1
Personal Computer

Reference Manual

CF-51 Series
Model No.
XP
We recommend that this Reference Manual be printed.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CF-51 Series

Summary of Contents for Panasonic CF-51 Series

  • Page 1: Reference Manual

    Personal Computer Reference Manual CF-51 Series Model No. We recommend that this Reference Manual be printed.

  • Page 2: Read Me First

    Read Me First Some of the illustrations in this manual may differ slightly in shape from the actual items in order to make the explanation easier to understand. If the user has logged on without the administrator authority, some functions may not be executable, and some screens may be not displayed as shown in this manual.

  • Page 3: Key Combinations

    Key Combinations CAUTION Do not press the following key combinations repeatedly in (quick) succession. Also, do not press different key combinations quickly one after another. Do not press the following key combinations while using the touch pad (external mouse) or other keys. NOTE Do not press the following key combinations until you log on to Windows and the hard disk drive indicator turns off.
  • Page 4 Key Combinations Functions Popup Window (Displayed after logging on to Windows) Fn+F3 Display change (When the external display is connected) By pressing this key combination, you can select either an external display, internal LCD or simultaneous. ( page CAUTION Do not press another key until the display destination has been completely switched.
  • Page 5 Key Combinations Functions Popup Window (Displayed after logging on to Windows) Fn+F4 Speaker on/off switch Pressing this key combination turns on/off audio from the internal speakers and headphone jack. (MUTE) NOTE Disabling the speakers will also disable the warning beep. Speakers connected to the USB port cannot be muted.
  • Page 6 Key Combinations Functions Popup Window (Displayed after logging on to Windows) Fn+F9 Remaining capacity of the battery pack Pressing this key combination displays the remaining battery capacity on the screen. When the battery pack is inserted in the computer (example) When the battery pack is not inserted in the computer...

  • Page 7: Hotkey Settings

    This is convenient when it is difficult to press two buttons simultaneously. Popup windows display ON/OFF Run the Hotkey Settings. Select [start] - [All Programs] - [Panasonic] - [Hotkey Settings]. Set the parameters. A. Use Fn key lock Add the check mark if you want to enable the Fn key lock function. The following Fn key lock function will then be enabled.
  • Page 8 Key Combinations Select [OK]. NOTE Each user can select separate settings for whether or not to use the Hotkey settings. If MUTE is set, you will not hear a beep. " " indicates any function key from...

  • Page 9: Led Indicators

    LED Indicators Power status Not lit Power off / Hibernation mode Green Power on Blinking green Standby mode Blinking green rapidly Due to extremely low temperatures, power cannot be turned on, or computer cannot resume from standby mode. Battery pack status page 28 This indicator lights green when CapsLock is Caps Lock...
  • Page 10 LED Indicators Multimedia pocket device This indicator lights when the multimedia status pocket device (floppy disk drive, DVD-ROM & CD-R/RW drive, DVD MULTI drive etc.) is accessed. This indicator shows the status of a second battery pack when a second battery pack is installed in the multimedia pocket.

  • Page 11: Touch Pad

    Touch Pad Use the touch pad to move the cursor on the screen and perform computer operations. A. Work Surface (touch pad) B. Left Button C. Right Button Function Operation Moving the Cursor Move the tip of your finger lightly over the work surface.
  • Page 12 Touch Pad Function Operation Scroll Scroll a document. The movements will differ depending on the application. NOTE Refer to [Mouse Properties] for information on basic operations other than the above. To display [Mouse Properties]: Select [start] - [Control Panel] - [Printers and Other Hardware] - [Mouse]. The operations of Scroll, Pan or Zoom will differ depending on the application.

  • Page 13: Standby/Hibernation Functions

    Standby/Hibernation Functions Starting Up Your Computer Quickly If you use the standby or hibernation function, you can shut down the computer without closing programs and documents. Upon restarting your computer from either the standby or hibernation mode, you can immediately continue working in all programs, or documents that were open at the time the computer was placed into standby or hibernation mode.
  • Page 14 Standby/Hibernation Functions From the shutdown screen • Standby In [start] - [Turn Off Computer], select [Stand By]. • Hibernation In [start] - [Turn Off Computer], press and hold Shift, then select [Hibernate]. Setting for Using the Hibernation Mode At the time of purchase, the computer is set so that hibernation mode can be used. Select [start] - [Control Panel] - [Performance and Maintenance] - [Power Options].
  • Page 15 Standby/Hibernation Functions • When the MP indicator or hard disk drive indicator is on ( page • When playing/recording audio files and displaying images (such as MPEG files). • When playing a DVD-Video. • When writing to a CD-R/RW disc. •...

