ADEMCO 6139 User Manual

Vista-20se/vista-20hwse
Hide thumbs Also See for 6139:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

See also: Installation Manual
Ademco Vista-20SE/Vista-20HWSE
General
This system offers you three forms of protection: burglary, fire and emergency. Your system consists of at least one
keypad that provides control of system operation, and includes various sensors that provide perimeter and interior
burglary protection, plus smoke or combustion detectors designed to provide early warning in case of fire.
Zones
Your system's sensing devices have been assigned to various "zones." For example, the sensing device on your Entry/Exit
door may have been assigned to zone 01, sensing devices on windows in the master bedroom to zone 02, and so on.
These number will appear on the display, along with a description for that zone (if programmed), when an alarm or
trouble condition occurs.
Burglary Protection
Your system provides four modes of burglary protection: stay, away, instant and maximum, and allows you to bypass
selected zones while leaving the rest of the system armed. You must turn on or "arm" the burglary protection portion of
your system before it will sense burglar alarms. The system also provides a chime mode, for alerting users to the
opening of protected doors and windows while the system is disarmed. Refer to the other sections of this manual for
procedures for using these features.
The following table lists the four different arming modes and the results of each:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6139 and is the answer not in the manual?

Questions and answers

Related Manuals for ADEMCO 6139

Summary of Contents for ADEMCO 6139

  • Page 1 Ademco Vista-20SE/Vista-20HWSE General This system offers you three forms of protection: burglary, fire and emergency. Your system consists of at least one keypad that provides control of system operation, and includes various sensors that provide perimeter and interior burglary protection, plus smoke or combustion detectors designed to provide early warning in case of fire.

  • Page 2: Arm & Disarm The System

    Arming Mode Exit Delay Entry Delay Perimeter Armed Interior Armed Away Stay Instant Maximum Arm & Disarm the System Checking for Open Zones Using the [*] READY Key Before arming your system, all protected doors, windows and other protection zones must be closed or bypassed (see BYPASSING section).

  • Page 3: Panic Alarms

    Quick Bypass: 1. Enter security code then press bypass. Example: [7] [2] [9] [6] then press the BYPASS key. 2. In a few moments, all open zones will be displayed along with the word BYPASS. Wait for these zones to be displayed before arming.

  • Page 4: Trouble Conditions

    A fire alarm sends a fire alarm message to the alarm monitoring company* and uniquely activates keypad and any external sounders (FIRE plus a zone number is also displayed). Fire Alarm System Fire Alarm System (If Installed) Your fire alarm system (if installed) is active 24 hours a day, providing continuous protection. In the event of an emergency, the installed smoke and heat detectors will automatically activate you security system, triggering a loud, interrupted sound from the Keypad.

  • Page 5: User Access Codes

    Telco Fault (or CHECK and zone 94) If the telephone line monitor feature has been programmed for your system, this display indicates that the telephone line has been disconnected or cut. In some systems, this display will be accompanied by a trouble sound from the keypad and the external sounder may be activated.
  • Page 6 To Activate Devices Enter security code then press [#] + [7] + then enter the number representing the device you wish to activate. To Deactivate Devices Enter security code then press [#] + [8] + then enter the number representing the device you wish to deactivate. Security Codes As an additional safety feature, other users who do not have a need to know your code can be assigned different security codes.

  • Page 7: Paging Feature

    To Delete a User: 1. Enter master code then press CODE key. 2. Enter the two-digit User Number (03-16) for the user whose code you are deleting. 3. Wait (about three seconds) until the keypad beeps once before pressing any other key. The code is automatically deleted.
  • Page 8 2. Enter the security code then press test key. 3. Listen. The external sounder should sound for 2 seconds and then turn off. If the sounder does not sound, call for service immediately. 4. Open each protected door and window in turn and listen for three beeps from the keypad. Identification of each faulted protection point should appear on the display.
  • Page 9 In addition, a battery-operated smoke detector with a low battery also emits a single "chirp" sound approximately once every 20–30 seconds, identifying itself as the smoke detector with the weak battery. Note: The low battery message comes on as a warning that battery replacement in indicated sensor(s) is due within 30 days.

This manual is also suitable for:

612761286137Vista-20seVista-20hwse
