® ® trademark and owned by the Bluetooth SIG, Inc. and any use of such mark by Dell Inc. is under license. Wi-Fi is a registered trademark of Wireless Ethernet Compatibility Alliance, Inc. 2012 - 06...
Contents Notes, Cautions, and Warnings....................2 1 Working on Your Computer.......................7 ........................7 Before Working Inside Your Computer ............................8 Turning Off Your Computer ........................8 After Working Inside Your Computer 2 Removing and Installing Components...................11 ..............................11 Recommended Tools ........................11 Removing the Secure Digital (SD) Card ........................11 Installing the Secure Digital (SD) Card .............................12...
Page 4
............................26 Removing the Modem Card .............................27 Installing the Modem Card ............................28 Removing the Speakers ............................29 Installing the Speakers ..........................29 Removing the Coin-Cell Battery ..........................30 Installing the Coin-Cell Battery ..........................30 Removing the ExpressCard Cage ..........................31 Installing the ExpressCard Cage ........................31 Removing the Power-Connector Port ........................32 Installing the Power-Connector Port ..........................32...
Page 5
Assigning a System Password and Setup Password ..............71 Deleting or Changing an Existing System and/or Setup Password 5 Diagnostics..........................73 ................73 Enhanced Pre-Boot System Assessment (ePSA) Diagnostics 6 Troubleshooting Your Computer.....................75 ...............................75 Device Status Lights ..............................76 Battery Status Lights 7 Technical Specifications......................77 8 Contacting Dell .........................83...
Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.
After you complete any replacement procedure, ensure you connect any external devices, cards, and cables before turning on your computer. CAUTION: To avoid damage to the computer, use only the battery designed for this particular Dell computer. Do not use batteries designed for other Dell computers.
Page 9
CAUTION: To connect a network cable, first plug the cable into the network device and then plug it into the computer. Replace the battery. Connect your computer and all attached devices to their electrical outlets. Turn on your computer.
Removing and Installing Components This section provides detailed information on how to remove or install the components from your computer. Recommended Tools The procedures in this document may require the following tools: • Small flat-blade screwdriver • Phillips screwdriver • Small plastic scribe Removing the Secure Digital (SD) Card Before Working Inside Your Computer .
Removing the ExpressCard Before Working Inside Your Computer . Follow the procedures in Press in on the ExpressCard to release it from the computer. Slide the ExpressCard out of the computer. Installing the ExpressCard Slide the ExpressCard into its slot until it clicks into place. After Working Inside Your Computer.
Installing the Battery Slide the battery into its slot until it clicks into place. After Working Inside Your Computer. Follow the procedures in Removing the Subscriber Identity Module (SIM) Card Follow the procedures in Before Working Inside Your Computer . Remove the battery.
Lift the base cover to remove it from the computer. Installing the Base Cover Place the base cover to align with the screw holes on the computer. Tighten the screws to secure the base cover to the computer. Install the battery. Follow the procedures in After Working Inside Your Computer .
Installing the Keyboard Trim Align the keyboard trim to its compartment. Press along the sides of the keyboard trim until it snaps in place. Install the battery. After Working Inside Your Computer . Follow the procedures in Removing the Keyboard Follow the procedures in Before Working Inside Your Computer .
Page 16
Disconnect the keyboard cable from the system board. Remove the keyboard from the computer. Peel back the adhesive tape securing the keyboard connector. Remove the keyboard cable from the keyboard.
Installing the Keyboard Connect the keyboard cable and secure it to the keyboard using the tape. Connect the keyboard cable to the system board. Slide the keyboard into its compartment and ensure that it clicks into place. Tighten the screws to secure the keyboard on the palmrest. Flip the computer and tighten the screws to secure the keyboard.
Remove the screw that secures the hard-drive caddy to the hard drive. Remove the hard-drive caddy from the hard drive. Remove the hard-drive isolation from the hard drive. Installing the Hard Drive Install the hard-drive isolation on the hard drive. Attach the hard-drive caddy to the hard drive.
Tighten the screws to secure the hard-drive caddy to the hard drive. Slide the hard drive into the computer. Tighten the screws to secure the hard drive to the computer. Install the battery. After Working Inside Your Computer . Follow the procedures in Removing the Optical Drive Follow the procedures in Before Working Inside Your Computer .