  • Page 16: Using The Power Switch

    Standby/Hibernation Functions Using the Power Switch Setting Select [start] - [Control Panel] - [Performance and Maintenance] - [Power Options] - [Advanced]. Select [Stand by] or [Hibernate] for [When I press the power button on my computer], and then select [OK]. Entering the standby or hibernation mode Press the power switch (A);...

  • Page 17: Using The Display

    Standby/Hibernation Functions Using the Display CAUTION Do not perform the following settings when the multimedia pocket device needs to be installed or removed. ( page Setting Select [start] - [Control Panel] - [Performance and Maintenance] - [Power Options] - [Advanced]. Select [Stand by] or [Hibernate] for [When I close the lid of my porta- ble computer], and then select [OK].

  • Page 18: Resuming Operation

    Standby/Hibernation Functions Resuming Operation CAUTION Until resuming is complete (requires about 15 seconds, or 60 seconds if connected to a network, after the display returns), avoid the following: • Touching the keyboard (except for password input), touch pad, or power switch. •...

  • Page 19: Security Measures

    Security Measures To prevent unauthorized access of your computer, the various security measures are provided below. Situation Function to use You do not want the settings in the Setup Supervisor Password (below) Utility to be changed User Password ( page You do not want your computer to be used Password on boot ( page...
  • Page 20 CAUTION Do not forget your password. If your Supervisor Password is forgotten, you will be unable to use your computer. Contact Panasonic Technical Support. When running the Setup Utility, do not leave your computer even for a short time, as the possibility exists for the password to be set/changed by another person.
  • Page 21 Security Measures Setting the User Password (enabling, changing, disabling) NOTE When the Supervisor Password has not been set, the User Password can not be set. Set the Supervisor Password if you have not done so. ( page To disable the User Password, start up the Setup Utility with the Supervisor Password. Run the Setup Utility.
  • Page 22 Security Measures NOTE Your password will not be displayed on the screen. Only up to seven alphanumeric characters can be used. • There is no distinction between upper and lower case letters. • Use only the upper horizontal row of numeric keys to input your password. •...
  • Page 23 Security Measures Select [Enable] or [Disable]. To enable the Password on boot Select [Enable] and press Enter. To disable the Password on boot Select [Disable] and press Enter. Enter Press and select [Yes], then press Starting Up When the Password on boot is Set The screen shown at left is displayed.
  • Page 24 Select [Disable] and press Enter. Enter Press and select [Yes], then press CAUTION To change your hard disk drive • Contact Panasonic Technical Support. • Before changing the hard disk, be sure to set the [Hard Disk Lock] to [Disable].
  • Page 25 Security Measures Preventing theft or damage to data using a floppy disk Disabling the floppy disk operation makes it impossible to read and write a floppy disk and to start the computer from a floppy disk. This can prevent data from being accessed illegally or overwritten accidentally using a floppy disk.

  • Page 26: Computing On The Road

    Computing on the Road Saving Power One of the main features of notebook-type computers is that you have the power of computing away from your home or office. In the following, information is provided on how to maximize use of the battery pack which is necessary for such computing. Four Important Points •...
  • Page 27 NOTE Select to view [Important Tips] for using the battery pack. You can also view [Important Tips] using the following procedures. Select [Important Tips] in [start] - [All Programs] - [Panasonic] - [On-Line Manuals].

