Motherboard Replacement Overview - Canon imagePRESS Server F200 Installation And Service Manual

You suspect a faulty motherboard
or hard disk drive.
Replace the hard disk drive.
Reinstall system software.
Problem solved?
No.
Reinstall old hard disk drive.
Replace the motherboard.
Connect the
motherboard replacement dongle.
Enter Service Mode and
verify the new motherboard
installation.
See page 55
R
EPLACING PARTS

Motherboard replacement overview

See page 68
See page 84
Yes.
See page 68
See page 51
Are test pages
printed successfully?
N
OTE
reference includes more
information for each task.
Reassemble system and verify functionality.
Transfer options and
BIOS information to the
new motherboard.
Yes.
No. Reinstall the old motherboard.
Return the new motherboard and
: Each page
See page 56
dongle to inventory.