Remove the screws that secure the optical-drive latch bracket to the optical-drive assembly Remove the latch bracket from the optical drive. Remove the optical-drive door from the optical drive. Installing the Optical Drive Secure the optical-drive door to the optical drive. Install the latch bracket to the optical drive.
Tighten the screws to secure the optical-drive latch bracket to the optical drive assembly. Secure the optical-drive latch to the optical drive assembly. Tighten the screw to secure the optical drive latch. Slide the optical drive into its slot. Flip the computer, and push in the eject latch to secure the optical drive. Install the battery.
Removing the Processor Before Working Inside Your Computer . Follow the procedures in Remove: a) battery b) base cover c) heat sink Rotate the processor cam lock in a counter-clockwise direction. Remove the processor from the computer. Installing the Processor Align the notches on the processor and the socket, and insert the processor into the socket.
Disconnect the antenna cables from the WLAN card. Remove the screw that secures the WLAN card to the computer. Remove the WLAN card from its slot on the system board. Installing the WLAN Card Insert the WLAN card into its connector at a 45–degree angle into its slot. Connect the antenna cables to their respective connectors marked on the WLAN card.
a) battery b) base cover Disconnect the heat-sink cable. Remove the screws that secure the heat sink to the system board. Remove the heat sink from the computer. Installing the Heat Sink Slide the heat sink into its original position in the system board. Tighten the screws to secure the heat sink to the system board Connect the heat-sink cable to the system board.
Removing the Bluetooth Card Before Working Inside Your Computer . Follow the procedures in Remove the: a) battery b) base cover Remove the screw that secures the bluetooth card to the computer. Disconnect the bluetooth cable from the system board. Remove the bluetooth card from the computer Disconnect the bluetooth cable from the bluetooth card.
Installing the Bluetooth Card Connect the bluetooth cable to the bluetooth card. Connect the other end of the bluetooth cable to the system board. Place the bluetooth card in its location in the computer. Tighten the screw to secure the bluetooth card to the system board. Install: a) base cover b) battery...
Disconnect the modem cable from the modem card. Grasp the modem card and remove the it from the computer. Installing the Modem Card Insert the modem card in its slot Seat the modem card, to ensure that the tab on the back of the card is engaged. Connect the modem cable to the modem card.
Removing the Speakers Before Working Inside Your Computer . Follow the procedures in Remove: a) battery b) base cover c) hard drive d) keyboard trim e) keyboard f) display assembly g) palmrest h) media board (available in E6430/E6430 ATG only) ExpressCard cage bluetooth card k) system board...
Installing the Speakers Align the speakers in the original position and connect the speaker cables. Tighten the screws to secure the speakers. Install: a) system board b) bluetooth card c) ExpressCard cage d) media board (available in E6430/E6430 ATG only) e) palmrest f) display assembly g) keyboard...
Installing the Coin-Cell Battery Place the coin-cell battery in its slot. Connect the coin-cell battery cable. Install: a) base cover b) battery After Working Inside Your Computer . Follow the procedures in Removing the ExpressCard Cage Before Working Inside Your Computer . Follow the procedures in Remove: a) battery...
Installing the ExpressCard Cage Place the ExpressCard cage into its compartment. Tighten the screws to secure the ExpressCard cage to the computer. Install: a) palmrest b) display assembly c) keyboard d) keyboard trim e) bluetooth card f) hard drive g) base cover h) battery Follow the procedures in After Working Inside Your Computer .
Remove the power-connector cable from the computer. Installing the Power-Connector Port Connect the power-connector cable to the computer. Install the power-connector bracket to its position in the computer. Tighten the screw to secure the power-connector bracket to the computer. Connect the power-connector cable to the system board. Install: a) base cover b) battery...
Remove the screw securing the power LED board to the display assembly. Remove the power LED board from the display assembly. Installing the Power LED Board Place the power LED board in its compartment in the display assembly. Tighten the screw to secure the LED board to the display assembly. Connect the power LED board cable to the display assembly.