  • Page 28: Battery Power

    Quickly save your data and power off your computer. Remove the battery pack and disconnect the AC adaptor, then connect them again. If the problem persists, contact Panasonic Technical Support. The battery pack or charging circuit may be defective. Battery cannot be recharged temporarily because the internal...
  • Page 29 Battery Power NOTE This computer prevents overcharging of the battery by recharging only when the remaining power is less than approx. 95% of capacity after the battery is fully charged. Check the Remaining Battery Power Press Fn+F9 to check the remaining battery power on the screen.
  • Page 30 Battery Power About High Temperature Mode This computer has a high temperature mode function that prevents the deterioration of the battery in high-temperature environments or when using the fully charged battery pack for a long period of time. To use the high temperature mode function, set [Environment] in the [Main] menu of the Setup Utility to [Auto] or [High Temperature].
  • Page 31 Battery Power When the Remaining Battery Charge Becomes Low The following is factory default setting. When remaining battery capacity falls to When remaining battery capacity falls to 5% [Critical battery alarm] [Low battery alarm] Displays a message indicating the low Displays a message indicating the low battery level.
  • Page 32 Battery Power A. When making a setting for [When the alarm goes off, the computer will] in [Alarms] - [Alarm Action]: Add a check mark for [Force stand by or shutdown even if a program stops responding.]. B. Set the value for [Critical battery alarm] to 5% or more. This is necessary for the standby or hibernation function to be completed (assuring data is saved) when the battery level is low.

  • Page 33: Replacing The Battery Pack

    Battery Power Use the "Battery Recalibration" utility to fully discharge the battery pack. Run the Setup Utility. ( page Select [Battery Recalibration] from [Exit] menu and press Enter. At the confirmation message, select [Yes] and press Enter. Once the battery indicator turns green, the battery pack will be completely discharged.
  • Page 34 Battery Power Power off your computer. (⇒Operating Instructions "Starting Up/Shutting Down") Do not shut down using the standby function. Turn your computer over and remove the cover (A). Slide and remove the cover without releasing the mark (B). Remove/Insert the battery pack (C). Removing Slide the latch (D), and then without releasing it, pull the tab (E) on the battery pack and remove it from the computer.

  • Page 35: Multimedia Pocket

    Multimedia Pocket You may use any of the following devices. Floppy disk drive DVD-ROM & CD-R/RW drive DVD MULTI drive Second battery pack NOTE Confirm the latest information on optional products in catalogs, etc. Be sure to read the operating instructions of the devices. Before connecting a peripheral such as a USB device or a PC Card, change the multimedia pocket device in accordance with the media in which the driver of the peripheral exists.

  • Page 36: Removing The Device

    Multimedia Pocket Inserting/Removing CAUTION Do not insert/remove the multimedia pocket device in the standby or hibernation mode, or when (multimedia pocket indicator) or (hard disk drive indicator) is on. Do not select [Stand by] or [Hibernate] as the setting for [When I close the lid of my portable computer] in the following menu.

  • Page 37: Inserting The Device

    Multimedia Pocket Inserting the device Gently insert the device into the multimedia pocket by pushing on both corners until it is firmly in place. CAUTION Insert the device with the plastic side on top. Do not insert the floppy disk drive into the multimedia pocket and connect the USB floppy disk drive simultaneously.

  • Page 38: Cd/Dvd Drive

    CD/DVD Drive Usage Precautions Before using the CD/DVD drive <Information for the DVD MULTI drive> When using the CD/DVD drive for the first time, press the eject button to open the CD/ DVD drive after the computer has been powered on, and remove the protective sheet from the lens area.

