This equipment is similar to other gate or door equipment and meets or exceeds
Underwriters Laboratory Standard 325 (UL 325). However, gate equipment has
hazards associated with its use and therefore by installing this product the installer
and user accept full responsibility for following and noting the installation and safety
instructions. Failure to follow installation and safety instructions can result in hazards
developing due to improper assembly. You agree to properly install this product and
that if you fail to do so Gates That Open, LLC, shall in no event be liable for direct,
indirect, incidental, special or consequential damages or loss of profits whether based
in contract tort or any other legal theory during the course of the warranty or at any
time thereafter. The installer and/or user agree to assume responsibility for all liability
and use of this product releasing Gates That Open, LLC, from any and all liability.
If you are not in agreement with this disclaimer or do not feel capable of properly
following all installation and safety instructions you may return this product for full
replacement value.
READ ALL INSTRUCTIONS CAREFULLY AND COMPLETELY before attempting to
install and use this automatic gate opener. This gate opener produces a high level of
force. Stay clear of the unit while it is operating and exercise caution at all times.
All automatic gate openers are intended for use on vehicular gates only.
This product meets and exceeds the requirements of UL 325, the standard which regulates gate
opener safety, as established and made effective March 1, 2000, by Underwriters Laboratories Inc.
For more information on Mighty Mule's full line of Automatic Gate Openers and Access Controls visit www.mightymule.com
Printed in China for Gates That Open, LLC.
Installation Manual
WARNING!
GTO Sales: 850-575-0176 • Fax 850-575-8912
GTO Technical Service 850-575-4144
For 24 hour/day, 7 day/week Technical Service visit http://support.gtoinc.com
rev 07.12.12
Advertisement
Table of Contents
Related Manuals for Mighty Mule 350
Summary of Contents for Mighty Mule 350
- Page 1 GTO Technical Service 850-575-4144 For 24 hour/day, 7 day/week Technical Service visit http://support.gtoinc.com For more information on Mighty Mule’s full line of Automatic Gate Openers and Access Controls visit www.mightymule.com rev 07.12.12 Printed in China for Gates That Open, LLC.
- Page 2 Class Rating The Mighty Mule Gate Opener is intended for use with vehicular swing gates in single family residential applications. The opener is system certified to be in compliance with UL 325, current edition, as of publication date. Vehicular Gate Opener Class Categories: Residential Vehicular Gate Opener—Class I: A vehicular gate opener (or system) intended for use in...
-
Page 3: Table Of Contents
Table of Contents Gate Opener Class Categories ..............inside cover Units and Standards Conversion Chart ............inside cover PLEASE READ THIS FIRST! ..............page iv Important Safety Instructions ................. Disconnecting the Opener ..................1 Important Safety Instructions for the Consumer ............2 Required Safety Precautions for Gates ..............4 Secondary Means of Protection Against Entrapment ..........5 Warning Signs and Labels ..................6 Technical Specifications... -
Page 4: Please Read This First
Thank you for purchasing a Mighty Mule Gate Opener — GTO's “do-it-yourself” automatic gate opener! When correctly installed and properly used, your Mighty Mule Gate Opener will give you many years of reliable service. Please read the following information and watch the enclosed video to ensure you have the correct system for your particular needs. -
Page 5: Important Safety Instructions
ONLY disconnect the opener when the opener power switch is OFF and the gate is NOT moving. Because the Mighty Mule gate opener is battery powered, disconnect the opener ONLY when the power switch on the control box is turned OFF. Unplugging the transformer does not turn power to the opener OFF. -
Page 6: Important Safety Instructions For The Consumer
IMPORTANT SAFETY INSTRUCTIONS For The Consumer WARNING: To reduce the risk of injury or death: 1. READ AND FOLLOW ALL INSTRUCTIONS. Failure to meet the requirements set forth in the instruction manual could cause severe injury or death, for which the manufacturer cannot be held responsible. 2. - Page 7 IMPORTANT SAFETY INSTRUCTIONS II. During Installation 1. Install the gate opener on the inside of the property and fence line. DO NOT install an opener on the outside of the gate where the public has access to it. 2. Be careful with moving parts and avoid close proximity to areas where fingers or hands could be pinched. 3.
