Display
NOTE:
The position of the WLAN antennas differs according to model. If your model has WWAN
capability in addition to WLAN, the WLAN antennas will be are located below the display. See (1) in
the table below.
Component
(1)
WLAN antennas (2)*
(2)
Webcam light
(3)
HP TrueVision HD Webcam
(4)
Internal microphone
(5)
Internal display switch
(6)
WWAN antennas (2)* (select models only)
*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately
around the antennas free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety and
Environmental Notices that applies to your country or region.
Description
Send and receive wireless signals to communicate with wireless
local area networks (WLANs).
NOTE:
To set up a WLAN and connect to the Internet, you
need a broadband modem (either DSL or cable) (purchased
separately), high-speed Internet service, purchased from an
Internet service provider, and a wireless router (purchased
separately).
On: The webcam is in use.
Records video, captures still photographs, and allows you to
video conference and chat online using streaming video.
Records sound.
Turns off the display and initiates Sleep if the display is closed
while the power is on.
NOTE:
The internal display switch is not visible from the
outside of the computer.
Send and receive wireless signals to communicate with wireless
wide area networks (WWANs).
Display
3