  • Page 39: About Discs

    CD/DVD Drive In addition, after running an application involving access to a disc, do not open the CD/ DVD drive until after the application has been closed. Cleaning We recommend cleaning the drive lens with an air puffer used for camera lenses. (Do not use any spray-type of lens cleaning products.) About Discs Do not use any discs that have become deformed, warped, or are not completely round.
  • Page 40 CD/DVD Drive When Using DVD Media To play DVD-Video or MPEG2 files, DVD playback software is required. (“WinDVD” is included in DVD Drive Utility Disc attached to this computer. For information on how to install WinDVD: page 47 About Regions Setting The DVD-Video has a region code that is fixed according to the region where it is sold.
  • Page 41 CD/DVD Drive NOTE [Confirm Region] will also be displayed if a DVD-Video with one region code is inserted into a drive for which another region code has already been set. Information for the DVD-ROM & CD-R/RW Drive (Model with a DVD-ROM & CD-R/RW Drive) When using the optional CD/DVD drive, read the operating instructions for the drive.
  • Page 42 CD/DVD Drive Depending on the disc, the quality of the write operation may not be so good. We recommend using any of the following discs. Recommended Discs: • CD-R HITACHI MAXELL, Ltd. MITSUBISHI KAGAKU MEDIA CO., Ltd. MITSUI CHEMICALS, Inc. RICOH Co., Ltd.
  • Page 43 CD/DVD Drive At the welcome screen, select [Next]. The License Agreement screen appears. Carefully read the agreement, then select [Yes]. At [Choose Destination Location], do not change the setting, and select [Next]. At [Select Program Folder], do not change the setting, and select [Next]. At [Start Copying Files], select [Next].
  • Page 44 CD/DVD Drive • DVD-RW Ver.1.1 (4.7 GB) • DVD-RW Ver.1.1/2X-SPEED DVD-RW Revision 1.0 (4.7 GB) • DVD-RAM Ver.2.0 or Ver.2.1 (4.7 GB/9.4 GB/1.4 GB/2.8 GB) • DVD-RAM Ver.2.1/3X-SPEED DVD-RAM Revision 1.0 (4.7 GB/9.4 GB) In the case of DVD-RAM, only non-cartridge discs or removable cartridge discs can be used.
  • Page 45 CD/DVD Drive To avoid damaging discs: • Do not touch the data surface (the side opposite the side with the title printed on it) as it can cause the disc to become dirty or scratched. • Do not allow discs to become dirty or scratched. •...

  • Page 46: Power Saving Mode

    CD/DVD Drive Inserting Place the disc with the label facing upward in the drive and push down the center of the disc until it clicks in place. Removing Hold down on the center spindle (B) and gently lift up on the edge of the disc. Close the tray.

  • Page 47: Installing Windvd

    WinDVD WinDVD is a software application for DVD playback. Here, you will find explanations and general information on the usage precautions and how to access the online manual. Refer to the online manual concerning the detailed use of the software application. page Installing WinDVD CAUTION...
  • Page 48 WinDVD Usage Precautions Do not enter the standby or hibernation mode, or switch the display by pressing Fn + F3 while WinDVD is running. Do not start WinDVD while the hard disk drive indicator is blinking immediately after the computer was started up. During video playback (while the MP indicator is on), do not perform the following.
  • Page 49 WinDVD When the playback screen appears too white: Right-click on the top of the WinDVD screen, and click on [Setup] - [Video] to display the [Color preset] setting screen. To change color settings in WinDVD, click on the WinDVD control panel, click on [Color], and set [Brightness], [Contrast], and [Color] on the sub-panel.
  • Page 50 WinDVD How to Access the Online Manual After starting WinDVD, you can access the Online Manual using either of the following procedures. Select "?" of the WinDVD control panel. Right-click on the WinDVD screen and select [Help]. SUPPORT INFORMATION If WinDVD does not operate properly, we recommend carefully reading the online help file first for problems with the operating environment or operations.

  • Page 51: B's Recorder/B's Clip

    B’s Recorder/B’s CLiP "B's Recorder" and "B's CLiP" are CD/DVD recording software applications developed by B.H.A Corporation. Here, explanations are given on general information about B's Recorder and B's CLiP and how to access the online manual. Refer to the online manual concerning the detailed use of the software application.
  • Page 52 B’s Recorder/B’s CLiP .Close all other software application before running the Setup program for B’s Recorder and B’s CLiP for added safety. Installing B’s Recorder/B’s CLiP CAUTION Close all other software application before running the Setup program for B’s Recorder and B’s CLiP for added safety. Log on with the administrator authority.
  • Page 53 B’s Recorder/B’s CLiP Running B’s Recorder/B’s CLiP B’s Recorder You can run B's Recorder using either of the following procedures. Select on the desktop. Select [start] - [All Programs] - [B.H.A] - [B's Recorder GOLD BASIC] - [B's Recorder GOLD BASIC]. B’s CLiP B's CLiP runs when the computer starts up, and is displayed on the taskbar.
  • Page 54 B’s Recorder/B’s CLiP How to Access the Online Manual B’s Recorder Select [start] - [All Programs] - [B.H.A] - [B's Recorder GOLD BASIC] - [DOC] - [User's Manual]. B’s CLiP Select [start] - [All Programs] - [B.H.A] - [B’s CLiP] - [User's Manual]. SUPPORT INFORMATION If B’s Recorder and B’s CLiP do not operate properly, we recommend carefully reading the online help file first for problems with the operating environment or operations.
  • Page 55 PC Cards Your computer has two PC Card slots. These slots conform to the PC Card Standard; therefore, communications or SCSI devices, etc., may be utilized. Type I (3.3 mm) or II (5.0 mm): Two cards can be used simultaneously. Type III (10.5 mm): One card can be used only in the slot 1.

