Operations
Unit (AIR-SA15R/Wireless Speaker System)
Setting the clock
Changing the display
Use buttons on the unit to set the clock.
To change the information on the display
1
Turn on the unit.
while the unit is on
Press
.
Press DISPLAY
2
button, the display changes as follows:
Select the clock set mode.
Press CLOCK/TIMER MENU
. If the current
When the unit is connected to an S-AIR main unit:
mode appears on the display, press /
Information of the connected S-AIR main unit
repeatedly to select "CLOCK, " and then press
Model name of the connected S-AIR main unit
CLOCK/TIMER ENTER
.
Clock
...
2)
3
Set the time.
When the unit is not connected to an S-AIR main unit:
"S-AIR" "UNLINKED"
Press /
repeatedly to set the hour, and
then press CLOCK/TIMER ENTER
. Use the
1)
The displayed information depends on the connected S-AIR main
same procedure to set the minute.
unit. Up to 16 characters can be displayed.
The clock settings are lost when you disconnect the
2)
Displayed for about 8 seconds.
power cord or if a power failure occurs.
To turn off the display
When the unit is turned off, the clock is displayed. You
can turn off the clock display to minimize the amount of
Listening to the sound of the
power consumed (Power Saving Mode).
connected S-AIR main unit
Press DISPLAY
displayed.
You can use the S-AIR function to listen to the sound of
Press the button again to display the clock.
an S-AIR main unit in a remote location.
Note
1
Perform the procedure described in "Establishing
The STANDBY indicator on the unit lights up when the unit is
the connection with an S-AIR main unit" and check
off.
that the S-AIR indicator
is lit.
2
Press S-AIR CH
repeatedly to select the desired
S-AIR channel of the S-AIR main unit.
Using the Timers
The unit offers two timer functions. If you use the
Daily Timer with the Sleep Timer, the Sleep Timer has
priority.
Use buttons on the unit to set the timers.
Sleep Timer:
You can fall asleep to music. This function works even if
Wireless strength
the clock is not set.
Press SLEEP
The S-AIR channels that can be selected depend
on the S-AIR main unit. For details, refer to the
Note
Operating Instructions supplied with the S-AIR main
Even if you set the timer, no sound is output from the unit if
playback on the connected S-AIR main unit ends within the set time
unit.
period or if communication with the S-AIR main unit is cut off.
3
Press VOLUME +/
to adjust the volume.
Daily Timer:
To operate the S-AIR main unit from the unit
You can wake up to the sound of the connected S-AIR
You can perform the following operations using the
main unit at a preset time.
buttons on the remote or unit.
Make sure you have set the clock.
1
Press VOLUME +/
To
Press
volume level while viewing the volume level
Start playback of a CD/DVD,
.
indication on the display.
etc.
2
Press CLOCK/TIMER MENU
Stop playback of a CD/DVD,
/CANCEL
.
etc.
3
Press /
then press CLOCK/TIMER ENTER
Pause playback of a CD/DVD,
.
etc.
"ON TIME" appears, and the hour indication flashes.
/
Select a track, file or chapter
.
4
Set the time to start playing.
of a CD/DVD, etc.
Press /
Select a preset station when
PRESET +/
.
then press CLOCK/TIMER ENTER
listening to the radio
The minute indication flashes. Use the procedure
Change the FM/AM band
Hold down S-AIR
above to set the minute.
when listening to the radio.
CH
until the band
5
Use the same procedure as in step 4 to set the time
changes.
to stop playing.
Depending on the connected S-AIR main unit,
the operation may differ. Refer to the Operating
Instructions of the S-AIR main unit.
To listen with headphones
Connect headphones (not supplied) to the
(headphones) jack located on the rear panel of the unit.
Note
The elapsed playing time or remaining playing time of the
CD/DVD, etc. being played on the S-AIR main unit may not
be displayed on this unit. In this case, "." appears.
6
Press /
option.
The default setting is underlined.
ALARM:
An alarm is output.
on the unit. Each time you press the
AUTO:
Sound from the connected S-AIR main unit is
1)
output. However, an alarm sounds in the following
2)
cases.
When communication with the S-AIR main unit
is cut off.
When no sound is output from the S-AIR main
2)
Clock
2)
...
unit or the audio signal level is too low.
