Page 2: Table Of Contents
All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.
Page 3: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 4 Introduction Indicates a message regarding child safety restraints. Refer to Seating and safety restraints for more information. Indicates that this Owner Guide contains information on this subject. Please refer to the Index to locate the appropriate section which will provide you more information. WARNINGS Warnings provide information which may reduce the risk of personal injury and prevent possible damage to others, your vehicle and its...
Page 5 Introduction INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation. EMISSION WARRANTY The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage.
Page 6 Do not use this vehicle for snowplowing. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Notice to owners of pickup trucks and utility type vehicles Utility vehicles have a significantly higher rollover rate than other types of vehicles.
Page 7 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control...
Page 8 Introduction Vehicle Symbol Glossary Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System...
Page 9: Instrumentation
Instrumentation Instrument cluster Instrument panel (pg. 10) Driver air bag dimmer switch (pg. 128) (pg. 22) Headlamp control (pg. 21) DOOR THEFT AJAR RPMX1000 SELECT/RESET km/h P RN BRAKE CRUISE FUEL DOOR ACCEL PEDALS Power adjustable foot pedals Hood release Speed control (pg.
Page 10: Audio System
Instrumentation Audio system (pg. 27) Gearshift (includes overdrive button) (pg. 161) BASS TREB FADE PUSH ON TAPE SEEK TUNE SCAN AUTO MUTE SIDE 1 . 2 COMP SHUFF A4WD COOL WARM 4WD control * (pg. 163) Climate control system Auxiliary power point (pg.
Page 11 Instrumentation WARNING LIGHTS AND CHIMES DOOR THEFT AJAR RPMX1000 RANGE FUEL SELECT/RESET SERVICE km/h SUSP ENGINE SOON P RN BRAKE CRUISE FUEL DOOR Low fuel Illuminates as an early reminder of a low fuel condition indicated on the fuel gauge (refer to Fuel Gauge in FUEL this chapter for more information).
Page 12 Instrumentation What you should do if the Service Engine Soon light illuminates Light turns on solid: This means that the OBD II system has detected a malfunction. Temporary malfunctions may cause your Service Engine Soon light to illuminate. Examples are: 1.
Page 13 Instrumentation Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts. For more information, refer to the Seating and safety restraints chapter. Brake system warning Momentarily illuminates when the ignition is turned to the ON position BRAKE to indicate a system check.
Page 14 Instrumentation High beams Illuminates when the high beam headlamps are turned on. SecuriLock anti-theft system This light indicates the anti-theft alarm system is armed. Momentarily THEFT illuminates when the ignition is turned to ON. If the light fails to illuminate, continues to flash or remains on, have the system serviced.
Page 15 Instrumentation Four wheel drive low (if equipped) Momentarily illuminates after the engine is started. Illuminates when RANGE four-wheel drive low is engaged. If the light continues to flash have the system serviced. Four wheel drive indicator (if equipped) Momentarily illuminates after the engine is started.
Page 16 Instrumentation Speed control This light comes on when either the CRUISE COAST/SET or RES/ACCEL controls are pressed. It turns off when the speed control OFF control is pressed, the brake is applied or the ignition is turned to the OFF position. Safety belt warning chime Sounds to remind you to fasten your safety belts.
Page 17: Fuel Gauge
Instrumentation GAUGES DOOR THEFT AJAR RPMX1000 RANGE FUEL SELECT/RESET SERVICE km/h SUSP ENGINE SOON P RN BRAKE CRUISE FUEL DOOR Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion.
Page 18 Instrumentation Speedometer Indicates the current vehicle speed. km/h Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating.
Page 19 Instrumentation Trip odometer Registers the kilometers (miles) of individual journeys. Press and release the reset button until a “T” P RN appears in the display (this represents the trip mode). Press and hold the button for three seconds to reset. Tachometer Indicates the engine speed in revolutions per minute.
Page 20 Instrumentation Engine oil pressure gauge This shows the engine oil pressure in the system. Sufficient pressure exists as long as the needle remains in the normal range (the area between the “L” and “H”). If the gauge indicates low pressure, stop the vehicle as soon as safely possible and switch off the engine immediately.
Page 21 Instrumentation Mode control Each press of the MODE control will display a different feature as follows: Fuel range. This displays the approximate number of kilometers (miles) left to drive before the fuel tank is empty. The indicated distance to empty may be inaccurate: •...
Page 22: Controls And Features
Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. High beams Push forward to activate. Pull toward you to deactivate. Flash to pass Pull toward you to activate and release to deactivate.
Page 23 Controls and features Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate with your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 24 Controls and features AUTOLAMP CONTROL The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for approximately 20 seconds after the ignition switch is turned to OFF.
Page 25 Controls and features The ignition must be in the ON position to operate the rear window defroster. The defroster turns off automatically after 10 minutes or when the ignition is turned to the OFF position. To manually turn off the defroster before 10 minutes have passed, push the control again.
Page 26 Controls and features This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle. The system may not detect smaller objects, particularly those close to the ground.
Page 27 Controls and features The reverse sensing system is automatically enabled when the gear selector is placed in R (Reverse) and the ignition is ON. A reverse sensing control allows the driver to disable the reverse sensing system only when the ignition is ON, and the gear selector is in R (Reverse).
Page 28 Controls and features Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. A second auxiliary power point is located on the lower rear side of the console.
Page 29 Controls and features Premium AM/FM Stereo/Cassette (CD Changer Compatible) BASS TREB FADE PUSH ON TAPE TUNE SEEK SCAN AUTO MUTE SIDE 1 . 2 COMP SHUFF Audiophile AM/FM Stereo/Cassette (CD Changer Compatible) BASS TREB FADE PUSH ON TAPE TUNE SEEK SCAN AUTO MUTE...
Page 30 Controls and features Volume/power control Press the control to turn the audio system on or off. PUSH ON Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 31 Controls and features • to increase volume compensation • to decrease or shut off the volume compensation AM/FM select The AM/FM select control works in radio, tape and CD modes (if equipped). AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations.
Page 32 Controls and features Tune adjust for CD changer • Press to select the previous TUNE disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode.) Refer to Shuffle feature for more information.
Page 33 Controls and features Scan function The scan function works in radio, tape or CD mode (if equipped). SCAN Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode.
