Form No. 3371-290 Rev A
1/3 Area Platform Lift
Workman
®
Heavy-Duty Utility Vehicle
Model No. 07347—Serial No. 311000001 and Up
To register your product or download an Operator's Manual or Parts Catalog at no charge, go to www.Toro.com.
Original Instructions (EN)

Advertisement

Table of Contents
loading

Related Manuals for Toro Workman 07347

Summary of Contents for Toro Workman 07347

  • Page 1 Form No. 3371-290 Rev A 1/3 Area Platform Lift Workman ® Heavy-Duty Utility Vehicle Model No. 07347—Serial No. 311000001 and Up To register your product or download an Operator's Manual or Parts Catalog at no charge, go to www.Toro.com. Original Instructions (EN)

  • Page 2: Table Of Contents

    4 Mount the Parking Brake Switch......8 additional information, contact an Authorized Service 5 Mount Rear Level Switch ........9 Dealer or Toro Customer Service and have the model 6 Reinstall Hood ..........10 and serial numbers of your product ready.

  • Page 3: Safety

    Such • Do not use platform lift during lightning, use could void the product warranty of The Toro® thunderstorms, or high winds. Company. • Never move vehicle while platform is raised.

  • Page 4: Safety And Instructional Decals

    Safety and Instructional Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or lost. 93-3701 93-3702 93-3710 93-3704 93-3711...
  • Page 5 93-3703 93-3705 93-3707 93-3706 93-3709...

  • Page 6: Setup

    Installation Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Qty. Remove the seat, shroud and fender – No parts required assemblies – No parts required Remove the hood Main Wire Harness w/ Relays Cable Tie Screw, 1/4 x 3/4 inch Install main wire harness w/relays...

  • Page 7: Remove The Seat, Shroud And Fender Assemblies

    CAUTION Pressurized hot coolant escaping can cause serious burns. Remove the Seat, Shroud and Allow engine to cool enough to touch before removing overflow tube or radiator cap. Fender Assemblies 6. Remove the capscrews securing the seats and shroud to mounting brackets (Figure 3). Remove the seats No Parts Required and shroud.

  • Page 8: Install The Main Wire Harness W/Relays

    Screw, 1/4 x 3/4 inch Nut, 1/4 inch 2. Locate an empty slot in the fuse block. If no empty slot is available, an additional fuse block (Toro part Fuse no. 92–2641) will have to be added. 3. Insert the included fuse into the empty fuse block For Workman 3000–4000 series...

  • Page 9: Mount The Parking Brake Switch

    mounting holes, mount the level switch bracket to rear axle with the locknuts previously removed. Mount the Parking Brake Switch Parts needed for this procedure: Parking brake switch Screws Procedure 1. Mount the parking brake switch to the parking brake G016822 mount with two screws as shown in Figure 5.

  • Page 10: Reinstall Hood

    Figure 8 G016821 1. Hitch frame extension tube Figure 7 2. Locate and remove the threaded insert from the 1. Hitch plate 2. Level switch bracket mounting hole in left and right vehicle frame channels, as shown in Figure 9. 2.

  • Page 11: Connect Wires

    5. Connect ground wire from lift to engine ground. 6. Remove the nut from the positive battery clamp (Figure 11). 7. Insert the positive wire from the lift and the ring terminal end of the red wire from the front harness onto the cable clamp screw and loosely secure it with the nut removed (Figure 11).

  • Page 12: Mount Circular Bubble Level

    Mount Circular Bubble Level Parts needed for this procedure: Circular Bubble Level Procedure Figure 13 Affix circular level to top of console cover positioning as 1. No—Step decal shown in Figure 12. For Workman HDX and HDX-D vehicles 1. Affix operation decal to top of console cover positioning as shown in Figure 12.

  • Page 13: Product Overview

    Emergency Lowering Valve Knob Product Overview Push the blue knob inward, rotate it 90 degrees Controls counterclockwise, and pull it out to activate the emergency lowering valve (Figure 16). To stop the lift and return it to normal operation, push the blue knob Up Button inward, rotate it 90 degrees clockwise and pull it out.

  • Page 14: Operation

    Check Tire Pressure Operation Check tire pressure every 8 hours or daily to assure Check Oil Level proper levels. Refer to the vehicle operator's manual for proper tire The lift reservoir is filled at the factory with 5W30 oil. inflation specification. Check level before lift is first operated and every 8 hours or daily, thereafter.

  • Page 15: Operating The Lift

    Operating the Lift The 1/3 platform lift is designed to be used only with a Workman Vehicle and must be mounted with the wiring harness, level, decals, switches and all interlock switches installed. DANGER Improper operation of platform lift may cause serious personal injury or death.
  • Page 16 If lift does not operate: • Make sure vehicle key and lift key are in "ON" position. • Make sure vehicle is parked on less than a 5 degree angle slope. • Make sure vehicle parking brake is "On". • Make sure vehicle engine is “OFF” and the oil pressure light is “ON”...

  • Page 17: Operating Tips

    Operating Tips DANGER Contact with moving scissor arms can cause The electrical system, battery and hydraulic lift cylinder personal injury. are not designed for continuous use. Allow some time, approximately 1-1/2 to 2 minutes, between lift • Stand clear of scissor arms while platform operations to maintain operating temperatures.
  • Page 18 DANGER Falling objects and overhead obstructions can cause personal injury. • Always wear hard hat and eye protection while operating platform or while in area below platform. • Never drop or throw articles from raised platform. • When raising platform be alert for overhead obstructions which could cause eye, head or crushing injuries.

  • Page 19: Maintenance

    Maintenance Battery Care 1. Battery electrolyte level must be properly maintained Check Safety Circuits and the top of the battery kept clean. If the machine is stored in a location where temperatures are The electrical safety circuits of the lift require the vehicle extremely high, the battery will run down more to be parked on a slope of less than 5 degrees, parking rapidly than if the machine is stored in a location...
  • Page 20 WARNING CALIFORNIA Proposition 65 Warning Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Wash hands after handling. WARNING Charging the battery produces gasses that can explode.

  • Page 21: Schematics

    Schematics Electrical Schematic (Rev. B)
