Sony ICF-CD2000 Marketing Operating Instructions

3-865-826-22 (1)
FM/AM CD Clock Radio
Operating Instructions
ICF-CD2000
Sony Corporation 1999
Printed in Malaysia
Owner's Record
Before You Begin
The serial number is located at the bottom.
Record the serial number in the space provided
Thank you for choosing a Sony CD clock radio!
below. Refer to them whenever you call upon
It will give you many hours of reliable service
your Sony dealer regarding this product.
and listening pleasure.
Before operating the CD clock radio, please read
Model No. ICF-CD2000
these instructions thoroughly and retain them for
Serial No.
future reference.
WARNING
Features
To prevent fire or shock
• PLL (Phase Locked Loop) synthesized travel
hazard, do not expose
clock radio with CD player.
• Wake up to your choice of alarm sound source
the unit to rain or
— CD (with selectable Wake-up track), radio
moisture.
(with selectable Wake-up station), or buzzer.
• Clock function for the traveller
— display the time in your destination with
You are cautioned that any changes or
the WORLD time function.
modifications not expressly approved in this
— display both the current time and the alarm
manual could void your authority to operate
time with the dual display.
this equipment.
• Simple radio operation with the Auto Station
Scan tuning and preset tuning. Preset tuning
stores up to 15 (10 FM, 5 AM) stations.
INFORMATION • Multi-functioned CD player — variety of
playback modes (repeat, shuffle, etc.) plus a
This equipment has been tested and found to
10-second Electronic Shock Protection
comply with the limits for a Class B digital
function to prevent skipping of sound.
device, pursuant to Part 15 of the FCC Rules.
• Stereo output from both the speakers and the
These limits are designed to provide reasonable
headphones.
protection against harmful interference in a
residential installation. This equipment
Note on AM channel step
generates, uses, and can radiate radio frequency
The AM channel step differs depending on areas.
energy and, if not installed and used in
The channel step of this unit is factory-set to
accordance with the instructions, may cause
10 kHz. Switch the channel step when using the
harmful interference to radio communications.
unit in areas with the 9 kHz frequency allocation
However, there is no guarantee that interference
system (see "Changing AM Channel Step").
will not occur in a particular installation. If this
equipment does cause harmful interference to
Area Channel step
radio or television reception, which can be
determined by turning the equipment off and North and South 10 kHz
on, the user is encouraged to try to correct the
American countries
interference by one or more of the following
Other countries 9 kHz
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the
equipment and receiver.
—Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/
TV technician for help.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
Precautions Specifications
CD player section
• Operate the unit on the power sources
specified in "Specifications." System
• The nameplate indicating voltage, etc. is Compact disc digital audio system
located at the bottom. Laser diode properties
• Disconnect the AC power adaptor cord by Material: GaAlAs
grasping the plug. Never pull it by the cord. Wavelength: 780 nm
• Do not leave the unit in a location near a heat
Emission duration: Continuous
source such as a radiator or airduct, or in a
Laser output: Less than 44.6 µW
place subject to direct sunlight, excessive dust, (This output is the value measured at a
mechanical vibration, or shock. distance of about 200 mm from the objective
• Allow adequate air circulation to prevent
lens surface on the optical pick-up block with
internal heat build-up. Do not place the unit on
7mm aperture.)
a surface (a rug, a blanket, etc.) or near Frequency response
materials (a curtain) which might block the +1
20-20,000 Hz dB
–1.5
ventilation holes.
Wow and flutter
• Should any liquid or solid object fall into the
Below measurable limit
unit, unplug (or remove batteries from) the
Radio section
unit and have it checked by a qualified
personnel before operating it further. Frequency range
• When the casing becomes soiled, clean it with a
Band Frequency Channel step
soft cloth dampened with a mild detergent
FM 87.5-108 MHz 0.1 MHz
solution. Never use abrasive cleansers or
chemical solvents, as they may mar the casing. AM 530-1,710 kHz 10 kHz
• The unit is not disconnected from the AC
FM 87.5-108 MHz 0.05 MHz
power source (mains) as long as it is connected
AM 531-1,710 kHz 9 kHz
to the wall outlet, even if the unit itself has
General
been turned off.
Time display
If you have any question, please consult your
12-hour system
nearest Sony dealer.
Speaker
5
Full range: 4 cm (1 / inches), 8 ohms (2)
8
Notes on Headphones
Output
i (headphones) jack (stereo minijack, 3.5 mm
Road safety
dia.)
Do not use headphones while driving, cycling, or
Power output
operating any motorized vehicle. It may create a
200mW + 200mW (at 10% harmonic
traffic hazard and is illegal in many areas. It can
distortion)
also be potentially dangerous to play your
Power requirements
headphones at high volume while walking,
Main unit:
especially at pedestrian crossings. You should
• 6V DC, four size AA (LR6) alkaline
exercise extreme caution or discontinue use in
batteries
potentially hazardous situations.
• DC IN 6V jack accepts supplied AC power
adaptor for use with 120 V AC, 60 Hz
Preventing hearing damage
Backup for Clock: 3V DC, one CR 2025
Avoid using headphones at high volume.
lithium battery
Hearing experts advise against continuous, loud
External power source
and extended play. If you experience a ringing in
DC IN 6V
your ears, reduce volume or discontinue use.