Page 34 Controls and features Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autoset memory preset 1.
Page 35 Controls and features Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control. Use the SEL FADE control to adjust the sound between the speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 36 Controls and features Rewind The rewind control works in tape and CD modes. • In tape mode, radio play will continue until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. • In CD mode, pressing the REW control for less than three seconds results in slow rewind.
Page 37 Controls and features Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. The Dolby noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 38 Controls and features Setting the clock with radio data system (RDS) feature Press the RDS control until SELECT HOUR or SELECT MINS is displayed. Use the SEL control to manually set the time. • Press to increase hours/minutes. • Press to decrease hours/minutes.
Page 39 Controls and features Use the SELECT control to change the equalization to the desired mode. Radio data system (RDS) feature This feature allows your audio system to receive station identification or program type from RDS-equipped FM radio stations. The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC) recommend FM radio broadcasters to use RDS technology to transmit information.
Page 40 Controls and features Program type • Press the RDS control until the FIND program type is displayed. • Use the SEL control to select the program type. With the feature on, use the SEEK or SCAN control to find the desired program type from the following selections: •...
Page 41 Controls and features Premium AM/FM Stereo/Single CD Radio BASS TREB FADE PUSH ON TUNE AUTO SCAN SEEK MUTE COMP SHUFF Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated.
Page 42 Controls and features Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 43 Controls and features AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FM select in CD or CD changer mode (if equipped) Press this control to stop CD play and begin radio play.
Page 44 Controls and features Seek function The seek function control works in radio, CD and CD changer mode (if equipped). Seek function in radio mode • Press to find the next SEEK listenable station down the frequency band. • Press to find the next listenable station up the frequency band. Seek function for CD or CD changer (if equipped) •...
Page 45 Controls and features Setting memory preset stations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.
Page 46 Controls and features Treble adjust The treble adjust control allows you to increase or decrease the audio BASS system’s treble output. TREB Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. FADE Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 47 Controls and features Fast forward The fast forward control works in CD mode. • In CD mode, pressing the control for less than three seconds results in slow forward action. Pressing the control for more than three seconds results in fast forward action. Eject function Press the control to stop and eject a Compression feature (if equipped)
Page 48 Controls and features Radio data system (RDS) feature This feature allows your audio system to receive station identification or program type from RDS-equipped FM radio station. The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC) recommend FM radio broadcasters to use RDS technology to transmit information.
Page 49 Controls and features • Use the SEL control to select the program type. With the feature on, use the SEEK or SCAN control to find the desired program type from the following selections: • Classic • Country • Info • Jazz •...
Page 50 Controls and features Setting the clock Press the RDS control until SELECT HOUR or SELECT MINS is displayed. Use the SEL control to manually set the time. • Press to increase hours/minutes. • Press to decrease hours/minutes. Rear seat controls (if equipped) The Personal Audio System, allows - VOLUME + front and middle seat passengers to...
Page 51 Controls and features To activate the Personal Audio - VOLUME + System, press the MODE speaker/headphone control. Press the MODE control to change audio sources (for headphone mode only). SEEK MEMORY Use the SEEK, VOLUME and MEMORY controls to make adjustments to the playing media.
Page 52 Controls and features Using headphones/Personal Audio System Plug a 3.5 mm headphone (not included) into the jack. Press the speaker on/off control to operate the headphones. DUAL PLAY illuminates in the radio display and the fade control is disabled. The rear speakers will cut out once the speaker on/off control is pressed. The front speaker will remain playing for the front passengers.
Page 53 Controls and features Seek function • In radio mode, press to find - VOLUME + the next listenable station down MODE the frequency band. • In radio mode, press to find SEEK MEMORY the next listenable station up the frequency band. •...
Page 54 Controls and features 1. Pull the lever to remove a CD tray from the magazine. 2. Insert one disc into each CD tray of the magazine (up to 6 discs). Ensure that the label side is facing If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
Page 55 Controls and features 5. Slide the door to the left to close. Use only compact discs containing this mark. The magazine does not need to be full for the changer to operate. Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove compartment when not being used.
Page 56 Controls and features Cleaning compact discs Inspect all discs for contamination before playing. If necessary, clean discs only with an approved CD cleaner and wipe from the center out to the edge. Do not use circular motion. CD and CD changer care •...
Page 57 Controls and features Radio reception factors Three factors can affect radio reception: • Distance/strength.The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/volume relative to other stations.
Page 58 Controls and features Temperature control knob Controls the temperature of the airflow inside the vehicle. COOL WARM Mode selector control Controls the direction of the airflow to the inside of the vehicle. The air conditioning compressor can operate in all modes except PANEL and FLOOR.
Page 59 Controls and features hot and full cold positions, the air distributed through the floor ducts will be slightly warmer than the air sent to the instrument panel registers. • FLOOR -Allows for maximum heating by distributing outside air through the floor ducts. However, the air will not be cooled below the outside temperature because the air conditioning does not operate in this mode.
Page 60 Controls and features • If your vehicle has been parked with the windows closed during warm weather conditions, the air conditioner will perform more efficiently in cooling the vehicle if driven for two or three minutes with the windows open. This will force most of the hot, stale air out of the vehicle.
Page 61: Automatic Operation
Controls and features Electronic Automatic Temperature Control (EATC) system (if equipped) The EATC system will maintain a selected temperature and AUTO automatically control airflow. You OUTSIDE TEMP AUTOMATIC can override automatic operation MAX A/C VENT PNL • FLR FLOOR FLR • DEF with any of the override controls, the fan speed control or steering wheel controls (if equipped).
Page 62 Controls and features windshield. In approximately 3 ⁄ minutes or less, the fan speed will start to increase and the airflow location will change to the floor area. If unusual conditions exist (i.e.-window fogging, etc.), the manual override controls allow you to select airflow locations and the fan control allows you to adjust fan speed as necessary.
Page 63 Controls and features Fan speed ( When AUTOMATIC is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, use the AUTOMATIC thumbwheel or steering wheel control to cancel automatic fan speed operation.
Page 64 Controls and features economical and will cool the inside of the vehicle faster. Airflow is from the instrument panel registers. This mode can also be used to prevent undesirable odors from entering the vehicle. • VENT-Distributes outside air through the instrument panel registers. However, the air cannot be cooled below the outside temperature because the air conditioning does not operate in this mode.
