USB Connection Terminal
1. Purpose: USB device connection or power supply.
2. USB Connector: Standard USB Mini-B type
3.
Interface Specification: Compliant with USB HID class
specification version 1.11
4. Input Power: 0.5A 5V dedicated DC adapter or USB Bus
power from a host device.
Bluetooth Connection Switches
1. Bluetooth HID Switch (Top)
20

5. Using the Projection Keyboard

This product is used as a keyboard and mouse via
Bluetooth HID and USB HID connection.

5.1 Connecting via USB HID

This device is compatible with all USB HID capable
operating system.
USB HID connection allows plug-n-play, without
installing a separate driver.
1) Connect Magic Cube® and host device using supplied
USB cable. Host device must support USB HID. Note:
Most Windows devices support USB HID.
2) Turn on Magic Cube®.
3) Green LED indicates proper connection. If LED
indicates blue, please check the connection.
