Page 1: Dome Camera
SNC-C6225 SNC-C7225 10x Network Mini Smart Dome Camera User Manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, Please visit our website. www.samsungsecurity.com... -
Page 2: Safety Information
If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifi cations or attempted repair.) When cleaning, do not spray water directly onto parts of the product. Doing so may cause fi re or electric shock If the camera is installed or rebooted after power failure when ambient temperature is below the freezing point, the dome cover is frosted. -
Page 3: Fcc Statement
safety information Do not expose the product to the direct airfl ow from an air conditioner. Otherwise, it may cause moisture condensation inside the Clear Dome due to temperature difference between internal and external of the dome camera. If you install this product in a low-temp area such as inside a cold store, you must seal up the wiring pipe with silicon, so that the external air can not fl... -
Page 4: Important Safety Instructions
important safety instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifi... -
Page 5: Table Of Contents
contents Introduction Features Recommended PC Specifi cations Compatible IP Routers Product & Accessories Parts Name & Functions Installation DIP Switch Setup Installation Using Surface Mount On The Ceiling Installation Using Ceiling Mount Bracket Installation Using Wall Mount Bracket Cabling Inserting/Removing an micro SDHC Memory Card Memory Card Information (not included) Operation Check points before operation... - Page 6 contents Network connection & Setup Connecting the camera to an IP router with the xDSL/Cable modem Connecting the camera to an IP router with local area networking Connecting the camera directly to a DHCP-based xDSL/Cable modem Connecting the camera directly to local area networking Searching for the camera Setting Static IP Manual Network Setting...
-
Page 7: Introduction
• Bidirectional Audio support. protect privacy zone. The mask is arbitrary-sized • Support with DDNS Service (Samsung DDNS, rectangular and locate any location in view space. Public DDNS) for Dynamic IP. • 7 rules of Schedule can be assigned by day and •... -
Page 8: Recommended Pc Specifi Cations
introduction RECOMMENDED PC SPECIFICATIONS • CPU : Pentium4/2.4GHz or higher • Operating System : Windows XP(Service Pack 2) / Windows Vista • Resolution : 1024x768 pixels or higher • RAM : 512MB or higher • Web Browser : Internet Explorer 6.0 or higher •... -
Page 9: Product & Accessories
PRODUCT & ACCESSORIES ❖ SNC-C6225 • Product Main Body Surface Mount Bracket • Accessories Terminal Block Torx Screw Driver Surface Mount Gasket Screw & Plastic Anchor (4pcs) Quick Guide Audio Cable Core Filter User Manual / IP Installer CD Cross Cable ... - Page 10 introduction ❖ SNC-C7225 • Product Main Body Sun Shield Housing • Accessories Terminal Block Torx Screw Driver Audio Cable Cross cable Core Filter Quick Guide User Manual / IP Installer CD • Mount Bracket Option Wall Mount Bracket Ceiling Mount Bracket (SADT-732WM) (SADT-732CM) 10 –...
-
Page 11: Parts Name & Functions
PARTS NAME & FUNCTIONS ❖ SNC-C6225 Surface Mount Bracket Mounting Hole Main Body Cabling Terminal Block Lockup Screw DIP Switch Dome Cover Main Unit / Surface Mount Bracket Back of Main Unit • Dome Cover • Lockup Screw Do not remove the protection vinyl from dome cover Fixes main unit brackets like surface, wall, and ceiling. - Page 12 introduction ❖ SNC-C7225 Sun Shield Housing Cabling Terminal Block Main Body Lockup Screw DIP Switch Dome Cover Main Unit / Sun Shield Housing Back of Main Unit • Dome Cover • Cabling Terminal Block Do not remove the protection vinyl from dome cover During installation, Power, Video, Communication, before fi...
