- Page 1 SL-3000 SERIES ™ HIGH TRAFFIC COMMERCIAL SLIDE GATE OPERATORS INSTALLATION INSTRUCTIONS & MANUAL BOOK FOR ARCHITECTS, GENERAL CONTRACTORS & DEALERS www.eliteaccess.com © COPYRIGHT 1988 BY ELITE ACCESS SYSTEMS, INC.
-
Page 2: Table Of Contents
LIST OF SL-3000 PARTS AND MAINTENANCE ....INSIDE BACK COVER © 1988 BY ELITE ACCESS SYSTEMS, INC. ALL RIGHTS RESERVED. NO PART OF THIS MANUAL MAY BE REPRODUCED IN ANY MEANS: GRAPHIC, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING WITHOUT THE EXPRESSED WRITTEN PERMISSION OF THE PUBLISHER. -
Page 3: Gate Post Warning
GATE POST WARNING IMPORTANT NOTICE! Because the coasting distance may vary due to changes in temperature, Elite does recommend the installation of a stop or catch post in front of the gate's path as shown in Fig. A. To do so will cause the gate to hit the post in certain instances. -
Page 4: Warning Signs
WARNING SIGNS WARNING IMPORTANT! Installers are required to adhere to this procedure: The UL required Warning Signs must be installed in plain view and on both sides of each commercial gate installed. Each sign is made with fastening holes in each corner and should be permanently secured in a suitable manner. -
Page 5: Types Of Installations
TYPES OF INSTALLATIONS FRONT INSTALLATIONS Reason: Cost efficient. REAR INSTALLATIONS Reason: Chain is not visible. CEILING MOUNT UNDERGROUND PARKING Reason: Space efficient - chain is not visible. -
Page 6: How To Connect The Chain For Different Types Of Installations
HOW TO CONNECT THE CHAIN FRONT INSTALLATIONS Weld front bracket with gate in open position. Weld rear bracket with gate in closed position. REAR INSTALLATIONS Cut the cover by 17 ⁄ ” Make sure the sprocket box is sealed. REAR INSTALLATIONS: HOUSING MODIFICATION The housing must be Important: For safe... -
Page 7: Cement Work
CEMENT WORK FOR THE PAD AND GATE Suggested installation for dirt ground. The measurements depend on the type of ground (ie., asphalt, cement, dirt) BELL BOX ⁄ " PVC 6" 24" 10" 8" 24" CONCRETE 24" ⁄ " x 3 ⁄... -
Page 8: Distance Between The Operator And Gate
DISTANCE BETWEEN THE OPERATOR AND GATE 4" 4" MIN. OF 4" SPACE BETWEEN GATE & SPROCKET CORRECT INSTALLATION INCORRECT INSTALLATION CORRECT INSTALLATION INCORRECT INSTALLATION CHOOSING MOVEMENT DIRECTION Plug the motor wires to left open socket. Plug the motor wires to right open socket. -
Page 9: How To Connect Power (120V)
2200 FEET CAUTION: ELITE ACCESS SYSTEMS, INC. IS NOT RESPONSIBLE FOR CONFLICTS BETWEEN THE INFORMATION LISTED IN THE ABOVE CHART AND THE REQUIREMENTS OF YOUR LOCAL BUILDING CODES. THE INFORMATION IS FOR SUGGESTED USE ONLY. CHECK YOUR LOCAL CODES BEFORE INSTALLATION. -
Page 10: Two-Way Adjustable Reversing Sensor
TWO WAY ADJUSTABLE REVERSING SENSOR MAX. Adjusted by qualified service personnel. MIN. DO NOT TOUCH! The level of sensitivity has to do with the weight of the gate and the condition of installation. Too sensitive = if the gate stops or reverses by itself. Not sensitive enough = if the gate hits an object and does not stop or reverse. -
Page 11: Master & Slave With Timer
