6 | Concentric Horizontal Vent Kit
2 Scope Of Delivery
The Bosch Greenstar Concentric Vent Kit comes packaged in two separate
boxes as described below.
87°
Ø3.1"
[80]
(O.D.)
Ø4.9"
[125]
(O.D.)
Box 2 components
Ø5.0"
[127]
(I.D.)
Ø3.2"
[81]
(I.D.)
6
Ø3.1"
[80]
(O.D.)
Ø6.3"
[160]
(O.D.)
Fig. 1 Scope of delivery - dimensions in inches (mm)
Fig.1 Legend:
Box 1 components:
1 90° elbow
2 Telescopic terminal assembly
3 Inner wall seal
4 Outer wall seal
5 Connecting/securing screws and wall anchors
Box 2 components:
6 Appliance adapter
Data subject to change
Box 1 components
2.5"
2.5
1.6"
1.6
0.4"
Ø3.2"
Ø5.0"
128
[81]
81
[127]
5.0
3.2
(I.D.)
(I.D.)
(I.D.)
(I.D.)
1
2.9"
75
[75]
2.9
4
3
8" (200)
Ø 4⅝" (119 )
Installation Manual
2
5
2x
4x
3x
Bosch Thermotechnology Corp.
