  • Page 1 SyncMaster 150MP / 170MP...
  • Page 2 User's Manual - 2 Index Main Page Safety Instructions Adjusting Your LCD Monitor Notational User Controls Power User control buttons Installation Direct-Access Features Cleaning On -Screen Display Other OSD Functions Introduction Screen Adjustment Animation Clips Unpacking Troubleshooting Front Check before Calling for Service Rear Problems and Solutions Remote Control...

  • Page 3: Safety Instructions

    User's Manual - 3 Safety Instructions- Notational Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment. Prohibited Important to read and understand at all times Do not disassemble Disconnect the plug from the outlet Do not touch Grounding to prevent an electric shock...
  • Page 4 User's Manual - 4 Safety Instructions -Power When not used for extended periods of time, set your PC to DPMS. If using a screen saver, set it to the active screen mode. Do not use a damaged or loose plug. This may cause an electric shock or fire.
  • Page 5 User's Manual - 5 Safety Instructions -Installation Do not cover the vents on the monitor cabinet. Bad ventilation may cause a breakdown or fire. Put your monitor in a location with low humidity and a minimum of dust. An electric shock or fire could result inside the monitor. Do not drop the monitor when moving it.
  • Page 6 User's Manual - 6 Safety Instructions -Cleaning When cleaning the monitor case or the surface of the TFT -LCD, wipe with a slightly moistened, soft fabric. Do not spray detergent directly on the monitor. Use the recommended detergent with a smooth cloth. If the connector between the plug and the pin is dusty or dirty, clean it properly with a dry cloth.
  • Page 7 User's Manual - 7 Safety Instructions -Other Do not remove cover(or back). No user serviceable parts inside. This may cause an electric shock or a fire. Refer servicing to qualified service personnel. If your monitor does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized dealer or service.
  • Page 8 User's Manual - 8 Safety Instructions -Other Never insert anything metallic into the monitor openings. This may cause an electric shock, fire or injury.
  • Page 9 User's Manual - 9 Introduction -Unpacking Please make sure the following items are included with your monitor. If any items are missing, contact your dealer User's Guide and Natural Power Cord Signal Cable(15 pin D-Sub) Color/Driver Installation CD DC Adapter Monitor Audio Cable Remote Control / Batteries (AAA X 2)
  • Page 10 User's Manual - 10 Introduction -Front For detailed information concerning the monitor functions, refer to User Controls under Adjusting Your Monitor. The monitor's front configuration may vary slightly depending on the monitor model. 1 Input Signal Indicators 5 Menu button 2 Source button 6 Power button / Power indicator 3 PIP button...
  • Page 11 User's Manual - 11 Introduction -Rear For detailed information concerning cable connections, refer to Connecting Cables under Setup. The monitor's rear configuration may vary slightly depending on the monitor model. Remove the cover to connect the cables. (Pull the joining part to remove the cover.) Power Connection Terminal (14V DC) This product may be used with 90 ~ 264.

  • Page 12: Remote Control

    User's Manual - 12 Introduction -Remote Control For detailed information of the Remote Control Unit functions, refer to Adjusting Your Monitor > User Controls > User Control Buttons > Remote Control buttons The remote control's configuration may vary slightly depending on the monitor model. The Remote control may function within a range of 0.23 to 33 feet (7cm to 10m) and 30 degrees to the left and right of the monitor's Remote Control Reception sensor.

  • Page 13: Replacing Batteries

    User's Manual - 13 Introduction -Remote Control 2. Replacing Batteries 1. Slide out the cover pressing part marked 2. Insert the batteries matching their polarities (+, -). 3. Slide in the cover.
  • Page 14 5. Turn on both your computer and the monitor. 6. You may enjoy clear and quality sound from the computer sound card using the monitor speakers. (You don't need to install any separate speakers for your computer.) Contact a local Samsung Electronics service center to buy optional items.

  • Page 15: Connecting Av Devices

    User's Manual - 15 Setup -Connecting to Other Devices AV input devices like DVDs, VCRs or Camcorders as well as your computer may be connected to the monitor. For detailed information on connecting AV input devices, refer to User Controls under Adjusting Your Monitor.

  • Page 16: Connecting To A Macintosh

    User's Manual - 16 Setup -Connecting to Other Devices 2. Connecting TV You may view television programs on the monitor if it is connected to an antenna or CATV cable without installing any separate TV reception hardware or software on your computer. 1.

  • Page 17: Connecting Headphones

    3. For older model Macintoshes, you need to adjust the resolution control DIP switch on the Macintosh adapter (optional) referring to the switch configuration table shown on its rear. 4. Turn on the monitor and Macintosh. Contact a local Samsung Electronics service center to buy optional items.