-
Page 13: Installation
ID, Baud Rate and communication protocol. Protocol Baud Rate 0x00 : Auto Protocol 0x00 : 2400 • Select the appropriate Protocol with DIP switch 0x03 : SAMSUNG 0x01 : 4800 combination. 0x02 : 9600 Switch State 0x03 : 19200 Protocol Pin1... -
Page 14: Installation Using Surface Mount On The Ceiling
MOUNT ON THE CEILING 4. Screw main unit to surface mount bracket with 4 lock-up screws. ❖ SNC-C6225 1. To pass cables to upside of ceiling, please, make about ø60mm hole on the ceiling panel. 2. Screw surface mount bracket to ceiling with 4 screws. -
Page 15: Installation Using Ceiling Mount Bracket
installation 3. After wiring cables to terminals, plug the terminals INSTALLATION USING CEILING into the bottom of main unit. Then, fi x the main MOUNT BRACKET unit with sunshield with 4 screws. ❖ SNC-C7225 1. Install ceiling mount bracket on the ceiling using 4 screws provided. -
Page 16: Installation Using Wall Mount Bracket
installation 3. After wiring cables to terminals, plug the terminals INSTALLATION USING WALL into the bottom of main unit. Then, fi x the main MOUNT BRACKET unit with sunshield with 4 screws. ❖ SNC-C7225 1. Use the 4 screws (provided) to secure the wall mount bracket to the wall. -
Page 17: Cabling
CABLING ❖ SNC-C6225/SNC-C7225 Audio In Microphone Audio Out Speaker DC 12V IrDA Sensor Controller/DVR Door Switch Sensors BNC Video Lamp Relay Out Network ❖ Power Connection • Please, check the voltage and current capacity of rated power carefully. Power Consumption... - Page 18 installation ❖ Video Connection • Connect with BNC coaxial cable. ❖ Audio Input/Ouput Connection Connect the AUDIO IN port of the camera with the microphone directly or LINE OUT port of the amplifi er that the microphone is connected to direct Mic Connection: Set Audio Input Gain high (10). Line Out Connection: Set Audio Input Gain low (1).
-
Page 19: Inserting/Removing An Micro Sdhc Memory Card
installation INSERTING/REMOVING AN MICRO SDHC MEMORY CARD ❖ Inserting an Micro SDHC Memory Card • Push the Micro SDHC memory card in the direction of the arrow shown in the diagram. Do not force the memory card in. If you can’t insert the memory card into the slot with ease, you might be inserting the card in the wrong direction. -
Page 20: Memory Card Information (Not Included)
installation MEMORY CARD INFORMATION (NOT INCLUDED) ❖ What is a memory card? The memory card is an external data storage device that has been developed to offer an entirely new way to record and share video, audio, and text data using digital devices. ❖... -
Page 21: Operation
operation CHECK POINTS BEFORE STARTING OSD MENU OPERATION • Function Using the OSD menu, Preset, Pattern, Auto Pan, • Before power is applied, please check the cables Scan and Alarm Input function can be confi gured for carefully. each application. •... -
Page 22: Preset
operation • Delete Auto Pan PRESET To delete Auto Pan, use OSD menu. • Function Max. 127 positions can be stored as Preset position. PATTERN The Preset number can be assigned from 1 to 128, but 95 is reserved for starting OSD menu. •... -
Page 23: Scan
operation SCAN OTHER FUNCTIONS • Function • Preset Lock The Scan function allows running sequence of This function is made to protect preset data from Presets, Pattern and/or Auto Pans. Max 8 Scan unauthorized overwriting. If Preset Lock is ON, Preset can be stored. -
Page 24: Osd Display Of Main Screen
operation • GENERAL/SPECIAL Image Setup • Action Title WB (White Balance) and AE (Auto Exposure) can Followings are possible Action Titles and their meaning. be set up independently for each preset. There are “SET PRESET ×××” When Preset ××× is stored 2 modes, “General”... -
Page 25: How To Use Osd Menu
STRUCTURE OF THE SETUP MENU SYSTEM SNC-C6225_v1.XX_XXXXXX INFORMATION COLOR SYSTEM NTSC/PAL AUTO/SAMSUNG PROTOCOL 4800/9600/19200/38400 BAUD RATE ADDRESS 1~255 XX:XX:XX:XX:XX:XX CAMERA ID DISPLAY SETUP ON/OFF PTZ INFORMATION AUTO/OFF/ON ACTION TITLE AUTO/OFF/ON PRESET LABEL AUTO/OFF/ON ALARM I/O... - Page 26 how to use osd menu FOCUS MODE AUTO/ONEAF/MANUAL CAMERA SETUP ON/OFF DIGITAL ZOOM OFF/ON IMAGE FLIP WB MODE AUTO/MANUAL <WHITE BALANCE SETUP> RED ADJUST 0 ~ 255 0 ~ 255 BLUE ADJUST <AUTO EXPOSURE SETUP> OFF/LOW/MIDDLE/HIGH BACKLIGHT AUTO1/AUTO2/DAY/NIGHT DAY/NIGHT 0 ~ 100 BRIGHTNESS AUTO IRIS...