Page 65 Controls and features Displaying outside temperature Press OUTSIDE TEMP to display the outside air temperature. It will be displayed until OUTSIDE TEMP is pressed again. OUTSIDE TEMP MAX A/C VENT PNL • FLR If the selected temperature is changed while the outside temperature is displayed, the new temperature will be displayed for four seconds after it is changed, then the outside temperature will return to the window.
Page 66 Controls and features • Under snowy or dirty weather conditions, your vehicle’s climate control system should be left in the OFF position when the vehicle is parked. This allows the climate control system to be free from contamination of outside pollutants. •...
Page 67 Controls and features Auxiliary A/C-heater controls (if equipped) Depending on your equipment package, your vehicle may be equipped with auxiliary A/C-heater controls. The auxiliary A/C-heater feature provides increased capacity to quickly heat or cool the vehicle. Besides the driver’s control panel for the front seat occupants, the second row auxiliary A/C-heater controls allow the rear passengers to control the temperature in the rear of the vehicle through a second control panel above the second row, or in the floor console.
Page 68 Controls and features In order for the auxiliary A/C-heater controls (if equipped) to function, REAR the driver’s auxiliary A/C-heater control must be set to REAR, unless COOL WARM PANEL FLOOR your vehicle is equipped with a moonroof and a navigation system. In which case, the rear auxiliary A/C-heater control console serves as the main control for the auxiliary climate control system.
Page 69 Controls and features POSITIONS OF THE IGNITION 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 70 Controls and features SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
Page 71 Controls and features To set a speed • Press SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 72 Controls and features To set a higher set speed • Press and hold SET ACCEL. Release the control when the desired vehicle speed is reached • Press and release SET ACCEL to operate the Tap-Up function. Each press will increase the set speed by 1.6 km/h (1 mph) or •...
Page 73 Controls and features To disengage speed control • Depress the brake pedal. Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed. To return to a previously set speed •...
Page 74 Controls and features Indicator light This light comes on when either the CRUISE SET ACCEL or RES controls are pressed. The vehicle speed must be at or above 48 km/h (30 mph). It turns off when the speed control OFF control is pressed, the brake or clutch is applied, or the ignition is turned to the OFF position.
Page 75 Controls and features WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 76 Controls and features OVERDRIVE CONTROL Activating overdrive (Overdrive) is the normal drive position for the best fuel economy. The overdrive function allows automatic upshifts and downshifts through all available gears. Deactivating overdrive Press the Transmission Control Switch (TCS) located on the end of OVERDRIVE the gearshift lever.
Page 77 Controls and features Forward storage bin (if equipped) Press the release control to open the storage compartment. The door will open slightly and can be moved to full open. The storage compartment may be used to secure sunglasses or a similar object.
Page 78 Controls and features One-touch moon roof (if equipped) With trip computer ROOF VENT VENT Without trip computer AUTO ROOF • Press and release the rear portion of the moon roof control to open. • Press and hold (as desired) the front portion of the moon roof control to close.
Page 79 Controls and features Trip computer For information on the trip computer, refer to Trip computer in the Instrumentation chapter. Electronic compass (if equipped) The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antennas. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.
Page 80 Controls and features Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. With trip computer 2. Locate the compass module mounted on the center rear view mirror post. 3.
Page 81 Controls and features Without trip computer 1. Press and hold the SELECT control until VAR appears in the display, then release. The display should show the current zone AUTO number. ROOF 2. Press the SELECT control until the desired zone number appears. The display will flash and then return to normal operation.
Page 82 Controls and features Without trip computer 1. Press and hold the SELECT control until CAL appears in the display (approximately eight seconds) and release. AUTO ROOF 2. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles.
Page 83 Controls and features Press the portion of the VENT control to open the power rear quarter windows. Press the portion of the VENT control to close the power rear quarter windows. Interior Lamps Map lamps With trip computer ROOF VENT VENT Without trip computer AUTO...
Page 84 Controls and features Rear dome lamp The dome lamp lights when: • any door is opened. • the instrument panel dimmer switch is held up until the courtesy lamps come on. • any of the remote entry controls are pressed and the ignition is OFF.
Page 85 Controls and features HOMELINK UNIVERSAL TRANSCEIVER (IF EQUIPPED) The HomeLink Universal Transceiver, located on the driver’s visor, provides a convenient way to replace up to three hand-held transmitters with a single built-in device. This feature will learn the radio frequency codes of most current transmitters to operate garage doors, entry gates, security systems, entry door locks, and home or office lighting.
Page 86 Controls and features 3. Using both hands simultaneously press and hold the hand-held transmitter button and the desired HomeLink button. Do not release the buttons until step 4 has been completed. Some entry gates and garage door openers may require you to replace step 3 with the procedure in the “Canadian Programing”...
Page 87 Controls and features Operating the HomeLink Universal Transceiver Once programmed, the HomeLink Universal Transceiver can be used in place of hand-held transmitters. To operate, simply press and release the appropriate HomeLink button (the red light will illuminate, indicating the signal is being transmitted).
Page 88 Controls and features 3. Press and release the programmed HomeLink button. Press and release the HomeLink button a second time to complete the training process. (Some garage door openers may require this procedure to be done a third time to complete the training). The 2nd or 3rd press from step 3 will activate the door.
Page 89 Controls and features POWER WINDOWS Press and hold the rocker switches to open and close windows. • Press the top portion of the rocker switch to close. AUTO • Press the bottom portion of the rocker switch to open. AUTO One touch down •...
Page 90 Controls and features Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls WINDOW LOCK except for the driver’s press the left side of the control. Press the right side to restore the window controls. Accessory delay With accessory delay, the window switches may be used for up to ten minutes after the ignition switch is turned to the OFF position or until...
Page 91 Controls and features POWER SIDE VIEW MIRRORS The ignition can be in any position to adjust the power side view mirrors. To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. MIRRORS 2.
Page 92 Controls and features Signal mirrors (if equipped) When the turn signal is activated, the outer portion of the appropriate mirror housing will blink red. This provides an additional warning to other drivers that your vehicle is about to turn. Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash.
Page 93 Controls and features POSITIVE RETENTION FLOOR MAT (IF EQUIPPED) Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal.
Page 94 The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Automatic arming...
