LUBRICATION

ENGINE
AFTER THE FIRST 5 WORKING HOURS
While the engine is warm, remove the drain cap or
plug and drain the crankcase (drain cap shown at A for
Kohler 20 hp below). Clean and replace the plug.
Change oil filter. Fill the crankcase with fresh oil to the
full mark.
GREASE FITTINGS
Every 50 Working Hours
Lubricate the following points
with grease:
1. Caster wheel pivots—2 points
2. Caster wheel bearings(on
wheel rim)—2 points
3. Deck idler pivot bearings:-2
points
4. Hydro belt tensioner: Located
under engine deck
NOTE, SPINDLES: The
spindles on these machines
use a superior sealed bearing
which does not require
relubrication.
16
DAILY
• Remove the dip stick and check that the level
reaches the full mark.
• See engine manual for proper oil viscosity and
grade.
• If necessary, top off with fresh oil. To obtain the
correct oil level, the machine must be level.
• DO NOT OVER FILL!
NOTES:
• See engine manual for oil and filter change intervals
after the break in period.
• See engine manual for specifications.
1
2
1
3
2
HYDRO
MIDSIZE
4
3