  • Page 18: Installing The Monitor Driver (Automatic)

    Driver installation is slightly different from one operating system to another. Follow the directions as appropriate for the operating system you have. Prepare a blank disk and download the driver program file at the Internet web site shown here. Internet web site : http://www.samsung -monitor.com/ (Worldwide) http://www.samsungusa.com/monitor/ (USA) http://www.sec.co.kr/monitor/...
  • Page 19 5. If you can see following Message window, then click the "Continue Anyway " button. Then click "OK " button. This monitor driver is under certifying MS logo,and this installation don't damage your system. The certified driver will be posted on Samsung Monitor Homepage http://www.samsung-monitor.com/ 6. Monitor driver installation is completed.

  • Page 20: Installing The Monitor Driver (Manual)

    Driver installation is slightly different from one operating system to another. Follow the directions as appropriate for the operating system you have. Prepare a blank disk and download the driver program file at the Internet web site shown here. Internet web site : http://www.samsung -monitor.com/ (Worldwide) http://www.samsungusa.com/monitor/ (USA) http://www.sec.co.kr/monitor/...
  • Page 21 User's Manual - 21 Setup -Installing the Monitor Driver (Manual) 5. Click " Update Driver.." and select "Install from a list or.." then click "Next" button. 6. Select "Don't search ,I will.." then click "Next" and then click " Have disk". 7.
  • Page 22 8. If you can see following "Message " window, then click the " Continue Anyway " button. Then click "OK" button. This monitor driver is under certifying MS logo,and this installation don't damage your system. The certified driver will be posted on Samsung Monitor Homepage http://www.samsung-monitor.com/ 9. Click the "Close" button then click "OK " button continually.

  • Page 23: Microsoft ® Windows ® 2000 Operating System

    User's Manual - 23 Setup -Installing the Monitor Driver (Manual) 10. Monitor driver installation is completed. ® ® 2. Microsoft Windows 2000 Operating System * When you can see "Digital Signature Not Found" on your monitor, follow these steps. 1. Choose "OK " button on the " Insert disk" window. 2.
  • Page 24 User's Manual - 24 Setup -Installing the Monitor Driver (Manual) 10. Select "Show all devices" and choose the monitor that corresponds to the one you connected to your computer and click "OK ". 11. Continue choosing "Close" button and " OK " button until you close the Display Properties dialogue box.
  • Page 25 User's Manual - 25 Setup -Using the FOLD button The monitor may be reclined from 0 to 90 degrees. When fully folded (reclined), the base becomes a handy holder for moving the monitor around. Reclining the Monitor Folding Base 1. Reclining Monitor 1.
  • Page 26 User's Manual - 26 Setup -Using the FOLD button 2. Folding Base 1. Disconnect the monitor cables. 2. Fully recline the monitor backward pressing the FOLD button. 3. Reconnect the monitor cables. You may install a VESA base when the monitor base is fully folded.
  • Page 27 Align the four bolt holes (1) on the monitor base with the holes (2) on the VESA base and then fasten the base with the four bolts (3) supplied. Only the supplied bolts should be used. Samsung Electronics will not be responsible for damages caused by using a base other than those specified.

  • Page 28: Monitor Buttons

    User's Manual - 28 Adujust Monitor -User control buttons The control button configuration may vary slightly depending on the monitor model. Monitor Buttons Remote Control Buttons 1. Monitor Buttons For more information about screen adjustment, refer to On -Screen Display 1.

  • Page 29: User Control Buttons

    User's Manual - 29 Adujust Monitor -User control buttons - CH + button Moves from one menu item to another vertically or adjusts selected menu values. In TV mode, selects TV channels. For more information, refer to Direct-Access Features > Channel. - VOL + button Moves from one menu item to another horizontally or adjusts selected menu values.
  • Page 30 User's Manual - 30 Adujust Monitor -User control buttons In PC Mode, turns on Video or TV screens in PIP mode. Using this function, you may view a Video or TV program while performing PC work. To deactivate the PIP screen, press the Exit button.
  • Page 31 User's Manual - 31 Adujust Monitor -User control buttons Adjusts the screen display automatically. For more information, refer to Direct-Access Features > Automatic Save. 17 Channel search button Automatically scans and registers TV channels available (viewable) in the current location. For detailed information on adjusting the TV screen, refer to OSD Functions >...

  • Page 32: Direct-Access Features

    User's Manual - 32 Adujust Monitor -Direct-Access Features Direct-Access Features let you display Monitor Adjustment Menu by simply pressing Auto button once. Or they are used to adjust monitor functions. You need to activate functions other than Auto Adjustment only when Auto-Access Features are off. Automatic Save OSD Lock/Unlock Volume...
  • Page 33 User's Manual - 33 Adujust Monitor -Direct-Access Features 4. Channel When OSD is not on the screen, push the button to select channel number. 1. Push the button to decrease the channel number. 2. Push the button to increase the channel number. This function is available in TV or PC + TV (PIP) mode only.
  • Page 34 User's Manual - 34 Adujust Monitor -On-Screen Display Characters and icons become highlighted in blue during adjustment for each menu. PC Screen Video Screen TV Screen OSD Control 1. PC Screen For detailed information on Screen Adjustment in the PC mode, refer to PC Screen Adjustment Animation Clips.