-
Page 27: Main Menu
how to use osd menu • ADDRESS Shows current Camera ID for PTZ MAIN MENU control. • Shows current Mac address. ROOT MENU <SYSTEM INFORMATION> DISPLAY SETUP <DISPLAY SETUP> <MOTION SETUP> <FUNCTION SETUP> DISPLAY SETUP <CAMERA SETUP> <SYSTEM SETUP> CAMERA ID <SYSTEM INITIALIZE>... -
Page 28: Motion Setup
how to use osd menu • DISPLAY [ON/OFF] MOTION SETUP Sets if camera makes mask shows or not on images. • CLEAR [CANCEL/OK] MOTION SETUP Deletes data in the selected mask NO. PRESET LOCK ❖ PWR UP ACTION Privacy Zone Area Setup D-FLIP JOG MAX SPEED 140/SEC... -
Page 29: Function Setup
how to use osd menu ❖ Parking Action Setup • PATTERN SETUP Up to 4 patterns can be stored in the dome. PARKING ACTION SETUP In this function, path data created by manual move of Joystick are recorded and you can playback the PARK ENABLE WAIT TIME 00:10:00... -
Page 30: Preset Setup
how to use osd menu ❖ Edit Preset Scene PRESET SETUP EDIT SCENE - PRESET 1 PRESET SETUP PRESET NO. <EDIT SCENE> <LABEL> CLR PRESET CANCEL CAM ADJUST GENERAL ALARM OUT ---- MOVE TO TARGET POSITION [ENTER : SELECT] BACK 0/0/x1/N EXIT •... -
Page 31: Auto Pan Setup
how to use osd menu When Auto Pan function runs, camera moves from the preset assigned as the 1st point to the preset assigned as the 2nd point in CW(Clockwise) direction. Then camera moves from the preset assigned as the 2nd point to the preset assigned as the 1st point in CCW(Counterclockwise) direction. -
Page 32: Scan Setup
how to use osd menu ❖ Edit Pattern SCAN SETUP By using Joystick, move to start position with SCAN SETUP appropriate zoom. To start pattern recording, SCAN NO. press ENTER key. UNDEFINED CLEAR SCAN CANCEL <EDIT SCAN> EDIT PATTERN 1 BACK EXIT MOVE TO START POSITION... - Page 33 how to use osd menu Set up Action, Dwell time and Option. Note that After fi nishing setting up an Action, press ENTER selected item is displayed in reverse. Move cursor key to one-upper-level menu (Step ). Move Left/Right to select items and move cursor cursor Up/Down to select Action number and Up/Down to change each value.
-
Page 34: Schedule Setup
how to use osd menu The meaning of each value: SCHEDULE SETUP Days: MON SCHEDULE SETUP WKD: Weekday MASTER ENABLE ALL: All days(Everyday) DAY TIME 1 UNDEFINED TIME 24hour Format 2 UNDEFINED PRS(Preset), AUP(Auto Pan), 3 UNDEFINED 4 UNDEFINED PTN(Pattern), SCN(Scan), 5 UNDEFINED HOM(Home) 6 UNDEFINED... -
Page 35: Camera Setup
how to use osd menu ❖ White Balance Setup CAMERA SETUP Setup the general functions of zoom camera module WB SETUP WB MODE AUTO ZOOM CAMERA SETUP - RED ADJUST - BLUE ADJUST FOCUS MODE ONEAF DIGITAL ZOOM IMAGE FLIP <WHITE BALANCE SETUP>... -
Page 36: System Setup
how to use osd menu • SHUTTER • RELAY TYPE SETUP [ESC/A. Flicker/Manual(×128~1/120000 sec)] Contact type of 1 Ch, RELAY OUTPUT is defi ned. [NORMAL OPEN / NORMAL CLOSE] If Iris is set to Manual and Shutter Speed is set to ESC, Shutter Speed should have highest priority. - Page 37 how to use osd menu SET HOME POSITION SET NORTH DIRECTION MOVE TO TARGET POSITION MOVE TO TARGET POSITION [ENTER : SELECT] [ENTER : SELECT] 0/0/x1/N 0/0/x1/N • SET NORTH DIRECTION • SET HOME POSITION HOME position means the origin of PAN angle You can set up North direction.
