- Page 1 CL920 Tablet PC Model FWS-002 User’s Guide...
- Page 2 Motion. respective companies. The information in this document is provided “as is” The warranties for Motion products are set forth in the and is subject to change without notice. Motion is not express limited warranty statements accompanying liable for errors or omissions in this document.
-
Page 3: Table Of Contents
Using Motion Dashboard ............20 Accessing Motion tools from the Windows notification area ..... 21 Using touch . - Page 4 Entering special keys with the extended keyboard......28 Using handwriting recognition ..........29 Using the built-in microphones .
- Page 5 System issues ............. . . 58 Frequently asked questions.
-
Page 6: Chapter 1 Getting Started
Getting Started The Motion CL920 Tablet PC is a durable, lightweight, and enterprise-ready rugged tablet that provides robust computing power and a variety of integrated features to increase productivity and reduce downtime in your mobile workflow. The CL920 Tablet PC includes these features: •... -
Page 7: Optional Features
Optional features This section describes the optional features available when you purchase your CL920. Integrated Qualcomm® Gobi™ technology 4G LTE mobile broadband with GNSS You can purchase an CL920 Tablet PC with an optional integrated 4G LTE mobile broadband with Global Navigation Satellite System (GNSS) module that enables you to connect to a variety of mobile broadband networks for sending and receiving data wirelessly. -
Page 8: Security
Security Your CL920 includes several features that you can use to enhance the security of your data and serve as the foundation for complementary security technologies. The core security features include password-protected BIOS, networking control, optional Computrace® Complete tracking software, WinMagic® SecureDoc™ hard drive encryption software, and TCG Trusted Platform Module (TPM) 1.2. -
Page 9: Motion® Cl-Series Slatemate™ With Magnetic Stripe Reader
Motion® CL-Series SlateMate™ with Magnetic Stripe Reader (MSR) and Barcode Scanner (BCS) You can purchase an optional CL-Series SlateMate™ with Magnetic Stripe Reader (MSR) and Barcode Scanner (BCS). The CL-Series SlateMate™ is the first in a family of integrated expansion modules designed to provide additional functionality. You can view additional information about the CL-Series SlateMate here: http://www.motioncomputing.com/us/... -
Page 10: Overview Of The Cl920
Overview of the CL920 The following photos illustrate the features available on the CL920 Tablet PC. Front Web camera light Volume Web camera buttons Microphones Speaker Battery charge indicator lights Ambient light sensor Touchscreen display Windows button Speaker Listen to audio warnings, music, and other multimedia applications. Web camera Interact with people online, stream video, or capture color images with a 1.3MP web camera. -
Page 11: Back
Battery charge Monitor battery status. When running on battery, the LED lights on the indicator lights front show the current level of battery charge when the battery gauge button on the left side of the tablet is pressed. Ambient light sensor Measures the light in your environment and can automatically adjust the brightness of the display. -
Page 12: Right Side
Right side Pen tether Pen bay attach point Pen bay release button Pen bay Store the pen when not in use. Pen bay release Press to open the pen bay. button Pen tether anchor Loop a pen tether through this attach point to keep your pen with the tablet. -
Page 13: Pen
The CL-Series digitizer pen includes a pressure-sensitive tip and a function button. The pen comes with an AAAA battery and pen tether. Function button Battery compartment You can purchase additional pens from the Motion Computing Accessories page. For more information on using the pen, see Adjusting pen settings on page 25. -
Page 14: Where To Begin With Your Cl920
The CL920 includes built-in Wi-Fi and Bluetooth. Your Tablet PC may also be equipped with mobile broadband. To set up available wireless networks, follow these steps: Step 1. Enable Wireless from Motion Dashboard 1. From the taskbar, tap the Dashboard icon. -
Page 15: Step 3: Get Familiar With Your Cl920 Tablet Pc
Step 3: Get familiar with your CL920 Tablet PC Once you’ve set up your CL920, take a few minutes to get familiar with your tablet PC. • Use Motion Dashboard to customize your tablet to fit your work style. See Using Motion Dashboard on page 20. -
Page 16: Step 4: When You Take A Break
Step 4: When you take a break When you leave your Tablet PC for a while, you can lock it to prevent unauthorized access by pressing the security button and then by tapping Lock this computer on the following screen. You can configure the Power button to shut down your Tablet PC or to put it in Sleep or Hibernate mode to save power when you press the Power button. -
Page 17: Attach The Pen Tether
2. Slip the other end of the tether through the attach point on the CL920, then pull the pen through the loop until it is tight. You can purchase additional pen tethers from the Motion Computing Accessories page. Insert the digitizer pen battery The digitizer pen is included with your CL920 and comes in a separate package along with an AAAA battery and pen tether. -