After Working Inside Your Computer . Follow the procedures in Removing the Input/Output (I/O) Board Follow the procedures in Before Working Inside Your Computer . Remove: a) battery b) base cover c) hard drive d) optical drive e) bluetooth card f) keyboard trim g) keyboard h) display assembly...
c) media board (available in E6430/E6430 ATG only) d) palmrest e) display assembly f) keyboard g) keyboard trim h) bluetooth card hard drive optical drive k) base cover battery After Working Inside Your Computer . Follow the procedures in Removing the Hard-Drive Support Plate Follow the procedures in Before Working Inside Your Computer .
Installing the Hard-Drive Support Plate Place the hard-drive support plate in its compartment. Tighten the screw to secure the hard drive support plate to the computer. Install the: a) palmrest b) display assembly c) keyboard d) keyboard trim e) optical drive f) hard drive g) base cover h) battery...
Page 37
Disconnect the media board cable (available in E6430/E6430 ATG only). Disconnect the touchpad cable. Disconnect the fingerprint reader cable. Lift and remove the palmrest from the computer.
Installing the Palmrest Align the palmrest assembly to its original position in the computer and snap it into place. Connect the following cables: a) media board (available in E6430/E6430 ATG only) b) touchpad c) fingerprint reader Tighten the screws to secure the palmrest to the computer. Install: a) keyboard b) keyboard trim...
Peel of the adhesive tape on the back of the WiFi-switch board and remove the WiFi-switch board. Installing the WiFi-Switch Board Fix the adhesive tape on the back of the WiFi-switch board and place the board in its slot. Tighten the screw to secure the WiFi-switch board. Connect the WiFi-switch board cable to the system board.
Page 40
h) WLAN card modem card heat sink k) processor palmrest m) ExpressCard cage Disconnect the power-connector cable from the bottom side of the system board. Remove the screws that secure the LVDS support bracket. Remove the LVDS support bracket from the computer. Disconnect the LVDS cable from the system board.
Page 41
Remove the antenna cables from the routing channel. Disconnect the coin-cell battery cable. Disconnect the speaker cable from the top side of the system board. 10. Disconnect the WiFi-board cable.
Page 42
11. Remove the screws that secure the system board. 12. Lift the edge of the system board to a 45–degree angle. 13. Release the system board from the ports and connectors. 14. Lift the system board from the computer.
Installing the System Board Place the system board on the chassis. Tighten the screws to secure the system board to the computer. Connect the following cables to the system board: a) WiFi-switch board b) speaker c) coin-cell battery d) LVDS Route the antenna cables through the routing channels.
Page 44
e) keyboard trim f) keyboard g) display assembly h) palmrest media board (available in E6430/E6430 ATG only) ExpressCard cage k) system board Disconnect the modem-card cable from the modem card. Remove the modem cable from the routing channel. Remove the screw that secures the modem-connector bracket to the computer. Remove the modem-connector bracket from the computer.
Remove the modem connector from the computer. Installing the Modem Connector Place the modem connector in its compartment. Place the modem-connector bracket on the connector. Tighten the screw to secure the modem-connector bracket. Route the modem connector cable. Connect the modem-card cable to the modem card. Install: a) system board b) ExpressCard cage...
Page 46
b) base cover Remove the screws that secure the LVDS support bracket to the system board. Remove the LVDS support bracket from the system board. Disconnect the LVDS cable. Disconnect the camera cable from the system board. Remove the LVDS cable from the routing channel.
Remove the screws to release the display assembly on both sides. Lift the display assembly and pull the LVDS and the antenna cables through the opening of the computer. 10. Remove the display assembly from the computer. Installing the Display Assembly Place the display assembly onto the computer.
Tighten the screws on both corners to secure the display assembly. Route the antenna and the LVDS cables through the routing channel. Connect the following cables to the computer: a) LVDS b) camera Connect the LVDS support bracket in its position on the computer. Tighten the screw to secure the support bracket to the computer.
Installing the Display Bezel Place the display bezel onto the display assembly. Starting from the top corner, press on the display bezel and work around the entire bezel until it clicks onto the display assembly. Press on the left and right edges of the display bezel. Install the battery.