-
Page 38: System Initialize
how to use osd menu SYSTEM INITIALIZE • Motion Confi guration SYSTEM INITIALIZE Preset Lock CLEAR ALL DATA Power Up Action CLR DISPLAY SET CLR CAMERA SET D-Flip CLR MOTION SET Jog Max Speed 140°/sec CLR FUNCTION SET REBOOT CAMERA Jog Direction NORMAL REBOOT SYSTEM... -
Page 39: Network Connection & Setup
Therefore, you must refer to Notice the network settings of your PC and do not enter the addresses presented in this manual. CONNECTING THE CAMERA TO AN IP ROUTER WITH THE XDSL/ CABLE MODEM SNC-C6225 xDSL or Cable Modem xDSL or Cable Modem... -
Page 40: Setting The Ip Address
network connection & setup ex2) If the address (LAN IP) of the IP router is 192.168.0.1 IP address: 192.168.0.100 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.0.1 ex3) If the address (LAN IP) of the IP router is 192.168.xxx.1 IP address: 192.168.xxx.100 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.xxx.1 ... -
Page 41: Connecting The Camera To An Ip Router With Local Area Networking
& setup CONNECTING THE CAMERA TO AN IP ROUTER WITH LOCAL AREA NETWORKING This is for a large network environment such as corporate offi ce, building, public offi ce and factory. SNC-C6225 SNC-C6225 IP Router External Remote PC... - Page 42 network connection & setup Connecting a local PC in the IP router to the camera Run the IP Installer on your local PC and search for the camera. If found, double-click the camera to start the Internet browser and try to connect to the camera. Alternately, launch the Internet browser manually and enter the IP address of the camera found in the address bar to connect to it.
-
Page 43: Connecting The Camera Directly To A Dhcp-Based Xdsl/Cable Modem
For the menu location of <Internet Connection Type> or DHCP selection, refer to the IP router’s documentation. When done, click the [Save] or [Apply] button to save the settings. xDSL or Cable Modem External Remote PC SNC-C6225 DDNS Server (Data Center, KOREA) Connecting to the camera from a remote PC Launch an Internet browser on the remote PC. -
Page 44: Connecting The Camera Directly To Local Area Networking
& setup CONNECTING THE CAMERA DIRECTLY TO LOCAL AREA NETWORKING SNC-C6225 External Remote PC SNC-C6225 Firewall DDNS Server (Data Center, KOREA) Local PC Connecting to the camera from a local PC in the LAN Launch an Internet browser on the local PC. -
Page 45: Searching For The Camera
network connection & setup SEARCHING FOR THE CAMERA ❖ IP Installer screen layout Device Name : Model name of the connected device. Mode : Shows the current selection between <Static> and <Dynamic>. MAC Address : The Mac address of the network interface of the camera. IP Address : The IP address of the camera. -
Page 46: Setting Static Ip
setting static ip MANUAL NETWORK SETTING Run the <IP Installer.exe> program and display the camera list found on the screen. For the initial run, the [Auto Set] and [Manual Set] button are all disabled. Select a camera you want from the camera list. •... - Page 47 setting static ip In the <PORT> fi elds, set up port numbers. • <HTTP Port>: A HTTP port used to connect to a camera using the Internet browser. The default value is 80. The HTTP port value can be changed by using the up/down button to the right.
