Summary of Contents for Miele KM 6322
- Page 1 Operating and installation instructions Ceramic cooktops with induction To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time. en-AU, NZ M.-Nr. 09 542 730...
-
Page 2: Table Of Contents
Warning and Safety instructions................ 4 Caring for the environment ................ 15 Overview....................... 16 Cooktop......................... 16 KM 6322 / KM 6323 .................. 16 KM 6347 / KM 6348 .................. 17 Controls / Indicators....................18 Cooking zone data ....................20 Using for the first time .................. 22 Cleaning the cooktop for the first time.............. - Page 3 Safety instructions for installation.............. 54 Safety distances .................... 55 Cooktops with frame or bevelled edge ............. 57 Installation notes ....................57 Building-in dimensions..................58 KM 6322 ...................... 58 KM 6347 ...................... 59 Installation ......................60 Flush-fitted cooktops.................. 61 Installation notes ....................61 Building-in dimensions..................
-
Page 4: Warning And Safety Instructions
They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for non- compliance with these instructions. Keep these instructions in a safe place and ensure that new users are familiar with the contents. - Page 5 This cooktop is not suitable for outdoor use. It is intended only to cook food and keep it warm. Any other use is not supported by Miele and could be dangerous. This appliance is not intended for use by persons (including...
- Page 6 Warning and Safety instructions Safety with children Young children must not be allowed to use this appliance. Older children may only use the appliance when its operation has been clearly explained to them and they are able to use it safely, recognising the dangers of misuse.
- Page 7 Repairs and other work by unqualified persons could be dangerous. Installation, maintenance work and repairs to electrical appliances must only be carried out by a Miele approved service technician. A damaged appliance is dangerous. Check it for any visible damage.
- Page 8 The manufacturer's warranty will be invalidated if the appliance is not repaired by a Miele approved service technician. Faulty components must only be replaced by genuine Miele spare parts. The manufacturer can only guarantee the safety of the appliance when Miele replacement parts are used.
- Page 9 Warning and Safety instructions If the cooktop is installed behind a furniture panel (e.g. a door), ensure that the door is never closed whilst the cooktop is in use. Heat and moisture can build up behind a closed furniture panel and cause subsequent damage to the cooktop, the housing unit and the floor.
- Page 10 Warning and Safety instructions Correct use The cooktop gets hot when in use and remains hot for a while after being switched off. There is a danger of burning until the residual heat indicators go out. Due to the high temperatures radiated, objects left near the cooktop when it is in use could catch fire.
- Page 11 Warning and Safety instructions When the appliance is switched on either deliberately or by mistake, or when there is residual heat present, there is the risk of any metal items left on the cooktop heating up, with the danger of burning.
- Page 12 Warning and Safety instructions Pans which boil dry can cause damage to the ceramic glass. Do not leave the cooktop unattended whilst it is being used. Only use pots and pans with smooth bases. Rough bases will scratch the ceramic glass. ...
- Page 13 Warning and Safety instructions Do not use two pans on a cooking zone, extended zone or PowerFlex zone at the same time. If the pan only partially covers the cooking zone, the handle could become very hot. Ensure that you always place the pan in the middle of the cooking zone.
-
Page 14: Cleaning And Care
Warning and Safety instructions Cleaning and care Do not use a steam cleaning appliance to clean this appliance. The steam could reach the electrical components and cause a short circuit. If the cooktop is built in over a pyrolytic oven, the cooktop should not be used whilst the pyrolytic process is being carried out, as this could trigger the overheating protection mechanism on the cooktop (see relevant section). -
Page 15: Caring For The Environment
Caring for the environment Disposal of the packing Disposing of your old material appliance The transport and protective packaging Electrical and electronic appliances has been selected from materials which often contain materials which, if are environmentally friendly for handled or disposed of incorrectly, disposal, and can normally be recycled. -
Page 16: Overview
Overview Cooktop KM 6322 / KM 6323 a Cooking zone with Booster b Cooking zone with Booster c PowerFlex cooking zone with TwinBooster d PowerFlex cooking zone with TwinBooster cd can be combined to form PowerFlex cooking area e Controls / Indicators... - Page 17 Overview KM 6347 / KM 6348 a Cooking zone with Booster b Cooking zone with Booster c PowerFlex cooking zone with TwinBooster d PowerFlex cooking zone with TwinBooster cd can be combined to form PowerFlex cooking area e Controls / Indicators...
-
Page 18: Controls / Indicators
Overview Controls / Indicators Sensor controls a For switching the cooktop on/off b Number sensors - For setting the power level - For setting the time c For activating/deactivating the system lock/safety lock d For switching on/off the Booster/TwinBooster e For selecting the cooking zone f For switching the PowerFlex cooking area on/off... - Page 19 Overview g Timer - For switching on and off - For switching between timer functions - For selecting a cooking zone (see "Switching a cooking zone off automatically") h For activating/deactivating Stop & Go Indicator lights i System lock/Safety lock activated j Booster/TwinBooster activated l Auto heat-up or extended power setting (see "Programming") m For cooking zone selection, e.g.
