Spacelabs 90207 Operation Manual page 19

EC04
ECn4
EC05
EC15
EC25
EC35
EC05
EC05 & EC45
EC45
EC05 & EC55
EC55
EC05 & EC65
EC65
EC05 & EC75
EC75
EC05 & EC85
EC85
EC05 & EC95
EC95
EC07
EC78
EC08
EC18
EC28
EC38
EC48
EC58
EC68
EC09
EC19
Operation
Blood pressure measurement not completed in the maximum time al-
lowed. Occasional EC04 messages may result from excessive patient
movement. Frequent EC04 messages would indicate an improperly ap-
plied cuff or a monitor malfunction which requires service.
(where n = 1 to 9) Indicates that one or more of the blood pressure results
have been corrupted and subsequently recovered. Frequent occurrence
of this message would indicate a malfunction that requires service.
The individual blood pressure result has been corrupted and cannot be
recovered.
Equipment malfunction. Return to Spacelabs Medical for service.
Monitor failed to initialize. Please initialize.
90207
At least one of the blood pressures or time readings obtained before the
event code is erroneous. Interpret all readings with caution.
90217
The monitor needs to be reinitialized.
Invalid bleed size. The monitor has automatically changed the bleed size
to 8 mmHg.
An unexpected loss of power possibly caused by: a) removal of the bat-
teries during a blood pressure measurement, b) hardware overpressure,
or c) a hardware time-out. Frequent EC55 messages would indicate a
malfunction which requires service.
90207
Equipment malfunction. Return to Spacelabs Medical for service.
90217
Extremely large artifact.
Equipment malfunction. Return to Spacelabs Medical for service.
EC05 & EC85 EC85
Medical for service.
Cuff pressure baseline is out of limits. The monitor should correct the
baseline automatically within 10 minutes, or it can be reset by initializ-
ing the monitor. If initialization does not correct the condition, the monitor
must be returned to Spacelabs Medical for calibration.
Clogged connector fi lter.
Too few data entries to accurately determine blood pressure. This mes-
sage may indicate that the cuff is not being worn by the patient (taken off
but left connected to the monitor). The message may also indicate that
motion artifacts cause the majority of the incomplete data.
Diastole above 200 mmHg.
Pulse pressure less than 16 mmHg.
A) Movement artifact at mean arterial pressure
B) Heart rate arrhythmia
A) Movement artifact at diastole
B) Heart rate arrhythmia
Division by zero.
Contradictory instructions sent to hardware (e.g., "pump ON and valve
open").
070-0137-03 Rev.L
Equipment malfunction. Return to Spacelabs
1-13
