Installing The Ct(U)-R Unit - NEC Electra Elite IPK II System Hardware Manual

Document Revision 3
___________________________________________________________________________________
ESI
ETU
Figure 9-25 Connecting a Multiline Terminal to a PC using a CT(U)-R Unit (Example)
___________________________________________________________________________________
9 - 24
This adapter can be installed on any Multiline Terminal except the DTR-2DT-1
TEL and ITH-8D/16D-2.
Figure 9-25 Connecting a Multiline Terminal to a PC using a CT(U)-R Unit
(Example) shows how the CT(U)-R Unit is connected to the ESI(8)-U( ) ETU
and to the PC. The required AC-2R/AC-3R Unit is not shown.
Multiline Terminal + CT(U)-R Unit
Line Cord (2-line)
3.5.1

Installing the CT(U)-R Unit

The CT(U)-R Unit should be installed after the switches are set.
When wall mounting the Multiline Terminal, a WM-R Unit must be
used. Refer to
8-29.
Installing Electra Elite IPK II Optional Terminal Equipment
Figure 9-24 CT(U)-R Unit
CT(U)-R Unit
Optional Headset
Section 13 Wall Mounting Multiline Terminals on page
Electra Elite IPK II
PC
USB Cable