Page 95 Check to make sure the coded key is an approved Ford coded key. If your keys are lost or stolen you will need to do the following: •...
Page 96 Controls and features Programming spare keys A maximum of eight keys can be coded to your vehicle. Only SecuriLock keys can be used. To program a coded key yourself, you will need two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible for timely implementation of each step in the procedure.
Page 97 Controls and features REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 98 Controls and features Locking the doors Press this control to lock all doors. The doors will lock and the lamps will flash. To confirm doors are closed and locked, press this control a second time within three seconds. The door(s) will lock again, the horn will chirp once and the lamps will flash.
Page 99 Controls and features To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. 2. Place the positive (+) side of new battery in the same orientation.
Page 100 Controls and features Programming remote transmitters It is necessary to have all (maximum of four — original and/or new) of your remote transmitters available prior to beginning this procedure. To program the transmitters yourself: • Place the key in the ignition and turn from 2 (LOCK) to 3 (OFF) and cycle between 3 (OFF) and 4(ON) eight times in rapid...
Page 101 Controls and features The battery save feature will turn off the interior lights 45 minutes after the last door is closed, even if the dimmer control is on. Memory seat/mirrors/adjustable pedal feature (if equipped) The memory feature allows automatic positioning of the driver seat, side mirrors and adjustable pedals to three programmable positions.
Page 102 Controls and features 7. Turn ignition to OFF. The horn will chirp once to confirm the procedure is complete. Autolock (if equipped) This feature automatically locks all vehicle doors when: • all doors, liftgate and liftgate window are closed • the engine is running •...
Page 103 Controls and features 2. Press 1/2 control within five seconds of step 1. 7 8 9 0 3. Enter your personal 5 digit code. Enter each digit within five seconds of previous one. Do not set a code that includes five of the same number or presents them in sequential order.
Page 104 Controls and features Locking the doors with the keyless entry system It is not necessary to enter the factory or personal code prior to locking all doors. To lock the doors: • Press the 7/8 control and the 9/0 control at the same time. Activating/deactivating autolock with the keyless entry system Before following the activation or deactivation procedures, make sure that the anti-theft system (if equipped) is not armed, ignition is off, and...
Page 105: Seating And Safety Restraints
Seating and safety restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 106 Seating and safety restraints Lift handle to move seat forward or backward. Pull lever up to adjust seatback. 60/40 split bench seat (if equipped) • Lift the release bar to move the seat forward or backward. Ensure the seat is relatched into place. •...
Page 107 Seating and safety restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. Using the manual lumbar support Turn the lumbar support control toward the front of vehicle to move the lumbar support forward for more direct support.
Page 108 Seating and safety restraints Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. The control is located on the outboard side of the seat cushion. Press to raise or lower the front portion of the seat cushion.
Page 109 Seating and safety restraints Memory seats/rearview mirrors/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat, outside rearview mirrors, and adjustable pedals to three programmable positions. The memory seat control is located on the driver door. • To program position one, move the driver seat to the desired position using the seat controls.
Page 110 Seating and safety restraints REAR SEATS Adjustable head restraints Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 111 Seating and safety restraints 3. Press the green control on the seatback to release the closeout panel. Rotate the panel to closeout the space in the floor. 4. Once the second row seats are in the down position, the front seats may be readjusted.
Page 112 Seating and safety restraints Reclining the seatback Locate the lever at the bottom of the seatback that reads “FOLD FLAT OR RECLINE”. Pull the lever upwards to recline the seatback. Third row seat The third row seat is equipped with combination lap and shoulder belts in the outboard seating positions and a manual adjust tongue lap belt in the center seating position.
Page 113 Seating and safety restraints Ensure that the second row seat is in the upright position in order to achieve optimum access to the third row. To minimize the risk of personal injury, the third row seat should not be left in the forward, stowed position while the vehicle is in motion. Please ensure that the seat is in the upright, fully latched position before putting the vehicle in motion.
Page 114 Seating and safety restraints 2. Before removing the seat, be sure that the detachable anchor tongue is stowed flat into the vehicle floor. 3. Use the black plastic clip (located just above the detachable anchor) to stow the loose seat belt. •...
Page 115 Seating and safety restraints Installing the third row seat Always latch the vehicle seat to the floor, whether the seat is occupied or empty. If not latched, the seat may cause injury during a sudden stop. When reinstalling a rear seat in your vehicle it must be placed in its original position.
Page 116 Seating and safety restraints 3rd row tip/stow feature The 3rd row seat has a tip/stow feature to increase cargo space without removing the seat from the vehicle. To put seat in tip/stow position: 1. Pull the seat release lever located on the lower right side of the seatback while pushing the seatback down into the seat cushion.
Page 117 Seating and safety restraints 6. Pull down support bar and push into floor latch. To return seat to seating position: 1. Hold seat and pull support bar from floor latch. 2. Rotate support bar up under seat. 3. Rotate floor latch down into floor tub. 4.
Page 118 Seating and safety restraints It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 119 Seating and safety restraints • Rear seats (if equipped) 2. To unfasten, push the release button and remove the tongue from the buckle. • Front seats • Rear seats (if equipped)
Page 120 Seating and safety restraints The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 121 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 122 Seating and safety restraints Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. After any vehicle collision, the front passenger outboard seat belt system must be checked by a qualified technician to verify that the “automatic locking retractor”...
Page 123 Seating and safety restraints Lap belts Adjusting the lap belt The lap belt should fit snugly and as low as possible around the hips, not across the waist. • 1st row and 3rd row (if equipped) center seating positions The lap belt does not adjust automatically. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming...
Page 124 Seating and safety restraints Front and second row safety belt height adjustment Your vehicle has safety belt height adjustments for the driver, front passenger and second row passengers. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button down and slide the height adjuster down.
Page 125 Seating and safety restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition switch illuminates 1-2 minutes and the is turned to the ON position... warning chime sounds 4-8 seconds.
Page 126 “I’m not going far” 3 of 4 fatal crashes occur within 25 miles of home. “Belts are Ford designs its safety belts to enhance comfort. If uncomfortable” you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 127 Seating and safety restraints Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the Belt Minder feature please follow the directions stated below.
Page 128 (if equipped), child safety seat tether bracket assemblies (if equipped), LATCH child seat tether anchors and lower anchors (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 129 This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further...