-
Page 20: Cooking Zone Data
Overview Cooking zone data Cooking zone KM 6322 / KM 6323 Ø in cm* Rating in watts for 230 V** 14–20 Normal 1850 Booster 3000 10–16 Normal 1400 Booster 2200 15–23 Normal 2100 TwinBooster, level 1 3000 TwinBooster, level 2 3700 ... - Page 21 Overview Cooking zone KM 6347 / KM 6348 Ø in cm* Rating in watts for 230 V** 16–23 Normal 2300 TwinBooster, level 1 3000 TwinBooster, level 2 3700 10–16 Normal 1400 Booster 2200 15–23 Normal 2100 TwinBooster, level 1 3000 TwinBooster, level 2 3700...
-
Page 22: Using For The First Time
Using for the first time Please stick the extra data plate for Switching on the cooktop for the appliance supplied with this the first time documentation in the space provided The metal components have a in the "After sales service, data plate, protective coating which may give off a warranty"... -
Page 23: Induction
Induction The induction principle When the appliance is switched on either deliberately or by mistake, An induction coil is located under each or when there is residual heat cooking zone. When a cooking zone is present, there is the risk of any metal switched on, this coil creates a items placed on the cooktop (e.g. -
Page 24: Noises
Induction Noises When using an induction cooking zone, the following noises can occur in the pan, depending on what it is made of and how it has been constructed. On the higher power settings, it might buzz. This will decrease or cease altogether when the power setting is reduced. -
Page 25: Pans
Induction – Lift pans into position on the Pans cooktop. Sliding them into place can Suitable pans: cause scuffs and scratches. – Stainless steel pans with a base that – Often the maximum diameter quoted can be magnetised. by manufacturers refers to the diameter of the top rim of the pot or –... -
Page 26: Tips On Saving Energy
Tips on saving energy – Use a lid whenever possible to minimise heat loss. – Select a smaller pan when cooking small quantities. A smaller pan uses less energy than a larger pan with very little in it. – Cook with as little water as possible. –... -
Page 27: Power Level Range
Power level range The cooktop is programmed with 9 power levels at the factory. If you wish to fine- tune a setting, you can extend the power setting range to 17 power levels (see "Programming"). Settings Default Extended setting settings (9 power (17 power levels) -
Page 28: Operation
Operation Operating principles Malfunction due to dirty and/or covered sensors: The glass ceramic cooktop is equipped If the sensors are dirty or covered, with electronic sensor controls which this could cause them to fail to react, react to finger contact. For safety to activate a function or even to reasons, in order to switch the cooktop switch the cooktop off automatically... -
Page 29: Switching The Cooktop On
Operation Residual heat indicator Fire hazard! Do not leave the cooktop unattended If a cooking zone is still hot, the residual whilst it is being used. heat indicator will light up after it has Please note that the heating up time been switched off. -
Page 30: Selecting The Power Setting - Extended Setting Range
Operation Selecting the power setting - PowerFlex cooking area extended setting range The PowerFlex cooking zones can be combined to form a PowerFlex cooking Touch the area between the sensors. area (see "Guide to the appliance - The power level selected flashes in the Cooktop"). -
Page 31: Auto Heat-Up
Operation Auto heat-up Continued Heat-up time cooking setting [min : sec] When Auto heat-up has been activated, the cooking zone switches on approx. 0 : 15 automatically at the highest setting and approx. 0 : 15 then switches to the continued cooking setting which you have previously approx. -
Page 32: Booster
Operation Cooking zones are networked in pairs Booster to supply the power for the Booster The cooking zones are equipped with a function. When the Booster function is Booster or TwinBooster (see "Overview selected, a proportion of energy is – Cooktop"). You can use the Booster taken away from the linked cooking function for a maximum of two cooking zone and the following happens within... - Page 33 Operation Touch the B I/II sensor repeatedly Switching on the Booster until the indicator light for the Booster Briefly touch the sensor of the goes out and the cooking zone desired cooking zone. setting appears in the display. Select a power setting if necessary. ...
