Installation Manual
DANGER : Danger from escaping flue gases
Ensure all vent pipes and chimneys are not damaged or
f
blocked.
Connect only one appliance to each vent system or
f
chimney liner.
The venting system piping must not feed into another air
f
exhaust duct.
Do not route the flue system piping through or inside
f
another air exhaust duct.
WARNING: Combustion air
Keep the combustion air free of corrosive substances
f
(halogenated hydrocarbons that contain chlorine or
fluorine compounds).
WARNING: Maintenance
Customers are advised to:
Sign a maintenance and inspection contract with an
f
authorized contractor. Inspect and maintain the gas
appliance as necessary and on a yearly basis. Service as
needed.
Use only genuine spare parts.
f
DANGER: Fatal accidents!
Carbon monoxide poisoning.
Carefully plan where you install the gas appliance.
f
Correct combustion air supply and flue pipe installation
are very important. If a gas appliance is not installed
correctly, fatal accidents can result such as carbon
monoxide poisoning or fire.
DANGER: Carbon monoxide poisoning.
Exhaust gas must be vented to outside using approved
f
vent material. (In Canada use only ULCS636 approved
material). Vent and combustion air connector piping
must be sealed gas-tight to prevent flue gas spillage,
carbon monoxide emissions and risk of fire, resulting
in severe personal injury or death. Approved vent
terminations must be used when penetrating to the
outside.
Bosch Thermotechnology Corp.
Concentric Horizontal Vent Kit | 5
WARNING:
Do not obstruct the flow of combustion and ventilation
f
air.
NOTICE:
The complete installation must comply with national,
f
state, and local code. The installation instructions in
both the gas appliance installation manual and this vent
system installation manual must be followed exactly.
NOTICE:
The concentric horizontal vent terminal is intended for
f
installation only with the
Bosch Greenstar and Bosch
Greenstar combi boilers
(hereafter referred to as
"appliance"):
- Greenstar Combi 100 ZWB28-3A23S3123
- Greenstar Combi 131 ZWB35-3A23S3123
- Greenstar Combi 151 ZWB42-3A23S3123
- Greenstar 57 ZBR16-3A23S3123
- Greenstar 79 ZBR21-3A23S3123
- Greenstar 100 ZBR28-3A23S3123
- Greenstar 131 ZBR35-3A23S3123
- Greenstar 151 ZBR42-3A23S3123
Data subject to change