-
Page 8: Required Safety Precautions For Gates
Install Warning Signs Warning signs alert people of automatic gate operation and are required when installing the Mighty Mule Gate Opener. The warning signs included must be installed on both sides of each gate. Furthermore, a walk-through gate must be installed if pedestrian traffic is expected near the vehicular gate. -
Page 9: Secondary Means Of Protection Against Entrapment
The Mighty Mule Gate Opener utilizes Type A, an inherent (i.e., built-in) entrapment sensing system as the primary type of entrapment protection. Also, the Mighty Mule Gate Opener has provisions for the connection of Type B2 protection to be used as the secondary type of entrapment protection, if desired. -
Page 10: Warning Signs And Labels
IMPORTANT SAFETY INSTRUCTIONS GTO DC SWING SERIES Conforms to UL325 5th Edition Standards xxxxxx 9901178 0000000 MM350- Serial No. Gates That Open, LLC - Tallahassee, Florida USA Product identification label (1) installed under rear mount on arm. Warning signs (2 enclosed) to be installed on each side of the gate (3–5 feet above the bottom of the gate) TO MANUALLY OPEN AND CLOSE THE GATE 1. -
Page 11: Technical Specifications
OPERATIONAL CAPACITY • The Gate Capacity Chart shows approximate cycles, per day, you can expect from the Mighty Mule Gate Opener when powered with a transformer. Actual cycles may vary slightly depending upon the type and condition of gate and installation. -
Page 12: Before You Begin
Solar Charging Options • 10 Watt Mighty Mule Solar Panel [FM123] • 5 Watt Mighty Mule Solar Panel [FM121] (See accessories on pg. 38) rev 07.12.12... -
Page 13: Check Direction Of Gate Swing
2. Check Direction of Gate Swing The Mighty Mule Gate Opener is designed for PULL-TO-OPEN installations. PUSH-TO-OPEN installations require a Push-To-Open bracket [FM148]. Push-to-Open Installation Instructions begin on page 31. Your Property Your Property Pull-To-Open Push-To-Open (arm extends to open) (arm retracts to open) 3. -
Page 14: Installation
Parts List – Opener and Mounting Hardware WARNING Installation Moving Gate Can Cause Video Injury Or Death KEEP CLEAR! Gate may move at any time. Do not allow children to operate gate or Customer Support Card (1) play in gate area. Receiver (1) This gate is for vehicles only. -
Page 15: Tools And Materials
Tools and Materials Tools Needed: • Power Drill • Open End Wrenches — " and " • Adjustable Wrench • " Drill Bit • Hacksaw or Heavy Duty Bolt Cutters • Small Flat Bladed Screwdriver • Large Phillips Screwdriver • Tape Measure •... -
Page 16: Installation Overview
Installation Overview for Pull-To-Open Gates PUSH-TO-OPEN installation instructions begin on page 31. The diagram shown below is an example of a pull-to-open installation on a chain link fence and single gate. Mounting the opener on a masonry column requires special procedures; see Column Installation Information on page 37 if you intend to mount the opener on a column. -
Page 17: Installation Of Mounting Hardware
Installation of Mounting Hardware INSTALLATION OF MOUNTING HARDWARE We recommend you position the opener near the centerline of the gate to keep the gate from twisting and flexing and to avoid backsplash from rain water. The Post Bracket Assembly The position of the post bracket assembly Metal Plate Wooden Post Metal Plate... -
Page 18: Install Post Bracket Assembly And Gate Bracket
Install Post Bracket Assembly and Gate Bracket Step 1 3/8" x 2" Bolt Insert the " x 2" bolt through NOTE: The following steps the center hole of the post are intended for pull-to-open brackets and post pivot gate installations. If you are Post Bracket bracket as shown. - Page 19 IMPORTANT: While determining the mounting point for the post pivot bracket assembly, be sure that the position allows for minimum 2 inches of clearance between the gate and the opener in both the open and closed positions, as shown in the diagrams below. This clearance will give the opener the most efficient leverage point for opening and closing the gate and more importantly provides the least possible pinch area.
- Page 20 Installing the Post Bracket Assembly and Gate Bracket Step 1 Mark fence post through middle of bracket slots Mark reference points for bolt holes on the fence post and drill 3/8" holes through middle of bracket slots. Mark reference points Post Bracket for bolt holes on the gate cross member through middle Assembly...