  • Page 56: Inserting A Pc Card

    PC Cards Inserting/Removing the PC Card Inserting a PC Card Simply slide the PC Card right-side-up until it snaps into place. Refer to the operating instructions of each card on how to insert the card. CAUTION Before connecting the PC card, change the multimedia pocket device in accordance with the media in which the driver of the PC card exists.

  • Page 57: Removing A Pc Card

    PC Cards Removing a PC Card CAUTION Do not remove a PC Card while your computer is in the standby or hibernation mode. When two PC Cards are inserted, perform the following procedure (from Step Step for each of the two cards). Note that the operation of removing the PC Card may not be complete, depending on the status of the PC Card or device connected to the PC Card, such as when a SCSI card is used to connect an external hard disk to the computer.

  • Page 58: Ram Module

    RAM Module Use a RAM module meeting the RAM module specifications below. If a module is used that does not meet the specifications, there are cases in which data may become unusable or the computer may not operate properly. RAM module specifications: 200 pins, SO-DIMM, 2.5 V, DDR SDRAM, PC2700 Either a PC2700 compliant RAM module or a PC2100 compliant RAM module can be added.

  • Page 59: Insert The Battery Pack

    RAM Module Insert/Remove RAM module. Inserting the RAM module Slide in the module at an angle. Press the RAM module down until the right and left hooks (A) lock into place. Removing the RAM module Gently open the right and left hooks (A). The RAM module will be raised at an angle.

  • Page 60: Port Replicator

    Port Replicator Port Replicator A port replicator is available as an option (CF-VEB511). This device eliminates the hassles of having you connect/disconnect the various cables when carrying your computer around and allows a variety of peripherals to be connected including a headphone or microphone, etc. The port replicator connects to the expansion bus connector (A) on the back of your computer.

  • Page 61: External Display

    External Display Power off your computer. (⇒ Operating Instructions "Starting Up/Shutting Down") Do not connect or disconnect devices while the computer is in standby or hibernation mode. Connect the external display. Connect the external display to the external display port (A) on your computer. Turn on the external display, then turn on your computer.
  • Page 62 External Display [start] - [Control Panel] - [Appearance and Themes] - [Display] - [Settings] - [Advanced] - [Troubleshoot] Also, carefully read the operating instructions of the external display. Dualview With Dualview, you can use both the internal LCD and the external display as an extended display domain.
  • Page 63 External Display Precautions When the application running is not shown on the display, refer to the following items. Under the condition the application is in the external display, or after the application is closed in the external display, there are cases the application will not be shown in the display when executed the next time if the position of the extended display is changed or the Dualview is closed.

  • Page 64: Control Panel

    External Display When an animated pointer is used for the mouse pointer (e.g., when changing the theme in [Appearance and Themes] of [Control Panel]) An error may occur when resuming from the standby or hibernation mode. In such cases, change the mouse pointer to the standard pointer with the following procedure. Display [Mouse Properties].
  • Page 65 Printer A printer can be connected to the parallel port (A) or the USB port ( page 66). When a printer is connected to the parallel port: Confirm whether or not the [Parallel Port] setting in the Setup Utility is optimal.( page NOTE You may need to install a driver for your printer.

  • Page 66: Connecting Usb Devices

    USB Devices Connecting/Removing USB devices Connecting USB devices Connect the USB device to the USB port (A) on your computer, referring to the operating instructions of the USB device. You may need to install drivers compatible with the operating system you are using for your USB devices.

  • Page 67: Removing Usb Devices

    USB Devices Removing USB devices CAUTION Do not remove a USB device while your computer is in the standby or hibernation mode. Save important data and close each application. Disable the device functions. Select on the taskbar and select the USB device, then select [Stop]. Follow the on-screen instructions.