Page 18: For More Information
• Using your CL920—Provides instructions for basic CL920 tasks including how to customize your tablet to fit the way you work using Motion Dashboard, how to use the cameras, how to set up speech recognition, and more. • Caring for your CL920—Provides suggestions for the care and maintenance of your... -
Page 19: For More Information
Chapter 1 Getting Started For more information 19... -
Page 20: Chapter 2 Using Your Cl920
Using your CL920 This chapter provides information about performing the following tasks: • Using Motion Dashboard on page 20 • Using touch on page 22 • Entering text and handwriting recognition on page 26 • Using the built-in microphones on page 29 •... -
Page 21: Motion Computing Applications
To open Motion Dashboard: • From the taskbar, tap the Motion Dashboard icon Motion Dashboard is organized into categories, which are listed on the left of the Dashboard. Tap a category to display its settings. Chapter 2 Using your CL920... -
Page 22: Accessing Motion Tools From The Windows Notification Area
You can access common Motion tools from the Windows notification area. Initially, the Motion icons do not appear in the Windows notification area. Tap the arrow to view more icons. Tap Customize to enable the icons to appear. Chapter 2... -
Page 23: Using Touch
Motion Dashboard—Opens the Motion Dashboard • Options—Lists options you can set: – Show Hard Drive Activity—When selected, the Motion icon blinks when there is hard drive activity. – Automatic Display Rotation—When selected, the CL920 automatically changes the viewing orientation (landscape to portrait or vice versa) when the tablet is physically rotated. -
Page 24: Changing To One-Tap Open For Touch
Switch between touch and pen input, in which case you double-tap to switch to touch input. This is useful to prevent the tablet from responding to unintentional touch input. To configure touch settings: 1. Open Motion Dashboard. 2. Tap Pen & Tablet. 3. Tap Touch Settings. -
Page 25: Adjusting Touch Settings
Change the location of menus to appear to the right of your hand, which is helpful if you’re left-handed. To change touch settings: 1. Open Motion Dashboard. 2. Tap Pen & Tablet. 3. Tap Pen & Input Devices. 4. Tap the Touch tab. -
Page 26: Adjusting Pen Settings
The CL920 Tablet PC responds only to the CL-Series pen that comes with the tablet. Do not use traditional pens or other pointing devices with the CL920. To change pen settings: 1. Open Motion Dashboard. 2. Tap Pen & Tablet. 3. Tap Pen & Input Devices. -
Page 27: Entering Text And Handwriting Recognition
To change this, run Setup from Tablet PC Settings to assign touch to your tablet display. A keyboard must be connected to the tablet to perform this procedure. To assign touch to the desired display: 1. Open Motion Dashboard. 2. Tap Pen & Tablet. 3. Tap Tablet PC Settings. 4. Tap the Display tab. -
Page 28: Opening And Closing The Input Panel
Tap the icons at the top of the input panel to view videos on making editing gestures. To hide the video tips, tap the icon on the right. By tapping the keyboard icon at the top of the pad, the input panel opens to the on-screen keyboard. -
Page 29: Entering Numbers With Numbers Pad
To dock or undock the input panel: 1. At the top of the input panel, tap Tools. 2. Select Docking. 3. Select either Dock at the top of the screen, Dock at the bottom of the screen, or Float. If you're left-handed, you can move the input panel to the right edge of the screen to make it easier to use. -
Page 30: Using Handwriting Recognition
Using handwriting recognition Handwriting recognition is enabled by default. The more you write, the quicker your handwriting is recognized because the tablet has an automatic learning tool that collects data about the words you use and how you write them. This data is stored under your user profile. -
Page 31: Connect An External Monitor
Connect an external monitor You can connect an external display monitor to the Micro-HDMI (Type D) port on the left side of the CL920. It supports resolutions of up to 1080p @ 60Hz. Additionally, the CL-Series Docking Station includes a VGA port that you can use to connect an external monitor. The CL-Series Docking Station is sold separately. - Page 32 Taking a photo with SnapWorks 1. Tap the camera icon on the Windows taskbar to activate Motion SnapWorks. 2. Hold the camera steady and point the lens at the object. 3. Press the SnapWorks camera icon to take the picture.
- Page 33 4. Point your camera at the subject you want to photograph. You can use the grid and center circle to help you line up your subject(s). 5. Tap the camera icon on the right side of the screen to take a picture. To zoom in or out on your subject, use the zoom adjustment slider on the left side of the screen.
- Page 34 Setting Description Camera Resolution Change the resolution of your photos. (Note: These resolution values apply to the documentation camera only.) Image Storage Specify the location where your photos are stored. Default Saved Use to select the image format you want to use for your Image Type photos.
