16 CP/BP Series

Fluid Pressure Drops

Table 3:
Flow Rate
Model
(GPM)
1
1.5
007 2
3
4
1.5
2
009
2.5
3.25
4
2
3
012
4
5.5
7
2
3
015
4
5.5
7
3
4
018
5
6.5
8
3
4.5
024
6
8
10
6 720 220 045
Pressure Pressure
Drop (FOH) Drop (PSI)
1.4 0.61
2.9 1.26
4.9 2.11
10.1 4.38
16.9 7.34
2.3 1.00
3.9 1.68
5.8 2.51
9.3 4.03
13.5 5.85
1.7 0.72
3.4 1.50
5.8 2.51
10.2 4.45
15.8 6.88
1.6 0.69
3.3 1.44
5.5 2.41
9.8 4.28
15.2 6.60
4.1 1.80
7.0 3.02
10.4 4.52
16.7 7.25
24.2 10.53
2.0 0.87
4.1 1.80
6.9 3.01
11.6 5.06
17.4 7.56
Subject to change without prior notice
Unit Specifications
Flow Rate
Model
(GPM)
4
5.5
030 7
10
13
5
7.5
036
10
12.5
15
7
8.75
042
10.5
13.25
16
8
10.67
048
12
14
16
9
12
060
15
17.5
20
10
13.5
070
17
20.5
24
Pressure Pressure
Drop (FOH) Drop (PSI)
1.2 0.51
2.1 0.91
3.2 1.41
6.1 2.67
9.9 4.28
2.3 1.01
4.8 2.09
8.1 3.51
12.1 5.25
16.8 7.29
2.8 1.22
4.2 1.82
5.8 2.53
8.9 3.85
12.4 5.41
3.6 1.55
6.0 2.61
7.4 3.22
9.8 4.25
12.4 5.41
3.7 1.60
6.2 2.69
9.2 4.02
12.2 5.30
15.5 6.74
2.8 1.24
4.9 2.12
7.4 3.22
10.4 4.50
13.8 5.98
Revised 01-11