-
Page 21: Mounting The Opener
Fence Post Installation of the Closed Position Stop The Mighty Mule Gate Opener firmly holds the gate in the closed position using the closed position stop plate. The closed position stop helps stabilize the gate leaf in the closed position. - Page 22 At this stage of the installation, the opener should be installed on the gate and the closed position stop plate should be in place. Check List • The gate is plumb, level, and swings smoothly on its hinges. • A plate or support was added for the gate bracket (if necessary). • The opener is level and mounted on the centerline of the gate. • All hardware is tightened at this time. Gate Swings Evenly and Freely Hung Firmly and Plumb Post Bracket Assembly Single Gate Opener v in In ju...
-
Page 23: Powering The System
CONNECTING THE BATTERY Control Board Access Cover Step 1 With the opener mounted in the upside down position remove the Control Board Access Panel Battery Harness on the bottom of the opener arm. Connector Control Board Battery Harness Connector 10 Foot Power Cable ON/OFF Switch Receiver Wires... -
Page 24: Detailed Wire Routing Diagram
See the illustrations to the right and below. Mighty Mule 350 Wire Routing To avoid stripping screw holes - tightening screws by hand with a hand held screwdriver is recommended. -
Page 25: Connecting The Transformer
CONNECTING THE TRANSFORMER IMPORTANT: Never connect the transformer and a solar panel to the opener control board at the same time. It will damage the control board. IMPORTANT: If you are using SOLAR PANEL(S) to charge the opener battery, skip this section and go to "Connecting Solar Panel(s)"... - Page 26 PULL-PUSH MODE1 MODE2 Step 7 LOCK/BEACON CHARGING Strip " off the ends of the low POWER voltage wire and twist tightly. Insert these ends to the 18 VAC terminal block located on the control board (see illustration at right). The wires can be LINK inserted into either terminal regardless 18VAC/...
-
Page 27: Connecting Solar Panel(S)
IMPORTANT: Never connect the transformer and a solar panel to the opener control board at the same time. It LIMIT REMOTE will damage the control board. PULL-PUSH If you are using the transformer included with the Mighty Mule Gate Opener to charge the opener battery, skip MODE1 MODE2 this section and go to "CONTROL BOARD SETTINGS" below. LOCK/BEACON... -
Page 28: Mounting The Receiver
MOUNTING THE RECEIVER Use the transmitter to check the range of the receiver before permanently mounting it. Consider the following when mounting the receiver: • Standard receiver cable length is 10 feet (receivers with a longer cable are available as special order items; call the GTO Sales Department). NEVER splice receiver cable! • DO NOT run cable in conduit containing ac wiring. -
Page 29: Setting The Closed Position Limit
SETTING THE CLOSED POSITION LIMIT Setting the Closed Position Limit For PULL-TO-OPEN Installation Turn the power switch on to the ON position Step 1 Step 2 Gate in Gate STATUS OPEN Closing Power switch is on, gate Press the transmitter to Postion is in the OPEN position, activate opener arm. -
Page 30: Obstruction Sensitivity And Auto-Close
Stall Force Potentiometer Setting IMPORTANT: For safety reasons the obstruction setting or Stall Force on the Mighty Mule Gate Opener control board STATUS comes from the factory set at MIN (minimum). In many gate installations this setting will need to be adjusted to overcome the weight and size of the gates. -
Page 31: Personalize Your Transmitter Setting
Personalize Your Transmitter Setting All transmitters have a standard setting and are ready to operate your Mighty Mule Gate Opener. For your safety and security, we strongly recommend that you replace the factory setting with your own personal setting. NOTE: If you have multiple transmitters, you should adjust all of them at this time. -
Page 32: Connecting Accessories
CONNECTING ACCESSORIES Input Connections • All control inputs are dry-contact, normally open, inputs. DO NOT apply external voltage sources to these inputs. • All inputs are connected with respect to COMMON terminal. • The status LED will blink once when any input is activated. COMMON: Circuit common (reference for all logic input) CYCLE: (Typically for use with push button or hard-wired keypad) • Each activation at this input will cycle the operation as follows: OPEN–STOP–CLOSE–STOP–OPEN EDGE: (Typically for use with safety edge device) • Activation of this input while the gate is closing will cause the gate... -
Page 33: Wiring Accessories
WIRING ACCESSORIES CHARGING POWER LINK 18VAC/ SOLAR INPUT RCVR DIP switch 4 set to OFF position (Default) Automatic Gate Lock Edge Sensor (FM143) Push Button Control (+12 v) ( – ) Photo Beams (R4222) (+12 v) ( – ) Keypad (FM137) Vehicle Sensor (FM138) (See additional wiring digram on pg. - Page 34 YELLOW, the BLACK as well as a separate length of wire, with a WIRE NUT. The other end of the single length of wire is connected to the COMMON terminal on the Mighty Mule 350 control board. Connect the RED wire from the sensor to the AUX OUT (H) terminal, and the BLUE wire to the EXIT terminal on the Mighty Mule 350 control board.