- Page 35 Editing a photo in SnapWorks 1. Tap the Gallery icon in the upper left-hand corner of the screen to open the directory where your photos are stored. You’ll see the most recent photos you have taken. 2. Double-tap the photo you want to edit. The photo opens and you’ll see two icons at the bottom left-hand corner of the screen that you can tap to open the SnapWorks photo editing tools.
- Page 36 Sending, printing, and copying your photos 1. To send your photo via email, tap the Gallery icon in the upper left-hand corner of the screen to open the directory where your photos are stored. 2. Tap your photo once to select it, then tap the Send icon You’ll see a pop-up window that tells you to choose a method to send your image.
-
Page 37: Using The Magnetic Stripe Reader (Optional)
Using the Magnetic Stripe Reader (optional) If you purchased a CL-Series SlateMate™ with Magnetic Stripe Reader (MSR) and Barcode Scanner (BCS), you can use the MSR to read any card that has a magnetic stripe on the back, such as a credit or debit card. Status light The following table illustrates the MSR status light conditions. -
Page 38: Supported Barcode Types
Supported barcode types The CL920 barcode scanner supports the following barcode types by default: • Code 39 • Interleaved 2 of 5 • Code 128/GS1-128 • Micro PDF417 • EAN/UPC - UPC-A • QR Code • EAN/UPC - UPC-E Other barcode types can be enabled by using the EasySet application. To download and Software Downloads install EasySet, go to , select your Tablet PC model and operating... -
Page 39: Barcode Scanner Tips
Under normal conditions, you can run the tablet on battery power for up to seven hours. If you ever need to replace the battery, contact your Motion Computing authorized service provider. Only authorized service providers can replace the battery. -
Page 40: Battery And Power Management Tips
Put your Tablet PC in Sleep mode when you’re not using it. • Stop unnecessary background applications and processes. • When not in use, disable wireless adapters using the Motion Dashboard Wireless settings. • Set the brightness of the display to automatically dim after a selected number of minutes of inactivity using the Motion Dashboard Display settings. -
Page 41: Changing The Power Plan
Changing the power plan By default, the CL920 uses the Motion Optimized power plan, which is designed specifically for Motion Computing tablets. It balances the need to save power while maximizing tablet performance. When the tablet senses no current activity, it goes into Power Saver mode automatically. -
Page 42: Changing How The Power Button Functions
Mobile Broadband network carrier. Enabling 4G LTE Mobile Broadband with GNSS Before you can establish a Mobile Broadband connection or use the Mobile Broadband GNSS receiver, you must ensure that Mobile Broadband is enabled in Motion Dashboard. Chapter 2 Using your CL920... -
Page 43: Using Integrated U-Blox 7-Based Augmented Gps
To reduce power consumption when running only on battery power and when 4G LTE Mobile Broadband with GNSS isn’t being used, disable Mobile Broadband in Motion Dashboard. To enable Mobile Broadband: 1. Open Motion Dashboard and tap Power. 2. Tap the switch beside Mobile Broadband to turn it on. -
Page 44: Using Winmagic® Securedoc
Using WinMagic® SecureDoc™ WinMagic SecureDoc is an application that enables you to encrypt your drive. This application is included with your CL920, but you have to enable it to implement drive encryption. To enable WinMagic SecureDoc: 1. From the Start menu, select All Programs > SecureDoc Disk Encryption> SecureDoc Control Center. -
Page 45: Using The Sim Card Reader
4. After you have enabled encryption, reboot your Tablet PC, and manually restart SecureDoc to complete the encryption process. For more information about WinMagic SecureDoc, go to http://www.winmagic.com/ products/full-disk-encryption-for-windows. Using the SIM card reader The SIM card slot holds one mini (2FF) SIM card, for use with the mobile broadband option. Contact your service provider for additional information. -
Page 46: Using The Sd Card Reader
To access the BIOS Setup Utility: 1. Restart your tablet. 2. As soon as the tablet starts, and no later than when the Motion splash screen appears, tap the screen with your finger or the pen. An alert sounds when you’ve accessed the BIOS Setup Utility. -
Page 47: Backing Up Your System
If a keyboard is attached to your CL920, you can press F2 to open the Setup Utility. Then, press the arrow keys to select items and press Enter to select a submenu. Backing up your system To protect against loss or accidental deletion, schedule backups to occur automatically on a regular basis. -
Page 48: Restoring Your System Image From Windows Control Panel
2. From the Windows Control Panel, tap System and Security category, then tap Back up your computer. 3. From the navigation bar on the left, tap Create a system image, then follow the on-screen instructions. For complete instructions, open Windows Help and search for “Back up your programs, system settings, and files. -
Page 49: Restoring Your System Without A System Image