When the S-AIR main unit is not ready for
playback at the set start time. Note that the alarm
continues to sound even if the S-AIR main unit
becomes ready after the start time has passed.
7
Press CLOCK/TIMER ENTER
The display shows the timer settings.
8
If you selected "ALARM" in step 6, go to step 9.
on the unit when the clock is
If you selected "AUTO" in step 6, prepare the sound
source on the S-AIR main unit.
For details on preparing the sound source, refer to
the Operating Instructions supplied with the S-AIR
main unit.
9
Press
to turn off the unit.
The unit turns on about 45 seconds before the preset
time.
If the unit is on at the preset time, the Daily Timer
will not play.
To stop the alarm
Press any button.
To activate or check the timer again
1
Press CLOCK/TIMER MENU
"SELECT" flashes in the display.
repeatedly.
2
Press CLOCK/TIMER ENTER
3
Press /
4
Press CLOCK/TIMER ENTER
To cancel the timer
1
Press CLOCK/TIMER MENU
"SELECT" flashes in the display.
2
Press CLOCK/TIMER ENTER
repeatedly to adjust the
3
Press /
4
Press CLOCK/TIMER ENTER
.
To change the setting
repeatedly to select "TIMER, "
Start over from step 1.
.
Tip
The Daily Timer setting remains as long as the setting is not canceled
manually.
repeatedly to set the hour, and
.
Remote (RM-ANU046)
repeatedly to select the desired
Turning off the remote control
function
In addition to the unit you already have, you can
connect other S-AIR sub units to a single S-AIR main
unit and use them together.
However, when using multiple S-AIR sub units near
each other, all the S-AIR sub units may receive the same
signal from the remote and the connected S-AIR main
unit may not function properly. To prevent this, you can
turn off the remote control function of the S-AIR sub
units.
Use buttons on the S-AIR sub unit whose remote
control function you want to turn off.
1
Press
to turn off the unit.
2
Press DISPLAY
repeatedly until the clock is
displayed.
3
Press
.
while holding down CLOCK TIMER/
ENTER
.
"RMT OFF" appears in the display and the unit is
turned on. If you try controlling the unit using the
remote, "RMT OFF" appears in the display and the
unit will not accept the signal from the remote.
To turn on the remote control function
Perform steps 1 and 3 above and check that "RMT ON"
appears in the display.
Note
Even when the remote control function is turned off,
and VOLUME +/
on the remote will continue to
function.
.
.
repeatedly to select "TIMER. "
.
.
.
repeatedly to select "OFF. "
.
Troubleshooting
1
Make sure the power cord is correctly and firmly
connected.
2
Find your problem in the checklist below, and take
the indicated corrective action.
If the issue persists, contact your nearest Sony dealer.
When bringing this unit in for repairs, be sure to
bring in the entire system (this unit, the S-AIR main
unit and wireless transceivers).
This product is a system product, and the entire
system is needed to determine the location requiring
repair.
If the STANDBY indicator flashes
Immediately unplug the power cord, and check if
anything is blocking the ventilation holes on the rear
panel of the unit.
After the STANDBY indicator
stops flashing,
reconnect the power cord, and turn on the unit. If the
issue persists, contact your nearest Sony dealer.
The remote does not function.
Remove any obstacles between the remote and the
remote sensor
on the unit, and position the unit
away from fluorescent lights.
Point the remote at the remote sensor
on the unit.
Move the remote closer to the unit.
The remote control function is off. Turn on the remote
control function.
The S-AIR indicator
is turned off.
Check that the power cord is connected securely and
the unit is turned on.
Check that the supplied wireless transceiver is inserted
securely to the unit.
Connecting the unit and S-AIR main unit is not
possible. (The S-AIR indicator
flashes.)
Check that the supplied wireless transceiver is inserted
securely to the unit.
If you use another S-AIR main unit, place it more than
8 m (26
1
/
feet) away from the S-AIR main unit you
4
are using.
Confirm the S-AIR IDs of the unit and the S-AIR
main unit.
The unit is paired with another S-AIR main unit. Pair
the unit with the S-AIR main unit you are using.
The unit is paired with another S-AIR main unit.
Cancel pairing.
Place so that the unit and the S-AIR main unit are
separated from other wireless devices.