Peel off the LVDS cable connector tape and disconnect the LVDS cable from the display panel. Remove the display panel from the display assembly. Installing the Display Panel Connect the LVDS cable and stick the LVDS cable connector tape. Flip the display and place it in the display assembly. Tighten the screws to secure the display panel to the display assembly.
Page 51
a) battery b) base cover Remove the screws that secure the LVDS support bracket to the system board. Remove the LVDS support bracket from the system board. Disconnect the LVDS cable. Disconnect the camera cable from the system board. Remove the LVDS cable from the routing channel.
Remove the screws to release the display assembly on both sides. Lift the display assembly and pull the LVDS and the antenna cables through the opening of the computer. 10. Remove the display assembly from the computer. Installing the Display Assembly Place the display assembly onto the computer.
Tighten the screws on both corners to secure the display assembly. Route the antenna and the LVDS cables through the routing channel. Connect the following cables to the computer: a) LVDS b) camera Connect the LVDS support bracket in its position on the computer. Tighten the screw to secure the support bracket to the computer.
Installing the Display-Hinge Caps Slide the left hinge cap on the display panel. Rotate the hinge downward to secure the hinge cap to the display panel. Repeat steps 1 and 2 for the right hinge cap. Install: a) display assembly b) keyboard c) keyboard trim d) bluetooth card...
Remove the screws that secures the display hinges to the display assembly. Remove the display hinges from the display assembly. Installing the Display Hinges Place both the display hinges on the panel. Tighten the screws to secure the display hinges to the display assembly. Place the display hinge plates on the hinges.
battery After Working Inside Your Computer . Follow the procedures in Removing the Camera Before Working Inside Your Computer . Follow the procedures in Remove: a) battery b) display assembly c) display bezel d) display panel Disconnect the LVDS and camera cable from the camera. Remove the screw that secures the camera to the display assembly.
Installing the Camera Install the camera in its slot on the display panel. Tighten the screw to secure the camera to the display assembly. Connect the LVDS and the camera cable to the camera. Install: a) display panel b) display bezel c) display assembly d) battery After Working Inside Your Computer .
Remove the LVDS and camera cable from the display assembly. Installing the LVDS and Camera Cable Route the LVDS and camera cable on the display assembly. Fix the adhesive the tape to secure the cable. Connect the LVDS and camera cable to the camera. Install: a) display hinges b) display panel...
Additional Information This section provides information for the additional features that are part of your computer. Docking Port Information The docking port is used for connecting the laptop to a docking station (optional). 1. Docking Port...
Boot Sequence allows you to bypass the System Setup‐defined boot device order and boot directly to a specific device (for example: optical drive or hard drive). During the Power-on Self Test (POST), when the Dell logo appears, you can: •...
Keys Navigation <Enter> Allows you to select a value in the selected field (if applicable) or follow the link in the field. Spacebar Expands or collapses a drop‐down list, if applicable. <Tab> Moves to the next focus area. NOTE: For the standard graphics browser only. <Esc>...
Page 63
Option Description • Disabled • Enabled • Enabled w/PXE (Default Setting) Parallel Port Allows you to define and set how the parallel port on the docking station operates. You can set the parallel port to: • Disabled • • • Serial Port Identifies and defines the serial port settings.
Page 64
Option Description • Enable SMART Reporting - This option is disabled by default. USB Configuration Allows you to define the USB configuration. The options are: • Enable Boot Support • Enable External USB Port Default Setting: both the options are enabled. USB PowerShare Allows you to configure the behavior of the USB PowerShare feature.
Page 65
Table 4. Video Option Description LCD Brightness Allows you to set the panel brightness when the ambient sensor is Off. Optimus Allows you to enable or disable the NVIDIA Optimus technology. • Enable Optimus - Default Setting. Table 5. Security Option Description Intel TXT (LT-SX) Configuration...
Page 66
Option Description Default Setting: Enable CPU XD Support Computrace Allows you to activate or disable the optional Computrace software The options are: • Deactivate (Default Setting) • Disable • Activate NOTE: The Activate and Disable options will permanently activate or disable the feature and no further changes will be allowed CPU XD Support Allows you to enable the Execute Disable mode of the processor.