-
Page 35: Push-To-Open Installation Instructions
PUSH-TO-OPEN INSTALLATION INSTRUCTIONS PUSH-TO-OPEN gates open out from the property (opener arms extend to open). A Push-To-Open Bracket is required for this type of installation. In 3/8" x 2" Bolt a Push-To-Open installation, the opener is installed while the gate is in the closed position and the opener fully retracted. - Page 36 IMPORTANT: While determining the mounting point for the post pivot bracket assembly, be sure that the position allows for minimum 2 inches of clearance between the gate and the opener in both the open and closed positions, as shown in the diagrams below. This clearance will give the opener the most efficient leverage point for opening and closing the gate and more importantly provides the least possible pinch area.
-
Page 37: Set Control Board For Push-To-Open
STALL FORCE Set Control Board for Push-To-Open CLOSE TIME LEARN LIMIT REMOTE Make sure the control box power switch is OFF. Use a small screwdriver to move the Number 1 DIP switch from the PULL-PUSH MODE1 MODE2 factory setting (OFF / Pull-To-Open) to ON for Push-To-Open. LOCK/BEACON PULL-PUSH Turn power switch ON. -
Page 38: Maintenance & Troubleshooting Guide
MAINTENANCE AND TROUBLESHOOTING GUIDE If your gate opener does not function properly after it is installed, use this guide before calling the GTO Service Department. • On all gates weighing 250 lbs. or more, routinely grease the ball bearing hinges at least 4 times a year; more frequently if the gates are in a coastal area. -
Page 39: Voltage Readings
LEARN LIMIT Mode: This LED will turn on when the ‘LEARN-LIMIT’ button is pressed. It will turn off after 3 seconds indicating that it has entered the learn limit mode (if not at the retracted limit) or cleared the previous learned limit (if at retracted limit). See "Setting Closed Position" section on page 26. Whenever there is a change in state at any of the inputs this LED will blink once. 3. -
Page 40: Warranty Repairs
WARRANTY REPAIRS If your Mighty Mule Gate Opener is not operating properly, please follow the steps below: 1. First use the procedures found in the Visual and Audible Diagnostic Indicators section (page 34). 2. If you are unable to solve the problem, call the GTO Service Department at (800) 543-1236, or (850) 575-4144. -
Page 41: Column Installation Information
COLUMN INSTALLATION INFORMATION F THIS OPENER WILL BE USED WITH GATES THAT ARE MOUNTED ON MASONRY, BRICK, OR ROCK (etc.) COLUMNS: READ THE FOLLOWING CAREFULLY BEFORE PROCEEDING The simplest solution is to install the opener in a push-to-open configuration. The minimum clearance is easier to achieve and clearance is no longer a problem, since the opener will be pushing the gate away from the column instead of pulling it toward the column. -
Page 42: Accessories
Key Chain Two Button Transmitter [FM134] The Key Chain Transmitter is a dual button version of the Mighty Mule® single button entry transmitter and has the same adjustable code settings. Used for 2 gates or 1 gate and garage door. - Page 43 Copyright infringement is a violation of federal law. Mighty Mule¨, E-Z Gate¨, GTO¨, are registered trademarks of GTO, America’s DIY Automatic Gate Openers is a trademark of GTO and are the exclusive property of GTO. All rights are reserved by GTO, and these marks may not be used, in any for without the prior, written permission of GTO.
