RUGGEDCOM WiN5100/WiN5200
User Guide
3. Connect the WiN1010 data adaptor to the 110 VAC/220 VAC power source using the cable.
Section 4.10.4

WiN1010 Data Adaptor LED Indicators

LEDs on the WiN1010 data adaptor front panel indicate the status of the WiN1010 power supply.
Table: WiN1010 Data Adaptor LED Indications
Name Color
PWR Green
LAN Green
WLNK Green
Section 4.11

Hazardous Location Installation

This equipment is suitable for use in Class 1, Division 2, Groups A, B, C, D hazardous locations when installed
using the Class 1, Division 2 installation kit (P/N MKIT0090).
WARNING!
EXPLOSION HAZARD
• Substitution of components may impair suitability for Class I, Division 2
• Do not disconnect equipment unless power has been switched off or the area is known to be non-
hazardous
• Use only Lambda DPP240-48-1 Power Supply in conjunction with the unit
RISQUE D'EXPLOSION
• La substitution decomposants peut rendre ce matériel inacceptable pour les emplacements de
Classe I, Division 2
• Avant de déconnecter l'equipment, couper le courant ou s'assurer que l'emplacement est désigné
non dangereux
• Utilisez l'unité uniquement avec une batterie de la marque Lamba DPP240-48-1
Contents of the Class 1, Division 2 Installation Kit:
• Lambda power supply unit (model DPP240-48-1)
• Y-Box Surge Suppression Unit
• DC cable for connection between the power supply unit (PSU) and the power-over-ethernet (PoE) injector
To install the equipment in a hazardous location, do the following:
1. Connect a DC cable between the PSU and PoE injector.
WiN1010 Data Adaptor LED Indicators
Description
Input power is connected
LAN link/activity display
Wireless link/activity display
Chapter 4
Installation Procedure
35
