Door Entry Monitors - Comelit Icona ViP User Manual

Door entry monitors

SETUP-ADVANCED-Door entry monitors
The section allows you to manage the parameters of the door entry
monitor system.
VIDEO SYSTEM
Addresses
Actuator directory
Cameras directory
Intercom Directory
„ Swipe your finger up or down to view all the available menu
options.
„ To access the desired function, press the corresponding icon.
» The available options are: Addresses / Actuators directory /
Cameras directory / Intercoms directory / Set tone repetition /
Set call times / Call divert / Alarms / Doors directory / Set audio
messages / Hands-free / Always record / Configure multiple
addresses.
Door entry monitors - Addresses
SETUP-ADVANCED-Door entry monitors-Addresses
This function allows you set the Vip address of the device.
ADDRESS
Configure ViP address
Master
Slave
„ Press CONFIGURE VIP ADDRESS to open the panel in which you
can enter the ViP address.
„ Select the device category of MASTER or SLAVE.
54
CONTENTS
Door entry monitors - Actuators directory
SETUP-ADVANCED-Door entry monitors-Actuators directory
This function allows you to add and manage actuators connected to This function allows you to add and manage actuators connected to
the ViP system. the ViP system.
1
00000001
1 2
4 5
7 8
0
„ Enter the desired value, then confirm.
ACTUATORS ACTUATORS
Actuator 1 Actuator 1
Actuator 2 Actuator 2
Actuator 3 Actuator 3
Actuator 4 Actuator 4
„ Press the icon to add a new element. „ Press the icon to add a new element.
ACTUATORS ACTUATORS
Configure name Configure name
Configure ViP address Configure ViP address
Module Module 255 255
Output Output
3
6
9
1 1