  • Page 68: Connecting Ieee 1394 Devices

    IEEE 1394 Devices A digital video camcorder or other IEEE 1394 standard device can be connected to the computer. Connecting IEEE 1394 devices Turn on the computer (⇒Operating Instructions "Starting Up/Shutting Down") and the IEEE 1394 device. Connect the IEEE 1394 device to the IEEE 1394 interface connector (A). Refer to the instructions manual included with the IEEE 1394 devices.
  • Page 69 Modem Connecting the Internal Modem with a Telephone Jack CAUTION Do not use the PBX internal phone lines installed in company offices. Doing so may lead to a fire or electric shock. It is not possible to connect the modem to any of the following lines. •...
  • Page 70 Modem When using this function, it is necessary to run a software application able to maintain the condition to receive telephone calls and to return the computer to the original condition after a call. For further details, refer to the operating instructions provided with software applications.
  • Page 71 Modem NOTE This function does not work when the computer is off or is in hibernation mode. After operations are resumed from standby mode, the screen remains dark. The former screen display will be restored when the keyboard or touch pad is touched. The computer cannot resume if a telephone is connected to the line of a modem (e.g., a PC Card modem) other than the internal modem.

  • Page 72: Connecting Lan

    When using the computer as a network computer, some additional settings may have to be made depending on the usage conditions. We recommend asking your system administrator or the person in charge of the network. Connecting LAN CAUTION Do not connect the modem telephone cable into the LAN port. Power off your computer.
  • Page 73 Display [Device Manager] screen. Select [Device Manager] in [start] - [Control Panel] - [Performance and Maintenance] - [System] - [Hardware]. Select the network adaptor you are using from [Network adapters]. Select [Advanced]. Confirm the settings of each item. Wake up from LAN This is a function of the internal LAN to automatically power the computer on from a network server when the computer is in the standby or hibernation mode.
  • Page 74 • When the AC adaptor and battery pack are removed from the computer or reattached to the computer. • When the LAN cable is disconnected and reconnected. After operations are resumed from standby mode, the screen remains dark. The former screen display will be restored when the keyboard or touch pad is touched. The computer may start up if accessed by another computer on the network.

  • Page 75: Wireless Lan

    Wireless LAN If you use a wireless LAN, you can use a network without cable connections. CAUTION Communication is performed through the wireless LAN antenna (A). Do not block the antenna area with your hand or otherwise interfere with the passage of the radio signals.

  • Page 76: The Settings

    Wireless LAN To prevent theft of data or unauthorized access to the hard disk via a wireless LAN (below). If you plan to use wireless LAN functions, we recommend that you do so only after making the appropriate security settings, such as for data encryption. We recommend turning the wireless LAN off when it is not used or out of range ( page...
  • Page 77 Wireless LAN (The setting described below is only an example. For the other settings, ask your system administrator or the person in charge of the network.) Select [64-bit] or [128-bit] from [Encryption Level]. Select [Use pass phrase] or [Use hex key], and enter the pass phrase or key. In the case of ASCII character: [64-bit (5 characters)] [128-bit (13 characters)] In the case of hexadecimal: [64-bit (10 digits)] [128-bit (26 digits)] Set the same value on the computer side and the access point side.
  • Page 78 Wireless LAN If the function fails to operate correctly Read the operating instructions for the access point carefully and check the settings. The access point fails to be displayed in [Available Networks] Select [Networks], then select the profile you are using, and select [Advanced]. [Connect to ad hoc networks only] may have been selected in [Connection preference].

  • Page 79: Hard Disk Drive

    Hard Disk Drive To change your hard disk drive, contact Panasonic Technical Support. Inserting/Removing the Hard Disk Drive CAUTION Be sure to back up all important data before changing the hard disk drive. ⇒ You can erase the data before changing the hard disk drive. ( Operating Instruc- tions "Hard Disk Data Erase Utility")
  • Page 80 Hard Disk Drive Inserting the hard disk drive Slide the cover back in place. Insert the battery pack. ( page CAUTION Be sure to insert the hard disk drive as illustrated. Confirm that the latch lock is correctly in place. If you carry your computer without the latch lock in place, the hard disk drive may fall out.

