DVP-NS72HP/NS77H//NS77HP/NS78H/NS78HP
SERVICE MANUAL
System
Laser: Semiconductor laser
Signal format system:
NTSC: (DVP-NS72HP/NS77H:US/
NS77HP:MX/NS78H:CND/
NS78HP:E,BR)
PAL/NTSC: (DVP-NS78H:
AEP,KR,RUS,SP,UK,TH)
Audio characteristics
Frequency response: DVD VIDEO (PCM
48 kHz): 2 Hz to 22 kHz (±0.5 dB)/
CD: 2 Hz to 20 kHz (±0.5 dB)
Wow and flutter: Less than detected value
(±0.001% W PEAK)
Outputs
(Jack name: Jack type/Output level/
Load impedance)
LINE OUT (AUDIO): Phono jack/
2 Vrms/ 10 kilohms
DIGITAL OUT (OPTICAL)
EXCEPT
(DVP-NS78H:AEP,RUS,UK)
Optical output jack/–18 dBm
(wave length 660 nm)
DIGITAL OUT (COAXIAL): Phono jack/
0.5 Vp-p/75 ohms
HDMI OUT: HDMI 19 pin-Standard
Connector
Photo : DVP-NS78H
SPECIFICATIONS
COMPONENT VIDEO OUT
(Y, P
, P
) (DVP-NS72HP/
B
R
NS77H:US/NS77HP:MX/
NS78H:CND/NS78HP:E,BR):
Phono jack/Y: 1.0 Vp-p/P
interlace
= 0.648 Vp-p, progressive or
*1
interlace
*2
= 0.7 Vp-p/75 ohms
*1
BLACK LEVEL
(COMPONENT OUT) is ON
*2
BLACK LEVEL
(COMPONENT OUT) is OFF
COMPONENT VIDEO OUT
(Y, P
/C
, P
/C
)
B
B
R
R
(DVP-NS78H:AEP,UK,KR,RUS,SP,TH):
Phono jack/Y: 1.0 Vp-p,
P
/C
, P
/C
: 0.7 Vp-p/75 ohms
B
B
R
R
LINE OUT (VIDEO): Phono jack/
1.0 Vp-p/75 ohms
S VIDEO OUT
(DVP-NS77H:US/NS77HP:MX/
NS78H:CND/NS78HP:E,BR/
NS72HP:US):
4-pin mini DIN/Y: 1.0 Vp-p,
C: 0.286 Vp-p/75 ohms
S VIDEO OUT
(DVP-NS78H:KR,SP,TH):
4-pin mini DIN/Y: 1.0 Vp-p,
C: 0.3 Vp-p (PAL),
0.286 Vp-p (NTSC)/75 ohms
RMT-D175A/RMT-D175P
General
Power requirements:
120 V AC, 60 Hz
(DVP-NS72HP/NS77H:US/
NS77HP:MX/NS78H:CND)
, P
:
B
R
220 – 240 V AC, 50/60 Hz
(DVP-NS78H:AEP,RUS,UK)
110 – 240 V AC, 50/60 Hz
(DVP-NS78H:KR,SP,TH/NS78HP:E/BR)
Power consumption: 11W
Dimensions (approx.):
430 × 43 × 210.4 mm
(17 × 1
(width/height/depth) incl. projecting parts
Mass (approx.): 1.76 kg (3
Operating temperature: 5°C to 35°C
Operating humidity: 25% to 80%
Supplied accessories
Audio/video cord (1)
Remote Commander (remote) (1)
R6 (size AA) batteries (2)
HDMI Cord (1) (DVP-NS72HP:US/
NS77HP:MX/NS78HP:E,BR)
A plug adaptor is included in some models
(DVP-NS78HP:E)
Specifications and design are subject to
change without notice.
CD/DVD PLAYER
AEP Model
DVP-NS78H
Brazilian Model
DVP-NS78H/NS78HP
Canadian Model
DVP-NS78H
E Model
DVP-NS78HP
Korea Model
DVP-NS78H
Mexican Model
DVP-NS77HP
Russian Model
Singapore Model
Thailand Model
UK Model
DVP-NS78H
US Model
DVP-NS72HP/NS77H
× 8
/
/
in.)
11
2
16
7
/
Ib.)
7
8