Page 130 Seating and safety restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag...
Page 131 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and tow hooks may affect the performance of the air bag sensors increasing the risk of injury.
Page 132 Seating and safety restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 133 Seating and safety restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 134 Seating and safety restraints The RCM (restraints control module) monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors, the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors). Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system.
Page 135 Do not attempt to service, repair, or modify the air bag supplemental restraint system, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always...
Page 136 Seating and safety restraints How does the side air bag system work? The side air bag system consists of the following: • An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
Page 137 Seating and safety restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with...
Page 138 Seating and safety restraints Disposal of air bags and air bag equipped vehicles For disposal of air bags or air bag equipped vehicles, see your local dealership or qualified technician. Air bags MUST BE disposed of by qualified personnel. SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children.
Page 139 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 140 (passenger side front and outboard rear seating positions) (if equipped) section in this chapter. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
Page 141 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 142 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 143 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 144 Seating and safety restraints 5. If you have not pulled out enough webbing to reach, allow the webbing to fully retract before attempting to pull it out again and repeat steps 2 through 4. 6. Pull the webbing through the child seat toward the buckle while pushing down with your knee on the child seat.
Page 145 The anchor bracket must be installed using the instructions provided with the kit. Tether anchorage hardware kits (part number 613D74) including instructions, may be obtained at no charge from any Ford or Lincoln/Mercury dealer. Tighten the anchor according to specifications. Otherwise, the safety seat may not be properly secured and the child may be injured in a sudden stop or collision.
Page 146 Seating and safety restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 147 Seating and safety restraints • You may need to pull the seatback forward to access the tether anchors. Make sure the seat is locked in the upright position before installing the child seat. Refer to the Folding Down The Rear Seats section in this chapter for information on how to operate the rear seats.
Page 148 Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 149 Starting Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs faster to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked. Do not allow the vehicle to idle for more than 10 minutes at the higher engine RPM.
Page 150 Starting 5. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely. This condition may occur when: •...
Page 151 Starting 3. If the temperature is below -12° C (10° F) and the engine does not start in 15 seconds on the first try, turn the key OFF and wait 10 seconds and try again. If the engine does not start in two attempts, press the accelerator pedal all the way to floor and hold.
Page 152 Starting WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 153: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 154 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal BRAKE...
Page 155 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and BRAKE remains illuminated (when the ignition is turned ON) until the parking brake is released.
Page 156 Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to help steer the vehicle. To prevent damage to the power steering pump: •...
Page 157 Driving Speed sensitive steering The steering in your vehicle is speed sensitive. At high speeds, steering assist will decrease to improve steering feel. If the amount of effort required to steer your vehicle changes while driving at a constant vehicle speed, have the power steering system checked by your dealer or a qualified service technician.
Page 158 Driving The air suspension shut-off switch is located behind an access panel underneath the passenger side instrument panel. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. Normal vehicle operation does not AIR SUSPENSION SWITCH require any action by the driver.
Page 159 Driving To avoid injury, never run the engine with one wheel off the ground, such as when changing a tire. PREPARING TO DRIVE YOUR VEHICLE Utility vehicles have a significantly higher rollover rate than other types of vehicles. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 160 Driving AUTOMATIC TRANSMISSION OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed. If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1.
Page 161 Driving Driving with a 4–speed automatic transmission Your vehicle’s automatic transmission is equipped with a special shift strategy that insures maximum heater performance during cold weather operation. When ambient temperature is –5° C (23° F) or below and the engine coolant temperature is below 38°...
Page 162 Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 163 Driving Each time the vehicle is started, the transmission will automatically return to normal overdrive mode. Every time the vehicle is shut off and restarted, you must press the transmission control switch to cancel overdrive operation if driving in overdrive is not desired. 2 (Second) Use 2 (Second) to start-up on slippery roads or to provide...
Page 164 Driving FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. When Four–wheel drive (4WD) is engaged, power is supplied to all four wheels through a transfer case. 4WD power can be selected when additional driving power is desired.
Page 165 Driving Positions of the Control-Trac system The Control-Trac A4WD system functions in three modes: A4WD • A4WD position delivers power to the rear axle. If the rear wheels lose traction, power will be automatically delivered to the front axle to maintain traction throughout the slippery condition.
Page 166 Driving Shifting from 4H to 4L (and 4L to 4H) 1. Bring the vehicle to a stop. 2. Depress the brake. A4WD 3. Place the gearshift in N (Neutral). 4. Move the 4WD control to the 4H (or 4L) position. Shifting to A4WD Move the 4WD control back to A4WD at a stop or at speeds up to...
Page 167 Driving If your vehicle gets stuck If the vehicle is stuck in mud or snow it may be rocked out by shifting from forward and reverse gears, stopping between shifts, in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 168 Driving synthetic lubricant and does not normally require a lubricant change for the life of the vehicle. Rear axle lubricant quantities should not need to be checked unless a leak is suspected. Driving on hilly or sloping terrain When driving on a hill, avoid driving crosswise or turning on steep slopes.
Page 169 Driving DRIVING THROUGH WATER Do not drive quickly through standing water, especially if the depth is unknown. Traction or brake capability may be limited and if the ignition system gets wet, your engine may stall. Water may also enter your engine’s air intake and severely damage your engine.
Page 170 Driving • GCWR (Gross Combined Weight Rating): Maximum combined weight of towing vehicle (including passengers and cargo) and the trailer. The GCWR indicates the maximum loaded weight that the vehicle is designed to tow. • Maximum Trailer Weight Rating: Maximum weight of a trailer the vehicle is permitted to tow.
Page 171 Driving Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section inthe Driving chapter of this owner guide. Loaded vehicles, with a higher center of gravity, may handle differently than unloaded vehicles.
Page 172 Driving TRAILER TOWING Trailer towing with your vehicle may require the use of a trailer tow option package. Trailer towing puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires, and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing.
Page 173 Driving Rear Maximum Trailer weight range Tire size - Engine axle GCWR - kg (0 - maximum) kg cm (inches) ratio (lbs.) (lbs.) 0-2 676 4.6L 3.31 40.6 (16) 4 990 (11 000) (0-5 900) 0-2 676 4.6L 3.31 40.6 (17) 4 990 (11 000) (0-5 900) 0-3 084...