For information about other software for your tablet, go to Motion Computing Accessories. You will find links to software solutions for purchase as well as free software downloads from Motion Computing and its service partners. Chapter 2 Using your CL920 Finding other software 48... -
Page 50: Chapter 3 Caring For Your Cl920
Caring for your CL920 Proper care and maintenance will keep your CL920 Tablet PC working and in good condition. For general information about care of the tablet and its components and accessories, see the Safety and Regulatory Guide included with your tablet PC. WARNING: Follow the guidelines listed in this chapter when caring for your tablet PC and its components. -
Page 51: Caring For The Display
Make sure you wipe off the pen with a soft cloth to avoid scratching the display. • If you’ll be working in harsher environments, Motion recommends that you purchase the Rugged Digitizer Pen for your CL920, which is available for purchase from the... -
Page 52: Traveling With Your Cl920 Tablet Pc
Use the following tips when you travel with your CL920 Tablet PC: • Put the Tablet PC in a case to protect the display. Motion Computing sells a variety of cases for the CL920. You can purchase one at the Motion Computing Accessories page. -
Page 53: Chapter 4 Troubleshooting And Faqs
Troubleshooting and FAQs Motion Computing tablet PCs are thoroughly tested for performance and quality, but occasionally issues can still occur. If you don’t find the information you’re looking for in this section, go to Motion Computing Support. Troubleshooting Use the information in this section to identify and resolve common issues. If an issue has more than one potential cause, the most common cause is listed first. -
Page 54: Battery Issues
Have the battery replaced. While the built-in lithium-ion battery is designed for a long battery life, you may find the need to replace it. If so, contact your Motion Computing service provider. Only authorized service providers can replace the battery. -
Page 55: Touch Or Pen Issues
Run touch setup on the desired display. Make sure a keyboard is attached to your tablet and then open Motion Dashboard. Tap Pen & Tablet, then tap Tablet PC Settings. Tap the Display tab, then tap Setup next to “Configure your pen and touch displays. ” Tap... - Page 56 • The pen function button may be disabled. To enable it, open Motion Dashboard then tap Pen & Tablet. Tap Pen & Input Devices and tap the Pen Options tab. Tap the checkbox next to “Use the pen button as a right-click equivalent.
-
Page 57: Ports And Connectors Issues
Panel then Network and Internet. View your active networks. If no network is connected, tap Connect to a network and select a network from the list. • Wi-Fi must be enabled from the Motion Dashboard. Open Motion Dashboard, tap Wireless and tap the checkbox next to Enable 802.11 Internal Wireless. •... -
Page 58: Bluetooth Wireless Tips
If the tablet still can’t detect the Bluetooth device, contact the device manufacturer for assistance. Bluetooth wireless tips Motion Computing and its Bluetooth partners have worked to ensure a positive experience with this technology and to ensure Bluetooth interoperability. In doing so, we have found the following issues: •... -
Page 59: Audio Issues
• The volume may be set too low or muted. You can use Motion Dashboard to increase the volume or turn mute off. Open Motion Dashboard, then tap Audio and move the slider to the desired volume. -
Page 60: System Issues
Use the Dynamic display setting. This automatically controls the display to conserve power. Open Motion Dashboard, tap Display then tap Dynamic. • Set the display to the dimmest level you are comfortable with. Open Motion Dashboard, tap Display then move the Brightness slider to the desired level. •... - Page 61 If the touchscreen doesn’t respond as expected or if it responds to unintentional input, you can re-tune it. Open Motion Dashboard, then tap Pen & Tablet, tap Touch Settings, tap Touch Tuning, then Start. A calibration program begins. Do not touch the display during the calibration process.
- Page 62 Can I recycle my old computer? • Yes. Motion Computing has a recycling program that allows free return of all Motion- branded products and non-Motion-branded electronics with the purchase of a similar Motion tablet for processing and disposal in an environmentally safe manner. For details,...
- Page 63 48 Getting Started doc 20 troubleshooting password 58 digital monitor 59 BIOS setup utility digitizer accessing 45 Motion Dashboard options 23 blinking power button 51 N-trig 23 Bluetooth tuning 23 discovery 56 discrete GPS receiver with WAAS, EGNOS,...
- Page 64 Motion Computing Support 51 changing 23 Motion Dashboard 20, 22 free software downloads 48 opening 20 Motion Optimized power plan 40 Motion utilities 21 gestures 24 multi-touch gestures 24 enable multi-touch 24 Getting Started 20 notification area 21...
- Page 65 25 about 41 Pen & Input Devices 24 Sleep mode 16 pen bay 12 SnapWorks™ by Motion 31 pen bay release button 12 SnapWorks™ by Motion® pen tether 17 configuring settings 32 pen tether anchor 12...
- Page 66 25 using troubleshooting 53 microphones 29 using 22 Motion Dashboard 20 using multiple monitors 26 power plans 40 touch tuning 23 sleep mode 41 calibrate 59 touchscreen display 11 caring for 49 Volume buttons 10 TPM 8 training classes...