Page 67
Option Description Hyper-Thread Control Allows you to enable or disable the HyperThreading in the processor. Default Setting: Enabled Table 7. Power Management Option Description AC Behavior Allows the computer to power-uon automatically, when AC adapter is plugged. The option is disabled. •...
Page 68
Option Description • Custom Charge — you can set the percentage to which the battery must charge . Battery Slice Configuration Allows you to define the how to charge the battery. The options are: • Standard Charge • Express Charge (Default Setting) Table 8.
It is recommended to update your BIOS (system setup), on replacing the system board or if an update is available. For notebooks, ensure that your computer battery is fully charged and connected to a power outlet Restart the computer. Go to support.dell.com/support/downloads.
Automatically detect my Service Tag for me b) Choose from My Products and Services List c) Choose from a list of all Dell products On the application and drivers screen, under the Operating System drop-down list, select BIOS. Identify the latest BIOS file and click Download File.
Use the following guidelines to assign the system password: – A password can have up to 32 characters. – The password can contain the numbers 0 through 9. – Only lower case letters are valid, upper case letters are not allowed. –...
Diagnostics If you experience a problem with your computer, run the ePSA diagnostics before contacting Dell for technical assistance. The purpose of running diagnostics is to test your computer's hardware without requiring additional equipment or risking data loss. If you are unable to fix the problem yourself, service and support personnel can use the diagnostics results to help you solve the problem.
Troubleshooting Your Computer You can troubleshoot your computer using indicators like Diagnostic Lights, Beep Codes, and Error Messages during the operation of the computer. Device Status Lights Table 13. Device Status Lights Turns on when you turn on the computer and blinks when the computer is in a power management mode. Turns on when the computer reads or writes data.
Battery Status Lights If the computer is connected to an electrical outlet, the battery light operates as follows: Alternately An unauthenticated or unsupported non-Dell AC adapter is attached to your laptop. blinking amber light and white light Alternately Temporary battery failure with AC adapter present.
Technical Specifications NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your computer. For more information regarding the configuration of your computer, click Start → Help and Support and select the option to view information about your computer. Table 15.
Page 78
Feature Specification 24-bit (analog-to-digital and digital-to-analog) Stereo conversion Interface: Internal high-definition audio External microphone-in/stereo headphones/external speakers connector Speakers Internal speaker amplifier 1 W (RMS) per channel Volume controls keyboard function keys, program menus Table 19. Video Feature Specification Type integrated on system board Controller •...
Page 79
Specification Type • HD(1366x768), WLED • HD+(1600 x 900) • FHD (1920 x 1080) Size Latitude E6430 14.0" Latitude E6530 15.6" Latitude E6430 ATG 14.0" Dimensions: Latitude E6430: Height 192.50 mm (7.57 inches) Width 324 mm (12.75 inches) Diagonal 355.60 mm (14.00 inches) Active area (X/Y) 309.40 mm x 173.95 mm...
Page 80
Table 24. Keyboard Feature Specification United States: 86 keys, United Kingdom: 87 keys, Brazil: 87 keys, Number of keys and Japan: 90 keys NOTE: Numeric keypad is available for Latitude E6530. Layout QWERTY/AZERTY/Kanji Table 25. Touchpad Feature Specification Active Area: X-axis 80.00 mm...
Page 81
Table 26. Battery Feature Specification Type • 4-cell (40 WHr) Lithium-ion battery with Express Charge (selected countries only) • 6-cell (60 WHr) Lithium-ion battery with Express Charge • 9-cell (97 WHr) Lithium-ion battery with Express Charge • 9-cell (87 WHr) Lithium-ion battery Dimensions: 4-cell / 6-cell: Depth...
Page 82
–40 °C to 70 °C (–40 °F to 158 °F) –40 °C to 70 °C (–40 °F to 158 °F) Table 28. Physical Feature Latitude E6430 Latitude E6530 Latitude E6430 ATG Height 26.90 mm to 32.40 mm (1.06 28.40 mm to 34.20 mm (1.11 29.50 mm to 37.70 mm (1.16...
2. Verify your country or region in the Choose a Country/Region drop-down menu at the bottom of the page. 3. Click Contact Us on the left side of the page. 4. Select the appropriate service or support link based on your need. 5. Choose the method of contacting Dell that is convenient for you.
