OIL FILLING
IMPORTANT: Do not overfill. Be sure that the outboard is upright (not tilted) when checking oil.
1. Remove the oil fill cap and refill with 1liter (1 quart ) of oil. Reinstall the oil fill cap.
2. Idle engine for five minutes and check for leaks. Stop engine and check oil level on dipstick. Add oil if
necessary.

Lubrication Points

1. Lubricate the following with Quicksilver or Mercury Precision Lubricants 2-4-C with Teflon or Special Lubricant
101.
• Steering friction adjustment shaft (tiller handle models) - Lubricate fitting.
• Swivel bracket - Lubricate through fitting.
• Transom clamp screws - Lubricate threads.
a - Steering friction adjustment shaft
b - Transom clamp screw
c - Swivel bracket
• Tilt tube - Lubricate through fittings.
MAINTENANCE
a
b
56
ob00591
c
ob00592