-
Page 34: Keeping Warm
Operation Setting the keeping warm function Keeping warm Briefly touch the sensor of the The keeping warm function is not desired cooking zone. designed to reheat food from the cold state. It is only for keeping food warm Touch the area between the 0 and 1 directly after cooking. -
Page 35: Timer
Timer Making changes The cooktop must be switched on to use the timer. Touch the sensor. You can select a time from 1 minute to Set a new minute minder time, as 99 minutes. described above. The timer can be used for two different Deleting the minute minder functions: ... -
Page 36: Switching A Cooking Zone Off Automatically
Timer If you want to set another cooking Switching a cooking zone off zone to switch off automatically, automatically follow the same steps as described You can set a time after which the above. cooking zone will switch off automatically. -
Page 37: Using Both Timer Functions At The Same Time
Timer If you want to show the times remaining Using both timer functions at which are counting down in the the same time background: The minute minder and automatic Touch the sensor repeatedly until switch-off functions can be used at the same time. -
Page 38: Additional Functions
Additional functions Stop & Go When Stop & Go is activated, the power of all cooking zones in use is reduced to power setting 1. The cooking zone power settings and the timer settings cannot be altered and the cooktop can only be switched off. A set minute minder and Booster time will continue to count down. -
Page 39: Safety Features
Safety features The safety lock is set when the Safety lock / System lock cooktop is switched on. When the The system lock and safety lock are safety lock is activated: deactivated if there is an interruption – The power settings for the cooking to the power supply. -
Page 40: Safety Switch-Off
Safety features Safety switch-off Safety switch-off with an overlong cooking time The safety switch-off mechanism is triggered automatically if one of the cooking zones is heated for an unusually long period of time. This period of time depends on the power setting selected. -
Page 41: Overheating Protection
If, despite removing the cause, the – The set power level will be reduced. overheating protection mechanism triggers again, contact Miele. – The cooking zone switches off automatically. flashes in the timer display alternating with . You can use the cooking zones again as usual when the fault message has gone out. -
Page 42: Cleaning And Care
Cleaning and care Clean the entire cooktop after each use. Danger of burning! Allow it to cool down before cleaning. The cooking zones must be switched Dry the appliance after using water to off. The cooktop needs to cool clean it. - Page 43 (spots with a glass-ceramic surface and the frame metallic appearance) can be removed or the frame and the worktop with using the Original Miele ceramic and sharp, pointed objects. stainless steel cooktop cleaner. This could damage the seals.
-
Page 44: Programming
Programming You can programme certain settings on Calling up programming the cooktop to suit your personal With the cooktop switched off, needs. Several settings can be changed touch the and sensors at the in succession. same time until the indicator light for After starting the programming function, the safety lock flashes. - Page 45 Programming Settings Programme Status Demonstration mode and Demonstration mode on factory default settings Demonstration mode off Factory default settings reinstated Stop & Go Number of power settings 9 power settings 17 power settings Induction warning tone when there is no pan or the pan is Quiet unsuitable Medium...
- Page 46 Programming Settings Programme Status Con@ctivity Not available - only on communication- Signed off enabled appliances retrofitted with a communication Signed on module/dongle Audible tone if the sensors are covered Sensor switch reaction speed Slow Normal Fast Programmes not shown here have no allocation. The factory setting is shown in bold.
-
Page 47: Problem Solving Guide
Problem solving guide With the aid of the following guide, minor problems can be easily corrected without contacting Miele. If, after reading this guide, you can't remedy the problem yourself, please call Miele (see back cover for details). Please note, however, that a call-out charge will be applied to unnecessary service visits where the problem could have been rectified as described in these operating instructions. - Page 48 Problem solving guide Problem Possible cause and remedy After switching the The system lock or safety lock is activated. cooktop on, appears Deactivate the system lock or safety lock (see in the timer display for "System lock / Safety lock"). several seconds.
- Page 49 Take any pans off the cooktop and wipe away any food deposits. Interrupt the power supply to the cooktop for approx. 1 minute. If the problem persists after power is restored, please contact Miele.
- Page 50 Make sure it has not been blocked by something like a fork. Remove the cause of the blockage. If this fault message continues to appear in the display, contact Miele. and other numbers There is a fault in the electronic module.
-
Page 51: Optional Accessories
250 ml appliance. These can be ordered online at: Removes heavy soiling, limescale deposits and aluminium residues. or from Miele (see end of this booklet Original Miele all purpose microfibre for contact details). cloth Saucepans and frying pans Miele offer a wide range of pans which are perfect for Miele cooktops. -
Page 52: Con@Ctivity
Con@ctivity Your cooktop is communication Further information regarding enabled and via the dongle supplied Con@ctivity is available on the internet with selected rangehoods can and in the instruction manuals of the communicate with the rangehood various components. (Con@ctivity). The cooktop sends information on its operating status to the rangehood. -
Page 53: Signing Off The Cooktop
Con@ctivity If you want to sign on your cooktop to Signing off the cooktop the Con@ctivity system, you will first With the cooktop switched off, need to sign on the rangehood. touch the and sensors at the same time until the indicator light for Signing on the cooktop the safety lock flashes. -
Page 54: Safety Instructions For Installation
Safety instructions for installation The appliance must only be installed and connected to the electricity supply by a suitably qualified and competent person in strict accordance with current national and local safety regulations. Fit the wall units and rangehood before fitting the cooktop to avoid damaging the cooktop. -
Page 55: Safety Distances
Safety distances Safety distance above the cooktop A minimum safety distance must be maintained between the cooktop and the rangehood above it. See the rangehood manufacturer's operating and installation instructions for details. If the manufacturer's instructions are not available for the rangehood, a minimum safety distance of 600 mm must be maintained. - Page 56 Safety distances Safety distances to the sides Minimum safety distances and back of the cooktop underneath the cooktop Ideally the cooktop should be installed To ensure sufficient ventilation to the with plenty of space on either side. cooktop, a certain gap must be left There may be a wall at the rear or a tall between the underside of the cooktop unit or wall on one side (right or left),...