Page 174 Driving Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of control and personal injury. Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle.
Page 175 Driving Adjusting an equalizing hitch so the rear bumper of the vehicle is lower or higher than it was unloaded will defeat the function of the load equalizing hitch and may cause unpredictable handling. Safety chains Always connect the trailer’s safety chains to the frame or hook retainers of the vehicle hitch.
Page 176 Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation. Improper removal/installation of the driveshaft can cause transmission fluid loss, damage to the driveshaft and internal transmission components.
Page 177 Driving 4WD vehicles electronic shift transfer case (with automatic transmissions) 4x4 vehicles with electronic shift on the fly cannot be towed with any wheels on the ground. Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination.
Page 178 Driving LUGGAGE RACK (IF EQUIPPED) The rear cross-bar can be adjusted to fit the item being carried. The front cross-bar does not move. To adjust the luggage rack, push the adjustment lever forward (toward the front of the vehicle), then slide the cross-bar forward and lock the adjusting levers by pushing them down (toward the back of the...
Page 179: Roadside Emergencies
Roadside emergencies GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: • 24–hours, seven days a week •...
Page 180 Roadside coverage beyond basic warranty In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, for uninterrupted Roadside Assistance coverage, you may purchase extended coverage prior to your Basic Warranty’s Roadside...
Page 181 Roadside emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 182 Roadside emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. NOTE: Always replace a fuse with one that has the specified amperage rating.
Page 183 Roadside emergencies Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 184 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description 7.5A Remote Entry Module, Mirrors, Memory Functions (Seats and Pedals) Speed Control Module, Reverse Lamp, EVO Module, Climate Mode Switch (Front Blower Relay), Daytime Running Lamp Relay, Reverse Sensing System, Autolock, E/C Mirror Cluster, Overhead Trip Computer, Compass, Brake Shift Interlock Solenoid,...
Page 185 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Headlamps (Hi Beams), Cluster (Hi Beam Indicator) Heated Mirrors, Heated Grid Switch Indicator Instrument Illumination (Dimmer Switch Power) — Not Used Audio, Air Suspension Module, GEM Module, Memory Module Starter Relay, Fuse 20, Transmission Range Switch Air Bag Module, Intelligent Passenger...
Page 186 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Relay 1 — Interior Lamp Relay Relay 2 — Battery Saver Relay Relay 3 — Rear Window Defroster Relay Relay 4 — One Touch Down Window Relay Relay 5 —...
Page 187 Roadside emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 20A * Power Point 30A* Powertrain Control Module 30A* Headlamps/Autolamps 20A* Console Powerpoint 20A* Trailer Tow Backup/Park Lamps 15A* Parklamps/Autolamps, Feeds Passenger Compartment Fuse 18 20A* Horn...
Page 188 Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating — Not Used 10A* Flip Windows 15A* Powertrain Control Module, Fuel Injectors, Fuel Pump, Mass Air Flow Sensor 10A* Trailer Tow Stop and Right Turn Lamp 10A* Trailer Tow Stop and Left Turn Lamp —...
Page 189 Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating — Not Used — Trailer Tow Park Lamp Relay — Front Wiper Run/Park Relay — Trailer Tow Backup Lamp Relay — A/C Clutch Relay — Rear Wiper Down — Foglamp Relay —...
Page 190 Roadside emergencies Spare tire information Your vehicle is equipped with a spare tire that may be used as a spare or a regular tire. The spare is identical to the other tires on your vehicle, although the wheel trim may not match. Location of the spare tire and tools The spare tire and tools for your vehicle are stowed in the following locations:...
Page 191 Roadside emergencies • To assemble, screw the parts together. To disassemble, unscrew. Removing the spare tire 1. Open the liftgate. 2. Twist counterclockwise and remove access plug (if equipped) from guide tube located just above the rear bumper. 3. Insert the straight end of the jack handle into the guide tube.
Page 192 Roadside emergencies Tire change procedure To prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed.
Page 193 Roadside emergencies 6. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 7. Turn OFF the air suspension switch (if equipped). 8. Position the jack according to the following guides and turn the jack handle clockwise until the wheel is completely off the ground.
Page 194 Roadside emergencies • Front (4x2) • Front (4x4) • Rear...
Page 195 Roadside emergencies To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire. •...
Page 196 Roadside emergencies Batteries contain sulfuric acid which can burn skin, eyes, and clothing, if contacted. Do not attempt to push-start your vehicle. Automatic transmissions do not have push-start capability. Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its adaptive strategy.
Page 197 Roadside emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 198 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 199 Roadside emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 200 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 201 It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 202: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 203 Maintenance and care Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2.
Page 204 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.6L V8 and 5.4L V8 engines 1. Battery 2. Automatic transmission fluid dipstick 3. Engine oil filler cap 4. Engine oil dipstick 5. Power steering fluid reservoir 6. Brake fluid reservoir 7.
Page 205 Maintenance and care 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P (Park). 4. Open the hood. Protect yourself from engine heat. 5.
Page 206 Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft or an equivalent oil meeting Ford specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 207 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 208 Only use a washer fluid that meets Ford specification . Refer to Lubricant specifications in the Capacities and specifications chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 209 Maintenance and care ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide. The coolant concentration should be maintained at 50/50 coolant and water, which equates to a freeze point of -36°...
Page 210 The cooling system in your vehicle is filled with either green-colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir. • Add Motorcraft Premium Engine Coolant (green-colored), VC-4–A (U.S.) or CXC-10 (Canada) or Motorcraft Premium...
Page 211 • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled Engine Coolant section). For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
Page 212 Operating an engine with a low level of coolant can result in engine overheating and possible engine damage. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored). However, not all coolant recycling processes produce coolant that meets Ford specification ESE-M97B44–A.
Page 213 Maintenance and care Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter. Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter. Severe climates If you drive in extremely cold climates (less than –36°...
Page 214 Maintenance and care What you should know about fail-safe cooling If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain.
Page 215 Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only Ford Premium Power Steering Fluid. 1. Start the engine and let it run until it reaches normal operating...
Page 216 Maintenance and care 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range. 5. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the range between the MIN and...
Page 217 Maintenance and care 5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If necessary, refer to Identifying components in the engine compartment in this chapter for the location of the dipstick. 6. Install the dipstick making sure it is fully seated in the filler tube. 7.
