Specifications - Polaris Phoenix 200 Owner's Manual

SPECIFICATIONS

Maximum Weight Capacity
Dry Weight
Fuel Capacity
Engine Oil Capacity
Transmission Oil
Rear Gearcase Oil
Rear Rack Capacity
Hitch Tongue Weight Capacity
Hitch Towing Weight Capacity
Overall Length
Overall Width
Overall Height
Wheelbase
Ground Clearance
Minimum Turning Radius
Engine Type
Lubrication
Engine Cooling
Displacement
Bore x Stroke
Alternator Output
Compression Ratio
Carburetor
Pilot Jet
Main Jet
Air Screw
Jet Needle
Ignition System
Ignition Timing
Spark Plug / Gap
Driving System Type
Shift Type
Drive Ratio, Front
Tires, Front
Tires, Rear
Front Suspension
Rear Suspension
96
Phoenix 200
215 lbs. (98 kg) (includes weight of operator,
cargo and accessories)
395 lbs. (179 kg)
2.5 gal. (9.5 l)
41 oz. (1200 ml)
18.6 oz. (550 ml)
4 oz. (120 ml)
70 lbs. (31.7 kg)
30 lbs. (13.6 kg) (Rear rack weight and tongue
weight not to exceed 30 lbs./13.6 kg)
300 lbs. (136 kg)
65 in. (165 cm)
42 in. (106.7 cm)
42 in. (106.7 cm)
45 in. (114.3 cm)
5.7 in. (14.5 cm)
65 in. (165.1 cm) unloaded
4-Cycle, Single Cylinder
Wet sump
Air
196 cc
65 x 59
210w @5000 rpm
9.2:1 Full Stroke
1 / 22 mm (VM Type)
40
98
1 Turn Out
2MKNN-4 clip
DC CDI
32 +/- 2 @ 3000 RPM
NGK CR6HSA / 0.6-0.7 mm
Constant Variable Transmission (CVT)
Side Lever (F/N/R)
N/A
21x7-10 / 4 psi (27.6 kPa)
20x10-9 / 4 psi (27.6 kPa)
Dual A-Arm w/7 in. (17.8 cm) travel
Mono-Shock Swing Arm w/6.5 in. (16.5 cm)
travel
