3. Description
H Hourmeter/service
display
displays the operation
hours. The meter only
counts if the consumers
such as drive or brush motor or suction
turbine are ON. A red dot at the bottom
right of the display flashes simultane-
ously. Equally displays occurring errors
when the (red) pilot lamp for fault di-
splay (G) alights.
Note:
Should the contact to the seat switch
not be given, the hourmeter starts
flashing.
I Pilot lamp for
battery charge
condition
Upon turning
ON the key
switch, all green
pilot lamps
alight in case of a perfectly charged
battery. During operation, the lamps
will successively extinguish as the
battery discharges.
A flashing red light indicates that ope-
ration will soon be interrupted and a
buzzer sounds.
L Key for brush drive
with pilot lamp (green)
turns the brush drive ON
and OFF. The green
lamps alights if the brush
head is lowered and the brushes
rotate. In case of malfunction, the fault
lamp (G) alights and an error code ap-
pears in the service display.
M Key for squeegee
and suction turbine
(on/off) with pilot lamp
(green)
is lowering/lifting out the
squeegee and turns the suction turbine
ON/OFF. The green lamp alights if the
squeegee is lowered and the suction
turbine ON. In case of malfunction, the
fault lamp (G) alights and an error co-
de appears in the service display.
