue systems, heat and fault calculation models
EN 50201-1 Boiler for gaseous fuels - Part 1: General
requirements and tests
EN 50201-2-1 Boilers for gaseous fuels - Part 2-1: Type C boilers
and Type B2, B3 and B5 boilers with a rated heat
input no greater than 1000 kW
Table 4 Regulations, standards and guidelines