Page 218 Maintenance and care Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick and also in the Lubricant specifications section in the Capacities and specifications chapter.
Page 219 Maintenance and care If the electrolyte level in the battery is low, you can add plain tap water to the battery, as long as you do not use hard water (water with a high mineral or alkali content). If possible, however, try to only fill the battery cells with distilled water.
Page 220 Maintenance and care Battery posts, terminals and related accessories contain lead and lead compunds. Wash hands after handling. For information on transmission operation after the battery has been disconnected see “Shift strategy” in the driving section. To account for customer driving habits and conditions, your automatic transmission (4R100) electronically controls the shift quality by using an adaptive learning strategy.
Page 221 Maintenance and care If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 222 Maintenance and care Changing the air filter element 1. Loosen the clamp that secures the air inlet tube to the engine air filter cover and disconnect the tube from the cover. 2. Loosen the clamp that secures the air filter cover to the air filter housing and carefully separate the cover from housing.
Page 223 Maintenance and care 4. Install a new air filter element. Be careful not to crimp the filter element edges between the air filter housing and cover. This could cause filter damage and allow unmetered air to enter the engine if not properly seated.
Page 224 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 225 Maintenance and care The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 226 Maintenance and care Tire rotation Because your vehicle’s tires perform different jobs, they often wear differently. To make sure your tires wear evenly and last longer, rotate them as indicated in the scheduled maintenance guide. If you notice that the tires wear unevenly, have them checked. •...
Page 227 Follow these guidelines when using snow tires and chains: • Use only cable type chains offered by Ford as an accessory or equivalent. SAE class “S” or other conventional link type chains may contact and cause damage to the vehicle’s wheel house and/or body.
Page 228 Maintenance and care WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 229 Maintenance and care Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 230 Maintenance and care The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container. Use the following guidelines to avoid static build-up when filling an ungrounded fuel container: •...
Page 231 Auto Makers’ Choice logo. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 232 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 233 Maintenance and care ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver. You must gather information as accurately and consistently as possible. Fuel expense, frequency of fillups or fuel gauge readings are NOT accurate as a measure of fuel economy.
Page 234 Maintenance and care Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in kilometers or miles). 2. Each time you fill the tank, record the amount of fuel added (in liters or gallons). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading.
Page 235 Maintenance and care • Using the air conditioner or defroster may reduce fuel economy. • You may want to turn off the speed control in hilly terrain if unnecessary shifting between third and fourth gear occurs. Unnecessary shifting of this type could result in reduced fuel economy. •...
Page 236 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 237 Maintenance and care Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 238 Maintenance and care • Foglamps • High-mount brakelamp • Brakelamps • Parking lamps • Turn signals • License plate lamp • Tail lamps • Back-up lamps Do not remove lamp bulbs unless they can be replaced immediately with new ones. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect lamp performance.
Page 239 Maintenance and care Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated. 8.
Page 240 Maintenance and care 4. Rotate the bulb socket counterclockwise and remove from the lamp assembly. 5. Carefully pull the bulb out of the socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly and rotate clockwise. 7.
Page 241 Maintenance and care Replacing foglamp bulbs 1. Remove the bulb socket from the foglamp by turning counterclockwise. 2. Disconnect the electrical connector from the foglamp bulb. 3. Connect the new foglamp bulb to the electrical connector. 4. Install the bulb socket in the foglamp turning clockwise. Replacing running board lamp bulbs For bulb replacement, see a dealer or qualified technician.
Page 242 Maintenance and care Replacing license plate lamp bulbs The license plate bulbs are located behind the rear bumper. To change the license plate lamp bulbs: 1. Reach behind the rear bumper to locate the bulb. 2. Twist the bulb socket counterclockwise and carefully pull to remove it from the lamp assembly.
Page 243 If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician. CLEANING AND CARING FOR YOUR VEHICLE Refer to the Customer Assistance chapter for a list of Ford-approved cleaners, polishes and waxes.
Page 244 Maintenance and care Washing your vehicle Wash your vehicle regularly with cold or lukewarm water. Never use strong detergents or soap. If your vehicle is particularly dirty, use a quality car wash detergent. Always use a clean sponge, washing glove or similar device and plenty of water for best results.
Page 245 Ultra Touch Prep and Finishing Kit (F7AZ-19K507–BA), Lacquer Touch-up Paint (ALBZ-19500–XXXXA), or Exterior Acrylic Spray Lacquer (ALAZ-19500–XXXXA) from the Ford Car Care Chemicals line. Please note that the part numbers (shown as XXXX above) will vary with your vehicle’s specific coloring. Observe the application instructions on the products.
Page 246 Cleaning the exterior lamps Wash with the same detergent as the exterior of your vehicle. If necessary, use a tar remover such as Ford Extra Strength Tar and Road Oil Remover (B7A-19520–AA). To avoid scratching the lamps, do not use a dry paper towel, chemical solvents or abrasive cleaners.
Page 247 Ford Ultra-Clear Spray Glass Cleaner, (E4AZ-19C507–AA), available from your Ford Dealer. Do not use abrasive cleansers on glass as they may cause scratches. The windshield or rear window is clean if beads do not form when you rinse it with water.
Page 248 For tougher soiling concerns, Ford recommends using the Deluxe Leather Care Kit F8AZ-19G253–AA, which is available from your Ford Dealer. This mild cleaner and special pad, cleans the leather and maintains its natural beauty. Follow the instructions on the cleaner label.
Page 249: Capacities And Specifications
EV-233 EV-233 Spark plugs* AWSF-32P AWSF-22W * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid High Fill to line on Performance reservoir DOT 3 Motor...
Page 250 Capacities and specifications Fluid Ford Part Application Capacity Name Transmission Motorcraft 4R70W 13.1L (13.9 fluid MERCON V quarts) Motorcraft 4R100 (4x2) 15.0L (15.9 MERCON ATF quarts) 4R100 (4x4) 15.5L (16.4 quarts) Transfer case Motorcraft 4x4 vehicles 1.9L (2.0 fluid MERCON ATF...