  • Page 81: Setup Utility

    Running the Setup Utility Turn on or restart the computer. Press while [Panasonic] boot screen is displayed soon after the computer begins the startup procedure. If [Enter Password] is displayed, enter your password. When the Setup Utility is started with Supervisor Password You can register all items of the Setup Utility.

  • Page 82: Key Operations

    Setup Utility Key Operations To display the corresponding "help" file. To display [Exit] menu. To move among the items. To move among the menus. F5 F6 To move among the values. Enter To display sub-menu of each item selected by To set default settings (except the password).

  • Page 83: Information Menu

    Setup Utility Information Menu Language: [English] Model No.: CF-xxxxxxxxx Serial No.: xxxxxxxxxx CPU Type: xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx CPU Speed: x.xx GHz BIOS: Vx.xxLxx Embedded Controller: Vx.xxLxx System Memory: xxx MB Video RAM: xxx MB Primary Master: xx GB Secondary Master: xxxxxxxx The IDE device, which is a device inserted into the multimedia pocket, is displayed. •...

  • Page 84: Main Menu

    Setup Utility Main Menu System Date: [xx/xx/xxxx] System Time: [xx:xx:xx] Touch Pad: [Enable] Display: [Simultaneous] Display Expansion: [Enable] CD/DVD Drive Speed: [High] Environment: [Auto] Normal Temperature Current Status: Date is shown in order of Month/Day/Year. Time is shown in 24-hr. style. This item is displayed only when [Environment] is set to [Auto].

  • Page 85: Advanced Menu

    Setup Utility The display destination in cases where Windows is not running is set here. When an external display is connected, the computer displays on both the internal LCD and the external display after Windows starts up regardless of the [Display] setting. Advanced Menu Serial Port: [Enable]...

  • Page 86: Security Menu

    Setup Utility Modem Disable Enable Disable Enable Disable Boot up from LAN Enable Wireless LAN Disable Enable This item is displayed only when [Parallel Port] is set to [Enable]. [Disable] is automatically set when [LAN] is set to [Disable]. This function works only for the internal LAN.
  • Page 87 Disable Enable When [Setup Utility Prompt] is set to [Disable], the message "Press F2 for Setup / F12 for LAN" is not displayed on [Panasonic] boot screen. Even if the message is not displayed, will work. Setting impossible when the Supervisor Password is not set.

  • Page 88: Boot Menu

    The device for starting up the operating system can also be selected during computer start-up. After the computer is turned on, and Esc is pressed at [Panasonic] boot screen, [Boot Menu] (the device selection screen) will appear. When the setting of [Boot] menu is changed, the selection screen display will also change.

  • Page 89: Exit Menu

    Setup Utility Exit Menu Save Values & Exit Exit Without Saving Changes Get Default Values Load Previous Values Save Current Values Battery Recalibration This item is not displayed when starting up the Setup Utility with the User Password. Parameters Save Values & Exit Exit the Setup Utility and save your changes to CMOS.

  • Page 90: Technical Information

    Technical Information Network Connections and Communications Software If the power saving function (standby or hibernation mode) activates while communications software is being used, the network connection may be interrupted, or performance may be adversely affected. If this happens, restart the computer. Be sure to close the communications software before using the power saving function.

  • Page 91: Dmi Viewer

    CPU and memory. Running DMI Viewer Select [DMI Viewer] from [start] - [All Programs] - [Panasonic]. The screen shown at left is displayed. When you select an item, detailed information on that item will be displayed.

  • Page 92: Icon Enlarger

    In this case, overlay the cursor to display pop-ups, scroll the screen, or use other functions to display the hidden elements. Close all applications other than "Icon Enlarger" when changing the screen display. Select [start] - [All Programs] - [Panasonic] - [Icon Enlarger]. Select the display size as [Normal Size], [Large Size], or [Extra Large Size].

  • Page 93: List Of Error Codes

    ( page If the problem persists, the internal clock battery may need to be replaced. Contact Panasonic Technical Support. 0271: Check date and time The date and time setting are incorrect.
  • Page 94 [Information] menu of the Setup Utility. If the hard disk is recognized, perform the reinstallation procedure. If not, contact Panasonic Technical Support. If a device is connected to the USB port, disconnect the device, or run the Setup Utility and set [Legacy USB Support] in [Security] menu to [Disable].

