3 Operation of Buttons

5
6
7
4
Figure 1
1. ON/OFF: Press this button to turn the system ON or OFF.
2. MODE: Change mode of operation.
AUTO COOL
3. FAN: Change fan speed.
AUTO LOW
You can not switch the fan speed in AUTO or DRY mode
4. ADJUST: Used to adjust setting.
Bosch Thermotechnology Corp. | 06.2019
Swing Timer Day off/Del
-
DRY HEAT FAN
MED HIGH
Bosch Climate 5000 Series Wired Wall Thermostat | 5
Copy/
Confirm Back/Turbo
Follow me
Mode
+
Fan speed
(Lock)
5. SWING: Adjust louver angle (Wall Mounted and Cassette type indoors only).
6. TIMER: Set up On/Off Timer, 7-Day schedule.
7. DAY OFF/DEL: Used to skip day during 7-Day scheduling or delete saved set up.
8. CONFIRM: Used to save setting change.
9. BACK/TURBO: To go back to previous page or select Turbo mode.
10. COPY/FOLLOW ME: Copy the setting or activate Follow Me function.
10
9
8
2
1
4
3
