Highlight TEMP2 and press SELECT (TEMP1
must be higher than TEMP2). Use the UP or
DOWN button to increase or decrease the
temperature and press SELECT. Use the BACK
button to return to the main screen.
3. Maintain Temperature
MENU/HELP > SET TEMP >MAINTAIN
In the SET TEMP menu, highlighting MAINTAIN
and pressing SELECT will turn on (or off) the
MAINTAIN function. MAINTAIN will run the
pump for the chosen body of water to keep the
water at the desired temperature. If this function
is on, as long as the heater/chiller is enabled for
that body of water, the system will automatically
turn on the pump every couple of hours for just
enough time to test the water temperature. If
the temperature meets the set point, the pump
will return to off. If the measured temperature is
different than the set temperature, the pump will
stay on and the heater/chiller will operate long
enough to bring the water to the set temperature.
4. Maintain Temperature Hours
MENU/HELP > SET TEMP >HOURS
Sets the desired time when this function will
activate (default setting is 12AM to 12AM;
24 hours a day). Highlight HOURS and press
SELECT. Use the UP or DOWN buttons to change
the HOURS the system will maintain the set
temperature.
4.3.4 Label Auxiliary Functions
MENU/HELP > SYSTEM SETUP > LABEL AUX > AUX 1-X >
CHOOSE LABEL TYPE > CHOOSE LABEL
Highlight MENU/HELP and press SELECT.
Highlight SYSTEM SETUP and press SELECT.
Highlight LABEL AUX and press SELECT.
Highlight the AUX you want to label and
press SELECT. Highlight GENERAL, LIGHT,
WATERFALL or CUSTOM LABEL and press
SELECT. Choose a name within these categories
by using the UP or DOWN button or the PAGE UP
or PAGE DOWN button, press SELECT when you
find the correct name. Choose CUSTOM to type in
your own names.
NOTE The Auxiliary labels AIR BLOWER and FILL
LINE have an automatic 0 minute runtime.
To change this setting, refer to the DEVICE
RUNTIME feature.
If DIP switch 1,2 or  are on, auxiliaries 1, 2
and  are labeled CLEANER, LOW SPEED
and SPILLOVER respectively and cannot be
relabeled.
4.3.5 Set Freeze Protection
MENU/HELP > SYSTEM SETUP > FREEZE PROTECT > SET
TEMP VALUE > SELECT FREEZE PROTECT DEVICE
Highlight MENU/HELP and press SELECT.
Highlight SYSTEM SETUP and press SELECT.
Highlight FREEZE PROTECT and press SELECT.
Use the UP or DOWN button to change the
temperature. Once the temperature is set press
the SELECT button to move to the next screen
to assign freeze protection to a selected piece of
equipment. Highlight a device and press SELECT.
"X" means the device has been assigned.
NOTE The filter pump is always assigned to freeze
protection.
4.3.6 Assign JVAs
MENU/HELP > SYSTEM SETUP > ASSIGN JVAs > SELECT JVA
Highlight MENU/HELP and press SELECT. Highlight
SYSTEM SETUP and press SELECT. Highlight AS-
SIGN JVA and press SELECT. Highlight the JVA you
wish to assign and press SELECT.
NOTE If a solar sensor is installed, the Solar JVA will
automatically be assigned and will be marked
as USED.
4.4 OneTouch Reset and Display Messages
4.4.1 Restarting the System
MENU/HELP > SYSTEM SETUP > CLEAR MEMORY >
CONTINUE > FINAL WARNING > CONTINUE
To remove all labeling, programming, assignments
and temperature settings, highlight MENU/HELP and
press SELECT. Highlight SYSTEM SETUP and press
SELECT. Highlight CLEAR MEMORY and press
SELECT. Highlight CONTINUE and press SELECT.
Use the UP or DOWN button to highlight YES or NO
and press SELECT. There will be about a 15 second
delay before you see the FINISHED screen. Highlight
CONTINUE and press SELECT to return to the
SYSTEM SETUP.