-
Page 48: Automatic Network Setting
setting static ip AUTOMATIC NETWORK SETTING Run the <IP Installer.exe> program and display the camera list found on the screen. For the initial run, the [Auto Set] and [Manual Set] button are all disabled. Select a camera you want from the camera list. •... -
Page 49: Setting Dynamic Ip
setting dynamic ip DYNAMIC IP SETTING ❖ Examples of using Dynamic IP • If the camera is installed on an IP router and obtains an IP using DHCP. • If the camera is connected directly to a xDSL/Cable modem using DHCP. -
Page 50: Using The Camera
using the camera CONNECTING TO THE CAMERA ❖ Connecting to the camera General • Run an Internet browser. • Enter the IP address for the camera in the Address input box. ex) IP Address: 192.168.1.200 → http://192.168.1.200 - The login window appears. If the HTTP port number is not 80 •... -
Page 51: Installing Activex
using the camera ❖ Checking the DDNS address • A DDNS address consists of <e> + <Last 6 digits of the MAC address> + <websamsung.net>. ex) - If the MAC address of the camera is 00: 0D : f1 : 30 : 00 : 2c → e + 30002c + websamsung.net = e30002c. websamsung.net ... - Page 52 using the camera ❖ Logging to the camera For the fi rst login, the username is “root” and password is “4321”. Type “root” in the <User name> input box. Type “4321” in the <Password> input box. • If you have changed the old password, type the new password here.
-
Page 53: Web Viewer
web viewer MAIN SCREEN In this section, the main GUI of the Network Smart Dome will be explained. & ! Click this menu to enter the search screen. @ Click this menu to enter Setup Tool. # Click this menu to view Network Smart Dome Camera Information. $ Live video Display. -
Page 54: Using The Camera
The captured screen image is saved in the specifi ed folder path. Default save paths are provided for each version of Windows. Windows XP: C:\Program Files\Samsung\SNC-C6225\SnapShot\Live To change the saving path, click [SAVE PATH] button( ) and then select the path you want. - Page 55 When plays stored avi fi les, use player where supports avi playing. Default save paths are provided for each version of Windows. Windows XP: C:\Program Files\Samsung\SNC-C6225\VidedClip\Live To change the saving path, click [SAVE PATH] button ( ) and then select the path you want.
-
Page 56: Using The Sd Search Viewer Screen
web viewer USING THE SD SEARCH VIEWER SCREEN If you connect to the camera, the following SD Search Viewer screen appears. ❖ SD Search Viewer Screen Layout Name Function and Description You can select the desired date to search for events generated. Date The thumbnail images are displayed based on the selected size. -
Page 57: Setup Tool
setup tool ❖ SETUP Screen Layout SETTING THE CAMERA You can set various functions such as Basic Setting, BASIC VIDEO & AUDIO SETUP System, Event, Network, etc. USER ❖ To setup the camera LANGUAGE In the viewer screen, click the [SETUP] tab. SYSTEM DATE/TIME SOFTWARE UPDATE... -
Page 58: Video & Audio Confi Guration
GOP contains three types of frames: I-Frame, • You can adjust the brightness and contrast from 1 P-Frame, B-Frame. to 100. (SNC-C6225, C7225 uses only I-Frame and P-Frame.) ❖ I-Frame is the default frame for video compression, Resolution also known as key frame, which contains one •... - Page 59 setup tool ❖ HTTP Webserver Port • Show the HTTP port used to connect to the camera using the web browser. The default port number is 80(TCP). ❖ Device Port (TCP) • A port used to control video transmission. The default value is 60001(TCP).