  • Page 35: Video Screen

    1) PIP Off / On: Turns the PIP mode on or off. (SyncMaster 150MP) Size: Allows the user to turn off or adjust the size of the PIP screen. (SyncMaster 170MP) 2) Position: Change PIP window position.

  • Page 36: Osd Control

    User's Manual - 36 Adujust Monitor -On-Screen Display Setup The channel system can be set in several different ways. 1) Channel System: Select a channel system that is being used in your region. • US-Air • US-Cable • Japan-Air • Japan-Cable Upon selecting a channel system, you will be asked if you want to perform "Channel Search".
  • Page 37 User's Manual - 37 Adujust Monitor -On-Screen Display You can choose one of 4 languages. (English, French, Spanish, Portuguese) Note: The language chosen affects only the language of the OSD. It has no effect on any software running on the computer. Position Move the OSD Window to the vertical and horizontal direction.

  • Page 38: Troubleshooting

    User's Manual - 38 Troubleshooting -Check before Calling for Service Check the following items yourself before calling for service. Contact the service center for problems that you cannot solve by yourself. Self-Test Feature Check Video mode not supported Display Adapter Driver For Better Display Dot Acceptable Maintenance and Cleaning...

  • Page 39: For Better Display

    User's Manual - 39 Troubleshooting -Check before Calling for Service adjust resolution, frequency or color and you cannot install the monitor driver. 1. Checking Adapter Driver Click Start --> Settings --> Control Panel --> Display --> Settings --> Advanced -- > Adapter. If "Default"...

  • Page 40: Maintenance And Cleaning

    Clean with a soft cloth after disconnecting the power cord. Do not use benzene, thinner or other flammable substances, or a wet cloth. We recommend a Samsung cleansing agent is used to prevent damage to the screen. 2. Maintaining the Flat Panel Display Screen Clean with a soft cloth (cotton flannel) smoothly.

  • Page 41: Problems And Solutions

    User's Manual - 41 Troubleshooting -Problems and Solutions The following table lists possible problems and their solutions. Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the warranty card, the phone number on the Information section or contact your...

  • Page 42: Problems Related To Audio

    User's Manual - 42 Troubleshooting -Problems and Solutions Picture rolls vertically. Check if the signal cable is securely connected. Connect it again securely.(Refer to Connecting to a Computer) Image is not clear. Picture is Run Frequency Coarse Fine tuning. blurred. Turn on again after removing all accessories (video extension cable, etc.) Set resolution and frequency to the recommended ranges.
  • Page 43 User's Manual - 43 Troubleshooting -Problems and Solutions Sound is too high pitched or too Adjust the Treble Bass to appropriate level. low pitched 4. Problems related to Remote Control Problems related to the remote control and their solutions are listed. Problems Items to check The remote control buttons do...
  • Page 44 User's Manual - 45 Troubleshooting -Q & A Frequently asked questions are summarized here for your reference. Question Answer How can I change the frequency? Frequency can be changed by reconfiguring the video card. Note that video card support can vary, depending on the version of the driver used.

  • Page 45: Specifications

    User's Manual - 45 Specifications -General Design and specifications are subject to change without prior notice. General Model Name SyncMaster 150MP LCD Panel Size 15.0 inch (Diagonal) Display area 304.1 (H) x 228.1 (V) Pixel Pitch 0.297 (H) x 0.297 (V)
  • Page 46 User's Manual - 46 Specifications -General Monitor body 382 x 57 x 380 mm With stand 382 x 188 x 380 mm Weight Monitor body 4.5 kg Carton 7.0 kg VESA Mounting Interface 75mm x 75mm (for use with Specialty(Arm) Mounting hardware.) Environmental considerations Operating Temperature : 50 °F ~ 104°F(10°C ~ 40°C)
  • Page 47 User's Manual - 47 Specifications -General Design and specifications are subject to change without prior notice. General Model Name SyncMaster 170MP LCD Panel Size 17.0 inch (Diagonal) Display area 338 (H) x 270 (V) Pixel Pitch 0.264 (H) x 0.264 (V) Type a-si TFT active matrix Viewing Angle...
  • Page 48 User's Manual - 48 Specifications -General Monitor body 448 x 63 x 438 mm With stand 448 x 207 x 438 mm Weight Monitor body 6.5 kg Carton 9.5 kg VESA Mounting Interface 100mm x 100mm (for use with Specialty(Arm) Mounting hardware.) Environmental considerations Operating Temperature : 50 °F ~ 104°F(10°C ~ 40°C)
  • Page 49 This monitor is EPA E NERGY S TAR compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPMS functionality. ® As an E NERGY S TAR Partner, SAMSUNG has determined that this product meets the ® ENERGY S TAR guidelines for energy efficiency.

