Refrigerator (Household use) 使用說明書 雪櫃 (家用) NR-E431GT-N3 Model No. 中 文 型號 Thank you for purchasing this Panasonic product. Please read these instructions carefully before using this product. Please keep this manual for future reference. 感謝您購買 Panasonic 的產品。 在使用本產品前,請仔細閱讀本說明書。 請妥善保存本手冊以備將來參考。...
Introduction Safety instructions What the symbols mean. Indicates the appliance must be Do not earthed to prevent electric shock Make sure you do this Do not take apart iso-butane 異丁烷 Indicates risk of death or serious injury. WARNING This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 4
Introduction When using... ● Do not hang or ride on the door. ● Do not apply water on the body or interior. (Otherwise, electrical insulation deteriorates and may cause shocks or fire.) ● WARNING: Do not damage the refrigerant circuit. (Otherwise, the flammable refrigerant may catch fire and lead to an explosion.) ●...
Page 5
Introduction ● If you detect a gas (such as city gas) leak, do not touch the refrigerator and open the windows to ventilate the kitchen. ● A flammable refrigerant is used. If you have damaged the cooling circuit (piping), open the windows to ventilate the kitchen and contact your dealer.
Installation Installation Choosing the right location 1. Place the refrigerator in the following locations. ● ● Locations free from heat and direct sunlight Locations where allow a heat to dissipate Minimize reduction of cooling power, and prevent The back surface may be fitted to the wall. electricity waste.
Page 7
Installation 3. Plug into a wall outlet. Plug into a wall outlet of the rated voltage on its own with the rated current and insert plug fully. ● The power plug can be plugged into an outlet immediately after installation. ●...
Operation To use all features Control panel Notice indicator (P. 19) • Occurrence of abnormality, demo mode. FRESH FREEZING (P. 11) QUICK ICE MAKING (P. 13) AUTO ICE OFF (P. 13) Refrigerator compartment Chilled room Fresh Freezing compartment compartment Freezer compartment ●...
Operation Foods stored Refrigerator For regular storage of food and drinks or Approx. 3 °C ~ 6 °C compartment temporary storage of those to be served soon. For storage of meat, fish, processed foods Approx. 0 °C ~ 2 °C Chilled room (such as hams and sausages) or dairy products.
Operation Refrigerator compartment Room lamp (LED) Glass shelf Door shelf (5) Duct Free set shelf Egg tray (for 15 eggs) Bottle shelf Partition shelf Control panel Chilled room (P. 8) ● Some food may be partially frozen. Reposition the food or set the refrigerator compartment temperature to “1”.
Operation The position of the second glass shelf from the top can be changed. Lift up the back of the shelf and pull it forward. Insert the shelf in the desired position by reversing the steps. ● Glass shelves are heavy. Please handle them with care so that they do not fall and cause any damage or injury. How to use the free set shelf Raise the front half and bend it back.
Operation Ice compartment Water supply tank Ice-making tray approx. 1.2 liters Back Automatic ice maker Ice storage box Front Water purification filter Sound-proof mat (Do not remove it.) Ice shovel (Provided in front of the box.) To use the automatic ice maker in comfort Please use only the drinking water for auto ice making.
Page 13
Operation Ice can be made in approx. 2 hours! To make ice Take out the water supply tank Add water if the level is below the “給水” line. (Replace the water in the water supply tank at least once a week.) Water supply tank Fill with water Add water up to the “満水”...
Operation Freezer compartment ● A lot of frozen food and cooked meal can be stored. Requests ● For the upper case of the freezer, put your food within the height of Freezer case (Upper) the case. ● For the lower case of the freezer, put your food below the upper limit line (↓食品はここまで↓) marked inside the case.
Appendix Cleaning, removing and re-installing Conduct periodic cleaning and maintenance to ensure that the refrigerator will be kept clean and that it will continue to operate for a long time. Before cleaning or conducting maintenance, be absolutely sure to disconnect the power plug from the wall outlet. Do not connect or disconnect the power plug with wet hands.
Page 16
Appendix Glass shelf / Free set shelf Once every 3 months ■ ■ Glass shelf (top shelf ) Free set shelf (the third shelf from the top) Unhook the protrusion at the back and pull the shelf. Stack the front part on the back part and pull it upward. Protrusion Protrusion Glass shelf...
Page 17
Appendix Water supply tank / Water purification filter Once a week Remove the lid and clean Turn the water purification Gently rinse the water Remove the packing the water supply tank with filter to unhook and purification filter. running on the edges from water.
Appendix In these cases? ● The power failed. Keep the doors closed and do not store additional food. ● [FRESH FREEZING] and [QUICK ICE MAKING] stop. Set these functions again to use after power recovery. ● The power plug was Wait at least 7 minutes, and then plug in the power plug.
Page 19
Appendix ● The automatic ice maker Stop ice making, with the water supply tank empty, and clean the ice maker. is not used for a long time. Discard water in the water supply tank. → W hen starting to use Press [AUTO ICE OFF] button for 3 seconds and stop ice the automatic ice making.
Appendix Setting to suit your preferences To adjust the temperature in more detail ■ The temperature for refrigerator compartment and freezer compartment can be set in 9 stages, more detailed than as “ 1 ”, “ 2 ” and “ 3 ”. (ECO NAVI does not operate when the temperature is adjusted in detail.) Setting Stage...
Appendix Troubleshooting If you feel that the refrigerator is not working properly, check out the following points first. If the trouble persists, disconnect the power plug and contact your dealer or an authorized service center. The following sounds are not abnormal. From inside the refrigerator.
Page 22
Appendix ● Rattling noise Is the floor stout and flat? (P. 6) ● Do both the legs reach the floor and is the refrigerator properly fixed? (P. 6) ● Do the sides of the refrigerator not touch the walls or furniture around the refrigerator? (P.
Page 23
Appendix Does not get cold at all ● Is it indicated in the notice indicator area of the control panel? (P. 19) ● When you use the refrigerator for the first time, from 4 to 24 hours or even more are required until the refrigerator begins to cool. ●...
Appendix ECO NAVI Q&A ● ECO NAVI by itself operates depending on the brightness around the When does ECO NAVI refrigerator, the change in the compartment temperature, frequency of door operate? opening and closing and the change in the storage amount. (ECO NAVI lamp lights up during ECO NAVI operation.) ●...
Appendix Specifications MODEL NR-E431GT-N3 TOTAL GROSS VOLUME 440 L TOTAL STORAGE VOLUME 335 L STORAGE FRIDGE VOLUME 198 L STORAGE ICE VOLUME STORAGE FRESH FREEZING VOLUME 11 L STORAGE FREEZER VOLUME 56 L STORAGE VEGETABLE VOLUME 65 L OUTSIDE DIMENSIONS 600 mm ×...