-
Page 60: User
setup tool ❖ RTP Port Range About User Level • Set up the range of port number to use for RTP Administrator The Administrator can use all functions and Protocol. change the PTZ control, setup or search. The Start number of RTP Port has to be even number Operator The Operator can use all function except and the last number must be greater than the start... -
Page 61: Date/Time
Click [Browse…] button and select the latest (PC time confi guration) settings. version of the fi rmware. Its fi le name should be ex) SNC-C6225-WEB_v1.XX_XXXXXX.tgz • Click [Install] button. The fi le is uncompressed and the software update begins. Software update may take tens of minutes. -
Page 62: Reset
setup tool ❖ Install a public certifi cate RESET • To install the certifi cate to camera, you need type Certifi cate Name (it can be arbitrarily assigned by user), Certifi cate fi le issued from authority and a key fi... -
Page 63: Record Setup
setup tool ❖ ❖ User ID User ID • Enter a user account ID to connect to login the FTP • Enter a user account ID to connect to connect the server. SMTP server. ❖ ❖ Password Password • Enter a user account password to login the FTP •... -
Page 64: Alarm Image Setup
setup tool ❖ Options a prior image of up to 30 seconds after an alarm is generated. (The maximum time is determined by the • Determine whether or not you wish to receive Email number of images to be sent per second.) notifi... -
Page 65: Motion
setup tool ❖ event is generated during the alarm output, the Activation Time delay time is recalculated on the basis of the most • You can set time to accept a motion detection to recently generated an alarm. take an action. <Alarm Image Transfer>: If <On>... -
Page 66: Schedule
setup tool ❖ Transfer Interval To set a motion detection target area • You can set the time interval to transmit images. You can set a specifi c area to detect a motion in. You can select a unit of time from <Seconds> or 1) In the MOTION window, click the [Motion Area] <Minutes>. -
Page 67: Ddns
• If your network provides data rate equal to or • For Samsung DDNS service, Host Name is higher than 100Mbps, it is recommended to set the assigned using last 3 bytes of MAC Address. <Bandwidth> to <Unlimited> or <5Mbps>. If you For example, your host name will be “e + fffe42... -
Page 68: Snmp
setup tool SNMP The system information of the cam can be monitored and changed by SNMP. SNMPv1 or SNMPv2 are utilized to monitor of the system information and SNMPv3 enables to change the system information. ❖ SNMP User Setup • The version3 can set up the account information for SNMPv3 owing to authentifi... -
Page 69: Appendix
appendix TROUBLESHOOTING PROBLEM SOLUTION I can’t access the camera from a • Check to make sure that the camera’s Network settings are appropriate. web browser. • Check to make sure that all network cables have been connected properly. • If connected using DHCP, verify that the camera is able to acquire dynamic IP addresses without any problem. - Page 70 appendix PROBLEM SOLUTION Data is not getting recorded on the • Make sure that the memory card is not defective. Micro SDHC memory card. SD Indicator will not turn on after • Make sure that the memory card is not defective. inserting an Micro SDHC memory •...
-
Page 71: Specifi Cations
Scan 8 Scan (20 action entities per Scan) Other Functions D-Flip, Auto Parking, Power Up Action etc. Communication RS-485 Protocol Auto, Samsung selectable Privacy Zone 4 Zone Alarm Input 2 Input Alarm Output 1 Relay Output Menu / PTZ Information etc Support 7 Languages: [ENGLISH /ESPAÑOL /FRANÇAIS /DEUTSCH /ITALIANO /РУССКИЙ... - Page 72 Scan 8 Scan (20 action entities per Scan) Other Functions D-Flip, Auto Parking, Power Up Action etc. Communication RS-485 Protocol Auto, Samsung selectable Privacy Zone 4 Zone Alarm Input 2 Input Alarm Output 1 Relay Output Menu / PTZ Information etc Support 7 Languages: [ENGLISH /ESPAÑOL /FRANÇAIS /DEUTSCH /ITALIANO /РУССКИЙ...
- Page 73 TCP/IP, HTTP, HTTPS, SSL, DHCP Streaming Unicast, Multicast Security HTTPS(SSL), Digest Authentication (ID/PW) DDNS Supporting Samsung DDNS and Public DDNS servers Max 10 Users at Unicast Mode Maximum User Access Max 20 Users at Multicast Mode Administrator Live Monitoring, PTZ control, SETUP...
-
Page 74: Dimension
DIMENSION ❖ SNC-C6225 Unit (mm) 3/4" PIPE THREAD 74 – 10x Network Mini Smart Dome Camera... - Page 75 appendix DIMENSION ❖ SNC-C7225 Unit (mm) • Wall Mount Bracket • Ceiling Mount Bracket English – 75...
