33933049GB.fm Page 4 Monday, January 10, 2005 5:27 PM
INSTRUCTIONS FOR USE
SLIM RANGE SINGLE SPLIT AIR
CONDITIONER WITH ECOLOGICAL GAS
AND WITH GAS R22
PREPARATION BEFORE USE
SAFETY PRECAUTIONS
IDENTIFICATION OF PARTS
REMOTE CONTROL
OPERATION INSTRUCTIONS
MAINTENANCE
TROUBLESHOOTING
PROTECTION
INSTALLATION INSTRUCTIONS
SLIM RANGE R22
SLIM RANGE
This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE).
This guideline is the frame of a European-wide validity of return and recycling on Waste Electrical
and Electronic Equipment.
4
Advertisement
Table of Contents
Related Manuals for Whirlpool SLIM RANGE R22
Summary of Contents for Whirlpool SLIM RANGE R22
-
Page 1: Instructions For Use
MAINTENANCE TROUBLESHOOTING PROTECTION INSTALLATION INSTRUCTIONS SLIM RANGE R22 SLIM RANGE This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). This guideline is the frame of a European-wide validity of return and recycling on Waste Electrical... -
Page 2: Preparation Before Use
33933049GB.fm Page 5 Monday, January 10, 2005 5:27 PM PREPARATION BEFORE USE Before using the air conditioner, be sure to check and preset the following. Remote Control presetting The remote control is NOT preset as Cooling Only Air Conditioner or Heat Pump by manufacturer. Each time the remote control batteries are replaced, the Cooling indicator and Heating indicator will flash... -
Page 3: Identification Of Parts
33933049GB.fm Page 6 Monday, January 10, 2005 5:27 PM IDENTIFICATION OF PARTS Indoor unit Outdoor unit Indoor unit Outdoor unit - Air Intake N - Air Intake - Front Panel O - Pipes and Power Connection Cord - Operation Panel - Drain Hose D - Display Note: Condensate water drains... -
Page 4: Operating And Display
33933049GB.fm Page 7 Monday, January 10, 2005 5:27 PM Operating and Display For SLIM model without LED only 1. Compressor indicator 4. Signal Receptor It lights up when compressor is running. Receives signal from the remote control. 2. Timer Indicator 5. - Page 5 33933049GB.fm Page 8 Monday, January 10, 2005 5:27 PM Operating and Display SILM model without LED SLIM model with LED 1. Compressor indicator (Red) 4. Timer Indicator (Orange) It lights up when compressor is running. It lights up during the set time. 2.
-
Page 6: Remote Control
33933049GB.fm Page 9 Monday, January 10, 2005 5:27 PM REMOTE CONTROL The remote control transmits signals to the system. A. ON/OFF button The appliance will be started when it is energized or will be stopped when it is in operation, if you press this button. B. -
Page 7: Operation Instructions
33933049GB.fm Page 10 Monday, January 10, 2005 5:27 PM OPERATION INSTRUCTIONS Operating modes 1. Selecting mode Each time MODE button is pressed, the operation mode is changed in sequence: COOLING FAN ONLY HEATING IMPORTANT: Heating mode is NOT available for cooling only air conditioner. 2. - Page 8 33933049GB.fm Page 11 Monday, January 10, 2005 5:27 PM ù Horizontal airflow control (with hands) Turn the control rods of the horizontal adjustment louvers to change horizontal air flow as shown. Note: The shape of the unit may look different from that of the air conditioner you have selected.
-
Page 9: Timer Mode
33933049GB.fm Page 12 Monday, January 10, 2005 5:27 PM Timer mode It is convenient to set the timer on with TIMER button when you go out in the morning to achieve a comfortable room temperature at the time you get home. -
Page 10: Sleep Mode
33933049GB.fm Page 13 Monday, January 10, 2005 5:27 PM Sleep mode SLEEP mode can be set in COOLING or HEATING operation mode. This function gives you a more comfortable environment for sleep. In SLEEP mode, The appliance will stop operation automatically after operating for 8 hours. -
Page 11: Maintenance
33933049GB.fm Page 14 Monday, January 10, 2005 5:27 PM MAINTENANCE Appliance maintenance Unplug from the power supply Stop the appliance before unplugging. To remove the front panel pull it outwards as shown in the figure (a) Wipe with a soft, dry cloth Use lukewarm water (below 40°C) to clean the appliance when it is very dirty. - Page 12 33933049GB.fm Page 15 Monday, January 10, 2005 5:27 PM PROTECTION Operating condition The protective device may trip and stop the appliance in the cases listed below. Outdoor air temperature is over 24°C *HEATING Outdoor air temperature is below -7°C Room temperature is over 27°C Outdoor air temperature is over* 43°C COOLING Room temperature is below 21°C...
-
Page 13: Installation Instructions
33933049GB.fm Page 16 Monday, January 10, 2005 5:27 PM INSTALLATION INSTRUCTIONS Distance from ceiling should be over 50 mm Installation diagram Distance from wall should be over 50 mm Distance from the wall should be over 50 mm Distance from floor should be over 2500 mm Air intake distance from the wall should be over 250 mm... -
Page 14: Select The Best Location
33933049GB.fm Page 17 Monday, January 10, 2005 5:27 PM Select the best location Indoor unit Location for Installing the Indoor Unit Where there is no obstacle near the air outlet and air can easily be blown to every corner. Pipe length Where piping and wall hole can easily be arranged. -
Page 15: Indoor Unit Installation
33933049GB.fm Page 18 Monday, January 10, 2005 5:27 PM Indoor unit installation 1. Installing the Mounting Plate Select a location to install the mounting plate according to the indoor Hook the line here Line drops from here unit location and piping direction. Adjust the mounting plate horizontally with a horizontal ruler or plumb line. - Page 16 33933049GB.fm Page 19 Monday, January 10, 2005 5:27 PM Thermally insulated Large pipe Thermal Insulation Piping: tube Place the drain hose under the piping. Power cord Insulating material: polythene foam over 6 mm in thickness. NOTE: Drain hose is prepared by user. Drain pipe should point downward for easy drain flow.
- Page 17 33933049GB.fm Page 20 Monday, January 10, 2005 5:27 PM 4. Connecting the Cable Front panel Terminal (inside) Indoor Unit Connect the power cord to the indoor unit by connecting the wires to the terminals on the control board individually in accordance with the outdoor unit connection.
-
Page 18: Wiring Diagram
33933049GB.fm Page 21 Monday, January 10, 2005 5:27 PM Wiring Diagram Make sure that the colour of wires of the outdoor unit and the terminal number are the same as those of the indoor unit. 7 K,9 K,12 K,18 K,22 K Model HEAT PUMP COOLING ONLY Indoor unit... -
Page 19: Air Purging
33933049GB.fm Page 22 Monday, January 10, 2005 5:27 PM Air purging Air containing moisture remaining in the refrigerant cycle may cause a malfunction of the compressor. After connecting the indoor and outdoor units, evacuate air and moisture from refrigerant cycle using a vacuum pump, as shown below. Vacuum pump Indoor unit 2-way valve...
