AUTODOME IP starlight 5000i (pendant)
NDP‑5512‑Z30│NDP‑5512‑Z30‑P
en
Installation Manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch AUTODOME IP starlight 5000i

Summary of Contents for Bosch AUTODOME IP starlight 5000i

  • Page 1 AUTODOME IP starlight 5000i (pendant) NDP‑5512‑Z30│NDP‑5512‑Z30‑P Installation Manual...

  • Page 3: Table Of Contents

    AUTODOME IP starlight 5000i (pendant) Table of contents | en Table of contents Safety About this Manual Legal Information Safety Precautions Important safety instructions Additional safety information Connection in Applications Important notices Use latest software Customer Support and Service Introduction...

  • Page 4: Safety

    Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.

  • Page 5: Important Safety Instructions

    Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information.

  • Page 6: Additional Safety Information

    | Safety AUTODOME IP starlight 5000i (pendant) Additional safety information Notice! The product shall be installed under the eaves of a building, and shall avoid direct exposure of the external wire to sunlight and water. Caution! Attach the metal mounting plate (supplied with the camera) to the inside of the pendant interface plate mount with the three (3) M4 screws (12 mm) (supplied with mount).

  • Page 7: Connection In Applications

    AUTODOME IP starlight 5000i (pendant) Safety | en Connection in Applications 24 VAC power source: This unit is intended to operate with a limited power source. The unit is intended to operate at 24 VAC (if PoE+ is not available). User supplied wiring must be in compliance with electrical codes (Class 2 power levels).
  • Page 8 | Safety AUTODOME IP starlight 5000i (pendant) instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his expense.

  • Page 9: Use Latest Software

    – Security advisories, that is a list of identified vulnerabilities and proposed solutions: https://www.boschsecurity.com/xc/en/support/product-security/security-advisories.html Bosch assumes no liability whatsoever for any damage caused by operating its products with outdated software components. Notice! Bosch strongly recommends upgrading to the latest firmware for the best possible functionality, compatibility, performance and security.

  • Page 10: Customer Support And Service

    | Safety AUTODOME IP starlight 5000i (pendant) Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. USA and Canada Telephone: 800-289-0096, option 5 Fax: 800-366-1329 Email: repair@us.bosch.com...

  • Page 11: Introduction

    Sales or Customer Service Representative from Bosch Security Systems. – Do not use this product if any component appears to be damaged. Please contact Bosch Security Systems in the event of damaged goods. – The original packing carton (if undamaged) is the safest container in which to transport the unit and must be used if returning the unit for service.

  • Page 12: System Requirements

    If you cannot connect, the unit may have reached its maximum number of connections. Depending on the device and network configuration, each unit can have up to 50 web browser connections, or up to 100 connections via Bosch Video Client or BVMS. Establishing the connection The unit must have a valid IP address and a compatible subnet mask to operate on your network.

  • Page 13: Configuration With Project Assistant App

    You can also use the Project Assistant app to complete the initial configuration of the camera. In order to use this device with the Project Assistant app by Bosch, you must download the app from the Bosch Download Store, from Google Play, or from the Apple Store.

  • Page 14: Product Description

    Specially designed and tuned for applications requiring surveillance in scenes with varying light levels, the AUTODOME IP starlight 5000i camera has an integrated 30X optical zoom to identify people at a maximum distance of 183 m (600 ft) with minimal loss of detail.

  • Page 15: Preparing Wiring

    AUTODOME IP starlight 5000i (pendant) Preparing Wiring | en Preparing Wiring Prepare and install all wiring for 24 VAC, PoE (Cat5e or better), alarms, and audio as necessary. For 24 VAC, follow the recommendations for maximum cable distance and wire gage.

  • Page 16: Preparing The Camera

    | Preparing the Camera AUTODOME IP starlight 5000i (pendant) Preparing the Camera Note: For pendant models, use T15. For in-ceiling models, use T10. Loosen the three (3) Hex screws in the trim ring / bubble enclosure with the appropriate Torx screwdriver.

  • Page 17: Installing A Microsd Card (Optional)

    AUTODOME IP starlight 5000i (pendant) Installing a microSD card (optional) | en Installing a microSD card (optional) Push the camera block until you see the card slot (item 1 in the following figure). Insert the card into the slot (item 2 in the following figure).
  • Page 18 | Installing a microSD card (optional) AUTODOME IP starlight 5000i (pendant) 3× Proceed with installation. 2023-02 | 1.4 | F.01U.413.551 Bosch Security Systems Installation Manual...

  • Page 19: Installing A Camera Directly To An Indoor Wall

    AUTODOME IP starlight 5000i (pendant) Installing a Camera Directly to an Indoor Wall | en Installing a Camera Directly to an Indoor Wall Installation Requirements – The wall is thick enough to install the mounting screws. – The wall can sustain at least eight (8) times the weight of the camera (1.88 kg (4.14 lb)): >...
  • Page 20 | Installing a Camera Directly to an Indoor Wall AUTODOME IP starlight 5000i (pendant) Thread all connection cables through the mounting cap. Attach the hook at the end of the Safety Tether to the loop attached to the top of the camera.
  • Page 21 AUTODOME IP starlight 5000i (pendant) Installing a Camera Directly to an Indoor Wall | en Bosch Security Systems 2023-02 | 1.4 | F.01U.413.551 Installation Manual...