Dimensions
Approx. 166.5 34 173 mm (w/h/d)
5 3 7
(Approx. 6 / 1 / 6 /
Caring for others
8 8
incl. projecting parts and controls
Keep the volume at a moderate level. This will
Mass
allow you to hear outside sounds and to be
Approx. 660 g (1 lb 7 oz) incl. batteries
considerate to people around you.
Supplied Accessories
Troubleshooting
Sony CR 2025 lithium battery (1)
AC power adaptor (1)
Stereo headphones (1)
Should any problem occur with the unit, make
the following checks to determine whether or not
Design and specifications are subject to change
servicing is required. If the problem persists,
without notice.
consult your nearest Sony dealer.
There is no radio or CD sound.
• The batteries are exhausted. Replace all
batteries when "E" appears in the display.
• The batteries are not inserted with correct
polarity.
• The AC power adaptor is not plugged in
properly.
• The volume is not adjusted properly.
• The headphones are plugged into the i
(headphones) jack when you are trying to
listen through the speakers.
• The disc is not placed correctly.
The CD player does not operate.
• The batteries are exhausted. Replace all
batteries when "E" appears in the display.
• The disc is not placed correctly (the labeled
surface should face up).
• The CD compartment lid is not completely
closed.
• The CD is dusty or defective. Clean the disc
with an optional cleaning cloth. Wipe the disc
from the center out.
The CD sound skips.
• The CD is dusty or defective. Clean the disc
with an optional cleaning cloth.
• The pickup lens is dirty. Clean the lens with a
commercially available blower.
• The unit is exposed to vibration.
• Activate the ESP function.
The CD, radio or buzzer alarm does not come
on at the preset time.
• The current time is not set correctly.
• The alarm time is not set correctly.
• An alarm mode has not been selected.
• The disc has not been placed (for CD alarm).
• The CD compartment lid is not completely
closed.
• The volume is not adjusted properly.
The clock flashes "AM 12:00" and the station
presets are erased.
• The lithium battery is exhausted. Replace it.
Installing Alkaline
Power Sources
Batteries
The unit cannot be played on manganese
1
batteries. Use only alkaline batteries.
Installing the Lithium
Battery for Clock Backup
1
Insert a pointed object into the hole
beside the lithium battery compartment
to eject the tray.
Bottom P
U
S
H
2
Push
2
Place the lithium battery CR 2025 on
the tray with the e side facing up, and
slide the tray into the compartment
until you hear a click.
CR2025
Battery life
Using Sony alkaline size AA (LR6)
CD (ESP on)
Note
Radio
The lithium battery is only for clock backup. The
unit cannot play a CD or the radio unless it is
Replacing batteries
powered by alkaline batteries or the AC power
adaptor. • When the batteries become weak, "E" flashes
Replacing the lithium battery
The battery life of the backup lithium battery is 3
months when both the alkaline batteries or house
• When "E" is lit in the display, the unit stops
current are not connceted. The lithium battery
will last longer with these power sources, since
inches)
either source will supply power for clock backup
8
as well.
If the clock flashes "AM 12:00" when you replace
the alkaline batteries, the lithium battery is
When the battery compartment lid
exhausted. Replace the lithium battery.
Reset the clock and the station presets if needed.
becomes detached
The battery compartment lid is designed to
Notes on batteries
become detached if opened with excessive force.
• Keep the lithium battery out of reach of In such a case, reattach it as shown below.
children. Should the battery be swallowed,
consult a doctor immediately.
• Wipe the batteries with a dry cloth to assure
good contact.
• Be sure to install the batteries in the correct
polarity position.
• Do not hold the batteries with metallic
tweezers, as doing so may cause a short-circuit.
• Do not break up the batteries or throw them
into a fire, which might cause them to explode.
Carefully dispose of used batteries.
CAUTION
Note
Danger of explosion if battery is replaced
When the unit is not being used for a long period
incorrectly. Replace only with the same or
of time, remove the batteries to avoid damage
equivalent type recommended by the equipment
from battery leakage and corrosion.
manufacturer. Discard used batteries according
to manufacturer's instructions.
Using House Current
Connect the supplied AC power adaptor
to the DC IN 6V jack, and plug it into a
wall outlet.
Be sure to plug in the adaptor securely to both
the DC IN 6V jack and to the wall outlet. The
unit automatically switches to external power
even with the batteries inserted.
to wall outlet
Notes
• When using the unit on AC power, we
• When the AC power adaptor is not to be used
• Do not remove the lithium battery even when
• If power from the AC power adaptor is
• Use only the supplied Sony AC power adaptor.
Slide the battery compartment lid in the
direction of the arrow and lift it up.
Bottom
Install four size AA (LR6) alkaline
batteries with correct polarity.
Insert the batteries with the polarity as
shown in the diagram at the bottom of the
unit. Be sure to insert the batteries from the
E terminal.
Approx. 7 hours
Approx. 17 hours
in the display. When the batteries are
exhausted, "E" stops flashing and remains in
the display. Replace all the four batteries with
new alkaline batteries of the same kind.
all operation. Only the clock display will
appear in the display. After replacing the
batteries, press CD u or RADIO•SLEEP so that
"E" disappears in the display.
2
1
AC power
adaptor
(supplied)
to DC IN 6V
recommend that you remove the dry batteries
to avoid possible battery leakage.
for a long period of time, be sure to unplug it
both from the DC IN 6V jack and from the wall
outlet.
operating the unit on house current, as it serves
as backup power for the memory.
disrupted due to power interruption, etc., the
unit switches to battery power when available.
Using any other adaptor may cause damage to
the unit.
Polarity of the plug
