OPERATING INSTRUCTIONS

NOTE: Before using the tool, read the
instruction book carefully.

INTENDED USE:

The machine is intended for driving in and loosening
screws as well as for drilling in wood, metal and
plastic.
BEFORE PUTTING INTO OPERATION
A) CHARGING THE BATTERY
The battery charger supplied is matched to the
Li-ion battery installed in the machine. Do not use
another battery charger.
The Li-ion battery is protected against deep
discharging. When the battery is empty, the machine
is switched off by means of a protective circuit: The
tool holder no longer rotates.
In a warm environment or after heavy use, the
battery pack may become too hot to permit
charging. Allow time for the battery to cool down
before recharging.
When the battery pack is charged for the first time
and after prolonged storage, the battery pack will
accept a 100% charge after several charge and
discharge cycles.
B) TO REMOVE THE BATTERY PACK (See Fig.
1-1)
Depress the Battery Pack Release Button firmly first
and then slide the Battery Pack out from your tool.
C) TO INSTALL THE BATTERY PACK (See Fig.
1-2)
Slide the fully charged Battery Pack onto the tool
with sufficient force until it clicks into position.
D) HOW TO CHARGE YOUR BATTERY PACK
(See Fig. 1-3)
CHARGING PROCEDURE
1) Plug the charger into an appropriate outlet. The
light will be green.
2) Slide the battery pack into the charger, the light
will turn to red to indicate the charging process has
started.
3) When charging is completed, the light will turn to
green. The pack is now fully charged, unplug the
charger and remove the battery pack.