  • Page 22: Installing A Surveillance Cabinet And Camera

    | Installing a Surveillance Cabinet and Camera AUTODOME IP starlight 5000i (pendant) Installing a Surveillance Cabinet and Camera The surveillance cabinet can attach directly to a wall, to a corner mount, or to a pole mount. To install the cabinet (power supply box), follow the instructions in the Surveillance Cabinet Installation Manual .
  • Page 23 AUTODOME IP starlight 5000i (pendant) Installing a Surveillance Cabinet and Camera | en Bosch Security Systems 2023-02 | 1.4 | F.01U.413.551 Installation Manual...
  • Page 24 | Installing a Surveillance Cabinet and Camera AUTODOME IP starlight 5000i (pendant) 2023-02 | 1.4 | F.01U.413.551 Bosch Security Systems Installation Manual...

  • Page 25: Installing A Roof Mount And Camera

    AUTODOME IP starlight 5000i (pendant) Installing a Roof Mount and Camera | en Installing a Roof Mount and Camera Installing the Roof Mount Determine the wall location on the roof for the camera and use the pendant parapet mount bracket as a template to mark the hole locations.

  • Page 26: Attaching The Mounting Cap And The Camera

    | Installing a Roof Mount and Camera AUTODOME IP starlight 5000i (pendant) Attach the pendant parapet mount bracket using at least six (6) stainless steel fasteners, three (3) on each side. (The bracket has eight (8) holes.) Be careful not to overtighten the fasteners because it may strip the threads.
  • Page 27 AUTODOME IP starlight 5000i (pendant) Installing a Roof Mount and Camera | en Thread all connection cables through the mounting cap. Attach the hook at the end of the Safety Tether to the loop attached to the top of the camera.
  • Page 28 | Installing a Roof Mount and Camera AUTODOME IP starlight 5000i (pendant) 2023-02 | 1.4 | F.01U.413.551 Bosch Security Systems Installation Manual...

  • Page 29: Installing A Pipe Mount And Camera

    AUTODOME IP starlight 5000i (pendant) Installing a Pipe Mount and Camera | en Installing a Pipe Mount and Camera Notice! Indoor use only! This mount shall only be installed indoors. No outdoors installation is permitted. 10.1 Tools Required – Appropriate tool for cutting a hole in drywall –...

  • Page 30: Attaching The Mounting Cap And The Camera

    | Installing a Pipe Mount and Camera AUTODOME IP starlight 5000i (pendant) 10.4 Attaching the Mounting Cap and the Camera To ensure a watertight seal, wrap Teflon tape () four times around the threads at the end of the mount.
  • Page 31 AUTODOME IP starlight 5000i (pendant) Installing a Pipe Mount and Camera | en Bosch Security Systems 2023-02 | 1.4 | F.01U.413.551 Installation Manual...
  • Page 32 | Installing a Pipe Mount and Camera AUTODOME IP starlight 5000i (pendant) 2023-02 | 1.4 | F.01U.413.551 Bosch Security Systems Installation Manual...

  • Page 33: Connection

    AUTODOME IP starlight 5000i (pendant) Connection | en Connection Warning! Bosch’s version of High PoE: If supplying power to the camera by HPoE or a midspan device, you must install additional surge protection. Caution! Compliance with EN50130-4 Alarm Standard - CCTV for Security Applications To meet the requirements of the EN50130-4 Alarm Standard, an ancillary uninterruptable power (UPS) supply is necessary.
  • Page 34 | Connection AUTODOME IP starlight 5000i (pendant) Label ID Description Cable Wire Color ALARM_COM Alarm Communications Red ALARM_OUT Alarm Out Brown ALARM_IN1 Alarm In 1 White ALARM_IN2 Alarm In 2 Blue AUDIO OUT Audio Out Grey Ground Black AUDIO GND...

  • Page 35: Decommissioning

    The device should only be passed on together with this Installation manual. 12.2 Disposal Disposal - Your Bosch product was developed and manufactured with high-quality material and components that can be recycled and reused. This symbol means that electronic and electrical appliances, which have reached the end of their working life, must be collected and disposed of separately from household waste material.

  • Page 36: Support

    Troubleshooting – Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ 2023-02 | 1.4 | F.01U.413.551 Bosch Security Systems Installation Manual...
  • Page 37 AUTODOME IP starlight 5000i (pendant) Support | Bosch Security Systems 2023-02 | 1.4 | F.01U.413.551 Installation Manual...
  • Page 38 | Support AUTODOME IP starlight 5000i (pendant) 2023-02 | 1.4 | F.01U.413.551 Bosch Security Systems Installation Manual...
  • Page 40 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2023 Building solutions for a better life. 202302102103...