  • Page 50: Preset Timing Modes

    However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Table 1. Preset Timing Modes SyncMaster 150MP Vertical Frequency Horizontal Frequency...
  • Page 51 User's Manual - 51 Specifications -Preset Timing Modes Table 2. NTSC Broadcasting Systems Color System Sound System Stereo System Channel System Countries Korea USA, Canada, Chile, Venezuela, Cuba, Colombia, NTSC BTSC (SAP) Jamaica, Mexico, Panama, Peru, Philippines, Puerto- Rico, Taiwan EIAJ Japan Japan...
  • Page 52 Information -Service Center U.S.A. : Samsung Computer Products Customer Service 400 Valley Road, Suite 201, Mt. Arlington, NJ 07856 Tel. : (973)601-6000, 1-800-SAMSUNG (1 -800-726-7864) Fax. : (973)601-6001 http://www.samsungusa.com/monitor/ BRAZIL : Samsung Eletronica da Amazonia Ltda. R. Prof. Manoelito de Ornellas, 303, Terro B Chacara Sto.
  • Page 53 SILOM ROAD ,SILOM,BANGRAK BANGKOK 10500 TEL : 0-2635-2567 FAX : 0-2635-2556 SOUTH AFRICA : Samsung Electronics,5 Libertas Road, Somerset Office Park, Bryanston Ext 16. Po Box 70006, Bryanston,2021, South Africa Tel : 0027-11 -549-1621 Fax : 0027-11-549-1629 http://www.samsung.co.za/ UKRAINE : SAMSUNG ELECTRONICS REPRESENTATIVE OFFICE IN UKRAINE 4 Glybochitska str.

  • Page 54: Service Center

    Tel. 01 57 47 51 00 Fax. 01 57 47 52 02 RFC: SEM950215S98 http://www.samsung.com.mx/ IMPORTADO POR: SAMSUNG ELECTRONICS MEXICO S.A. DE C.V. SATURNO 44 COL. NVA. INDUSTRIAL VALLEJO DEL. GUSTAVO A. MADERO C.P. 07700 MEXICO D.F. TEL. 5747-5100 RFC: SEM950215S98 EXPORTADO POR: SAMSUNG ELECTRONICS CO.,LTD.
  • Page 55 User's Manual - 55 Information -Terms Sync Signal Sync (Synchronized) Signals refer to the standard signals that are required to display desired colors on the monitor. They are divided into Vertical and Horizontal Sync Signals. These signals display normal color images by the set resolution and frequency. Types of Sync Signals Separate This is a scheme of transmitting individual vertical sync signals to the monitor.
  • Page 56 Communications Commission. It is available from the U.S. Government Printing Office, Washington, DC 20402, Stock Number 004-000-00345-4. The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 3351 Michelson Drive, Suite #290, Irvine, CA92612 USA Tel) 949-975-7310...
  • Page 57 User's Manual - 57 Information -Regulatory This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations of ICES -003. Cet appareil Numé rique de classe B respecte toutes les exigences du R èglemont NMB-03 sur les é...
  • Page 58 User's Manual - 58 Information -Regulatory TCO'95-Ecological requirements for personal computers (TCO applied model only) AB general requirements AB2 Written Eco-document acompanying the products Congratulations! You have just purchased a TCO'95 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and to the further development of environmentally-adapted electronic products.
  • Page 59 User's Manual - 59 Information -Regulatory Sweden Sweden Fax: +46 8 782 92 07 E-mail (Internet): development@tco.se Current information regarding TCO'95-approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ TCO'95 is a co-operative project between(3 logos) Environmental Requirements Brominated flame retardants are present in printed circuit boards, cables, wires, casings and housings.
  • Page 60 User's Manual - 60 Information -Regulatory TCO'99-Ecological requirements for personal computers (TCO applied model only) Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 61 User's Manual - 61 Information -Regulatory TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings.
  • Page 62 How to install the Natural Color software Insert the CD included with the Samsung monitor into the CD -ROM Drive. Then, the initial screen of the program installation will be executed. Click Natural Color on the initial screen to install the Natural Color software.
  • Page 63 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 64 (Worldwide) http://www.samsungusa.com/monitor/ (USA) http://www.sec.co.kr/monitor/ (Korea) http://www.samsungmonitor.com.cn/ (China)