-
Page 57: Cooktops With Frame Or Bevelled Edge
Cooktops with frame or bevelled edge Tiled worktop Installation notes Seal between the cooktop and the worktop Grout lines and the hatched area underneath the cooktop frame must be smooth and even. If they are not, the cooktop will not sit flush with the worktop and the sealing strip Do not use sealant between the underneath the cooktop will not provide... -
Page 58: Building-In Dimensions
Cooktops with frame or bevelled edge Building-in dimensions KM 6322 a Front b Installation height c Con@ctivity connection d Mains connection box The mains connection cable (1440 mm long) is supplied separately with the cooktop. - Page 59 Cooktops with frame or bevelled edge KM 6347 a Front b Installation height c Con@ctivity connection d Mains connection box The mains connection cable (1440 mm long) is supplied separately with the cooktop.
-
Page 60: Installation
Cooktops with frame or bevelled edge Installing the cooktop Installation Feed the mains connection cable Preparing the worktop down through the cut-out. Make the worktop cut-out as shown Place the cooktop centrally in the in "Building-in dimensions". Observe cut-out. -
Page 61: Flush-Fitted Cooktops
Flush-fitted cooktops The cooktop can be installed Installation notes – in a suitable cut-out in a natural stone Flush fit cooktops are only suitable for worktop. installation in natural stone (granite, marble), tiled or solid wood worktops. – in a suitable cut-out in a tiled or solid Certain models are suitable for wood worktop with a wooden building into glass worktops - please... -
Page 62: Building-In Dimensions
Flush-fitted cooktops Building-in dimensions KM 6323 a Front d Stepped cut-out for granite or marble worktops b Installation height e Mains connection box c Con@ctivity connection The mains connection cable (1440 mm long) is supplied separately with the cooktop. Cut-out dimensions for granite or marble worktops. Please take careful note of the inset diagram. - Page 63 Flush-fitted cooktops KM 6348 a Front d Stepped cut-out for granite or marble worktops b Installation height e Mains connection box c Con@ctivity connection The mains connection cable (1440 mm long) is supplied separately with the cooktop. Cut-out dimensions for granite or marble worktops. Please take careful note of the inset diagram.
-
Page 64: Installation
Flush-fitted cooktops Solid wood / tiled / glass worktops Installation Granite and marble worktops a Worktop b Cooktop a Worktop c Gap b Cooktop d Wooden frame 13 mm (not supplied c Gap with appliance) As the ceramic glass and the worktop As the ceramic glass and the worktop cut-out have a certain dimensional cut-out have a certain dimensional... - Page 65 Flush-fitted cooktops Preparing the worktop Make the worktop cut-out as shown in "Building-in dimensions". Observe the safety distances (see "Safety distances"). Solid wood, tiled and glass worktops: Fix the wooden frame 7 mm below the top edge of the worktop (see diagram).
-
Page 66: Electrical Connection
AC 230 V, 50 Hz repair work is dangerous to users. The voltage and rated load are given on Miele cannot be held liable for the data plate. Please ensure these damage or injury caused by incorrect match the household mains supply. -
Page 67: Wiring Diagram
If the mains connection cable needs to be replaced, it must be replaced with a special connection cable, type H 05 VV- F (PVC insulated), available from Miele, in order to avoid a hazard. The connection data is given on the data plate. -
Page 68: After Sales Service, Data Plate, Warranty
After sales service, data plate, warranty After sales service In the event of any faults which you cannot easily remedy, please contact Miele. See back of this booklet for contact details. Please quote the model and serial number of your appliance when contacting Miele. - Page 71 Freemans Bay, Auckland 1011 Miele Experience Centre South Melbourne: 206-210 Coventry Street Miele Experience Centre South Melbourne, VIC 3205 Auckland: Miele Experience Centre and Office Sydney: 8 College Hill 3 Skyline Place Freemans Bay, Auckland 1011 Frenchs Forest, NSW 2086 Telephone:...
- Page 72 KM 6322 / KM 6323 / KM 6347 / KM 6348 en-AU, NZ M.-Nr. 09 542 730 / 02...