Page 251 Capacities and specifications Fluid Ford Part Application Capacity Name 5.4L V8 engine 26.4L (27.9 with 2 row quarts) radiator and aux rear heat Front axle Motorcraft SAE 4x4 vehicles 1.8-2.0L (3.5-3.7 lubricant 75W-90 pints) Premium 4x4 Front Axle Lubricant Rear axle Motorcraft SAE 2.9-3.1L (5.5-5.8...
Page 252 The axle lubricant should be changed any time the axle has been submerged in water. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles.
Page 253 Capacities and specifications Ford part Ford part Ford Item name number specification Driveshaft, slip Premium Long XG-1-K or ESA-M1C75-B spline, double Life Grease XG-1-C or Cardan joint XG-1-T center ball Engine coolant Motorcraft VC-4–A (US) or ESE-M97B44-A Premium Engine CXC-10...
Page 254 Use of any fluid other than the recommended fluid may cause transmission damage. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118-A for complete refill of Ford Traction-Lok rear axles.
Page 255 Capacities and specifications ENGINE DATA Engine 4.6L V8 engine 5.4L V8 engine Cubic inches Required fuel 87 octane 87 octane Firing order 1-3-7-2-6-5-4-8 1-3-7-2-6-5-4-8 Spark plug gap 1.3-1.4 mm 1.3-1.4 mm (0.052-0.056 inch) (0.052-0.056 inch) Ignition system Coil on plug Coil on plug Compression ratio 9.37:1...
Page 256 Capacities and specifications Vehicle equipped with 16” tires and base suspension...
Page 257 Capacities and specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 258: Customer Assistance
5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to...
Page 259 Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 260 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business) •...
Page 261 THE DISPUTE SETTLEMENT BOARD (U.S. only) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes • available free to owners and lessees of qualifying Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford...
Page 262 • the name of the dealer(s) who sold or serviced the vehicle • a brief description of your unresolved concern • a brief summary of the action taken by the dealer(s) and Ford Motor Company • the names (if known) of all the people you contacted at the dealership(s) •...
Page 263 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 264 UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 265 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 266 * May be sold with the Motorcraft name FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs;...
Page 267 Customer assistance Carpeted cargo mat Dash trim (wood grain) Engine block heaters Tire step Travel equipment Auto headlamps with DRL Bike rack Bumper mount bike carrier Canoe carrier Cell phone holder Daytime running lights (DRL) Factory luggage rack adaptors Fog lights Framed luggage covers Hard side luggage box Hard side ski box...
Page 268 Customer assistance Protection and appearance equipment Air bag anti-theft locks Cargo liners, interior Carpet floor mats Door edge guards Fender flares Flat splash guards Front end covers (full and sport) Hood deflectors Inside mirror with compass display Inside mirror with compass and temperature display Leather steering wheel Locking gas cap Molded splash guards...
Page 269 • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment. ORDERING ADDITIONAL OWNER’S LITERATURE...
Page 270 Customer assistance IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, the manufacturer shall be required to either replace the vehicle with one substantially identical or repurchase the vehicle and reimburse the buyer in an amount equal to the actual price paid or payable by the consumer (less a reasonable allowance for consumer...
Page 271: Reporting Safety Defects
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 272: Index
Index fluid, specification ....254 Auxiliary power point ....26 Accessory delay ......89 Axle Air bag supplemental restraint lubricant system ......128–129, 134 specifications ....251, 254 and child safety seats ....131 refill capacities ......248 description ......129, 134 traction lok ......157 disposal ......133, 137 driver air bag ....131, 135 indicator light ...11, 133, 136 operation ......131, 135...
Page 273 Cruise control (see Speed child safety belts ....137 control) ........69 Child safety seats ......138 Customer Assistance ....178 attaching with tether Ford accessories for your straps .......143–144 vehicle ........264 in front seat ......140 Ford Extended in rear seat ....140, 142–143 Service Plan ......257 Getting assistance outside the Cleaning your vehicle ....242...
Page 274 Index Driving under special Floor mats ........92 conditions ........167 Fluid capacities ......248 mud ..........166 Foglamps ........22 sand .........166 snow and ice ......167 Four-Wheel Drive through water ....166, 168 vehicles ........14, 163 control trac .......24, 163 description ......164 driving off road .......165 Emergencies, roadside electronic shift ....24, 164 jump-starting ......194...
Page 275 Index Gas mileage (see Fuel Heating ........56 economy) ........232 heating and air conditioning system ........56 Gauges .........16 battery voltage gauge ....18 HomeLink universal engine coolant temperature transceiver (see Garage door gauge .........17 opener) ......84, 86–87 engine oil pressure gauge ..19 Hood ..........202 fuel gauge ........16 odometer ........17...
Page 276 Index Locks autolock ........101 Lamps childproof ........89 autolamp system .......23 doors ..........89 bulb replacement Lubricant specifications ...251, 254 specifications chart ....241 Lumbar support, seats .....106 cargo lamps .......22 daytime running light ....21 fog lamps ........22 headlamps .........21 Message center .....19, 78 headlamps, flash to pass ..21 english/metric button ....19 instrument panel, dimming ..22...
Page 277 Index Power distribution box (see lap belt ........122 Fuses) ........185 warning light and chime ....12, 15, 123–124 Power door locks ....89, 101 Safety seats for children ..138 Power steering ....155–156 fluid, checking and adding ..214 Seat belts (see Safety fluid, refill capacity ....248 restraints) ........116 fluid, specifications ..251, 254 Seats ..........104...
Page 278 Index replacing ........225 Vehicle loading ......168 rotating ........225 Ventilating your vehicle ...151 snow tires and chains ....226 tire grades .......224 treadwear ........223 Towing ........171 Warning chimes ......15 recreational towing ....175 Warning lights (see Lights) ..10 trailer towing ......171 Washer fluid ......207 wrecker ........200 Water, Driving through .....168 Traction-lok rear axle ....157...
Page 280: Filling Station Information
Use either green-colored Motorcraft Premium Engine Coolant or yellow-colored Motorcraft Premium Gold Engine Coolant. DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 281 Filling station information Some transmission fluids may be labeled as dual usage, such as MERCON and MERCON V. These dual usage fluids are not to be used in an automatic transmission that requires use of the MERCON type fluid. However, these dual usage fluids may be used in transmissions that require the MERCON V type fluid.

Ford 2001 Expedition Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Ford 2001 Expedition

Summary of Contents for Ford 2001 Expedition

Table of Contents
