INTRODUCTION

Connections

o.
1. HDMI 2 (v1.4) Connector
HDMI 1(v2.0)(4K) / MHL Connector
2.
3. USB Power Out (5V 1.5A) Connector
4. VGA In / VGA In 1 Connector
5. Composite Connector
6. Audio In 1 / Microphone Connector
7. Kensington Lock Port
TM
8. Audio Out Connector
9. Audio In 2 Connector
10. VGA Out Connector
11. RS232 Connector
12. RJ-45 Connector
13. Power Socket
14. VGA In 2 Connector
15. S-Video Connector
16. HDBaseT Connector