MASTER AND SLAVE WITH TIMER 115 Volt 115 Volt PLACE 4 LOW VOLTAGE WIRES BETWEEN OPERATORS MASTER J2 SLAVE J2 1. Connect pin #1 of J2 Master to pin #1 of J2 Slave. Connect pin #2 of J2 Master to pin #2 of J2 Slave. Connect pin #6 of J2 Master to pin #8 of J2 Slave. -
Page 12: Master & Slave / No Timer
MASTER AND SLAVE / NO TIMER 115 Volt 115 Volt PLACE 2 LOW VOLTAGE WIRES BETWEEN OPERATORS MASTER J2 SLAVE J2 1. Connect pin #2 of J2 Master to pin #2 of J2 Slave. 2. Connect pin #1 of J2 Master to pin #1 of J2 Slave. 3. -
Page 13: Three Push-Button System
THREE PUSH-BUTTON SYSTEM THREE PUSH BUTTON SYSTEM (OPEN-STOP-CLOSE) Step 1- Connect open push button to terminal #3 & 4 on the main terminal block. Step 2- Connect close push button to pin #7 & 8 on the J2. Step 3- Connect push stop button to pin #3 & 4 on the J2 and cut off the jumper wire #W4. CAUTION! Make sure each push button is dry contact and there are no jumper wires between them. -
Page 14: Terminal Input Connections
TERMINAL INPUT CONNECTIONS • • • • • • • • Output power FIRE STRIKE SAFETY EXIT RADIO POWER GATE OPEN 8 = ground (-) LOCKED RELAY DEPT. OPEN LOOP LOOP REC. 10 = 24 DC (+) ELEC. RESET 8 = 24 volt 1&2 3&4 5&6... -
Page 15: Safety And Exit Loop
SAFETY LOOP The reason for a safety loop is, to prevent the gate from closing on a car or any other object while it is exiting or stopped in the middle of the gate area. 4’ 4’ 4’ 4’ 8’ 4’... -
Page 16: Emergency Release
EMERGENCY RELEASE STANDARD 1. Turn the power OFF 2. Make sure the crank tool fits the crank input, as shown above: Turn the crank to open the gate. To speed up the process you may use a wireless power drill (6”/sec). OPTION 1: MODEL CP-17 Pull firmly on the “T”... -
Page 17: How To Replace The Control Board
HOW TO REPLACE THE CONTROL BOARD Pull out 2 plugs. Unscrew 3 nuts and pull out the control board. YOU WILL HEAR A “BEEP” SOUND WHEN 1. The gate is too heavy. • • • • 2. Unwanted objects are on the gate track 3. -
Page 18: Troubleshooting/Led Information Center
TROUBLESHOOTING/LED INFORMATION CENTER • • • • • • • • • FIRE STRIKE SAFETY EXIT RADIO POWER GATE OPEN LOCKED RELAY DEPT. OPEN LOOP LOOP REC. ELEC. RESET 1&2 3&4 5&6 7&8 8&9&10 BRAKE MOTOR • • OPEN RELAY RESET MOTOR If the gate is not moving in any direction... -
Page 19: Sl-3000 Parts
SL-3000 PARTS Q008 Q114 Q010 Q033 Q031 Q032 Q030 Q028 Q029 Q026 Q027 Q023 Q025 Q021 Q101 Q022 Q020 Q017 Q018 Q009 Q016 Q015 Q014 Q006 Q013 Q005 Q004 A H-110 Q003... - Page 20 SL-3000 PARTS LIST AH-110 - CHAIN #41 Q021 - GEAR PULLEY Q003 - CHAIN BOLT Q022 - ELECTRIC BOX Q004 - CHAIN BRACKET Q023 - LIMIT SWITCH BOX Q005 - SL-3000 CHASSIS Q025 - MOTOR PULLEY Q006 - PC BOARD NUTS (SET) Q026 - CRANK INPUT Q008 - COVER - NON UL Q027 - MOTOR CAPACITOR...
- Page 21 ELITE ACCESS SYSTEM AVAILABLE PRODUCTS INDOOR INTERCOM OUTDOOR OUTDOOR DIGITAL SPEAKER INTERCOM LOCK WITH INTERCOM SPEAKER OUTDOOR DIGITAL LOCK CARD READER FIRE BOX KEY STATION KEY SWITCH ELECTRIC EYE THREE PUSH BUTTON REMOTE CONTROL SYSTEM SAFETY LOOP...
- Page 22 A UHM Rubber Rollers ATTENTION In order to reduce any severe injuries, Elite Access Systems recommends the electric gate be either: covered with a mesh (picture B) or installed in such a way which to prevent small children or any other persons from...