Stop using any other wireless devices.
The connected S-AIR main unit is turned off. Make
sure the power cord is connected and turn on the S-
AIR main unit.
The S-AIR channel fails to change.
Check that the unit and the S-AIR main unit are
connected properly.
There is no sound.
If you use another S-AIR main unit, place it more than
8 m (26
1
/
feet) away from the S-AIR main unit you
4
are using.
Confirm the S-AIR IDs of the unit and the S-AIR
main unit.
Check the pairing setting.
Place so that the unit and the S-AIR main unit are
closer.
Stop using any equipment that generates
electromagnetic energy such as a microwave oven.
Place so that the unit and the S-AIR main unit are
separated from other wireless devices.
Stop using any other wireless devices.
Change the S-AIR ID settings of the unit and the S-
AIR main unit.
Turn off the unit and S-AIR main unit and then turn
them on again.
Check that the power cord is connected securely and
the unit is turned on.
Increase the volume of the unit.
Check that headphones are not connected to the
(headphones) jack on the rear panel of the unit.
There is noise or the sound skips.
If you use another S-AIR main unit, place it more than
8 m (26
/
feet) away from the S-AIR main unit you
1
4
are using.
Place so that the unit and the S-AIR main unit are
closer.
Stop using any equipment that generates
electromagnetic energy such as a microwave oven.
Place so that the unit and the S-AIR main unit are
separated from other wireless devices.
Stop using any other wireless devices.
Change the S-AIR ID settings of the unit and the S-
AIR main unit.
Do not place a mobile phone near the unit and the
S-AIR main unit, as this may result in noise.
To reset the unit to factory settings
If the unit still does not operate properly, reset the unit
to factory settings.
1
Disconnect and reconnect the power cord, and
then turn on the unit.
2
Press /CANCEL
, DISPLAY
and
on
the unit at the same time.
All user-configured settings, such as timer, clock, etc.
are deleted.
Messages
CANCEL : Time out without pairing.
COMPLETE : Pairing is completed.
ID A : Sets the S-AIR ID to "A. "
ID B : Sets the S-AIR ID to "B. "
ID C : Sets the S-AIR ID to "C. "
LINKED : The unit is connected to the S-AIR main unit.
PAIRING : Pairing is in progress.
RMT OFF : The unit is not accepting signals from the
remote because the remote control function is set to
"RMT OFF. "
S-AIR : Displayed from the point power of the unit is
turned on until connection with the S-AIR main unit
is established.
TIME NG : The Daily Timer start and end times are set
to the same time.
UNLINKED: The connection with the S-AIR main unit
is cut off.
Specifications
Amplifier section
U.S.A. model:
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 3 ohms loads, both channels driven, from
300 20,000Hz; rated 4 watts per channel minimum
RMS power, with no more than 10% total harmonic
distortion from 250 milliwatts to rated output.
Other models:
Continuous RMS power output (reference):
4 + 4 watts (3 ohms at 1 kHz, 10% THD)
Output
(stereo mini jack): Accepts headphones with an
impedance of 8 ohms or more
Speaker section
Speaker system: Full range, bass-reflex type
Speaker units: 65 mm, cone type (2)
Nominal impedance: 3 ohms
Wireless transceiver (EZW-RT10)
Communication System: S-AIR Specification version 1.0
Output: 12.0 milliwatts
Frequency band: 2.4000 GHz 2.4835 GHz
Modulation method: DSSS
Power requirements: DC 3.3 V, 350 mA
Dimensions (w/h/d): 50 × 13 × 60 mm (2 ×
17
/
×
32
2
/
in)
3
8
Mass: 24 g (1 oz)
General
Power requirements: 120 V AC, 60 Hz
Power consumption: 15 watts
Dimensions (w/h/d): Approx. 300 × 136 × 115 mm
(11
7
/
× 5
3
/
× 4
5
/
in)
8
8
8
Mass: Approx. 2.2 kg (4 lb 14 oz)
Supplied accessories: Wireless transceiver EZW-RT10
(1)/Remote commander (RM-ANU046) (1)/R03 (size
AAA) batteries (2)
Design and specifications are subject to change without
notice.
Halogenated flame retardants are not
used in the certain printed wiring
boards.
Advertisement