  • Page 95: Dealing With Problems (Advanced)

    When a problem occurs, refer to this page. If a problem appears to be related to a software application, read the software related manual. If you still cannot troubleshoot the problem, contact Panasonic Technical Support. You can use the PC Information Viewer to check the computer's usage status ( page 108).
  • Page 96 If the message still appears even after trying the above measure, this may be an indication that some type of hard disk failure has occurred. Contact Panasonic Technical Support. When the administrator password is Set the password again in the following procedure.
  • Page 97 Computer], and select [Properties]. Select [Tools] - [Check Now]. Select [Start] after selecting required items in [Check disk options]. At startup, hold down F8 when [Panasonic] boot screen disappears , and release your finger when the Windows Advanced Options Menu is displayed.
  • Page 98 Dealing with Problems (Advanced) Display The power has not been turned off, but Has the computer been set to the power-saving mode? To resume operation of after a certain period of time, there is your computer from the condition the power of the display is off (for energy no display conservation purposes), press any key unrelated to the direct triggering of a selection, like Ctrl.

  • Page 99: Shutting Down

    Setup Utility [Enter Password] is displayed Enter the Supervisor Password or User Password. If you have forgotten it, contact Panasonic Technical Support. [Advanced] and [Boot] menu can not Restart the Setup Utility with the Supervisor Password. be registered Some items in [Security] menu can not Restart the Setup Utility with the Supervisor Password.

  • Page 100: Standby/Hibernation Function

    The red indicator blinks Quickly save your data and power off your computer. Remove the battery pack and disconnect the AC adaptor, then connect them again. If the problem persists, contact Panasonic Technical Support. The battery pack or charging circuit may be defective.
  • Page 101 Dealing with Problems (Advanced) Battery Indicator The green indicator blinks In high temperature mode, the battery pack is discharging to a level of 80% normal temperature mode.( page 30) Do not remove the battery pack while the battery indicator is blinking green. A level of 80% in normal temperature mode is displayed as [100%] in high temperature mode.

  • Page 102: Connecting Peripherals

    Dealing with Problems (Advanced) Network Unable to use wireless LAN Confirm that [Wireless LAN] is set to [Enable] in the Setup Utility. Confirm that is displayed on the taskbar. is not displayed on the taskbar, confirm that [On] is selected for [Switch radio] in [Intel(R) PROSet] - [General].
  • Page 103 Confirm that a driver for your operating system has been installed. USB floppy disk drives do not work as Only the Panasonic CF-VFDU03 USB floppy disk drive (optional) can be used. a boot drive Remove the floppy disk drive from the multimedia pocket.
  • Page 104 Poor performance when forwarding Follow the on-screen instructions. data via a PC card (e.g., unstable Select [Performance] in [start] - [Panasonic] - [CPU Idle Setting] and video images when writing videos select [OK], then select [Yes]. to a DV camera using an IEEE1394 The computer will be restarted automatically.

  • Page 105: Disk Operations

    Your drive or file may not have been properly set. Check to see if the hard disk is full. If it is full, delete unnecessary files. Your hard disk content may be corrupted. Contact Panasonic Technical Support. Trouble has occurred with the disc set You may need to clean the lens or disc.
  • Page 106 Dealing with Problems (Advanced) Disk Operations If the CD/DVD drive vibrates Is the disc bent or labeled? excessively or is noisy Check to see if the disc is inserted correctly, and check that the disc is in good condition. If the disc is good and inserted correctly, set [CD/DVD Drive Speed] to [Low] in the Setup Utility.

  • Page 107: Fast User Switching Function

    Dealing with Problems (Advanced) Fast User Switching Function Some applications may not work When switching to a different user with the Fast User Switching function, the properly following problems may occur. • Some applications may not work properly. • Key combination with Fn may not work. •...
  • Page 108 You can use the PC Information Viewer to check the computer's usage status, and use this information when calling Panasonic Technical Support for advice. (If you have not logged on with the administrator authority, some information will be displayed as [Not Found].)
  • Page 109 You can also save a copy of the screen to a file using the following procedure. Select [start] - [All Programs] - [Panasonic] - [PC Information Viewer] - [Screen Copy]. At the time of purchase, the computer is set so that a copy of the screen can be saved to a file by pressing Ctrl+Alt+F8.
